Ducasa M-28 Downflow Manual de usuario

M-28 Downflow

Operating and Installation Instructions

(Read these instructions carefully and retain for future

reference)

NOTE:

A qualified electrician must carry out the electrical installation of this product. The Electrical installation must

comply with the current UK regulations. Any claim on the warranty could be invalid if these requirements

have not been met.



Contents
INTRODUCTION .......................................................................................................... 3
IMPORTANT SAFETY INFORMATION....................................................................... 3
SPECIFICATIONS........................................................................................................ 4
INSTALLING THE DEVICE.......................................................................................... 4
Electrical Connection ....................................................................................................... 4
Location of The Heater .................................................................................................... 4
Mounting The Heater....................................................................................................... 4
OPERATING INSTRUCTIONS..................................................................................... 5
INITIAL SETUP............................................................................................................. 5
Setting the time ............................................................................................................... 5
Selection of The Mode..................................................................................................... 6
24H COUNTDOWN TIMER.......................................................................................... 6
STANDBY..................................................................................................................... 6
MANUAL OPERATION................................................................................................. 7
PROGRAMME FUNCTION.......................................................................................... 7
OPEN WINDOW DETECTION..................................................................................... 8
SWING FUNCTION...................................................................................................... 8
CHILD-LOCK FUNCTION ............................................................................................ 8
REMOTE CONTROL VIEW.......................................................................................... 9
CONTROL PANEL VIEW............................................................................................. 9
OVERHEAT PROTECTION ....................................................................................... 10
CLEANING & MAINTENANCE................................................................................... 10
MAINTENANCE AND CARE...................................................................................... 10
GUARANTEE.............................................................................................................. 10






•Before using your new heater, please carefully read through the following instructions.

KEEP THIS BOOKLET IN A SAFE PLACE SO THAT YOU MAY REFER TO IT IN THE

FUTURE.

•After removing the packaging, make sure that the heater is in good condition.

•Dispose of the packaging according to local guidelines if no longer needed.

1. The heater should be mounted on the wall so that the air outlet is facing downwards. You

must not install it vertically and it must be mounted level.

Do not store or use any flammable materials or sprays in the vicinity of the heater. Do not

cover the air outlet and inlet vents.

2. If the electricity cable gets damaged it must only be replaced by a technician appointed by

the supplier. This will avoid possible risks and ensure that special tools are available if

needed.

3. The heater must not be located immediately below an electrical socket.

5. If the heater is not being used or you are repairing the heater, ensure that the heater is

disconnected from the power supply.

6. Do not touch the heater with wet hands.

7. If the motor is not working properly, stop it immediately and notify the supplier.

8. While using the heater, do not leave the door or window open otherwise it will influence

the heating effect.

9. When you turn off the heater, the fan will remain on for 30 seconds to allow the heater to

cool down. After this time the heater will shut down.

10. Using the remote you can set the programme.

11. The remote control will only function with CR2025 batteries.

12. At the end of the heater’s working life, the remote battery must be removed before it is

disposed of.

13. All batteries must be disposed of following local guidelines.

14. The heater must be installed at least 2m above the floor.

15. In case of breakdown or damage turn off the appliance at the main On/Off switch and

notify the supplier.

16.This appliance is not intended to be used by persons (incl. children) with limited physical,

sensory or mental capabilities, or who lack experience, except for those under supervision

or who have received instruction in the use of the appliance from a person responsible for

their security.

17.Children must be supervised in order to ensure that they do not play with the appliance.

18. CAUTION —some parts of this product can become very hot and cause burns.

Particular attention has to be given where children and vulnerable people are present.

1. INTRODUCTION

2. IMPORTANT SAFETY INFORMATION

Model names

Voltage

Power

M-28 Downflow

AC220-240V 50/60Hz

2000W

Electrical Connection

A qualified electrician must carry out the electrical installation of this heater. The electrical

installation must comply with the current UK regulations. Any claim on the warranty will be

invalid if these requirements have not been met.

The radiator requires a 220/240V 50/60Hz power supply.

Connecting wires:

Brown: Live

Blue: Neutral

The power supply must comply with the current regulations for the power rating of the

product.

The apparatus must be connected into a fused connecting box with an appropriate sized

fuse for the heater.

