E-con Systems E-CAM52 35x Instrucciones de uso

e-CAM52_35x Hardware User Manual 04-Jan-12

Confidential Page 1 of 10

e-con Systems India Pvt Ltd

17, 54th Street,

Ashok Nagar

Chennai-600083

www.e-consystems.com

e-CAM52_35x

Hardware User Manual

Revision 1.0

Monday, January 4, 2012

Customer/Partner

e-CAM52_35x Hardware User Manual 04-Jan-12

Confidential Page 2 of 10

Contents

1Revision History ....................................................................................................................... 3

2Introduction............................................................................................................................... 4

3Scope ....................................................................................................................................... 4

4Disclaimer................................................................................................................................. 4

5Description................................................................................................................................ 5

5.1 Block diagram:................................................................................................................. 6

5.2 Interface Connector Pin Description................................................................................ 6

6Mechanical Specification.......................................................................................................... 8

6.1 Camera Board outline...................................................................................................... 8

7E-CAM52_35x board handling procedure................................................................................ 8

e-CAM52_35x Hardware User Manual 04-Jan-12

Confidential Page 3 of 10

eCAM52_35x

1 Revision History

Rev

Date

Major Changes

Author

1.0

4–Jan –2012

Based on eCAM52_35x Rev A hardware

Selva Raj

e-CAM52_35x Hardware User Manual 04-Jan-12

Confidential Page 4 of 10

2 Introduction

e-CAM52_35x camera daughter board has been designed and developed by e-con Systems

India Pvt Ltd. The eCAM52_35x camera daughter board uses a 5MP flexible PCB Autofocus

camera module based on OV5640 CMOS sensor from Omnivision. This camera daughter board

can be directly interfaced to the OMAP3530 Evaluation board from Texas Instruments (TI). e-con

Systems also provides Linux and Windows CE camera drivers and sample applications for these

camera daughter boards. This document describes how to interface the e-CAM52_35x camera

daughter board on TI’s OMAP3530 EVM board and how to use the same.

This camera daughter board is designed for the TI’sSitara/DaVinci family of processors and can

easily be adapted to interface with other Application Processors with similar CMOS Image sensor

interface.

This camera daughter board is also supplied with the sample applications. The DirectShow

compliant Windows CE camera driver and the Sample Camera Application are provided as is

without any warranties, implied or explicit.

3 Scope

The scope of this document is limited to the description of the camera daughter board and how to

interface this daughter board on the TI OMAP3530 EVM board. This also lists down any

precautions to be taken, if any.

4 Disclaimer

The specifications of the camera daughter board and instructions on how to use this daughter

board with OMAP3530 EVM are provided as reference only and e-con Systems reserves the right

to edit/modify this document without any prior intimation of whatsoever.

e-CAM52_35x Hardware User Manual 04-Jan-12

Confidential Page 5 of 10

5 Description

The e-CAM52_35x camera daughter board designed to interface with the standard Micron

camera header of OMAP3530 Rev-G EVM from TI. The e-CAM52_35x camera board

accommodates the OV5640 5M pixel auto-focus camera module. OV5640 is a low voltage high

performance color CMOS sensor from Omnivision. This board contains an onboard oscillator, the

necessary voltage source, powers and reset sequence to support the functionality of this camera

module on the TI OMAP3530 EVM.

Figure 1:eCAM52_35x camera daughter board

e-CAM52_35x Hardware User Manual 04-Jan-12

Confidential Page 6 of 10

5.1 Block diagram:

The following block diagram explains the camera daughter board design in brief.

Figure 2: eCAM52_35x daughter board block diagram

5.2 Interface Connector Pin Description

The e-CAM52_35x camera daughter board connects to the OMAP3530 EVM board through a 26-

pin Micron camera header. The following table lists down the pin numbers and signal names of

this Micron camera header.

e-CAM52_35x Hardware User Manual 04-Jan-12

Confidential Page 7 of 10

Signal Name

Pin type

Description w.r.t camera

DVP out bit 2

DVP out bit 3

DVP out bit 4

DVP out bit 5

DVP out bit 6

DVP out bit 7

DVP out bit 8

DVP out bit 9

DVP out bit 0

DVP out bit 1

GND

PWR

Ground

GND

PWR

Ground

HSYNC

DVP Horizontal sync output

Do not connect

RESET#

Active low reset input

VSYNC

DVP Vertical sync output

SDA

I/O

SCCB Serial Data signal

SCL

SCCB Serial Clock signal

Do not connect

VCAM

PWR

Camera Power in

VCAM

PWR

Camera Power in

PCLK

I/O

DVP Pixel clock output

GND

PWR

Ground

GND

PWR

Ground

Do not connect

Table 1:Micron Camera interface connector pin detail

e-CAM52_35x Hardware User Manual 04-Jan-12

Confidential Page 8 of 10

6 Mechanical Specification

6.1 Camera Board outline

Figure 3: eCAM52_35x board outline dimensions (in mm).

7 E-CAM52_35x board handling procedure

The e-CAM52_35x board should be mounted to Micron Camera header (J31) of the OMAP 3530

EVM Rev G as indicated in the following steps

e-CAM52_35x Hardware User Manual 04-Jan-12

Confidential Page 9 of 10

1. Put the jumper connecting Pin 2 and 3 of JP1 header on OMAP 3530 EVM Rev G. This is

required to connect the camera signals to Micron connector (J31). This is illustrated in

the picture below

Figure 4: JP1 jumper setting

2. The camera board’s pin one is indicated as below.

Figure 5: eCAM52_35x CN2 pin 1 indication

3. Insert the camera board into the Micron header (J31) of the OMAP EVM board as shown

in the image below. Note that the camera module should face outside the board.

Pin 1

e-CAM52_35x Hardware User Manual 04-Jan-12

Confidential Page 10 of 10

Figure6: eCAM52_35x interfaced with OMAP3530 Rev G EVM
