INSTALLATION/OWNER'S MANUAL
AM/FM/CD/MP3/WMA Receiver with Detach Face
XDM6220
2
XDM6220 INSTALLATION
Preparation
TYPICAL FRONT-LOAD DIN MOUNTING METHOD
Please read entire manual before installation.
Before You Start
• Disconnect negative battery terminal. (consult a qualified technician for instructions)
• Avoid installing the unit where it would be subject to high temperatures, such as from
direct sunlight, or where it would be subject to dust, dirt or excessive vibration.
Getting Started
• Remove 2 transit screws located
on top of the unit.
• Insert the supplied keys into the
slots as shown, and slide the unit
out of the mounting sleeve.
• Install mounting sleeve into
opening, bending tabs to secure.
• Connect wiring harness and
antenna. (consult a qualified
technician if you are unsure)
• Certain vehicles may require an
installation kit and/or wiring
harness adapter (sold separately).
• Test for correct operation and slide
into mounting sleeve to secure.
• Snap trim ring into place.
• Mount the iplug™ adapter to any
smooth clean surface using the
supplied double-sided tape or
#2 x 3/8” Phillips head screws.
3
XDM6220 INSTALLATION
Wiring Diagram
FUSE
When replacing the fuse,
make sure new fuse is the
correct type and amperage.
Using an incorrect fuse
could damage the radio. The
XDM6220 uses one 10 amp
AGC fuse (Battery) located
in-line.
4
XDM6220 OPERATION
Control Locations
Release
Power
Mute
Audio
Band/Play/Pause
Auto Store/Preset Scan/Enter
Mode/Search
Eject
Tune/Track Up/Down
Loudness
Display/0
1
2
3
4
5
6
7
8
9
10
11
EQ/9
Tuner Scan/8
Local/Distance/7
Preset 6/Folder Up
Preset 5/Folder Down
Preset 4
Preset 3/Intro
Preset 2/Random
Preset 1/Repeat
Volume Up/Down
12
13
14
15
16
17
18
19
20
21
21
1 2 3
The XDM6220 allows playback of your favorite MP3 and WMA files recorded on CD-R and
CD-RW discs. Its powerful on-board DSP processor decodes the compressed audio while
maintaining near-CD sound quality. An internal SRAM buffer provides ESP (Electronic
Skip Protection) to virtually eliminate skipping and allows alphanumeric or direct track
search - even while a song is currently playing!
45 6 7 8
9
20 18 11 10
17 16 15 14 13 12
19
5
XDM6220 OPERATION
General Operation
Press RELEASE and pull away from the left side to remove.
To re-install, insert right side of faceplate first then push
left side to secure.
Remove trim ring and install supplied #1 x 7/32” Phillips
head screw through left side of mounting frame into faceplate.
Press PWR or any other button (except eject or volume up/
down) to turn the unit on. Inserting a disc will turn the unit
on automatically. Press PWR to turn the unit off.
Press MODE to select between tuner, CD player and auxiliary
input. Modes of operation are indicated in the display.
Press LOUD to activate and deactivate the loudness contour
curve. Activating this feature will enhance the bass and
treble frequencies when listening to music at low volumes.
Adjust volume using VOL t / VOL s (00-46).
Press and hold PWR for 3 seconds to program currently
selected volume level. "P-VOL" and the current volume level
will momentarily appear in the display.
Press EQ to select between POP, JAZZ, CLASSIC, BEAT,
ROCK and OFF (default) equalization curves. Any adjustment
to the Bass or Treble settings automatically cancels the
current EQ curve (if one is selected).
Press DISP to select between clock and radio frequency
(tuner mode), clock and CD track/elapsed time (CD mode),
or clock and AUX (AUX mode).
With the unit on, press and hold DISP until the clock begins
to flash, then release. Press TUNE << to adjust the hours
and TUNE >> to adjust the minutes. Press DISP momentarily
to save the selected time.
The clock will display 12-hour AM/PM time in USA frequency
spacing mode (PM 10:00). In European frequency spacing
mode, the clock will display 24-hour time (22:00).
Faceplate Removal
Semi-permanent
Faceplate Installation
Power On/Off
Mode
Loudness
Volume
Programmable
Turn-On Volume
Preset EQ Curves
Display
Set the Clock
12/24-hour Clock
6
XDM6220 OPERATION
General Operation
In tuner mode, press and hold DISP then press TUNE >>
to select function priority display. “FREQ” will momentarily
appear in the display.
