DSC ALEXOR Manual de instrucciones

DSC Alexor Page 1 of 7

DSC Alexor

Quick User Guide

DSC Alexor Page 2 of 7

Arming & Disarming the System

Arming (Turning on)

Close all sensors (i.e. close doors and windows). The Ready indicator should be on. Arm

the system using either of the methods below.

Arming Method #1: Enter your access code. If exit door is opened and closed, system will

arm in AWAY mode. If exit doors is not opened and closed, system will arm in STAY mode.

Arming Method #2: Press STAY button or AWAY button until keypad beeps and arming

process begins.

If armed in the AWAY mode, you now have 30 seconds to leave the premises. To cancel the

arming sequence, enter your access code.

Note: If motion detectors have not been installed on the alarm system, there is no difference

in arming in STAY or AWAY mode.

Disarming (Turning off)

Enter your access code to disarm anytime the system is armed. The keypad will beep if you

walk through the entry door. Enter your code within 45 seconds to avoid an alarm condition.

Quick Exit

If the system is armed and you need to exit, use the Quick Exit function to avoid disarming

and rearming the system.

1. Press and hold the EXIT button for 2 seconds. You now have 2 minutes to leave the

premises. When the door is closed again, the remaining exit time is cancelled.

Before Calling…

♦Is the keypad beeping? Press *2. This will silence the beeping and let you

know where the trouble is.

♦Is there a flashing triangle on the keypad? Press *2 for status information.

♦Is siren going off? ENTER CODE to stop siren.

DSC Alexor Page 3 of 7

Bypassing Zones

Use the zone bypassing feature when you want to arm the system, but skip a zone that you

want to leave open or requires service. Bypassed zones will not be able to sound an alarm.

Zones cannot be bypassed once the system is armed. Bypassed zones are automatically

cancelled each time the system is disarmed and must be bypassed again, if required, before

the next arming.

Bypassing Zones

1. Press *1.

2. Scroll to the desired zone number using the < > keys, then press *to select the

zone, or directly enter the 2-digit number of the zone you wish to bypass.

3. Press # to exit bypass mode and return to Ready state.

4. Continue with arming the system.

Recalling Bypassed Zones

To recall the last set of bypassed zones:

1. Press *1.

2. Press 9 9.

3. Press # to exit bypass mode and return to Ready state.

4. Continue with arming the system.

Alarm Memory

When an alarm occurs, the Memory indicator (and Fire indicator, if applicable) will turn on.

To view which sensor(s) generated the alarm, press *3. Use the scroll < > buttons to view

the sensors in memory. Press # to exit.

To clear the memory, arm and disarm the system.

Access Codes

Master Access Code

The master code is the only code that can add and delete other user codes and perform

other various functions (such as entering date and time) on the alarm system. The master

code can be changed, but cannot be deleted.

To change the Master Access Code:

1. Press *5, then the current Master Code.

2. Press 40.

3. Enter the new 4-digit Master Code.

4. Press # to exit.

User Access Codes

The system will allow up to 16 individual user codes. As codes are added and deleted, keep

a list in a safe location for reference. An accurate list will help track codes as future changes

are made.

To Add or Change a User Access Code:

1. Press *5, then enter Master Code.

2. Use the scroll < > buttons to find the specific code.

3. Press * to select.

DSC Alexor Page 4 of 7

4. Enter 4-digit user code

5. Press # to exit.

To Delete a User Access Code:

1. Press *5, then enter Master Code.

2. Use the scroll < > buttons to find the specific code.

3. Press *.

4. Press *.

5. Press # to exit.

Note: The keypad will display the user number with a letter “P” if a user code has already

been programmed.

Chime Mode

Your system can alert you to the opening of a door while it is disarmed by using the CHIME

feature. When activated, three beeps will sound at the keypad whenever a door is opened.

Press CHIME button for 2 seconds, or *4 to enable or disable the chime feature. The

CHIME icon will appear in display. The system will sound 3 beeps when feature is turned

on, or one long tone to indicate the door chime is off.

Time & Date Programming

1. Press *6, then enter your Master Access Code.

2. Press 1.

3. Enter the time in 24-hour format, using military time (HH:MM).

4. Enter the date (MM:DD:YY).

5. Press # to exit programming.

Keypad Adjustments

Brightness and Contrast

The keypad has 4 different brightness/contrast levels.

1. Press *6, then enter your Master Access Code.

2. Use the < > buttons to scroll to either Brightness Control or Contrast Control.

3. Press *to select the setting you want to adjust.

4. a) Brightness Control: There are 4 backlighting levels. Use the < > buttons to scroll to

the desired level.

b) Contrast Control: There are 10 different display contrast levels. Use the < >

buttons to scroll to the desired contrast level.

