Eaglemaster E5 Manual de usuario
IMPORTANT:
Please read the entire manual for complete details on the features, accessories and
operation before attempting to use your security system.
This Security system must be installed by a qualified technician to ensure proper
operation. Do not attempt to install or modify this system yourself as
this way void your warranty.
2-WAY CAR ALARM SYSTEM
Instruction manual
Table of contents
About your system
System maintenance
Remote battery replacement
LCD 2-way configuration
1-way remote description
2-way & 1-wayremote function table
Standard LCD 2-wayicon instructions
Standard features
ToARM the system
Defective Zone Bypass& Alert
Auto Reset
Arm without sirenchirp
ToDISARM the system
Programming 2-way remote
Disable remote receiving
Remote button 1.2.3on/off
Vibrate mode on/off
Time adjust mode
Alarm clock setting
2-way signal pagingfeatures
Command Page
Alarm Page
Page Recognition (Acknowledgement)
Check-in range notification(on/off )
Reminder disarm status(Programmable)
Vehicle statuschecking
Turn on LCD display backlight
Intrusion Alert
2-way LCD IntrusionAlert
Disarm without sirenchirp
Silent arm mode
Automatic REARM (programmable)
Passive arm (programmable)
Panic mode
Dual stage shocksensor
Remote sensor bypass
Car search mode
Confort /window close
Valet mode
Ignition controlled doorlock/unlock(programmable)
Ch-4: 2nd stagedoor unlock (programmable)
Ch-4: Remote latched(programmable)
Passive immobilizer (programmable)
Arming without Remotecontrol (programmable)
1.
2.
2-1.
3.
4.
5.
6.
7.
7-1.
7-2.
7-3.
7-4.
7-5.
8.
8-1.
8-2.
8-3.
8-4.
8-5.
8-6.
8-7.
9.
9-1.
9-2.
9-3.
9-4.
9-5.
9-6.
9-7.
9-8.
9-9.
9-10.
9-11.
9-12.
9-13.
9-14.
9-15.
9-16.
9-17.
9-18.
9-19.
9-20.
9-21.
9-22.
3
4
4
4
5
5
6
9
9
9
9
10
10
11
11
11
11
12
12
12
12
13
13
13
13
13
14
14
14
15
15
15
15
16
16
16
17
17
17
17
17
17
18
18
-1-
Page
2nd step disarm
Remote trunk open
CH-5: Dome lightsupervision
CH-5: ArmW/Engine running
CH-5:Turbo mode
CH-6: Programmable output
CH-7: Programmable output
Red/black programme (+)input
- Reverse warning
- Heard lightwarning
- Extra sensor(knock sensor) input
Siren chirps ON/OFF(programmable)
Status LED timer
Power disconnecting memory
Emergency reset switch
Emergency disarm (Valet SW &PIN code)
Anti car-jacking mode
R.f antenna callswitch
Set your ownPIN code
Programme mode features
Wiring diagram
Programme mode table
Transmitter programming
System installation
Central door lockwiring
9-23.
9-24.
9-25.
9-26.
9-27.
9-28.
9-29.
9-30.
9-31.
9-32.
9-33.
9-34.
9-35
9-36.
9-37.
11.
12.
13.
14.
15.
16.
17.
18.
19.
20.
18
19
19
19
20
20
20
20
20
20
20
21
21
21
21
21
22
23
23
24
24
25
27
28
30
-2-
About Your System
NOTE:
Congratulations on yourpurchase of this state-of-the-art vehicle security system.
With proper installationthis system will provide superior protection and performance for
many years tocome.
What is included:
Acontrol module
2-way pager transceiverantenna
One 5-button 2-wayLCD remote transmitter
One 3-button or4-button random code remote transmitter
Dual stage shocksensor
High output 6-tonesiren (optional)
Status LED indicator
Valet over-rideswitch
Options and Accessories:
This system includesseveral optional inputsand outputs allowing the creation ofa
completely personalized securityand convenience system by offering manyoptional
features such as:
2nd stage doorunlock
Horn honk output
2pulse signal doorunlock
Engine turbo timemode
Check range notification
Arm/disarm chirpon/off
*Many require additionalparts and/or labor, see storefor details
Some of thefeatures described in this manual mayrequired additional parts and/or
labor, andmay not be included as partof the standardinstallation of thisunit.
Additionally, manyfeatures of thissecurity system have selectable options thatmust be
activated or programmedduring the system's installation. These itemswill be identified
in the followingsections. Please discuss these features andany questions you may
regarding the installationof this product with your authorizeddealer.
Window close control
Anti car-jack bydoor switch
Power trunk/hatch release
Glass breakage sensor
Micro-wave detector
Back-up battery sirem
-3-
System maintenance
The system requiresno specific maintenance other than batteryreplacement for the remotes.