Note:
"FUNC" will appear in CD or AUX modes.
Radio frequency (tuner mode), CD track/elapsed time (CD
mode) or AUX (AUX mode) will be displayed by default.
Note:
When playing MP3/WMA files, the track number/elapsed
time, track name, directory name, title, artist, album, year
or comment will be displayed by default. Clock is accessed
by pressing DISP momentarily.
Press and hold DISP then press TUNE << to select time
display priority. “TIME” will momentarily appear in the
display. Clock will be displayed by default. Radio frequency,
CD track/elapsed time or MP3/WMA file information is
accessed by pressing DISP momentarily.
Programs unit to display clock/no clock when unit is off.
Press and hold MODE then press PRESET 1 to select clock
priority on/off. “CLK ON” or “CLK OFF” will momentarily
appear in the display.
Press and hold for more than 2 seconds to RESET the unit
upon initial installation or if abnormal operation occurs.
The reset button is located behind the faceplate. Refer to
page 2 for details.
Press and hold AUD for 3 seconds to turn confirmation
beep on/off. "BEEP ON" or BEEP OFF" will momentarily
appear in the display.
Press MUTE to silence the audio. “MUTE” will flash in the
display. Press MUTE again to cancel.
Programmable Display
Priority
Programmable Clock
Priority
Reset
Confirmation Beep
Mute
Press AUD to select between Volume (default), Bass, Treble,
Balance & Fader.
Press AUD until BAS appears
Press VOL t or s to adjust
( -6 minimum / +6 maximum)
Press AUD until TRE appears
Press VOL t or s to adjust
( -6 minimum / +6 maximum)
Press AUD until BAL appears
Press VOL t or s to adjust
(BAL L 12-BAL 00-BAL R 12)
BAL 00 represents equal balance
Press AUD until FAD appears
Press VOL t or s to adjust
(FAD F 12-FAD 00-FAD R 12)
FAD 00 represents equal fader
Individual Bass and Treble settings are retained in memory
for AM, FM, CD, and AUX modes. This allows you to save
the Bass and Treble settings separately for each mode.
Example:
FM tuner mode can have Bass +3 and Treble -1 while CD
mode can have Bass +2 and Treble +2.
Note:
Any adjustment to the Bass or Treble settings automatically
cancels the current EQ curve (if one is selected).
7
XDM6220 OPERATION
General Operation
Audio
Bass
Treble
Balance
Fader
Source Audio Memory
Press TUNE << or TUNE >> momentarily to seek the next
strong station.
Press TUNE << or TUNE >> for more than 2 seconds, then
release. "MANUAL" will momentarily appear in the display.
Press TUNE << or TUNE >> momentarily to move radio
frequency up or down one step at a time. Press and hold to
advance quickly. If tuning is not adjusted for 5 seconds, the
unit will return to seek tuning mode (default). "AUTO" will
momentarily appear in the display.
Press SCAN to preview strong stations on the current band,
pausing for 5 seconds at each. Press SCAN again to cancel.
Press LOC to activate local tuning for strong station reception
only. Press LOC again to cancel and resume distance tuning
(default).
Press BAND to select between FM1, FM2, FM3, AM1 and AM2
bands.
Press and hold BAND then press TUNE << to select
European frequency spacing. Press and hold BAND then
press TUNE >> to select USA frequency spacing (default).
Up to 18 FM stations and 12 AM stations can be stored. To
store a station, select the desired band and station. Press
and hold the desired preset button (1-6) for more than
2 seconds. When stored, the preset number will appear in
the display. The station can be recalled anytime by pressing
the corresponding preset button.
Note:
Function buttons 7, 8, 9 and 0 apply to MP3 and WMA
playback only.
Press AS/PS for more than 2 seconds to automatically store
the six strongest stations in the current band. Automatic
Local/Distance is activated during the initial band scan.
Press AS/PS for less than 2 seconds to scan presets 1-6 on
the current band, pausing for 5 seconds at each. Press
AS/PS again to cancel.
8
XDM6220 OPERATION
Tuner Operation
Seek Tuning
Manual Tuning
Scan Tuning
Local/Distance
Band
Frequency Spacing
Storing and Recalling
Station Presets
Automatically Store
Stations
Preset Scan
Insert CD
Eject CD
Track Select
Fast Forward and Reverse
Pause
Intro
Repeat
Random
CD-R/CD-RW Compatibility
With the label facing up, insert a standard size CD into the
CD slot. The CD will automatically begin playback.
