Eaton 706r Manual de usuario

706r EN

Part No. 12656689 Issue 3

This product complies with the requirements of European Directive: 1995/5/EC (Radio

&Telecommunications Terminal Equipment Directive).

Fig. 1

Fig 1. 706r Controls and Indicators

1. Activity LED

2. Control Button (grey)

3. PA Button (orange)

4. Lock Button (black)

5. Aerial

Fig 1. 706r Bediening en indicatie

1. Activiteiten LED

2. Controleknop (grijs)

3. Alarmknop (oranje)

4. Vergrendeling (zwart)

5. Antenne

Fig 1. Commandes et voyants de l’émetteur 706r

1. LED d’activité

2. Bouton de commande (gris)

3. Bouton Panique (orange)

4. Bouton de verrouillage (noir)

5. Antenne

Figura 1. Controlli ed Indicazioni del 706r

1. LED di attività

2. Pulsante di Controllo (grigio)

3. Pulsante Allarme Panico (arancione)

4. Pulsante di Blocco (nero)

5. Antenna

Fig. 1 706r knapper og indikatorer

1. Aktivitets LED

2. Kontrolknap (grå)

3. PA knap (orange)

4. Sikringsknap (sort)

5. Antenne

Fig. 1. 706r Knapper og indikatorer

1. Aktivitets-LED

2. Kontrollknapp (grå)

3. PA knapp (oransje)

4. Låseknapp (svart)

5. Antenne

Fig. 1 706r knappar och indikatorer

1. Aktivitets LDC

2. Kontrollknapp (grå)

3. PA knapp (orange)

4. Säkringsknapp (svart)

5. Antenn

Abbildung 1: Regler und Anzeigen des 706r

1. Aktivitäts-LED

2. Schaltknopf (grau)

3. Notrufknopf (orange)

4. Sperrknopf (schwarz)

5. Antenne

Figura 1. 706r Controles e indicadores

1. LED de actividad

2. Botón de control (gris)

3. Botón AP (naranja)

4. Botón de bloqueo (negro)

5. Antena

Figura 1. Comandos e Indicadores do 706r

1. LED de Actividade

2. Botão de Comando (cinzento)

3. Botão Alarme de Pânico (laranja)

4. Botão de Bloqueio (preto)

5. Antena

Introduction

The 706rEUR-00 has an integral tilt switch and can be used as a personal attack

transmitter up to 900m from a Scantronic receiver.

Speciﬁcations

Part No.:

Power Supply:

Battery Life:

706rEUR-00

Lithium power cell (soldered in place)

Typically 5 years.

Temperature Range: -10 to +55°C

Dimensions: 170H x 45W x 30D (including aerial)

Weight: 68 gms

Channels 2

Display One LED for transmitter activity and learning.

Compliance Product is CE tested to EN 50081-1 and EN 50082-1.

Radio Section Operating frequency 868.6625MHz at 20kHz bandwidth. I-ETS 300

220. CE tested to I-ETS 300 339 (draft standard).

Transmitter range Up to 900m free space (range depends on the receiver aerial and

the nature of the receiving path).

Compatible Equipment

762r Two channel receiver

8 channel receiver

Radio Survey Tool.

768r/769r

DET-RSURV01

7500r Domestic Radio Panel

Preparing The 706r For Use

When delivered from the factory the 706r has a battery ﬁtted and is powered up in PA

mode.

Learning the Transmitter

Consult the Installation and Programming Guides for the appropriate receivers. The Activity

LED pulses out the unit’s ID at every activation and can be used for infra red learning.

Programming

The 706r has three modes: PA, Tilt Switch - Buzzer, and Tilt Switch - Silent. When

delivered from the factory the unit is in PA mode.

Tilt Switch With Buzzer

To change from PA to Tilt Switch - Buzzer mode press and hold the Control button for

ﬁve seconds. The buzzer gives a double beep and the Activity LED ﬂashes to signal the

change in mode.
