Dual AXXERA XDMA7100 Instrucciones de funcionamiento

CD Receiver

Installation & Owner's Manual

CD-R/RW Compatible

Front USB Port

iPod®/iPhone®/Flash Drive

2 Aux Inputs

Front & Rear

MP3/WMA

Playback

XDMA7100

SDHC Supported

XDMA7100

TYPICAL FRONT-LOAD DIN MOUNTING METHOD

REMOVAL KEYS

MOUNTING SLEEVE

HEAD UNIT

MOUNTING KIT

OR DASH OPENING

Preparation

Please read entire manual before installation.

Before You Start

•Disconnectnegativebatteryterminal.Consultaqualifiedtechnicianforinstructions.

•Avoidinstallingtheunitwhereitwouldbesubjecttohightemperatures,suchasfrom

directsunlight,orwhereitwouldbesubjecttodust,dirtorexcessivevibration.

Getting Started

•Removetrimringfromunit,

•Remove2transitscrewslocatedontopoftheunit.

•Insertthesuppliedkeysintotheslotsasshown,andslidetheunitoutofthemounting

sleeve.

•Installmountingsleeveintoopening,bendingtabstosecure.

•Connectwiringharnessandantenna.Consultaqualifiedtechnicianifyouareunsure.

•Certainvehiclesmayrequireaninstallationkitand/orwiring

harnessadapter(soldseparately).

•Testforcorrectoperationandslideinto

mountingsleevetosecure.

•Snaptrimringintoplace.

XDMA7100

REMOTE IN

FRONT R/SUB AUX

R-CH

L-CH

BLUE

BLACK

RED

YELLOW

Remote Turn-On

Connect to amplifier or power

antenna. Insulate wire if not used.

Ground

Connect to the vehicle

chassis ground.

Accessory

Connect to an existing ignition

circuit or switched 12 volt source.

Memory

Connect to the battery

circuit or constant 12 volt source.

Right Front

Gray/Black (-)

Gray (+)

Left Front

White/Black (-)

White (+)

Left Rear

Green/Black (-)

Green (+)

Right Rear

Violet/Black (-)

Violet (+)

Antenna

Connector

Steering Wheel Interface Input

PAC SWI-PS connection

(sold separately)

REAR/SUB

(selectable)

FRONT AUX INPUT

(rear)

RCA Preamp Output

Connections

FUSE

Whenreplacingthefuse,

makesurenewfuseisthe

correcttypeandamperage.

Usinganincorrectfusecould

damagetheradio.

TheXDMA7100usesone

10ampATMfuselocated

besidethewiringconnector.

Wiring Diagram

XDMA7100

Control Locations - Receiver

Control Function Description

1Release Opensandremovesthefrontpanel.

2Audio/Menu Accessestheaudiooptions.Holdtoaccessthesetupmenu.

3Select/Power Activatesmusicsearches.Confirmsmenuoptions.Holdtoturnthepoweroff.

4Track/TuneUp Changestothenextsongorradiostation.Holdtofastforwardorseekup.

5Mode Changestoanothermodeofoperation.Holddowntopoweroff/on.

6Mute Silencestheaudiooutput.

7EQ Cyclesthroughthepresetequalizercurves.

8Eject EjectstheCD.HoldtoforceejectastuckCD.

9USBPort ConnectaUSBflashdrive,iPodoriPhonedevice.

10 AuxiliaryInput Connecta3.5mmcablefromtheheadphoneoutputofanMP3player.

11 Loud TogglestheLoudsoundmodeonandoff.

12 Preset6/FolderUp Recall/Setpreset6.Changestothenextfolder.

13 Preset5/FolderDown Recall/Setpreset5.Changestothepreviousfolder.

14 Preset4/Play/Pause Recall/Setpreset4.Cyclebetweenpause/play.

15 Preset3/Intro Recall/Setpreset3.Intromenu(playsthefirst10secondsofeachsong).

16 Preset2/Random Recall/Setpreset2.Randommenu(shufflessongsinarandomplaybackorder).

17 Preset1/Repeat Recall/Setpreset1.Repeatmenu(repeatthecurrentsong,folderoralbum).

18 Track/TuneDown Changestotheprevioussongorradiostation.Holdtorewindorseekdown.

19 Display Cyclesdisplayedinformation.Holdtosettheclock.

20 Band/Esc Accessesmoreradiopresets,cyclesbetweenFM/AMradio.Exitsmenus.

2 4 5

6798

111215 14 13

20 1017 1619

XDMA7100

Control Locations - Remote

Preset6/FolderUp

Loud

Equalizer

Mute

Preset4/Play/Pause

Preset5/FolderDown

Preset1/Repeat

Band/Esc

Tune/TrackDown

Mode

Select/Power( )

VolumeUp

Audio/Menu

Tune/TrackUp

Volume Down

Display

Preset2/Random

Preset3/Intro

12 3 4

518

617

716

815

1112

1013

914

615

716

817

918

514

413

312

211

110

XDMA7100

Press oranyotherbutton(exceptEJECT)toturntheunit

on.Pressandhold for3secondstoturntheunitoff.