LCD 2-Way Remote Battery Replacement
The 2-way remoteis powered by a 1.5VAAA battery. The BatteryLevel indicator hasthree level
indicators that serveas a visual indication of batterycharge. When thebattery reaches a low
charge level thatrequires replacement, the transceiver will generatea single notificationchirp,
and the BatteryLevel indicator will flash continuously.
Toreplace the battery, gently pull the battery coverrelease tab, thenslide the door down to
expose the batteryand remove the expired battery.Place the new battery into the transceiver
observing the correctpolarity. Whenpower is returnedthe transceiver will light all iconsin the
LCD and generateall beeper tones once.
3 & 4-ButtonRemote Battery Replacement
Your remote is poweredby a 12V A27 thatwill last approximatelyone year under normal use.
When the batterybegins to weaken, operating range willbe reduced andthe LED on the remote
will dim.
FULL REPLACE EMPTY
LCD 2-Way configuration
-4-
Button 1 Button 2
Button 3
Button 4
Button 5
LCD display
Antenna
TR-45
CALL
AHJ
IMMO
AM
PM
PASS
X
T
R
BRAKE
2-way & 1-way Remote Function Table:
Functions Step Condition
Arm and door lock
Arm without siren chirp
Disarm and door unlock
Disarm without siren chirp
Trunk open
Anti car-jack mode
Panic mode
Car search mode
1st stage sensor bypass
2nd stage sensor bypass
Valet mode
Status check & Back light
Remote button 1.2.3 on/off
Silent arm mode
Enable check-in range
Vibrate mode on/off
Disable remote receiving
Time adjust mode
Alarm clock setup
Press once
Press once then within 3sec. press once
Press once
Press once then within 3sec. press once
Press over 2sec
Press together over 2sec..
Press over 2sec.
Press once after 8sec. of armed
Press once within 8sec. of armed
Press once within 8sec. of armed
Press together over 2sec.
Press once
Press over 2sec.
Press once. & Press 1-way once.
Press once within 8sec. of armed.
Press over 2sec.
Press together over 2sec.
Press together over 3sec.
Press together over 3sec.
Disarmed & ACC off
Disarmed & ACC off
Armed
Armed
Any time
ACC ON
Armed
Armed
Armed
Armed
ACC ON
Disarmed
Armed
1-Way Remote Transmitter Description (optional 3 & 4 button available)
Button 1 (Arm / Door lock)
LED indicator
Button 2 (Disarm / Door unlock)
Button 3 (Trunk open)
Button 4 (Silent arm mode)
TX-4R
NO:
-5-
T
R
Standard LCD 2-way icon instructions
Remote transmitting asignal.
System Armed.
Passive arming &
Auto re-arming mode.
Panic mode.
Check-in range turnON status.
System Disarmed.
1st-stage sensor bypass.
Door open whenarmed.
Weak signal notification.
Silent Armed.
2nd-stage sensor bypass.
Trunk open when armed.
-6-
PASS
X
PASS
X
AHJ
IMMO
Hood open whenarmed.
Door switch triggered.
Ignition switch triggered.
Valet mode.
1st stage sensortriggered.
Trunk switch triggered.
Passive immobilizer mode.
Arm W/engine runningmode.
2nd stage sensortriggered.
Hood switch triggered.
Anti car-jacking mode.
Turbo mode.
-7-
-8-
AM
AM
CALL
Call / pagemode.
2way time display.
Hand brake indication.
(Optional for startermodel)
2way receiving OFFmode. 2way button OFFmode.
Alarm clock.
2way battery levelindication.
2way Vibration mode.
Extra sensor triggered.
(Knock sensor) optional
BRAKE
Disable remote receiving
You may turn offthe 2-Way remote receiving signal from the mainunit. Press button
simultaneously for 2sec.until one long beep is heard.Remote receiving is now
disabled. To turn on receiving again, Pressbutton simultaneously untiltwo long
beep is heard,remote receiving is now enable.
2way remote button ON/OFF
For safety purpose,this 2-way remotecan be lockout the remote buttonin order notto
mis-touched the buttons.Press button forover 2sec. until one beep is heard, remote
button is nowlocked. To turn onremote button, pressbutton for over2sec. until two
beeps is heard,remote button isnow unlocked.
Programming 2-way remote
2-way LCD display:
2-way LCD display:
If set withvibration only
the 2-way LCDwill display :
-9-
Vibrate mode on/off
Press button for over 2sec. the2-way remote will respond tone & vibrate feature,
the button pressing 2sec. will changethe feature, see under table:
Beeps 2-way remote feature
Vibrations
1-beep
1-beep
1-time
1-time
Remote with toneand vibration
Remote with vibrationonly
Remote with toneonly