We recommend that the connecting box is positioned 10cm to the right of the product.

According to regulations, the product must be connected to the power supply by means of

an all-pole circuit breaker with a contact gap of at least 3mm or by a thermal-magnetic circuit

breaker.

Location of The Heater

In bathrooms, the heater must not be sited inside the protected area.

The heater switches must not be reachable, directly or indirectly, by a person in the bath or

shower.

The heater, under no circumstances, should be installed directly below an electric power

point.

Mounting The Heater

•Important! Make sure that there are no electric cables or other installations (for

example water pipes) are located near the drill holes. Make sure that the heater is

fitted securely and is mounted horizontally with the air outlet facing downwards.

The product should be fitted with 2 screws, allowing a minimum of 25cm of unobstructed

space either side of the heater.

Ensure that there is a minimum of 20cm of unobstructed space above the heater.

4. INSTALLING THE DEVICE

3. SPECIFICATIONS

NOTE: Some of the heater’s functions can only be accessed using the remote included with

the heater.

Switching ON (Master Switch)

Once the heater has been mounted on the wall and correctly connected to the main

electricity power supply, press the master On-Off switch at the back of the heater on the

right hand side.

With the switch in the On position, the flush part will be at the top of the switch.

NOTE: If the power is interrupted for any reason, when the power is restored the heater will

be in standby and the clock will be reset and all selected functions will default to off. Your

temperature and program will be retained.

Setting the time

Before operating the heater you must set the date and time.

To do this press the “LOCK” button on the remote control until the LED display shows 00:00

and the “Mo” icon. Then follow the steps below:

1. Press the “Set” button and the “Mo” icon will begin to flash.

Use the + or - button to scroll through to the correct day. (Mo=Monday...Su=Sunday

etc.) then press “Set”

2. The hour part of the time will start to flash.

Using the + or –button set the current hour and then press “Set”

3. The minute part of the time will start to flash.

Using the + or –button set the current minutes and then press “Set”

NOTE: Once the “Set” button has been pressed, you have 5 seconds to input your choice

and press “Set” to move to the next option, otherwise the heater will return to standby.

If the heater is switched off at the mains, the day and time will be lost.

5. OPERATING INSTRUCTIONS

6. INITIAL SETUP

Selection of The Mode

This function is only accessible using the remote control.

NOTE: Pressing the On/Off button located on the rear of the heater underneath the master

On/Off switch will cycle the heater between standby and (2000w) mode which is

explained below.

With each press of the “MODE” button you cycle between the 3 modes listed below:

•No symbol = The heater will blow room temperature air using the internal fan unit

•(1000w) = The heater will blow warm air using the 1000w element

•(2000w) = The heater will blow hot air using the 2000w element

This function is only accessible using the remote control.

This function can be used to put the heater into standby mode after a user defined period of

hours (Up to 24 hours)

To set this function press the “24H” button and when 00:00 is shown on the display, press

the “24H” button to increase the duration of the timer in 1 hour increments.

To cancel the timer you will need to re-enter the 24H function and set the countdown timer to

00:00

While this function is active the heater can be used normally.

NOTE: If you use the remote to select the standby function then the countdown timer will be

cancelled.

This function is only accessible using the remote control.

With each press of the “ON/OFF” button you cycle the heater between the currently selected

mode of operation and standby.

In standby mode the heater will not heat and the power icon will be shown on the display.

If the heater has been heating the fan will run for 30 seconds to cool the heater down. While

this is happening the power icon on the heater will flash.

When the fan stops the outlet vent flap will close and the power icon will stay illuminated.

NOTE:

•If the heater is put into standby mode, the swing and open window functions will be

turned off when the heater is next changed from standby mode.

•If the heater is in program mode prior to being put into standby, the mode that the

heater will enter once standby has been exited is manual mode.

7. 24H COUNTDOWN TIMER

8. STANDBY

This function is only accessible using the remote control.

To adjust the set temperature, use the + or - buttons to set the desired temperature from

10℃to 49℃.

The heater will heat the room following the protocol below:

•When the room temperature is 1 degree or more above the set temperature, the

heater will blow room temperature air.

•When the room temperature drops 2 degrees below the set temperature, the heater

will heat using the (1000w) setting.