Press MODEtoselectbetweenAM/FM,CDplayer,auxiliary

front/rear,operationofiPod,USBandSDcard.Modesof

operationareshowninthedisplay.

NOTE:CD,USBandoperationofiPodmodeswillnotappear

unlessaCDisinsertedorUSB/iPoddevicesareconnected.

TheXDMA7100offerstwoauxiliaryinputports,a3.5mm

portonthefrontpanelandanRCAconnectionontheback

oftheunit.Useeitherconnectiontoconnectaudiodevice,

MP3player,etc.PressMODEtoselectAUXFRONTorAUX

REARmodes.

Thesteeringwheelinterfaceinputlocatedonthebackof

theheadunitallowsconnectiontothePacific Accessory

Corporation (PAC) SWI-PSinterfacemodule(sold

separately).Visitwww.pac-audio.comfordetails.

Toconfiguresteeringwheelcontrols,followtheinstructions

providedwiththePAC SWI-PSinterfacemodule.After

installingtheinterfacemodule,insertthemodule's3.5mm

jackintotheportonthebackoftheheadunit.

Adjustvolumeusingvolumeknob(00-46).

Press DISPtoselectbetweenclockanddifferenttypesof

information,suchasradiofrequency,CDtrack/elapsedtime

orMP3/WMAsonginformation.

Press RESETuponinitialinstallationorifabnormaloperation

occurs.Resetbuttonislocatedbehindthefrontpanel.

Withtheuniton,pressandholdDISPuntiltheclockbegins

toflash,thenrelease.PressTUNE

toadjustthehours

and TUNE

toadjusttheminutes.PressDISP momen-

tarilytosavetheselectedtime.

Theclockwilldisplay12-hourAM/PMtimeinUSAfrequency

spacingmode(PM10:00).InEuropeanfrequencyspacing

mode,theclockwilldisplay24-hourtime(22:00).

PressandholdAUDIO/MENUformorethan3secondsto

accessthesetupmenu.PressAUDIO/MENUmomentarily

toselectbetweenthemenufunctionsandrotatethevolume

knobleft/righttoadjustoractivatethedesiredfunction.

Power On/Off

Mode

Auxiliary Inputs

Steering Wheel

Interface Input

Volume

Display

Reset

Set the Clock

12/24-hour Clock

Setup Menu

General Operation

XDMA7100

General Operation - Setup Menu

Menu Function Options Action

Auto Station

Store AUTOSTORE Press SELECTtoseekandsave6strongstationsinthe

current band. (Tuner mode only)

Local/Distance

Tuning

LOCALOFF Activatesdistancetuning(Tuner mode only).

LOCALON Activateslocaltuningforstrongstationreceptiononly(Tuner

mode only).

Tuner

Frequency

Spacing

FREQUSA ProgramstheunittoUSAtunerspacing.

(200kHzforFMand10kHzforAM).(Tuner mode only)

FREQEUR ProgramstheunittoEuropeantunerspacing.

(50kHzforFMand9kHzforAM).(Tuner mode only)

Selectable iPod

Control

IPODFULL ProgramstheheadunittoadvancedcontroloftheiPod/

iPhonedevice.(Operation of iPod mode only)

IPODBASIC ProgramstheheadunittobasiccontroloftheiPod/iPhone

deviceandallowsmusictobecontrolledfromtheiPod/

iPhonedevice.(Operation of iPod mode only)

Clock

Display

CLOCKOFF Programsunittonotdisplaytheclockwhenthepowerisoff.

CLOCKON Programsunittodisplaytheclockwhenthepowerisoff.

Front Auxiliary

Input

AUXFRON Enablesthefrontpanel3.5mmauxiliaryinput.

AUXFROFF Disablesthefrontpanel3.5mmauxiliaryinput.

Rear Auxiliary

Input

AUXREON EnablestherearRCAauxiliaryinput.

AUXREOFF DisablestherearRCAauxiliaryinput.

Rear/Sub

RCA output

R/SSUB ProgramstheRear/SubRCApreampoutputtosubwoofer.

