Easypix MyStudio Podcast Manual de usuario
EN
USER MANUAL
FR : Un manuel dans votre langue est disponible sur Internet:
IT: Il manuale nella sua lingua può essere trovato su Internet:
ES: Puede encontrar un manual en su idioma en Internet:
PT: Um manual em seu idioma pode ser encontrado na Internet:
PL: Instrukcjęw swoim języku możesz znaleźć na stronie:
SWE: En handbok på ditt språk finns på Internet:
NL: Een handleiding in uw taal vindt u op internet:
bit.ly/2ZMbsIB
www.easypix.info/download-manuals/download/mystudio-podcast/
EN
1
Table of content
Retaining instructions .........................................................3
Explanation of safety warnings ...........................................4
Product introduction...........................................................4
Intended use.......................................................................4
Restrictions .........................................................................5
Safety instructions ..............................................................5
Operating environment.......................................................6
Description of the product contents ...................................7
Microphone controls and functions ....................................8
Preparing your podcast kit for use ......................................9
Step 1: Secure the boom arm to your desk ...................9
Step 2: Mount and connect the mic ............................10
Step 3: Mic positioning................................................12
Step 4: Mute and Noise Reduction functions ..............13
Step 5: Selecting your mics input level ........................14
Box contents .....................................................................17
Technical specifications.....................................................18
Condenser Microphone ..............................................18
Headphones................................................................19
Disposal ............................................................................19
Declaration of conformity .................................................20
EN
2
Disclaimer
Easypix makes no representations or warranties with
respect to this manual and, to the maximum extent
permitted by law, expressly limits its liability for breach of
any warranty that may be implied to the replacement of
this manual with another.
Furthermore, Easypix reserves the right to revise this
publication at any time without incurring an obligation to
notify any person of the revision.
Easypix is not responsible or liable for misuse of the
information that is contained herein. If you have any
suggestions for improvements or amendments or have
found errors in this publication, please notify us.
All pertinent state, regional, and local safety regulations
must be observed when installing and using this product.
For reasons of safety and to help ensure compliance with
documented system data, only the manufacturer shall
perform repairs to components.
Failure to observe this information can result in injury or
equipment damage.
Copyright © by Easypix GmbH
All rights reserved. No part of this publication may be
reproduced, distributed, or transmitted in any form or by
any means, including photocopying, recording, or other
electronic or mechanical methods, without the prior
written permission of the publisher. For permission
requests, please write to the publisher below.
Easypix GmbH, Em Parkveedel 11, 50733 Köln, Germany
EN
3
support@easypix.com • www.easypix.com
Retaining instructions
Read this manual and its safety instructions before using
this product.
Follow all the instructions. This will avoid fire, explosions,
electric shocks or other hazards that may result in damage
to property and/or severe or fatal injuries.
The product shall only be used by persons who have fully
read and understand the contents of this user manual.
Ensure that each person who uses the product has read
these warnings and instructions and follows them.
Keep all safety information and instructions for future
reference and pass them on to subsequent users of the
product.
The manufacturer is not liable for cases of material damage
or personal injury caused by incorrect handling or non-
compliance with the safety instructions.
EN
4
Explanation of safety warnings
Warning indicates a hazard with a medium level of risk
which, if not avoided, could result in serious injury.
Indicates information considered important, but not
hazard-related.
Product introduction
MyStudio Podcast Kit for Creators provides everything
required to start users on their creative journey in the
world of podcasting or recording and is suitable for use
wherever the recording or broadcasting of a voice is
required. The kit contains all of the essentials required to
get your voice heard.
Intended use
This product is intended for use where the recording or
broadcasting of your voice is required such as podcasting,
narration, online gaming, online chat or vocal recording etc.
WARNING
NOTICE
EN
5
Restrictions
The product is not suitable for children under 3 years
because of choking hazard.
•Contains small parts, in order to avoid swallowing,
please ensure any use by children is undertaken with
adult supervision.
•This product is not suitable for use in wet conditions.
•Please ensure all parts are kept dry at all times.
•Ensure all parts are not exposed to extreme
temperatures.
Safety instructions
This product is only suitable for the purpose described,
the manufacturer is not liable for damage caused by
abnormal use.
Please read this instruction manual carefully before use.
Keep all small parts out of the reach of small children.
•To avoid high frequency feedback, ensure the
WARNING
WARNING
WARNING
EN
6
product is not used at high volumes when placed
in front of speakers.
•Please dispose of the waste and residues at the
end of the service life of the product according to
local laws and regulations.
•If you think this product is damaged in any way,
please do not use the product.
Operating environment
•Do not expose the product components to
abnormally high or low temperatures.
Store the components (at room temperature) in a dry
and dust-free location and never expose them to high
temperatures or direct sunlight.
•Protect the components from falls, shock and impact.
EN
7
Description of the product contents
1. Boom arm
2. Pop filter flexible arm
3. Microphone
4. Mic shock mount
5. Pop filter
6. Desk mount bracket
7. USB plug – Connect this end to your computer
8. USB plug – Connect this end to the mic
9. Foam mic shields
10. Stereo headphones
EN
8
Microphone controls and functions
1. Protective mesh housing
2. Noise reduction indicator light
3. Volume
4. Mute / Noise reduction button
5. USB connection socket
6. 3.5mm Audio output / Headphones socket
EN
9
Preparing your podcast kit for use
Step 1: Secure the boom arm to your desk
1. Securely attach the boom arm mounting bracket to a
desk or hard flat surface
2. Insert the boom arm into the bracket
3. Secure the boom arm in the bracket by tightening the
thumb screw
4. Attach the microphone shock mount to the other end
of the boom arm by screwing it tightly to the
adjustable threaded screw.
Complete the set up by attaching the flexible pop
filter to the boom arm and fitting the foam shield on
the mic.
