Dometic CDF-11 Manual de usuario

Bordbar CDF-11

EN 4 Compressor bordbar

Instruction Manual

FR 17 Bordbar à compresseur

Notice d’emploi

BordBar CDF-11

EMERGENCY OVERRIDE

NORMAL USE

10 9

765432

POWER

FRIDGE FREEZER

ERROR

SET

1 2 3 4 5 6 7

BordBar CDF-11

1 2 3

Safety instructions BordBar CDF-11

Please read this operating manual carefully before starting the device.

Keep it in a safe place for future reference. If the device is resold, this

operating manual must be handed over to the purchaser along with it.

Contents

1 Safety instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

2 Intended use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

3 Scope of delivery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

4 Technical description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

5 Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

6Cleaning and maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

7 Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

8 Disposal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

9 Technical data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

Please observe the following safety instructions.

1 Safety instructions

1.1 General safety

Do not operate the device if it is visibly damaged.

Ensure that the ventilation slots are not covered.

This device may only be repaired by qualified personnel. Inade-

quate repairs can lead to considerable hazards.

Do not use electrical devices inside the cooler unless they are

recommended by the manufacturer for the purpose.

Persons (including children) whose physical, sensory or mental

capabilities or lack of experience and knowledge prevents them

from using the appliance safely should not use this appliance

without initial supervision or instruction by a responsible person.

Electronic devices are not toys.

Always keep and use the device out of the reach of children.

Children must be supervised to ensure that they do not play with

the device.

Food may only be stored in its original packaging or in suitable

containers.

BordBar CDF-11 Safety instructions

The cooling device is not suitable for transporting caustic mate-

rials or materials containing solvents.

Do not open the refrigerant circuit under any circumstances!

Connect the device with the 12/24 V lead supplied to a 12/24 V

socket.

Do not pull the plug out of the cigarette lighter or the socket by

the cable.

If the connection cable is damaged, it must be replaced with the

cable of the same type and specifications.

Pull out the connection cable:

– Before cleaning and maintenance

– After use

On boats: if the device is powered by the mains, ensure that the

power supply has a ground fault interrupter circuit. Danger of

fatal injuries!

Disconnect the cooling device and otherpower consuming de-

vices from the battery before connecting the quick charging de-

vice.

Check that the voltage specification on the type plate corre-

sponds to that of the energy supply.

1.2 Operating the device safely

Before starting the device, ensure that the power supply cable

and the plug are dry.

Do not place the device near naked flames or other heat sourc-

es (heaters, direct sunlight, gas ovens etc.)

Caution! Danger of overheating!

Ensure at all times that there is sufficient ventilation so that the

heat that arises during operation does not build up. Make sure

that the device is sufficiently far away from walls and other ob-

jects so that the air can circulate.

Do not fill the inner container with ice or fluid.

Never immerse the device in water.

Protect the device and the cable against heat and moisture.

Intended use BordBar CDF-11

A few water drops may form inside the cooler if it has been cool-

ing for a lengthy period. This is normal because the moisture in

the air condenses to water when the temperature in the cooler

falls. The cooler is not defective. Wipe it out with a dry cloth if

necessary.

Do not touch exposed cables with your bare hands. This espe-

cially applies when operating the device with an AC mains pow-

er supply. Danger of fatal injuries!

The manufacturer cannot be held liable for damage resulting

from improper usage or incorrect operation .

2 Intended use

The cooler CDF-11 is suitable for cooling and freezing foodstuffs.

The device has been designed for use with a 12/24 V on-board power sup-

ply socket of a car (cigarette lighter) or caravan.

The appliance may also be used for camping use. The appliance shall not be

exposed to rain.

Caution!

If you wish to cool medicines, please check if the cooling capacity

of the device is suitable for the medicine in question.

3 Scope of delivery

Cooling device

Connection cable for 12/24 V connection

Carry strap

BordBar CDF-11 Technical description

4 Technical description

The cooler can chill products, keep them cool as well as freeze them. A main-

tenance-free, CFC-free refrigerant circuit with compressor provides the cool-

ing.

