User%manual%
%
Main%features%
•! 3!meters!waterproof,!photo!capture!and!video!recording!under!water!
•! FHD!1920x1080,!HD!1280x720P,!VGA!640x480,!QVGA!320x240!
•! Max.!24M!pixels!
•! !Convenient!dual!screens,!1.8!inch!front!screen,!2.7!inch!TFT!rear!screen!
•! !Face!detection,!image!stabilization,!web!cam!function,!various!scene!modes!
•! !4x!digital!zoom!
•! High!speed!continuous!shooting! ! !
•! Built-in!speaker,!microphone!
•! !Micro!SD!card!support!up!to!32GB!(not!included)!
•! Built-in!LED!flash! !
!
!
Preparation%before%use% %
Please!install!the!lithium!battery!provided!with!your!camera!before!first!use.!
!
1.!Slide!the!battery!cover!on!the!bottom!of!the!camera:! ! !
!
2.!Please!install!the!battery!in!a!right!direction!
3.!Close!battery!cover!
!
Note:% %
Please!remove!the!battery!when!you!know!the!camera!will!not!be!used!for!extended!periods.!
!
%
%
%
%
%
%
%
Installing!lithium!battery!
!
Charging%the%lithium%battery%
Connect!the! camera! to! your! computer! using! the! USB! cable.! The! red! LED! illuminates! to!
indicate!charging!is!in!progress.!The!LED!will!switch!off!to!indicate!when!the!battery!is!fully!
charged.!
!!!
Computer%requirements%Windows%7/XP3!
Your!computer!should!have!the!following!minimum!requirements!in!order!to!transfer!photos!
and!videos:! !
Windows7/XP!system!or!more!higher!Pentium!series!processor! !
128MB!memory!/!150MB!available!disk!space!/!USB!Interface! !
Recommended!display!resolution:!1024x768!resolutions.16!bit!color!or!higher.!
!
Computer%requirements%Windows%Vista%
If!using!Windows! Vista! your!computer!should! have! the! following! minimum! requirements! in!
order!to!transfer!photos!and!videos:! !
800!MHZ!processor!and!521MB!system!memory!
20GB!Hard!disk!with!at!least!15GB!available!space!
Support!for!SVGA!graphics! !
USB!Interface!
!
Computer%requirements%for%Mac%
Power!Macintosh!G3!500!MHZ!or!higher!configuration!
Mac!OS!X!version!or!10.5.x!or!more!earlier!version!
256MB!or!more!system!memory!with!150MB!available!disk!space!
800x600!or!higher!display!resolution!
%
Camera%overview%
%
!!!! !
!
!
Icons:%Battery%Power%
!Full!Charge!!!!!!!!!!!!!!
! ! Half!Charge!!!!!!!!!!!!
!!No!Charge!!!!!!!!!!!!!!!!!!!!!!
Quality%
!Common!!!!!!!!!!!!!!!!!!!!!!!
!Fine! ! ! ! !
!Super!Fine!
Flashing%Light%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%
!!!!Flash!On! !
!!!Auto!Flash!
!!Flash!Off!
%Anti-Red%Eye%Flashing%Light% %
Mode%
Photo Playback!
!video! ! !
!
!Self-timer!10s!
!!Self-timer!5s!
!!Self-timer!2s!
%Self-timer!off%
Digital%Zoom%
1.00X! % 4.00X!
Protect%
!!Protect! %
!
Anti-shake%
! Anti-shake!On! !
! ! Anti-Shake!Off!
Scenes%
! Auto! ! Night!Portrait! ! Night!scene!
! Portrait! ! ! Landscape! ! Beach! ! ! ! ! ! ! ! ! ! ! ! ! ! ! ! ! ! ! ! ! ! !
! High!Sensitivity!
Installing%Micro%SD%card%
The!camera!supports!Micro!SD!memory!cards!up!to!32GB!max!(not!included).!
The!camera’s!internal!memory!only!stores!one!photo!for!testing!purposes.! !
Please!insert!a!Micro!SD!card!into!the!memory!card!slot!before!use,!being!careful!to!ensure!
that!the!card!is!installed!correctly.!
When! inserted! correctly! the! card! will! slide! into! place! smoothly! and! a! ”Click”! sound!will!
confirm! that! it! is! locked! in! place.! A! Micro! SD! card! icon! will! display! on!the! LCD! screen! to!
confirm!the!camera!has!detected!the!card.!
To!remove!the!card!simply!press!firmly!and!it!will!pop!out!of!the!memory!card!slot.!
Note:%
1.%All%photos%will%saved%on%the%Micro%SD%card%once%the%Micro%SD%card%installed.%
2.%Formatting%will%delete%all%data%on%the%memory%card.%
3%.Please%do%not%remove%the%Micro%SD%card%when%formatting%as%this%may%damage%the%card.%
%
%
Turning%on%the%camera%
Press!the!power!key!on!the!top!of!camera!to!turn!on!the!camera.!
The!LCD!screen!will!activate!to!confirm!the!camera!is!working.! !
! !
Photo%capture%mode%
After!turning!the!camera!on,!the!
icon!will!be!displayed!on!the!LCD!screen!to!confirm!the!
camera!is!in!photo!mode!
!
Switching%between%displays%
To!switch!between!the!front!and!rear!screens!press!the!‘Display!screen!switching’!Key.!
Each!press!of!this!button!will!activate!the!front!1.8”!screen!and!rear!2.7”!screen!in!turn.!
