Dräger Alcotest 6820 Manual de usuario
Dräger Alcotest® 6820
Alcohol Screening Device
Dräger Alcotest® 6820 is the logical successor to the successful Alcotest®
6810. The compact hand-held measuring instrument Alcotest® is quickly ready
for use and is adaptable to international guidelines. With an even more sturdy
enclosure and the proven Dräger sensor, Alcotest® 6820 is a reliable partner
for breath alcohol analyses. FOR LAW ENFORCEMENT PURPOSES OR
USE IN DOT-REGULATED INDUSTRIES ONLY.
Benefits
02 | Dräger Alcotest® 6820
Dependable under harsh conditions
At Dräger, we understand that roadside breath alcohol testing occurs in a wide variety of environmental
conditions. The sleek design and quality workmanship enable the Alcotest 6820 to stand up to hard use and
varying environmental conditions from hot and dry, to cold and wet. Durable casing material and a sealed
battery compartment make the instrument highly resistant to cold or moisture; in addition, it was designed
specifically to keep out dust and water.
Easy to use, easy to read
Roadside testing can be a challenging and dangerous task requiring a high degree of concentration. This is
where the true value of an easy-to-operate device comes into play. All measurement functions are controlled
with a single button. The instrument guides you through the breath alcohol test with easily understandable full-
text messages on a large, backlit display. An LED indicator and acoustic signals support the visual display and
indicate when the test is complete. Two menu keys let you easily navigate the menu and access statistical data
and settings.
Practical design
The compact size of the Alcotest 6820 makes it easy to hold and operate with only one hand. The mouthpiece
snaps easily into the holder even when it’s dark thanks to its intuitive shape. Whether you are right- or left-
handed or whether you’re testing traffic moving on the right or left side of the road, the display is always in clear
view. After use, the mouthpiece can be removed easily and without contamination.
Ready for use within four seconds
An integrated electrochemical Dräger sensor provides very short response times, coupled with precision and
durability. Ready for use within four seconds, the Alcotest 6820 has even faster startup and response times
than its predecessor, the Alcotest 6810. Test results are reliable – whether the temperature is 23°F or 122°F.
Even with high alcohol content, the sensor provides fast, accurate results. And this is true in all measurement
modes, active and passive measurements.
Slide 'n' Click mouthpiece
The patented Dräger mouthpieces prevent any manipulation attempts. Plus, the optional return valve limits
contamination. The Alcotest 6820 uses the same reliable mouthpiece as the Alcotest models 5510 and 7510.
Improved data management capabilities
The Alcotest 6820 offers optimized software for device configuration and downloading data. You can also
transfer data from the device to a PC via a USB connection and use the same connection to configure the
device. State and customer specific configurations are available.
Benefits
Dräger Alcotest® 6820 | 03
Stores up to 5000 test results, prints onsite
With its expanded memory capacity, the Alcotest 6820 can store up to 5000 test results. Up to 250 tests are
readily available to be recalled and printed at any time. An optical interface enables wireless transmission of
data to the Dräger mobile printer onsite – no cable required.
Rechargeable batteries
A new feature of the Alcotest 6820 is the option to purchase two NiMH rechargeable batteries, rather
than disposable batteries that have to be periodically changed. For your convenience, the batteries can be
recharged without removing them from the device. If you prefer, the device can also run on disposable AA
batteries.
For Law Enforcement Purposes or Use in DOT Regulated Industries Only
Accessories
ST-8404-2006
Dräger Mobile Printer
The Dräger Mobile Printer prints breath alcohol and drug test
measurement results without using a dedicated power supply. The
Mobile Printer documents measurement results of the Dräger Alcotest®
6820, Dräger Alcotest® 7510, as well as some Alcotest® 7410 Plus
versions, and the Dräger DrugTest® 5000. FOR LAW ENFORCEMENT
USE OR USE IN DOT-REGULATED INDUSTRIES ONLY.
Accessories
04 | Dräger Alcotest® 6820
D-12910-2009
USB Cable
ST-178-2004
Mouthpieces (Slide 'n' Click)
Mouthpieces are supplied in packs of 100, 250 and 1,000, with and
without non-return valve.
