DS18 CANDY-MICRO2 Manual de usuario

Dear Valued Customer:

Thank you for purchasing the DS18 CANDY-MICRO2.

This Hi-Fi power amplier will satisfy any demands regarding

sound reproduction in your car. With its impressive deep-

bass power reserves, low harmonic content, and neutral

reproduction, it takes car Hi-Fi to new heights. The amplier

includes features such as, low operating current, rapid

switching capabilities, and excellent temperature stability.

Experience and enjoy how this high tech machine perfectly

reproduces magnicent sound!

MICRO

BEFORE THE CONNECTION

For professional installation of a sound system , appropriate wiring

kits are available in car audio retail stores. Attend the sufcient prole

section (at least 25 mm2), the suitable fuse rating and the conductivity

of the cables when you purchase your wiring kit. Clean and remove rust-

streaked and oxidized areas on the contact points of the battery and

the ground connection. Make sure that all screws are screwed on tight

after the installation because loose connections may cause malfunctions,

insufcient power supply and interferences.

MICRO

INSTALLATION INSTRUCTIONS

ELECTRICAL INTERCONNECTION

CANDY-MICRO2

micro

POWER

STEREO

INPUT LEVEL

BRIDGED

MONO

MODE

AUX

INPUT

BRIDGED

MONO

HIGH

INPUT

HIGH

OUTPUT

REM + 12V

GND GND

+ R -

+ L -

+ R -

+ L -

AUX HIGH

GAIN

MIN MAX

2 3

micro

CANDY-MICRO2

MICRO

GND

Connect this GROUND terminal with a suitable contact

ground point on the vehicle’s chassis. The ground wire

must be as short as possible and must be connected to a

blank metallic point at the vehicle’s chassis. Ensure that this

ground point has a stable and safe electric connection to the

negative “-”pole of the battery. Check this ground wire from

the battery to the ground point if possible and enforce it, if

required. Use a ground wire with a sufcient cross section

and the same size like the plus (+12V) power supply wire.

REM

Connect the turn-on signal (e.g. automatic antenna) or the

turn-on remote signal of your headunit with the REM-terminal

of the amplier. Use a suitable cable with a sufcient cross

section (0.5 mm2). Thereby the amplier will turn on or off

automatically with your headunit.

BATT+12V

Connect the BATT +12V-terminal with the +12V pole of

the vehicle’s battery. Use a suitable cable with a sufcient

cross section and install a additional in-line fuse. For safety

reasons the distance between the fuseblock and the battery

must be shorter than 30 cm. Do not install the fuse into the

fuseblock until the installation is completed.

The GAIN (LEVEL INPUT) controller adjusts the input

sensitivity of the amplier to align the audio signal from the

head unit. The input sensitivity is adjustable from 0.28 to

6.1 Volts.

MICRO

CANDY-MICRO2

micro

POWER

STEREO

MODE

INPUT LEVEL

BRIDGED

MONO

AUX

INPUT

BRIDGED

MONO

HIGH

INPUT

HIGH

OUTPUT

REM + 12V

GND GND

+ R -

+ L -

+ R -

+ L -

AUX HIGH

1 2 3 4 5

FUNCTIONS AND OPERATIONAL CONTROLS

POWER: If the POWER LED lights up, the amplier is ready

for operation.

The STEREO and MONO BRIDGED switch selects the

required operation mode of the amplier on the STEREO or

MONO BRIDGED.

AUX INPUT: comes with an auxiliary stereo signal input to

connect an external source, mp3 player, audio sources. Input

sensitivity is adjustable from 0.28 to 6.1 V RMS.

INPUT LEVEL: The INPUT LEVEL switch selects the required

operation mode of the amplier on the AUX or HIGH.

CONNECTION: The High Input is suitable to connect the

amplier inputs with speaker wires, if your headunit is not

equipped with pre amplier RCA outputs. Never use the

High Level Input and the RCA inputs at the same time.

MICRO

HIGH

INPUT

HIGH

OUTPUT

REM + 12V

1: Black GND

2: Black GND

3:Green Black OUTPUT L-

4:Green OUTPUT L+

5: White Black INPUT L-

6: White INPUT L+

7: Grey INPUT R+

8: Grey Black INPUT R-

9: Purple OUTPUT R+

10: Purple Black OUTPUT R-

11: Orange REM

12: Red +12V

GND GND

+ R -

+ L -

+ R -

+ L -

CORRECTOR WIRING DIAGRAM

MICRO

CANDY-MICRO2

micro

POWER

STEREO

INPUT LEVEL

BRIDGED

MONO

MODE

AUX

INPUT

BRIDGED

MONO

HIGH

INPUT

HIGH

OUTPUT

REM + 12V

GND GND

+ R -

+ L -

+ R -

+ L -

AUX HIGH

MODE AUX HIGH

INPUT LEVEL

STEREO

MP3 PLAYER

AUXILIARY STEREO

PREAMPLIFIER SOURCE

AUXILIARY STEREO

PREAMPLIFIER SOURCE

PRE OUT

RADIO OUT

BRIDGED

MONO

CANDY-MICRO2

micro

POWER

STEREO

INPUT LEVEL

BRIDGED

MONO

MODE

AUX

INPUT

BRIDGED

MONO

HIGH

INPUT

HIGH

OUTPUT

REM + 12V

GND GND

+ R -

+ L -

+ R -

+ L -

AUX HIGH

MODE AUX HIGH

INPUT LEVEL

STEREO BRIDGED

MONO

AUX INPUT

Auxiliary analog

stereo signal.

Sensitivity is

adjustable from 0.28

to 6.1 V RMS.

MICRO

CANDY-MICRO2

micro

POWER

STEREO

INPUT LEVEL

BRIDGED

MONO

MODE

AUX

INPUT

BRIDGED

MONO

HIGH

INPUT

HIGH

OUTPUT

REM + 12V

GND GND

+ R -

+ L -

+ R -

+ L -

AUX HIGH

MODE AUX HIGH

INPUT LEVEL

STEREO BRIDGED

MONO

CANDY-MICRO2

micro

POWER

STEREO

INPUT LEVEL

BRIDGED

MONO

MODE

AUX

INPUT

BRIDGED

MONO

HIGH

INPUT

HIGH

OUTPUT

REM + 12V

GND GND

+ R -

+ L -

+ R -

+ L -

AUX HIGH

MODE AUX HIGH

INPUT LEVEL

STEREO BRIDGED

MONO

Loudspeaker left

2-8 Ohms

Mono Bridged

4-16 Ohms

Loudspeaker right

2-8 Ohms

INTERCONNECTION EXAMPLE

• Connect the left or right speakers with the speaker outputs by using

appropriate wires.

• Ensure by any means, that the total impedance load of all speakers is

not lower than 2 ohms. Too low impedance causes high temperature and

will shut down the amplier operation.

• Always ensure the correct polarity of the speakers. The interchange of

plus and minus can cause a total loss of bass playback and could damage

the speakers.

INTERCONNECTION

MICRO

TECHNICAL DATA

Channels 2CH

Watts on 4 Ohms 2 x 65W

Watts on 2 Ohms 2 x 80W

Watts on 4 Ohms mono bridged 1 x 160W

Frequency Range-3dB 19Hz~39kHz

Signal To Noise Ratio >80dB

THD&Noise <0.1%

Input Sensitivity 0.28V - 6. 1V

Speaker Impedance 2-16 Ohm

Fuse Size External Recommended 20A

Dimensions (LxHxW) mm 84 x 39 x 124

CANDY-micro 2

3.5 x 1.5 x 4.9 Inches