•When the room temperature drops 4 degrees below the room temperature, the

heater will heat using the (2000w) setting.

NOTE: When the set temperature is reached, the heater will continue to circulate room

temperature air and the fan will still be active. This is not a fault with the heater!

This function is only accessible using the remote control.

This function will allow you to set a 7 day week programme with each day having a single on

off period per day.

Ensure that the heater is not in standby mode and press the “W-Timer” button, then follow

the steps below:

1.When the “Mo” icon appears and starts flashing, press the “W-Timer” button.

2.Select the hour for the on period using the + or –buttons. Then press the “W-Timer”

button.

3.Select the minutes for the on period using the + or –buttons. Then press the “W-Timer”

button.

4.Select the hour for the off period using the + or –buttons. Then press the “W-Timer”

button.

5.Select the minutes for the off period using the + or –buttons. Then press the “W-Timer”

button.

6.The “Tu”icon will now be flashing, Press the “W-Timer” button and repeat steps 2 to 5.

Then repeat this process for the rest of the week.

7.Once you have programmed Sunday’s off period press the “W-Timer” button to run the

programme. “W”will now be shown at bottom of the display.

8.Press the “Delay”button to set the temperature for the on period for Monday using the +

and –buttons, then press the “Delay” button to move to Tuesday.

Repeat this process for the rest of the week.

9.Once you have set Sunday’s on temperature and pressed the “Delay” button your

programme will be set and running.

9. MANUAL OPERATION

10. PROGRAMME FUNCTION

NOTE:

•When the heater reaches the programmed off time, the heater will be programmed

as off and will not heat. This cannot be changed.

•Once the “W-Timer” button has been pressed, you have 5 seconds to input your

choice and press the “W-Timer” button to move to the next option, otherwise the

heater will return to the previously used mode.

This function is only accessible using the remote control.

In order to save energy, if a window opens and causes a sudden drop in temperature the

heater will stop heating.

When activated the symbol is shown on the display. By default this function is

deactivated. To change the status of the function, press the “AUTO” button.

To deactivate this function press the “AUTO” button on the remote again.

When activated if the heater detects a temperature drop of 3ºC or greater within a minute

while it is heating, it will turn off and go to the standby screen.

NOTE: If Open Window Detection engages, you will manually have to take the heater off

standby and re-engage Open Window Detection.

This function is only accessible using the remote control.

Activating this function will allow the flap located below the air outlet of the heater to oscillate

aiding in the circulation of air.

Each press of the “Swing” button turns this function on or off.

This function is only accessible using the remote control.

When activated the display will only show the power icon and cannot be altered with the

remote.

To activate this function, press the “LOCK” button on the remote. To cancel this function

press the “LOCK” button again.

11. OPEN WINDOW DETECTION

12. SWING FUNCTION

13. CHILD-LOCK FUNCTION

Only use lithium CR2025 3V batteries with the remote control.

The remote control buttons do the following:

1. “ON/OFF” Cycles the heater between standby or the

currently selected mode of operation

2. “24H” Sets a countdown timer from 1 to 24 hours.

3. “Mode” Cycles the mode of operation between fan

only/ 1000w and 2000w.

4. “Swing” Each press cycles flap oscillation setting

on or off.

5. “LOCK” Child-Lock function for the heater

6. “AUTO” Open Window Detection setting

7. “Delay” Used in conjunction with other modes

8. “W-Timer” Create and modify the 7 day program

9. “+” Increase

10. “-” Decrease

11. “Set” Modify the day of the week and time

15. CONTROL PANEL VIEW

14. REMOTE CONTROL VIEW

This heater is protected with an overheat protection failsafe that switches the heater off

automatically if it senses that it is about to overheat.

An example of this would be due to total or partial obstruction of the inlet vents.

In this scenario, disconnect the mains power to the heater and wait 30 seconds for it to cool

down. Once the heater has cooled down, remove any obstruction from the inlet vents.

Switch it back on as described earlier in the manual.

After the heater has been switched on, the heater will operate normally. If the problem

persists, please contact your supplier for assistance.

Before undertaking any cleaning or maintenance on the heater, disconnect it from the power

supply.

For cleaning it is recommended to use a soft moist rag and neutral detergent. Do not use an

abrasive cloth or substances which could affect the appearance of the heater.