R/SREAR ProgramstheRear/SubRCApreampoutputtorear.

Beep

Confirmation

BEEPOFF Disablestheconfirmationbeep.

BEEPON Enablestheconfirmationbeep.

Programmable

Turn On Volume PRO-VOL# Programsunittoalwaysturnonataspecificvolume

(defaultisOFF).Anyvolumelevel1-46canbeselected.

Power on

Message

MSGOFF Disablespoweronmessage.(example:GOODMORNING)

MSGON Enablespoweronmessagetobedisplayed.

Scrolling

Option

SCROLL15S Programsunittoscrollinformationonceevery15seconds

(default).

SCROLLONCE Programsunittoscrollonce,thenshowthefirst10

charactersondisplay.

SCROLLON Programsunittoscrollcontinuously.

SCROLLOFF Programsunittoshowthefirst10charactersonthedisplay.

Illumination

Dimmer

DIMMERHI Programsunittothebrightestilluminationlevel.

DIMMER MED Programsunittothemiddleilluminationlevel.

DIMMER LOW Programsunittothedimmestilluminationlevel.

Demonstration

Mode

DEMOOFF Disablesthedemonstrationmode.

DEMOON Enablesthedemonstrationmessage.

XDMA7100

Press AUDIOmomentarilytoselectbetweenBass,Treble,

Balance,Fader,SubwooferandSourceVolumeLevel.

Press AUDIO until BASSappearsthenrotatevolumeknob

left/righttoadjust(-6minimum/+6maximum).

Press AUDIO until TREBLEappearsthenrotatevolume

knobleft/righttoadjust(-6minimum/+6maximum).

Press AUDIO until BALappearsthenrotatevolumeknob

left/righttoadjust(BALLEFT12-BALRIGHT12).

•BALEVENrepresentsequalbalance

Press AUDIO until FADERappearsthenrotatevolumeknob

left/righttoadjust(FADERFRONT12-FADERREAR12).

•FADEVENrepresentsequalfader

Press AUDIO until SUBappearsthenrotatevolumeknob

left/righttoadjust(0minimum/+12maximum).

*Note: SubwooferoptionwillnotappeariftheREAR/SUB

optioninthesetupmenuissettoREAR.Refertopage7for

details.

Press EQtocyclethroughthefollowingequalizationcurves:

FLAT(default),POP,JAZZ,CLASSIC,BEAT,ROCKandUSER.

AnymanualadjustmenttotheBassorTreblesettingsare

automaticallysavedasUSER.

Thesourcevolumelevelcontrolallowsagainadjustment

foreachaudiosource:AM,FM,CD,AUXFRONT/REAR,

operationofiPod,USBandSDcard.Setthesourcevolume

levelforeachmode,dependingontherelativevolumeof

eachaudiosource.

Tosetthesourcevolumelevel,pressAUDIOuntilSRC

LEVELappears.Afteronesecond,thecurrentmodewill

appearonthedisplay.Turnthevolumeknobtoadjust

theaudiolevelofthecurrentsource(-6minimum/+6

maximum).

Note: Onlythecurrentmodewillbeavailableforadjustment.

Toadjustanothermodeofoperation,pressMODEuntilthe

desiredmodeisselected,thensetthesourcevolumelevel

forthatmode.

Audio

Bass

Treble

Balance

Fader

*Subwoofer

Source Volume Level

General Operation

BASS TREBLE BALANCE FADER SUBWOOFER* SOURCE LEVEL

XDMA7100

Seek Tuning

Manual Tuning

Band

Storing and Recalling

Station Presets

Press TUNE

or TUNE

formorethanonesecond

toseektothenextstrongstation.

Press TUNE

or TUNE

momentarilytochange

radiofrequencyupordownonestepatatime.Pressand

holdtoadvancequickly.

Press BANDtoselectbetweenFM1,FM2,FM3,AM1and

AM2bands.

Upto18FMstationsand12AMstationscanbestored.To

storeastation,selectthedesiredbandandstation.Press

andholdthedesiredpresetbutton(1-6)formorethan

2seconds.Whenstored,thepresetnumberwillappearin

thedisplay.Thestationcanberecalledanytimebypressing

thecorrespondingpresetbutton.

AM/FM Tuner Operation

XDMA7100

Insert CD

Eject CD

Track Select

Fast Forward and

Reverse

Pause

Intro

Repeat

Random

CD-R/CD-RW

Compatibility

Withthelabelfacingup,insertastandardsizeCDintothe

CDslot.TheCDwillautomaticallybeginplayback.

