DSE MV Series Manual de usuario
MV SERIES – MDVR for vehicles
How to connect via web with CMSV6
How to install the system
How to configure the functions
MV Series - MDVR for vehicles
Installation manual
INSTALLATION MANUAL
Page 1
AHD video recorders
DSE SRL – ITALY – WWW.DSE.EU
MV SERIES – MDVR for vehicles
Contents of the manual
INSTALLATION MANUAL
Page:2
possibility.
This manual explains how to install cameras and video recorders, how to perform the
MV video recorders are vehicle DVRs suitable for CVBS and AHD analog cameras up to 2MP
DSE SRL – ITALY – WWW.DSE.EU
basic settings and how to connect from computer via WEB for models that include this
(1080P). They are ideal in combination with our vehicle cameras.
Machine Translated by Google
MV SERIES – MDVR for vehicles
Box contents
INSTALLATION MANUAL
Page:3
1 – MDVR VCR
DSE SRL – ITALY – WWW.DSE.EU
3 – 4 ADAPTER CABLES FOR CAMERAS (Minidin – BNC/DC)
5 – 1 RJ45 NETWORK ADAPTER CABLE (only for models with this function)
4 – 1 CVBS MONITOR ADAPTER CABLE (Minidin – BNC/DC)
2 – 3G ANTENNA, WiFi ANTENNA, GPS
The MDVR you purchased is a vehicle video recorder.
6 – POWER CABLES AND ACCESSORIES
functions)
The package includes:
7 – REMOTE CONTROL
(only in models with these
Machine Translated by Google
MV SERIES – MDVR for vehicles
Hard disk installation
SD card installation
INSTALLATION MANUAL
Page:4
the appropriate key.
The DVRs with hard disk allow you to install a 2.5 "hard disk inside
All DVRs in this range are designed to be able to record to SD card. To access the slot
MDVRs accept SD cards, or microSD cards with adapter, up to 256GB capacity.
Once the hard disk has been inserted, it is important to close the lock on the removable tray with
DSE SRL – ITALY – WWW.DSE.EU
SD card you must first unlock the protective cover with the included lock key.
Machine Translated by Google
MV SERIES – MDVR for vehicles
REC led for memory check
INSTALLATION MANUAL
Page:5
DSE SRL – ITALY – WWW.DSE.EU
ON – Disc or SD card is present but the MDVR is not recording. This can
FLASHING - The disc or SD card is present and the MDVR is recording
OFF – The disc or SD card is missing or not recognized
memory is full and overwriting is disabled.
it is also used to understand the memory status (SDcard or HDD). The LED can assume 3 states:
happen if the settings do not allow for registration at that moment or if the
All On the front of the MDVR there is a Led called REC which indicates the status of the recording e
Machine Translated by Google
MV SERIES – MDVR for vehicles
Power connection
INSTALLATION MANUAL
Page:6
half, according to the following scheme
For the DVR to start up, it is necessary to apply the positive simultaneously to the red (IN+) and
time programming you can use the following scheme
If, on the other hand, you want the DVR to always be active or to turn on based on its
connecting the red cable to the battery positive and the yellow cable to the ACC output of the control unit
battery power.
As a rule, you connect the DVR so that it switches on and off automatically when switched on
half. The power cable to be connected to the vehicle's electrical panel is included to receive
DSE SRL – ITALY – WWW.DSE.EU
yellow (ACC) and the negative to the black wire (GND).
All DVRs in this range accept power from 8 to 36VDC to suit any
Machine Translated by Google
MV SERIES – MDVR for vehicles
DSE SRL – ITALY – WWW.DSE.EU
the MDVR does not turn on check that the power supply is between 8 and 36V and that the power supply
The power cable is equipped with a protection fuse.
If nothing appears on the monitor check that you have connected it correctly to the VOUT output.
to the power applied to the power cables as described in the previous chapter. Self
Disk and that the fuse located in the power cable is intact.
The MDVRs do not have a power button, but will automatically turn on based on
is capable of delivering at least 50W. Also check that you have locked the hard door key
INSTALLATION MANUAL
Page:7
Power up MDVR
Machine Translated by Google
MV SERIES – MDVR for vehicles
Adapter cables
INSTALLATION MANUAL
Page:8
adapters, you can buy 4-pin female mini-din connectors and solder the cables directly
BNC (Video) and RCA (Audio). You will use these cables to connect the cameras and monitor.
DSE SRL – ITALY – WWW.DSE.EU
to the connector following the following pin-out
If you want to reduce the overall dimensions, it is to maximize the resistance to vibrations, instead of using cables
are supplied with a set of adapter connection cables with DC terminals (12VDC power supply),
and relay outputs.
fixing which makes them protected against vibrations. To connect cameras, monitors, etc. to MDVRs
Adapter cables are also included for network connection (where provided) and inputs
The MDVRs use aviation type MiniDIN connectors because they are compact and have a locking ring
Machine Translated by Google
MV SERIES – MDVR for vehicles
DSE SRL – ITALY – WWW.DSE.EU
INSTALLATION MANUAL
Page:9
Machine Translated by Google
MV SERIES – MDVR for vehicles
LEDs and connections - MV-41
INSTALLATION MANUAL
Page:10
SD – SD card status
model does not support AHD1080P.
NET - Not used
DSE SRL – ITALY – WWW.DSE.EU
GPS – GPS status LED
included which provides a DC connector to power the camera at 12VDC, a video BNC and a
RCA for any audio. The MDVRs support analog CVBS, AHD720P cameras. This
VLS – Lost video
PWR – Power LED
of the electrical panel
ERR – System error led
A/V IN1 A/V IN2 – Inputs for video/audio cameras. Connect the cameras here with the cable
IR – Remote control receiver
DC 8-36V – Connect red to battery positive, black to battery negative, and yellow to ACC line
USB – Backup port