!
!
!
!
!
Photo%shooting%
To!capture!a!photo!press!the!shutter!key!
There!will!be!a!slight!delay!while!the!photo!is!stored!on!the!memory!card.!
After!taking!a!photo,!the!number!displayed!on!the!screen!indicates!how!many!more!photos!
can!be!taken!considering!the!current!settings!and!the!size!of!the!memory!card!installed!in!the!
camera!at!that!time.!
A!message!will!be!displayed!on!the!screen!when!the!SD!card!is!full.!
To!continue,!please!transfer!all!data!on!the!SD!card!to!your!computer!or!insert!a!new!memory!
card.!
!
Digital%zoom%
Your!camera!features!a!4x!digital!zoom.! !
Press!the!up!button!to!zoom!in!and!the!down!button!to!zoom!out.!
!
Built-in%Flash% %
Press!the!‘Flash’!key!to!activate!the!various!flash!modes.!
The! !icon!indicates!‘Flash!Off’.!The!flash!will!not!operate!when!this!mode!is!selected.!
The !icon!indicates!‘Auto!Flash’!mode!and!the!camera!will!activate!the!flash!automatically!
if!required!in!low!light!conditions.!
The!!icon!indicates!‘Flash!Mode’!and!the!flash!will!operate!every!time!a!photo!is!taken.! !
The! !icon! indicates! ‘Anti-Red! Eye’! mode.! The! camera! flash! will! operate! a! flash! burst! to!
reduce!the!red!eye!effect!in!your!photos.!
!
Scenes%
The!following!‘Scene’!modes!are!available!to!facilitate!photo!capture!in!different!
environments:! !
Auto,!night!landscape!portrait,!night!landscape,!portrait,!landscape,!sports,! !
party,!beach!or!high!sensitivity.!
If!required,!you!can!select!a!mode!that!best!matches!the!conditions!you!are!shooting!in.! !
!
!
!
!
Press!the!power!key!to!turn!on!camera,! !
The! !icon!will!be!displayed!on!top!left!of!the!LCD!display.!
1.!Press!the!Menu!key!
2.!Press!the!left/right!keys!to!choose!‘Scene’!icon! !
3.!Press!up/down!key!to!select!your!preferred!scene.!
Auto,!night!landscape!portrait,!night!landscape,!portrait,!landscape,!sports,!party!
4.%Press!OK!to!confirm.!
!
Selection%the%photo%resolution%
1.!Press!the!Menu!key!
2.!Press!left/right!key!to!select!photo!size!icon!‘MP’.!
3.!Press!the!up/down!key!to!choose:!
!!!!(24M)!5600x4200!,!(20M)!5200x3900!,!(18M)!4896X3672,!(16M)!4608x3456!
!!!!(14M)!4416x3312,!(12M)!4000x3000,!(10M)!3648x2736,!(8M)!3264x2448,!
!!!!(7M!HD)!3648x2048,!(7M)!3072x2304,!(5M)!2592x1944,!(3M)!2048x1536,!
!!!!(2MHD)!1920x1080,!(2M)!1600x1200,!(VGA)!640X480!
4.!Press!the!OK!key!to!confirm!your!selection.!The!photo!size!icon!will!be!displayed!on!the!LCD!
screen!
!
Anti-shake!
Your!camera!features!an!anti!shake!function!to!deliver!better!photo!quality!when!a!tripod!is!
not!being!used.!
1.!Press!the!Menu!key!
2.!Press!the!left/right!keys!to!select!anti!shake!icon! !
3.!Press!the!up/down!key!to!select!anti!shake!on/off!
4.!Press!OK!to!confirm!your!selection,! !
5.!The! ! icon!will!be!displayed!on!the!LCD!screen!to!confirm!anti-shake!is!activated.!
!
%
%
%
Face%detection%
To!activate!the!face!detection!function.!
1.!Press!the!Menu!key!
2.!Press!the!left/right!keys!to!select!the!face!detection!icon! !
3.!Press!the!up/down!keys!to!select!face!detection!on/off.!
4.!Press!OK!key!to!confirm!your!selection.!
!
Continuous%shooting%
The! continuous! shooting! function! allows! you! to! capture! 6! individual! photos! in! rapid!
succession!with!just!one!press!of!the!shutter!button.!
1.!Press!the!Menu!key!
2.!Press!the!left/right!keys!to!select!continuous!shooting!icon! !
3.!Press!the!up/down!keys!to!select!continuous!shooting!on/off!
4.!Press!OK!key!to!confirm!your!selection.!
!
Please%Note:! !
When!using!the!‘Continuous!Shooting’!function,!the!photo!resolution!automatically!changes!
to!VGA.!
!
Self%timer%
1.!Press!the!Menu!key.!
2.!Press!the!left/right!keys!to!select!the!self-timer!icon! !
3.!Press!the!up/down!keys!to!review!the!self-timer!options.!
4.!Press!the!OK!key!to!confirm!your!selection.!
!
Settings%
The!camera!with!21!different!setting!options.! !
EV,!ISO,!White!balance,!Sharpness,!Quality,!Effects,!Setting!Time,!Auto!Shut!down,!Language,!
Frequency! Format,! Default,! Mule! mode,! Light! detect,! Sensitivity,!Continuous! shooting,! Anti!
shake,!Photo!size,!Scene!option,!Self-timer,!Face!Detection.!
!
!