5. The level is automatically saved when you press # to exit.

Buzzer Level

The buzzer provides an audible confirmation of a pressed button or that a command to the

panel has been executed. The keypad has 21 different buzzer levels. A level of 00 disables

the buzzer.

1. Press *6, then enter your Master Access Code.

2. Use the < > buttons to scroll to Buzzer Control, then press * to select.

3. Use the < > buttons to scroll to the desired level. The level is automatically saved

when you press # to exit.

DSC Alexor Page 5 of 7

Trouble Conditions

When a trouble condition is detected, the System Trouble indicator will turn on and the

keypad will beep every 10 seconds. Press # to silence the beeps. Press *2 to view the

trouble condition. The Trouble indicator will flash. Use the scroll < > buttons to view troubles.

Trouble Comments Action

Alternate Communicator

Trouble

Indicates SIM Card Lock, GSM Trouble,

Ethernet Trouble, Central Station Receiver

Trouble, Supervision Trouble and SMS Config.

Trouble. Press < > to scroll through individual

troubles.

Call for Service.

Service Required (Press 1

for more information) Indicates Low Battery, System Trouble,

System Tamper or RF Jam detected.

Call if service is required.

Loss of AC Power If the building and/or neighborhood has lost

electrical power, the system will continue to

operate on battery power for several hours.

Check AC Connection. Call if

service is required.

Telephone Line Fault

The system has detected that the telephone

line is disconnected.

If no dial tone on phone, call

phone company.

If dial tone on phone, call

Keyhole for service.

Failure to Communicate

The system attempted to communicate with

the monitoring station, but failed. This may be

due to a Telephone Line Fault.

Send signal to Monitoring

Company. Call to put account

out of service prior to sending

signal.

Module/Sensor Fault

The system is experiencing difficulties with

one or more module/sensor on the system.

Continue to press 5 to navigate through the

Zone, Keypad and Siren fault menus.

May clear on its own in 24-

hour period. If not, replace

battery. If problem persists,

call for service.

Module/Sensor Low Battery

The system has detected a low battery

condition with one or more module/sensor on

the system. Continue to press 7 to display to

zone(s), wireless key(s), key-pad(s), siren(s)

and prox tag(s).

Replace battery.

Loss of Time & Date If complete power was lost (AC and Battery),

the time and date will need to be programmed.

Press *.

Reprogram Time & Date. (See

page 4)

Blank Display/No Response

Keypad battery may have discharged beyond

the usable level.

Replace battery.

“Panel Response Not

Received” message

The keypad has not lost wireless

communication with the panel. Occasional

display of this message may be caused by

local radio frequency interference.

If trouble persists, call for

service.

Orange Trouble LED on the

control panel

The PC9155 has detected that an RF Jam

condition has been present for at least 20

seconds.

If trouble persists, call for

service.

DSC Alexor Page 6 of 7

Testing Your System

NOTE: Inform your Monitoring Station when you begin and end system testing.

Alarm Central Station: 1-800-452-3555.

Siren and Keypad Display Test

This test activates all display pixels and indicator lights on the keypad and does a 4-second

check of the siren.

1. Press *6, then enter your Master Code.

2. Press 4.

The following will occur:

-The system activates the siren output on medium volume for 2 seconds followed by

full volume alarm for 2 seconds. All display lights and LCD pixels will turn on.

- The Ready, Armed, Trouble and Power LED’s will flash for the duration of the test.

4. To exit the function menu, press #.

Keypad Low Battery

The flashing trouble icon on a keypad will indicate that keypad has a low battery.

WT4901 Siren Battery Test (If installed on system)

To determine which siren has a low battery, press and hold the test button located at the

front of the siren, for 5 seconds.

- If the siren sounds for 4 seconds, the batteries are good.

- If the siren doesn’t sound, the batteries are low.

Walk Test

Walk Test mode allows you to test the operation of each detector in the system. While in

Walk Test mode, the Ready, Armed, and Trouble LED’s will flash to indicate that the Walk

Test is active. The Walk Test can be terminated at anytime by re-entering * 6 + Master Code

+ 8 on the keypad. The system will also automatically terminate the Walk Test on

completion; it will sound an audible warning (5 beeps every 10 seconds), beginning 5

minutes before the termination of the test.

1. Before testing, ensure that the system is disarmed and the Ready light is on.

2. Press # and close all zones to return the system to the Ready state.

3. Press *6, then enter your Master Code.

4. Press 8.

5. To test the zones, activate each detector in turn (e.g., open each door/window or

walk in motion detector areas).

The system will display the following message when each zone (detector) is activated:

“Secure System Before Arming < >”, or “Secure or Arm System”. Use the < > buttons to

view which zones are open. The message will disappear when the zones are closed.

DSC Alexor Page 7 of 7

Keypad Quick Guide

Status Display Icons

(S = Steady, F = Flashing)
