1 Notes on using the manual .................................................7
2 General safety instructions .................................................7
3 Intended use .........................................................7 - 8
4 Components ............................................................8
5 Specications ........................................................8 - 9
6 Installation ..........................................................9 - 10
7 Operation..............................................................11
8 Warranty and Product Liability .........................................11 - 12
1 Notes on using the manual
Note
Supplementary information for operating the device.
fig. 2 A, page 2 : This refers to an element in an illustration. In this example, item A in
gure 2 on page 2.
2
Caution!
Safety Instruction: Failure to observe this instruction can cause material damage and
impair the function of the device.
EN
Table of contents
Dometic Tank Monitor System Notes on using the manual
2 General safety instructions
The manufacturer will not be held liable for claims for damage resulting from the following:
• Faulty assembly or connection
• Damage to the unit from mechanical inuences, misuse or abuse
• Float switches fouled with tissue paper
• Alterations to the unit without express written permission from the manufacturer
• Use for purposes other than those described in this manual
3 Intended use
3.1 OPTION 1: DTM04 tank monitor system
DTM04 Tank Monitor System provides electronic monitoring of the liquid level inside a holding tank.
Three oat switches inside the tank activate a set of four lights on an indicator panel. The lights indicate
Empty, Low, Mid and Full levels. The Full level indicates when the liquid level is within 51 mm (2 in.) of
the top of the holding tank. The other oat switches are connected to adjustable probe stems which
can be positioned according to the tank height and the desired indicator panel readings.
3.2 OPTION 2: DTM04 tank monitor system with “full tank” shut-down relay
When the optional “Full Tank” Shut-down Relay (available separately) is connected to the DTM04 panel,
and the holding tank reaches the Full level, the relay shuts off power to the electric toilet. This prevents
use of the toilet and the possibility of overlling the holding tank. See Components for “Full Tank” Shut-
down Relay item numbers. The relay handles a maximum electrical current of 30 amps.
8
Dometic Tank Monitor SystemIntended use
System Voltage Amp
12 V DC without shut-down relay
with shut-down relay
0.008
0.145
24 V DC without shut-down relay
with shut-down relay
0.004
0.090
Specications subject to change without notice.
4 Components
Items in fig.
1 page 2 Description Item Number (Europe / North America)
1 DTM04 cover panel 860003853114778 / 385311477
2DTM04 circuit panel/
mounting frame 860003853114836 / 385311483
3 #6 fastener 860003853116120 / 385311612
4“Full Tank” shut-down relay
(available separately)
9107100013 / 385311579 – 12 V DC
9107100014 / 385311580 – 24 V DC
5 Compression nut kit 860003853102583 / 385310258
6 Float/stem kit 860003852302689 / 385230268
7Float/lock ring kit 860003853111030 / 385311103
8Flexible probe kit 860003852309304 / 385230930
9O-ring 860003853112509 / 385311250
10 Probe cap/O-ring 860003853116179 / 385311617
1
5 Specifications
5.1 Materials
3.3 Features
“Power on” indicator. One Tank Monitor panel light is always lit to assure system operation.
Long-lasting, foul-proof tank probes. Semi-exible probe stems move with tank contents to reduce
stress. Integral sensor delay prevents false readings.
Probe cap fits Dometic DHT-L series holding tanks. Also ts other tanks equipped with 76 mm (3 in.)
NPT opening in top of tank.
For holding tanks up to 56 cm (22 in.) deep. Flexible probes can be adjusted to t many tank sizes.
12 or 24 V DC operation.
5.2 Electrical Current Draw
Panel frame and mounting frame: ABS
Panel surface: Polycarbonate resin
Circuit breaker or fuse
required for DTM04 panel:
1 amp
Maximum shut-down relay
rating for 12 or 24 V DC
toilet system:
30 amps
Probe cap: PVC
Floats: Nitrile rubber ebonite
9
1. Select panel location away from direct contact with water
and oil.
2. Conrm clearance for wire connections behind wall, hull liner
or bulkhead.
3. Using control panel template (g. 8 , page 5), cut out
panel access hole (E, F) and drill fastener holes (G).
4. With electrical power off, route 18-gauge stranded copper
wire from power source, through circuit breaker or fuse (not
provided), to panel location. Route additional wire according
to diagram (g. 4 , page 3 – see wiring diagram key
below), depending on your application, to panel location.
Make sure wires extend out through access hole.
5. Make proper wiring connections to wires extending from
bottom of circuit panel (g. 3 A 2, page 3).