D-9486-2014
NiMH Rechargeable Batteries
Alkaline batteries or set of rechargeable batteries for 6820
D-12913-2009
Charger
For power supply kit
Accessories
Dräger Alcotest® 6820 | 05
D-1112-2014
System Case
Services
D-19092-2016
Dräger Service
When you rely on Dräger breath alcohol and drug screening equipment,
you can rest assured you made the right choice. For more than 60
years, we’ve been the global market leader in advanced breath alcohol
testing and employ cutting-edge technology to provide devices that are
fast, reliable, and easy to use. That’s the Dräger Service Advantage.
Related Products
06 | Dräger Alcotest® 6820
D-58698-2012
Dräger Alcotest® 5510
The Dräger Alcotest® 5510 handheld screener provides the quality,
accuracy, and reliability that our customers have come to expect
from our breath alcohol detection products. With a wide range of
available configurations, the instrument is easily adaptable to meet user
requirements and local regulations for preliminary breath testing. The
intuitive interface allows the officer to quickly take the breath alcohol
sample, read the result, and proceed. FOR LAW ENFORCEMENT USE
ONLY
ST-15093-2008
Dräger Alcotest® 7510
The Alcotest® 7510 allows for breath alcohol analysis for any application,
and is listed on the National Highway Traffic Safety Administration's
Conforming Product List (NHTSA CPL) as an evidential breath tester.
This instrument has received the OIML Certificate of Conformity. FOR
LAW ENFORCEMENT USE ONLY.
Technical Data
Dräger Alcotest® 6820 | 07
Test method Electrochemical Dräger sensor for 1/4“ technology; alcohol-
specific
Test range 0 to 0.500% BAC; display indication when exceeding test range
Sampling Standard: automatic sampling when minimum volume is reached
Passive sampling or manual triggering of sampling possible
Ready for use Approx. 2 s after powering up
Test result display Approx. 3 s (with 0 mg/l), 10 s (at 0.5 mg/l, room temperature)
Operating temperature -5 to +50°C; +23 to +122°F
Display Graphic LCD display with background illumination;
1.61 in x 0.95 in (41 mm x 24 mm); 128 x 64 pixels
LED 3 colors to indicate messages or alerts
Acoustic alarms Different signal tones indicate various messages and alerts
Memory Space for saving the last 5,000 tests with test number, date and
time (ability to recall last 250 on device)
Power supply Two AA batteries or NiMH batteries, battery indicator on the
display.
Around 1,500 breath tests can be conducted with one set of
batteries.
Charging rechargeable NiMH batteries is possible in device
Calibration Wet gas or dry gas calibration
Dimensions (H × W × D), weight 5.79 in x 2.56 in x 1.53 in (147 mm x 65 mm x 39 mm);
approx. 0.57 lbs
Device configuration Device settings configurable directly via device menu
(PIN required). No additional PC software required
Vibration and impact Meets EN 60068-2-6, EN 60068-2-27, EN 60068-2-64,
MIL-STD 810F
CE marking Directive 89/336/EEC (electromagnetic compatibility)
Data interfaces USB to PC; optical interface for printer control
Standard Meets EN 15964
Protection type IP54; keeps out dirt and water
Ordering Information
Dräger Alcotest® 6820 (test unit, 3 mouthpieces, 2 batteries,
hand strap, plastic case)
83 22 660
Dräger Alcotest® 6820 Basic Law Enforcement Kit (includes
device, 100 mouthpieces, 12 batteries, Mobile Printer, 2 rolls of
paper, USB cable, software and system case)
44 14 141
Mobile Printer for Law Enforcement Applications 44 15 532
PSU (power source) 600 mA, 11 V, for charging NiMH batteries 83 16 991
Diagnostics Software 83 17 915
USB cable for downloading data 83 19 715
Notes
08 | Dräger Alcotest® 6820
Not all products, features, or services are for sale in all countries.
Mentioned Trademarks are only registered in certain countries and not necessarily in the country
in which this material is released. Go to www.draeger.com/trademarks to find the current status.
CORPORATE HEADQUARTERS
Drägerwerk AG & Co. KGaA
Moislinger Allee 53–55
23558 Lübeck, Germany
www.draeger.com
Customer Service:
USA
+1 800-4DRAGER
(+1 800-437-2437)
Technical Service:
USA
+1 800-4DRAGER
(+1 800-437-2437)
Locate your Regional
Sales Representative at:
www.draeger.com/contact
90 69 960 | 17.06-2 | HQ | PP | Subject to modifications | © 2017 Drägerwerk AG & Co. KGaA