Press EJECT to eject the CD. The unit will change to previous
mode of operation (AM, FM, or auxiliary input). If the disc is
not removed within 10 seconds, the unit will reload the disc.
The unit does not have to be turned on to eject CD.
Press TRACK >> to skip to the beginning of the next track.
Press TRACK <<
to return to the beginning of the current
track. Pressing TRACK <<
again skips to the beginning of
the previous track.
Press and hold TRACK >> or TRACK <<
to fast forward or
reverse a track.
Press
l
/
II
to temporarily stop CD playback.
Press
l
/
II
again to resume playback.
Press INT to play the first 10 seconds of each track.
Press INT again to cancel.
Press RPT to continuously repeat selected track.
Press RPT again to cancel.
Press RDM to play all tracks in random order. Press RDM
again to cancel. Random mode is retained in memory when
selecting between tuner, CD player and auxiliary input
modes and when the unit is turned on/off.
Some CD-Rs and CD-RWs may be incompatible with this
unit, depending on media type and recording method. In
addition, the following CDs may be incompatible with this
unit:
CDs exposed to extreme temperatures or direct sunlight for
extended periods of time, CDs recorded in which a recording
session failed or a re-recording was attempted and, or
encrypted or copy-protected CDs which do not conform to
the audio CD-DA red book recording standard.
9
XDM6220 OPERATION
CD Player Operation
10
XDM6220 OPERATION
CD Player Operation - MP3/WMA Files
Playing an MP3/WMA Disc
MP3 Icon
WMA Icon
Folder Icon
Displaying Information
Character Support
When an MP3/WMA encoded disc is first inserted,
“READING” will appear in the display. Depending on the
number of files and folders, this may take several seconds.
The icon will illuminate anytime a valid MP3 encoded
disc is inserted and flash in MP3 search/navigate modes.
The icon will illuminate anytime a valid WMA encoded
disc is inserted and flash in WMA search/navigate modes.
The icon will illuminate anytime a folder is selected in
the file/folder search modes.
Press DISP to select between track number/elapsed time
(default), clock, track name, directory name, title, artist,
album, year and comment.
“NO ID3 TAG” will be displayed if the MP3 file contains no
ID3 tag information.
“UNKNOWN” will be displayed if the WMA file contains no
WMA tag information.
“ROOT” will be displayed if the directory name of a root
folder is not labeled.
Maximum character display information
• Track name – 32 character maximum
• Directory name – 32 character maximum
• *Song title – 30 character maximum
• *Artist name – 30 character maximum
• *Album name – 30 character maximum
• *Year – 4 character maximum
• *Comment – 28 character maximum
*Song title, Artist Name, Album name, Year and Comment
will only be displayed if included with the MP3/WMA file.
When referring to MP3/WMA playback, the following terms
are synonymous:
• File name and track name
• Folder name and directory name
Este manual sirve para los siguientes modelos
1
Tabla de contenidos
Otros manuales de Receptor de coche de Dual
Dual
Dual XD5125 Instrucciones de funcionamiento
Dual
Dual XDM7615 Instrucciones de funcionamiento
Dual
Dual XD7600 Instrucciones de funcionamiento
Dual
Dual AXXERA XDMA7200 Instrucciones de funcionamiento
Dual
Dual DSA2062 Instrucciones de funcionamiento
Dual
Dual DC535Bi Instrucciones de funcionamiento
Dual
Dual AXXERA X2DMA500 Instrucciones de funcionamiento
Dual
Dual XR4115 Instrucciones de funcionamiento
Dual
Dual XD28BT Instrucciones de funcionamiento
Dual
Dual XDMA6540 Instrucciones de funcionamiento
Dual
Dual DV712 Instrucciones de funcionamiento
Dual
Dual XDCP97BT Instrucciones de funcionamiento
Dual
Dual XHD7720 Instrucciones de funcionamiento
Dual
Dual AXXERA XDMA7800 Instrucciones de funcionamiento
Dual
Dual DCPA701 Instrucciones de funcionamiento
Dual
Dual XDM6350 Instrucciones de funcionamiento
Dual
Dual XDMA6855 Instrucciones de funcionamiento
Dual
Dual XDVD8183 Instrucciones de funcionamiento
Dual
Dual XDMA690 Instrucciones de funcionamiento
Dual
Dual XDVD8183 Instrucciones de funcionamiento
