IPStar
Operation Manual
Talk over Internet for Free
DSG Technology, Inc.
http://www.dsgtechnology.com
Chapter 1. Understanding the IPStar
A Brief Overview
No Computer Needed
User-friendly Interface
Main Features
IPStar-to-IPStar Mode
IPStar-to-Phone Mode
Direct-Link Mode
Direct-IP Mode
Free Online Upgrade
Chapter 2. Installing the IPStar
Package Contents
Installing the IPStar
Basic Requirements to Use IPStar
Chapter 3. IPStar Configuration Mode
Entering Configuration Mode
Structure of Configuration Mode
Using Phone Keypad to Configure IPStar
Browsing the Menu
Selecting Between Fixed Values
Editing the Data of an Option
Using Buttons to Configure IPStar
Browsing the Menu
Selecting Between Fixed Values
Editing the Data of an Option
Basic Setup (IPStar-to-IPStar / Direct-Link Mode)
ITSP Setup (IPStar-to-Phone Mode)
Internet Setup
System Setup
TABLE OF CONTENTS
Table of Contents
Chapter 4. Making Internet Calls
Making an IPStar-to-IPStar Call
Making an IPStar-to-Phone Call
Using Direct-Link Mode
Using Direct-IP Mode
Monitoring the Status of IPStar
To End an Internet Call
To Speed-Up the Internet Disconnection
Quick Internet Disconnection
To Receive an IPStar Call
UsingYour Phone Keypad to Trigger IPStar
Chapter 5. Upgrading the IPStar
Upgrade Notification
Restoring Original Version
Chapter 6. How to Get an ITSP Account
(IPStar-to-Phone)
Checking the ITSP Account Balance
Appendix A. Technical Specifications
Appendix B. Troubleshooting
Table of Contents
In the past, real-time voice information is sent over the Public Switched Telephone
Network (PSTN). With the Circuit-Switched Technology, every call takes up a dedicated
bandwidth. End-to-end calls are established on the basis of a sequence of dialed digits,
and the PSTN dedicates a physical path between callers. Although the telephone
equipment establishes the call path at the beginning of the call, the path may change
between calls, but not during any specific call.
A Brief Overview
Understanding the IPStar
Congratulations on the selection of IPStar. Besides being relatively inexpensive
to install and easy to configure, IPStar is the first Internet Telephony appliance that
provides both IPStar-to-IPStar and IPStar-to-Phone capabilities via Internet!
CHAPTER 1
IPStar is a revolution of Voice over Internet Protocol (VoIP) product that offers full
duplex, high quality and low latency voice conversation through the Internet. Choosing
IPStar is an important addition to the home or office for its International and Long-
Distance cost-saving benefits.
Understanding the IPStar 1-1
No Computer Needed
1-2 IPStar Operation Manual
In comparison with a PSTN, an Internet Protocol (IP) Network has a Packet-Switched
architecture. Devices transmit data in packets, and the path from end to end can vary
within an established session. In addition to data, packets also contain addressing
information, which routing devices use to send information to its destination. Routing
devices maintain tables which instruct them how to direct packets. As networking
environments change, routing devices are updated with dynamic protocols.
Traditionally, the PSTN was the only network supporting voice communication. With an
IPStar, voice traffic can be sent over IP-based Packet-Switched networks!
IPStar possesses its own processor and network interface; it works intelligently. Simply
enter the Internet account into the IPStar with the phone keypad and press the
button on the IPStar, then users are ready to talk as long as they wish via Internet. All of
the communication costs will be eliminated except a local Internet connection charge.
No Computer Needed
With a back-lit LCD display and five buttons, IPStar is extremely easy to use and to
configure. The smart setup program allows the IPStar ready-to-go in three minutes. All
the system status can be clearly monitored through the LCD panel.
User - Friendly Interface
•
Backward Button
•
Downward Button
•
Flash Button (Start/Stop/Setting)
•
Upward Button
•
Forward Button
Main Features
Understanding the IPStar 1-3
IPStar is a unique and efficient electronic device being made. In addition to IPStar-to-
IPStar and Direct Link modes, the unparalleled IPStar-to-Phone and Direct-IP modes
greatly enhance the capability of voice communication by using Internet. IPStar users can
save significantly on Long-Distance and International call charges with these features.
Main Features
If the receiving party is equipped with an IPStar, just dial the phone number as usual and
talk to the remote IPStar owner instantly. When the call is answered, simply press the
on the IPStar and the call will be automatically switched from a regular phone call
to an Internet call.
IPStar-to-IPStar Mode
Every IPStar has the ability to communicate with other Internet Telephony products, such
as DSG IP1000 and DSG IP2000 Gateways*. With an active Internet Telephony Service
Provider* (ITSP) account, users can call all the covered areas with extra-low service rates.
IPStar-to-Phone Mode
Every IPStar comes with a unique six-digit ID number. In Direct-Link mode, simply dial
the ID with a leading key and you will be connected to other on-line IPStar users
immediately. The users will save the cost of an initial Long-Distance call with this
feature.
Direct-Link Mode
IPStar has the ability to communicate with other compatible Internet Telephony products,
such as InterStar, IPStar, or any DSG IP1000 and DSG IP2000 Gateways*. By setting the
IPAddress of receiving gateway, IPStar may route the call to an extension or PSTN via
these compatible gateways.
Direct-IP Mode
Note: To use IPStar-to-Phone mode, callers must apply an active ITSP account number
from DSG compatible ITSPs. Please check www.dsgtechnology.com and refer to
Chapter 6 How to Get an ITSPAccount for further information.
Note: An Internet Telephony Gateway is a gate between Internet and PSTN (Public
Switched Telephone Network). The Internet Telephony Gateway enables callers using
Internet to talk to regular phone users without IPStar.
Main Features
1-4 IPStar Operation Manual
The design of IPStar is extremely flexible. More and more new options and functions will
be added into the IPStar via the online upgrade function. Users are guaranteed to enjoy
the latest added features for instant convenience and hassle-free selections at no cost.
Free Online Upgrade
Note: IP1000 and IP2000 are part of the DSG’s selection of Internet Telephony products.
IP1000 is a stand-alone Internet telephony gateway and IP2000 is an NT-based Internet
Telephony gateway. Please check www.dsgtechnology.com for further information.
Free Online Upgrade
Understanding the IPStar 1-5
User-Friendly Interface
1-6 IPStar Operation Manual
Installing the IPStar
Connecting IPStar is as simple as connecting an answering machine.
CHAPTER 2
In the IPStar package, users will find:
• An IPStar
• An operation manual
• Aquick start guide
• Awarranty card
• An 12V/1ADC power adapter
• An RJ-11 phone cord
Package Contents
Installing the IPStar 2-1
