Duronic BS401 Manual de usuario

Creative Consumer Electronics

Bathroom Scales - BS401

PLEASE READ ALL THE INSTRUCTIONS BEFORE USE

English Manual

Manuel d’utilisation en français

Gebrauchsanleitung auf Deutsch

Manual de Instrucciones en Español

Manuale D’istruzioni In Italiano

Contents

English Manual

Specication

Unit Conversion

1. Capacity - 180 kg / 397lb

2. Units - kg / lb

3. Unit conversion - Unit conversion key

4. Division - 0.1kg / 0.2lb

5. Power - 3V (2xbattery AAA 1,5V )

6. Keys for setting target weight - SET /UP /DOWN

7. Target weight range - 10Kg,150Kg or 22Lb - 330LB

8. Numbers of users - 8 persons - (P1-P8)

9. Automaticidenticationfunction

10. Automaticidenticationrange-2Kg

11. Previous Measurements

12. Auto step-on or manual switch on

13. Auto off function

14. Error indications

Press the UNIT button on the back of the scale to select measuring unit(kg/lb).

The default unit is Kg, kg=kilograms, lb=pounds

NOTE:Whenusingthescalesforthersttime,orwhenchangingitsposition

or location, the scale should be restarted twice and should be free of objects

andonarm,atsurfacetoensureaccuratemeasurements.Thisisfor

calibrating the scale. If you do not perform these measures, measurements

may be incorrect.

Setting Target Weight

1. Press SET enter into setting mode. Then press SET key again. The LCD

screen display user No.

When the screen displays the user No, press UP( ) /DOWN( ) to

choose the user No. (P1-P8),

PressSETforconrmation.

2. When the screen displays the target weight, press UP( ) /DOWN ( )

tosettheuser’stargetweight.PressSETforconrmation.

3. After setting your target weight ,you must measure your weight before the

scaleautomaticallyturnsoff.Afteryoutaketherstmeasurement,thescale

will automatically memorize your weight and target weight. When you use the

scales next time it will automatically identify the user based on weight and

there is no need to set the user information again (unless there are multiple

users of the same weight).

Measuring The Weight

1. Placethescalesonarm,atsurfaceandstandonthescaletomeasure

yourweight.Thescalewillstartautomaticallyandthenbeginashingwhilst

itmeasuresyourweightandidentiestheuserNo.andtargetweight.The

scale will identify your target weight and compare your current weight with your

previous weight to decide what color backlight to display (green, yellow or red).

If the current weight is close to your target weight within +/-0.1kg, the green

backlight will display; If current weight is far away from the target weight, the

backlight will display according to below situations. A. Users who want to lose

weight must set their target weight lower than their current weight.

- When the current weight is less than the previous weight a yellow backlight

light

- When the current weight is more than the previous weight a red backlight will

display;

B. Users who want to gain weight must set their target weight more than

their current weight.

* When the current weight is more than the previous weight a yellow backlight

will display;

* When the current weight is less than the previous weight a red backlight will

display;

2. The scale will automatically identify users and the display the target weight.

3. Then display will show the difference between the user weight and the

target weight.

4. If the display shows a minus sign in front of the difference weight it means

that the user weight

is less than the target weight, for example, the user weight is 80Kg and the

target weight is 90Kg;

the difference is -10.0Kg. If there is no minus sign showing in front of the

weight difference it means

thattheuser’sweightismorethanthetargetweight.

Previous Measurements

5. If the scale cannot identify the user, it is because the weights of two users are

within 2.0kg of each other.

The LCD screen will display two or more user No. press the UP( ) / DOWN( )

button to choose the correct user No.

1. Press SET key to switch on the scale. Then press SET key again, The LCD

screenwilldisplayuserNo.ickering,pressUP()/DOWN()tochoose

the user No. which you wish to query.P1-P8.

2. AfteryouhavenishedselectingtheuserNo.waitfor3seconds,the

screenwillautomaticallydisplaytheuser’stargetweightandtheuser’s

previous weight.

3. Users can press the UP( ) /DOWN( ) keys to change the user No.. If

press SET key again, then

enter to setting target weight mode.

1. Overload indication and Low battery indication.

2. The difference between the weight and the target weight is too high or too low.

Step onto the scale and it will automatically turn

on. Stand still with your weight evenly

distributed between both legs. The scale will

display your weight.

Weigh Only

Errors Indication