Check that the hot air outlet and the inlet vents are free of dust and dirt.

During cleaning, be careful not to touch the heating elements.

In case of breakdown and/or poor functioning of the heater, disconnect the heater from the

power supply and contact your supplier.

NOTE: As a result of continual improvements, the design and specification of the heater

may differ slightly to the unit illustrated on the packaging.

Ducasa heaters require very little maintenance.

The surfaces of the heater must not be cleaned with an abrasive product or those containing

granular substances. We recommend regular cleaning with PH neutral products.

In order to clean the heater, it is recommended that the electric power is switched off.

Your appliance is guaranteed for two years from the date of purchase –during this period

we will repair or exchange, at our discretion, any faulty or defective parts providing the

appliance has been used in accordance with the operating & installation instructions and

has not been misused or mistreated in any way.

Any unauthorized repair or attempted repair will invalidate the guarantee. You may be asked

to return the product to our workshop for inspection to establish whether the fault is covered

under the guarantee.

The guarantee is valid in the UK only.

This guarantee is additional to your statutory rights.

In the unlikely event of a problem with your appliance please contact your supplier.

16. OVERHEAT PROTECTION

17. CLEANING & MAINTENANCE

18. MAINTENANCE AND CARE

19. GUARANTEE

Tabla de contenidos

Otros manuales de Calentador de Ducasa

Ducasa

Ducasa AVANT-DGP 350 Manual de usuario

Ducasa

Ducasa ALU STONE Manual de usuario

Ducasa

Ducasa Sunrise-Eco SR03DE Manual de usuario

Ducasa

Ducasa INOX Manual del propietario

Ducasa

Ducasa Sunray RF15 Manual de usuario

Ducasa

Ducasa RP-10 Manual de usuario

Ducasa

Ducasa M-28 SPLIT Manual de usuario

Ducasa

Ducasa AVANT-DGP 350 Manual de usuario

Ducasa

Ducasa AVANT-A 350 Manual de operación y mantenimiento

Ducasa

Ducasa Colorado SCR Series Manual de usuario

Ducasa

Ducasa Colorado MCR Manual de usuario

Ducasa

Ducasa DP 1300 Manual de usuario

Ducasa

Ducasa Sunrise Manual de usuario

Ducasa

Ducasa Colorado TCR 140 Manual de usuario

Ducasa

Ducasa Richmond DPL 10 Instrucciones de funcionamiento

Ducasa

Ducasa AVANT-DGi+ 350 Manual de usuario

Ducasa

Ducasa Richmond DPL 15 Instrucciones de funcionamiento

Ducasa

Ducasa M-59 Manual de usuario

Ducasa

Ducasa Sunrise Eco-Pro SR03D-EP Manual de usuario

Ducasa

Ducasa The Vitro-i+ Manual de operación y mantenimiento

Ducasa

Ducasa AVANT-DGS 350 Manual de usuario

Ducasa

Ducasa Sunburst Series Manual de usuario

Manuales populares de Calentador de otras marcas

oventrop

oventrop Regucor Series Manual de usuario

Blaze King

Blaze King CLARITY CL2118.IPI.1 Manual de usuario

ELMEKO

ELMEKO ML 150 Manual de usuario

BN Thermic

BN Thermic 830T Manual de usuario

KING

KING K Series Guía

Empire Comfort Systems

Empire Comfort Systems RH-50-5 Guía de inicio rápido

Well Straler

Well Straler RC-16B Manual de usuario

EUROM

EUROM 333299 Manual de usuario

Heylo

Heylo K 170 Manual de usuario

Eterna

Eterna TR70W Manual de usuario

Clarke

Clarke GRH15 Manual de instrucciones

IRSAP

IRSAP The Radiator Company Ovali Manual de usuario

Empire Heating Systems

Empire Heating Systems WCC65 Manual de usuario

Wetekom

Wetekom 92 86 43 Manual de usuario

Desa

Desa SPC170-F Manual de usuario

Watlow

Watlow Watrod Electric Tubular Heaters Manual de usuario

Haverland

Haverland ECO-DRY GPS Series Manual de lista de piezas

Stelpro

Stelpro ASILVC2060 Series Manual de usuario