Press EJECTtoejecttheCD.Theunitwillchangeto

previousmodeofoperation.Ifthediscisnotremovedwithin

10seconds,theunitwillreloadthedisc.Theunitdoesnot

havetobeturnedontoejectCD.

Press TRACK

toskiptothebeginningofthenext

track.PressTRACK

toreturntothebeginningofthe

currenttrack.PressingTRACK

againskipstothe

beginningoftheprevioustrack.

PressandholdTRACK

or TRACK

to fast

forwardorreverseatrack.

Press

totemporarilystopCDplayback.

Press

againtoresumeplayback.

Press INT toentertheIntromenu,thenturnthevolume

knobtoselectoneofthefollowingoptions:

•OFF-CancelstheINT function.

•ALL-Playsthefirst10secondsofeachtrack.

Press RPT toentertheRepeatmenu,thenturnthevolume

knobtoselectoneofthefollowingoptions:

•OFF-PlaysalltracksonCD.

•TRACK-Continuouslyrepeatsselectedtrack.

Press RDM toentertheRandommenu,thenturnthe

volumeknobtoselectoneofthefollowingoptions:

•OFF-CancelstheRDM function.

•ALL-Playsalltracksinrandomorder.

SomeCD-RsandCD-RWsmaybeincompatiblewiththis

unit,dependingonmediatypeandrecordingmethod.In

addition,thefollowingCDsmaybeincompatiblewiththis

unit:

CDsexposedtoextremetemperaturesordirectsunlightfor

extendedperiodsoftime,CDsrecordedinwhicharecording

sessionfailedorare-recordingwasattemptedand,or

encryptedorcopy-protectedCDswhichdonotconformto

theaudioCD-DAredbookrecordingstandard.

CD Player Operation

Tabla de contenidos

Otros manuales de Receptor de coche de Dual

Dual

Dual XDM6400 Instrucciones de funcionamiento

Dual

Dual DMCPA70BT Instrucciones de funcionamiento

Dual

Dual DCPA701 Instrucciones de funcionamiento

Dual

Dual DSA1007 Instrucciones de funcionamiento

Dual

Dual XML8100 Instrucciones de funcionamiento

Dual

Dual iPlug XDM6220 Instrucciones de funcionamiento

Dual

Dual XDVD110BT Instrucciones de funcionamiento

Dual

Dual XD7500 Instrucciones de funcionamiento

Dual

Dual XDMA6438 Instrucciones de funcionamiento

Dual

Dual XDVD1175BT Manual de usuario

Dual

Dual MXD135BT Instrucciones de funcionamiento

Dual

Dual DXRM59BT Instrucciones de funcionamiento

Dual

Dual MXD426BT Instrucciones de funcionamiento

Dual

Dual DV1014BH Instrucciones de funcionamiento

Dual

Dual XDCP97BT Instrucciones de funcionamiento

Dual

Dual XHD6425 Instrucciones de funcionamiento

Dual

Dual XD28BT Instrucciones de funcionamiento

Dual

Dual XD5125 Instrucciones de funcionamiento

Dual

Dual DXDM280BT Instrucciones de funcionamiento

Dual

Dual DM90MIR Instrucciones de funcionamiento

Dual

Dual XML8150 Instrucciones de funcionamiento

Dual

Dual AXXERA XDMA7600 Instrucciones de funcionamiento

Dual

Dual XDM265 Instrucciones de funcionamiento

Dual

Dual ZDM6800 Instrucciones de funcionamiento

Manuales populares de Receptor de coche de otras marcas

Motorola

Motorola VWA63 Manual de usuario

Nextar

Nextar D3201 Manual de usuario

Alpine

Alpine CDE-163BT Manual de usuario

Pioneer

Pioneer DEH-P645R Manual de usuario

Axxera

Axxera XDMA7600 Instrucciones de funcionamiento

XM OnyX Manual de usuario

Sound Storm

Sound Storm STM93R Manual de usuario

Soundstream

Soundstream VIR-5000 Manual de usuario

Avson

Avson MKT Platform Manual de usuario

Sony

Sony MEX-1HD - Audio Library System Manual de usuario

Pioneer

Pioneer DVH-P500UB Manual de usuario

JVC

JVC KD-AHD69 Manual de usuario

Blaupunkt

Blaupunkt SANTIAGO CR 87 Manual de usuario

Sony

Sony CDX-4160 - Cd Receiver Manual de usuario

XFIRE AUDIO

XFIRE AUDIO BMW42S Manual de usuario

VDO

VDO CD 2253 Manual de usuario

Volvo

Volvo 13 84 580 Manual de usuario

ZENEC

ZENEC ZE-160DVD Manual de usuario