6. Remove panel cover (g. 3 A 1, page 3) from circuit panel/
mounting frame (A 2), if necessary, by carefully pulling them
apart.
7. Install mounting frame to wall with four fasteners (g. 3 A 3).
8. Push panel cover onto mounting frame until it locks into
place.
1. At step 4 (above), route and connect 14-gauge stranded copper wires according to wiring diagram
(g. 4 , page 3) and wiring diagram key (see below).
2. Insert “Full Tank” shut-down relay into receptacle on back of circuit panel.
6.1 Tank Monitor Panel (g. 3 A, page 2)
6.2 “Full Tank” Shut-down Relay (optional accessory) (g. 1 4, page 2)
DTM04 Panel Template
Dimensions (g. x , page 5)
3
1
Dometic Tank Monitor System Specifications
Caution!
Do not install DTM04 panel in an atmosphere with potentially flammable or
explosive vapors.
Ref. Dimension
A 83 mm / 3.25 in.
B 83 mm / 3.25 in.
C 67 mm / 2.63 in,
D 67 mm / 2.63 in.
E 55 mm / 2.16 in.
F 68 mm / 2.69 in.
G 2 mm / 0.10 in. dia.
HCut-out area.
Allow 51 mm / 2 in.
clearance behind wall.
6
6
4
4
4
3
3
3
5.3 Dimensions (g. 2 , page 2)
5.4 Approvals
ISO 8846; EMC Directive 2004/108/EC
Ref. Dimension
A 83 mm / 3.25 in.
B 83 mm / 3.25 in.
C51 mm / 2 in. clearance behind wall
D 10 mm / 0.38 in.
2
Ref. Dimension
E 111 mm / 4.375 in.
F 25 mm / 1.0 in.
G 527 mm / 20.75 in.
H 69 mm / 2.75 in.
6 Installation
10
Dometic Tank Monitor SystemInstallation
6.4 Key to DTM04 system wiring (g. 4 , page 3)
Ref. Description
A DTM04 indicator panel
B Wastewater tank
C 12 V DC
D 24 V DC
E V DC ground
F 1-amp circuit breaker or fuse
G Red
H Blue
I Black
J Green
K Yellow
L Orange
M Full level probe
4
Ref. Description
N Mid level probe
O Low/Empty level probe
P 12 or 24 V DC
Q Toilet system circuit breaker or fuse
R + V DC to electric toilet system
S + V DC to “full tank” monitor (optional)
Notes:
1. Heavy line indicates 14 gauge or larger stranded
copper wire is required.
2. Other wire can be 18 gauge stranded copper wire
or larger.
Caution!
Operator must know local regulations for emptying a holding tank.
Caution!
Do not install probe cap in fuel tank. Never install Dometic probe cap with oat switches
into a tank that contains anything other than waste water, grey water or fresh water.
6.3 Probe Cap (g. 3 B, page 2)
1. Loosen compression nuts on adjustable probes and install probe cap into tank. Following
numbers printed on top of probe cap, slide the “1” probe (g. 3 B 4, page 3) down until the
oat touches the bottom of the tank. Tighten “1” compression nut and mark the probe tube at
the top of the nut. Do not cut the probe tube at this mark. Loosen the compression nut, slide
the probe up, and carefully cut the “1” probe tube 42 mm (1.625 inches) below the mark without
damaging the wires inside the tube. Pull the wires through the black wire cover and push the
probe down into the compression nut until the black wire cover touches the compression nut.
The recessed shoulder of the oat, or the letters “NO”, should be facing down (B 5).
2. Remove probe cap from tank and adjust the “2” probe (g. 3 B 6, page 3) for one-half full level
for black or gray water tanks. Tighten the compression nut and cut the probe tube off 10 mm
(0.375 inch) above the compression nut without damaging the wires. Slip the black wire cover
onto the top of the tube. The recessed shoulder of the oat, or the letters “NO”, should be facing
up (B 7).
3. Route 18-gauge stranded copper wires from monitor panel and DC ground source to the probe
cap. Use quick-disconnect terminals on oat switch wires to prevent twisting wires when remov-
ing the cap. With cap removed from tank, connect the wires according to the wiring diagram
(g. 4 , page 3), turn on electrical power to system, and test the oats by moving them up and
down and monitoring the DTM04 panel. Disconnect the wires and install the probe cap and O-
ring into the tank. Reconnect the wires.
3
3
3
4