The cooler is suitable for mobile use.

When used in vehicles the cooler can be secured with the seat belt.

An integrated battery monitor can be set to protect your vehicle battery from

discharging to dangerously low levels (see chapter “Using the battery moni-

tor” on page 11).

If an error occurs within the interior electronics, the cooling can be kept by

using an emergency switch.

4.1 Description of the device

Position in fig. , page 2

Item Description

1Control panel

2Cup holder

3 Fixing position for seat belt

4 Interior LED light

5Cooling compartment

6 Freezer compartment

7Lock

8 Skid proof pad

9Handles

10 Carry strap

11 Connection socket

12 Emergency switch

Technical description BordBar CDF-11

4.2 Operating and display elements

Control panel (fig. , page 2)

Item Description Explanation

1 On/Off buttonSwitches the cooler on or off when the button is

pressed for between one and two seconds

2 POWER Status indication

LED lights up greenCompressor is on; preset

temperature isn’t reached

yet

LED lights up orange Preset temperature is

reached

LED flashes orange Insufficient voltage

3 ERROR LED flashes red Device is switched on but

not ready for operation

4 SET Selects the input mode

– Set Temperature

– Set temperature unit (Celsius or Fahrenheit)

– Set battery monitor

5Display Shows the temperature inside the cooling compart-

ment

The first three digits of the four-digit display show the

temperature, the fourth digit shows the temperature

unit (°C or °F).

In case of an error the display shows the error mes-

sage “Err1” or “Err2”.

6 + Press once to increase the value

7 – Press once to decrease the value

BordBar CDF-11 Operation

5 Operation

The device is equipped with an interior LED light which remains on whenever

power is connected. The power consumption of this LED light is extremely

low and insignificant compared to the overall power consumption of the de-

vice.

5.1 Before initial use

Note

Before starting your new cooling device for the first time, you

should clean it inside and outside with a damp cloth for hygienic

reasons (please also refer to the chapter “Cleaning and mainte-

nance” on page 14).

5.2 Energy saving tips

Choose a well ventilated installation location which is protected against di-

rect sunlight.

Allow warm food to cool down first before placing it in the device to keep

cool.

Do not open the cooling device more often than necessary.

Do not leave the lid open for longer than necessary.

Defrost the cooler once a layer of ice forms.

Avoid unnecessary low temperatures.

5.3 Locking the cooler

Close the lid.

Press the lock (fig. 7, page 2) down until it snaps in audibly.

5.4 Connecting to a cigarette lighter

Note

If you connect the device to the cigarette lighter of your vehicle, re-

member that the ignition must be turned on to supply the device

with power.

Operation BordBar CDF-11

5.5 Securing the cooler in the vehicle

Open the lid of the cooler.

Place the seat belt into the fixing position (fig.3, page 2) of the cooler.

Close the lid.

Fasten the seat belt and tighten it.

5.6 Switching-on the cooler

Caution – Danger of overheating!

Ensure at all times thatthere is sufficient ventilation so that the

heatthat generated during operation can dissipate. Ensure that

theventilation slots are not covered. Make sure that the device

issufficiently far away from walls and other objects so that the

aircan circulate.

Warning – Danger of damaging the device!

Disconnect the cooler and other consumer units from the battery

before you connect the battery to a quick charging device.

Overvoltage can damage the electronics of the device.

The cooler can be operated with 12 V or 24 V .

For safety reasons the cooler is equipped with an electronic system to pre-

vent polarity reversal. This protects the cooler against short-circuiting when

connecting to a battery.

Place the cooler on a firm foundation.

Make sure that the ventilation slots are not covered and that the heated

air can dissipate.

Connect the 12/24 V connection cable to the cigarette lighter or an

12/24 V socket in your vehicle.

Caution!

Ensure that the only those objects are placed in the cooler that are

intended to be cooled at the selected temperature.

Note

During normal operation the emergency switch (fig.12, page 2)

has to be set to the “Normal” position.
