e-con Systems See3CAM CU135 Manual de usuario
See3CAM_CU135
Camera
Version 1.0
e-con Systems
1/11/2017
DFU Application
User Manual
© Copyright e-con Systems. 2017. All rights reserved. 1
Disclaimer
e-con Systems reserves the right to edit/modify this document without any prior
intimation of whatsoever.
2 See3CAM_DFU Application User Manual
Contents
INTRODUCTION TO FIRMWARE 3
INSTALLING THE SEE3CAM_DFU APPLICATION 4
STEP 1-WELCOME SCREEN 4
STEP 2-INSTALLATION PATH SELECTION 4
STEP 3-READY TO INSTALL WINDOW 5
STEP 4-ATTACHING THE DEVICE 5
USING THE SEE3CAM_DFU APPLICATION 7
STEP 1-DEVICE SELECTION 7
STEP 2-FIRMWARE SELECTION 8
STEP 3-FIRMWARE UPDATE PROCESS 8
STEP 4-FIRMWARE UPDATE COMPLETE 10
TROUBLESHOOTING 13
FAQ 14
WHAT’S NEXT? 16
SUPPORT 17
© Copyright e-con Systems. 2017. All rights reserved. 3
Introduction to Firmware
The firmware is a program, embedded into the See3CAM device, which ensures
proper functioning of the device. The firmware can control all the features of the
device.
The See3CAM has a stable firmware that has been embedded into the device. But as
e-con Systems continuously works on this project, new firmware will be released
which has additional features that are supported in the See3CAM device. Please
refer to Firmware Release Notes to know about additional features. The new
firmware also includes bug fixes, and hence it is essential to upgrade this firmware
to avail the new features of See3CAM device.
This document highlights the process of updating a new firmware in the See3CAM
product. In future to add new functionalities to the See3CAM device, e-con Systems
will release new firmware binary. You can update this firmware into the See3CAM
device by using the See3CAM_DFU application.
4 See3CAM_DFU Application User Manual
Installing the See3CAM_DFU Application
To perform a firmware update, it is essential to install the See3CAM_DFU
application. The steps to install the See3CAM_DFU application are as follows:
Step 1. Welcome Screen
Step 2. Installation Path Selection
Step 3. Ready to Install Window
Step 4. Attaching the Device
Step 1 - Welcome Screen
As a first step, double click the See3CAM_DFU application setup file. The files
required are extracted and you can view the Welcome screen as shown below.
Figure 1: Welcome Screen
Click the Next button to go to the next screen.
Step 2 - Installation Path Selection
To select the installation path, you can either use the default installation path
C:\Program Files\e-con Systems\See3Cam_DFU\ or can change to another
installation path. After choosing the installation path, you can click the Next button
as shown below.
© Copyright e-con Systems. 2017. All rights reserved. 5
Figure 2: Installation Path Selection Window
Step 3 - Ready to Install Window
To begin the installation, you can click the Install button as shown below.
Figure 3: Ready to Install Window
Step 4 - Attaching the Device
The See3CAM device can be attached to the PC, and you can view the completion
window as shown below.
6 See3CAM_DFU Application User Manual
Figure 4: Completion Window
Click the Finish button to exit the Setup Wizard.
© Copyright e-con Systems. 2017. All rights reserved. 7
Using the See3CAM_DFU Application
The steps to update the firmware of any See3CAM device using See3CAM_DFU
application are as follows:
Step 1. Device Selection
Step 2. Firmware Selection
Step 3. Firmware Update Process
Step 4. Firmware Update Complete
Step 1 - Device Selection
Click the Device drop-down list which lists all the devices connected to the PC and
select the camera to update the firmware as shown below.
Figure 5: Device Selection
If no devices are connected for update, No Device Connected label will be displayed
as shown below.
8 See3CAM_DFU Application User Manual
Figure 6: Drop-down List Empty when no See3CAM Device is Connected
Step 2 - Firmware Selection
Click the Browse key and select the firmware image file as shown below.
Figure 7: Firmware File Selection Window
You can verify the product name and the firmware version before proceeding. Click
the Open group on the Home tab to view the firmware image.
Note: Please refer to Firmware Release Notes from firmware image package to know
more about the update in firmware.
Step 3 - Firmware Update Process
To start the firmware update process, click the F/W UPDATE button as shown
below.
© Copyright e-con Systems. 2017. All rights reserved. 9
Figure 8: Firmware Update Process
You can switch the device to Firmware Update mode and can start erasing the Old
Firmware as shown below.
Figure 9: Switching to e-con DFU and Erasing the Old Firmware
The application reads the firmware file and updates it into the device as shown
below.
