Dosatron D3WL Manual del operador

D3WL

Congratulations on your new Dosatron.

Please read the following important information.

QUICK START UP

D3WL

3m3/h 14 US GPM

IMPORTANT NOTES

For complete information on the features and operations,

refer to your Manual on www.dosatron.com

or download our DOSATRON app

NEED HELP ?

Contact your DOSATRON distributor for service or parts

This document does not form a contractual engagement on the part of Dosatron International

and is for information only. Dosatron International reserves the right to alter product

specification or appearance without prior notice.

DOSATRON INTERNATIONAL S.A.S. Certified QEH&S System

Rue Pascal - B.P. 6 - 33370 TRESSES (BORDEAUX) - FRANCE

Tel. 33 (0)5 57 97 11 11

Fax. 33 (0)5 57 97 11 29 / 33 (0)5 57 97 10 85

[email protected] - www.dosatron.com

CUSTOMER SERVICE - SERVICE CLIENTÈLE (WORLDWIDE - EUROPE)

MANUFACTURED BY - FABRIQUÉ PAR :

WATER LINE

- When connecting a DOSATRON either to the public water

supply or to its own water source, you must respect the

regulations in force concerning protection of the source i.e.

backflow prevention, etc.

- Contact local authorities for requirements of backflow

prevention.

- When installing, operating, and maintaining the DOSATRON

water powered metering pump, keep safety considerations

foremost. Use proper tools, protective clothings, and eye

protection when working on the equipment and install the

equipment with a view toward ensuring safe operation.

- Follow the instructions in the manual and take additional

safety measures appropriate to the liquid being pumped and

the temperature of the water that powers the DOSATRON. Be

extremely careful in the presence of hazardous substances (e.g.

corrosives, toxins, solvents, acids, caustic, flammables, etc.).

- Before applying any aggressive chemicals, please consult your

distributor to confirm compatibility with the dosing pump.

- Dosatron Water Line pumps which REF contains index «N»

are certified under NSF/ANSI Standard 61 & 372 (Drinking

Water Treatment Equipment). They are certified for use with

calcium hypochlorite (max concentration 65% ) and with sodium

hypochlorite (max concentration 15 %). The temperature of the

treated water should not exceed 23°C.

Hand tighten. No tools needed.

CAUTION

ET346/QSUCED3WL-05-18

CLICK CHART

Clicks l/h Clicks l/h

2 130 16 1020

4 260 32 2040

8 510 46 3000

DO NOT USE THIS UNIT WITHOUT A 60 MICRON

[300 MESH] WATER FILTER*

OR YOUR WARRANTY WILL BE VOID.

*The 60 micron [300 mesh] water lter (sold separately)

protects your unit from debris in the water that causes

scoring to the piston and housing.

KNOW YOUR WATER FLOW!

GRADUALLY TURN ON THE WATER.

COUNT THE NUMBER OF CLICKS IN 15 SECONDS.

DO NOT EXCEED 46 CLICKS.

MAXIMUM PRESSURE 6 bar [87 PSI]

RECOMMANDATIONS

Maximum: 46 clicks/15 sec.

%NO !

Max.Torque 20 Nm thus 2 kg (1 N.m = 0,1 DaN.m)

Valve Check

valve

Filter

Filter :

60 microns [300 mesh]

Depending on your

water quality

BY PASS Option

Air-Bleed

Button

Ø 4 Ø 8

When possible,

DO NOT PLACE

the container directly

under

the DOSATRON

INSTALLATION

HINTS

Scan the QR-

code on the

dosing pump.

SPECIAL

D3WL3000IE

8 9
