Easypix DVC 527 Manual de usuario

Preface

Thank you for purchasing this camera.

Equipped with three shooting modes (Capture Mode, Video

Mode, and Playback mode), this camera will fulfill your entire

digital picture processing needs. This card-sized and lightweight

camera offers a max resolution of 10 megapixels high-quality

image along with precise 8xdigital zoom. The built-in internal

memory can store your images and videos. Through the

USB cable connection, pictures and video clips can be

easily transferred from the camera to the PC. The TV-out

function allows pictures and images to be screened through

the TV unit. Continuous shooting function allows users to

take multiple frames in quick succession.

To make the best out of this camera, it is strongly suggested

that you read through this manual prior to operating this

camera.

Quick Start

This quick start provides an overview function of this camera. For

quick reference, please refer to the following flow chart:

Before shooting:

Turning the cameraOnand Off (page

)

- Flash setting (page 7)

- Zooming In and Out (page 12)

- Installin

the software

e 26

)

Basic Shooting

- Shooting images (page 11)

- Viewing images (page 12)

- Deleting images (page 12)

Other functions

- Recording audio (page 8)

- Recording video (page 22)

Downloading pictures and images

to your PC

- Connecting through USB(page 27)

- Connecting through TV-out (page 29)

Preface ............................................................................... 1

Quick Start .......................................................................... 2

Prior to Operating the Camera............................................ 4

Unpacking the Camera ....................................................... 4

Identifying Components ...................................................... 5

Basic Function Buttons ....................................................... 6

Loading the Batteries.......................................................... 9

Insert SD card..................................................................... 9

Basic Settings ................................................................... 10

Formatting the Internal Memory and SD Card.................. 10

Basic Operating Procedure................................................11

Turning the Camera ON/OFF ............................................11

Basic Shooting Skills .........................................................11

Zooming In/Out ................................................................. 12

Viewing Pictures ............................................................... 12

Protecting and Deleting Pictures ...................................... 12

Three Main Modes and Instructions ................................. 13

Capture Mode ................................................................... 15

Video Mode....................................................................... 22

Playback Mode ................................................................. 24

Making Connections ......................................................... 26

Installing Software............................................................. 26

Connecting through the USB ............................................ 27

Connecting through TV-out............................................... 29

Appendix........................................................................... 30

Prior to Operating the Camera

Setting up this digital camera is quick and simple. Follow these steps,

and you’ll be on your way to infinite boundaries.

Unpacking the Camera

1. Clear all items from the box. (It is highly recommended that the box

and wrappings are kept for future usage)

2. Double check for the following items:

Hand Strap

CD-RO Pouch Mini USB cable

Video cable

Camera

Batteries

Quick Guide

Identifying Components

Flash

Lens

Self-timer

LED

Lens Cove

Status LED

Mode Switch Recording

button Zooming Out/In

5 Way Button

Display

LCD display

Connectivit

(

USB and TV-Out

)

Power Button

SD Card

Compartment

Wrist

Strap

Moun

Focus

Switch

Shutter Button

Battery

Compartment

Basic Function Buttons

This section will explain the basic function buttons to instantly operate

this camera.

Self-timer: The self-timer function is used in any of the following

modes: Capture and Video. A tripod is highly recommended when using

the self-timer. Press the right button to select self-time (press once

(twice) to activate the shutter 2 (10) seconds after the shutter button is

pressed fully.) When the icon appears on the LCD, press the shutter

button to activate.

Continuous shot: This function allows 3 continuous shots.

Continuously press the right button three times to activate this function.

NOTE: 1. Turn off the Flash prior to using the continuous shot function.

2. Under continuous shot, the flash will remain inactive.

3. If the internal or SD card have run out of memory, the

continuous shot will not function.

Mode Switch

Zooming

Out/In

Left/Flash Button Ri

ht/Sel

-timer Button

Up/ Protect Button

Down/ Delete Button

Dis

OK Button

Recording

utton

Flash: This button can set flash as Force Off, Force On and Auto.

Force off: Default setting of flash mode.

Auto: Press flash button once to automatically activate the flash.

Force on: Press flash button twice again for force on.

Zoom: This camera has 8x digital zoom.

Resolution Digital Zoom

7.0M(3072x2304)x1

6.0M(2880x2160) x1

5.0M(2560x1920) x1

4.0M(2304x1728) x1

3.0M(2048x1536) x8

2.0M(1600x1200) x8

1.3M(1280x960) x8

VGA (640x480) x8

In Capture/Playback/Video mode:

Zoom in: Press “Zoom in” button to magnify image

Zoom out: Press “Zoom out” button to narrow the image

Menu: This function allows you to change settings of this camera in

Capture/ Video/ Playback mode.

10.0M(3600x2700)x1

Display: This button allows you to turn the display On or Off.

In “Capture” and “Video” mode: All “capture” information is displayed in

the default setting. Press once to dispay with 3x3 grid (grids can help

users to compose a picture). Press the second time to hide the

information and press the third time to turn off LCD.

In “Playback” mode: All “Playback” information is displayed in the default

setting. Press once to hide the information and once more to turn off

LCD.

Focusing Switch: This button enables you to manually adjust from

“Marco” “Normal” and “Infinity” according to the shooting distance.

Audio Record: This button allows you to record audio.

In the “Capture” and “Video” modes, press the “Audio Record” button to

start recording. Press this button again to stop recording and return to

previous mode.

In the “Playback” mode, press this button to record a voice memo for the

current picture.

Tip:

1. The voice memo allows you to record a voice memo of 20

seconds for the current picture.

2. You can play back the recorded file and voice memo on your PC.

Loading the Batteries

This camera uses 2 AAA batteries.

1. Slide the battery cover in the direction of the arrow, then lift to open.

2. Load the included batteries into the battery compartment. (a)

Insert SD card

Insert the SD card into the slot. (b)

NOTE: 1. Do not open the battery compartment while the USB file

transfer is in process.

2. Once new batteries are loaded, users will need to reset the date

and time.

3. Do not open the battery cover or remove the batteries when the

camera is in its “ON” status. Only remove the batteries when

the camera is not in use, or in its “OFF” status.

4. If you do not plan on using the camera for a long period of

time, please remove the batteries.

5. This camera, built in a memory, is ready for use without a SD

memory card.

CAUTION! 1. It is recommended that rechargeable batteries be used.

2. To improve battery performance, replace all installed batteries

at the same time and keep batteries away from heat

3. Do not mix battery types or it may cause a fire or explosion.

Use only one battery type at one time.

4. Batteries should be inserted in the battery compartment with the

“+” and “-” sides facing correctly.

Basic Settings

Upon turning the camera on, a “welcome image” will appear on the LCD

display. Please proceed with the following settings:

Language Preference Setting

13 laguages are available for selection in this camera. Please refer to

“Language” setting under “Setup”. (Page 20)

Date and Time Setting

Please refer to the “Date and Time” setting under setup function. (Page

19)

Formatting the Internal Memory and SD Card

1. Formatting SD Card

Prior to its initial usage, format the SD card. To format the SD card,

please insert your compatible SD card into SD slot. Then proceed

with the following steps:

1). Press “Menu” button in the “Capture” mode and select

“Formatting”.

2). Press “OK” button to confirm. The SD card will be formatted.

2. Formatting the Internal Memory

1). Take out SD card from the slot and format the Internal Memory by

following the above mentioned steps .

Note: To select a “Welcome Image”, users can select “Setup” in the

“Menu” in “Capture” mode.

NOTE: 1. Prior to formatting the SD card, deactivate the “Protect SD

card” function.

2. The internal memory cannot be formatted when the SD card is

in the camera.
