SR3 Bluetooth and Proximity Reader

Quick Start Guide

Wire the Reader

WARNING: Do not press and hold the button on the back of the reader. This procedure clears the unit’s memory

and ﬁrmware, which renders the device inoperable until it is reconﬁgured and re-enrolled.

Disconnect power before wiring the reader. After wiring and reconnecting power, the LED turns steady yellow, indicating

that the reader is ready for enrollment. Follow these guidelines when wiring the reader: Connections must be made in

accordance with NFPA 70: Do not connect to a receptacle controlled by a switch. Minimum wire gauge is 24 AWG with a

maximum single wire run length of 500 ft (150 m).

Caution: Do not cut the braided directional antenna wire. Wrap it around and secure it to the wiring harness for

future use.

WIRE COLOR PURPOSE TYPICAL X1 SERIES

TERMINALS

TYPICAL 734 SERIES

TERMINALS

TYPICAL KEYPAD

WIRES

Red Power (Positive) R1 RED Red

Black Ground (Negative) B1 BLK Black

White Data 1 W1 WHT White

Green Data 0 G1 GRN Green/White

Blue Green LED LC LC None

Orange Beeper* (optional) BC RA None

Purple Red LED (optional) None None None

Yellow Smart Card Present (optional) None None None

Copper, braided - Do not cut Directional Antenna (optional) None - Do Not Cut None - Do Not Cut None - Do Not Cut

* If connected, the orange wire (beeper) mimics keypad beeping.

Table 1: Wire Connections

SR3 Bluetooth and Proximity Readers support Mobile Credentials and 125 kHz proximity credentials. The reader comes

with two mounting options, mullion or single-gang, and is suitable for indoor or outdoor use. The SR3 uses the Wiegand

reader protocol to communicate with door controllers or access control modules.

Procedure

The installation must follow this procedure:

Step 1 (Technician): Install the reader.

Step 2 (Technician): Enroll and associate the reader with a system in Tech APP.

Step 3 (Administrator): Purchase credentials for a customer in Dealer Admin.

Step 4 (Customer): Assign credentials to a user in Virtual Keypad.

Step 5 (End User): Bind a mobile credential to a user’s device in Virtual Keypad.

Step 6 (End User): Use the credential at the SR3 Bluetooth Reader.

Full Installation Guide

To view the full SR3 Installation Guide (LT-2505), scan this QR code or visit DMP.com.

This quick start guide walks you through Step 1 and Step 2. For the full installation guide, follow the QR code below.

18205

LT-2519 21343

INTRUSION • FIRE• ACCESS• NETWORKS

2500 North Partnership Boulevard

Springﬁeld, Missouri 65803-8877

Domestic: 800.641.4282 | International: 417.831.9362

DMP.com

LED Operation

LED COLOR LED BEHAVIOR MEANING

None None No power or LED not connected

Yellow Spinning Powering on

Yellow Steady Connected to power, ready for enrollment

White Steady Enrolled, waiting for credential

Blue Spinning Searching for credential

Green Flash Access Granted

Speciﬁcations

Operating Voltage 12VDC

Current Draw 100 mA typical at 12 VDC

135 to 155 mA max at 12VDC

Read Range Adjustable, range 3.0 in to 30 ft (7.62 cm to 9.14 m)

Operating Temperature -27 °F to 151 °F (-33 °C to 66 °C)

Recommended Humidity 85% RH or lower, non-condensing

IP Rating IP65

Dimensions 6.0” x 1.7” x 1.3” (15.24 cm x 4.32 cm x 3.30 cm)

Weight 0.5 lb (0.23 kg)

Mobile Device and Software Requirements

▶The SR3 uses BLE Version 4.2 or higher

▶Android devices with Version 8.0 (Oreo) or higher and Bluetooth enabled

▶iOS devices with Version 10.0 or higher and Bluetooth enabled

▶Tech APP (Version 2.15.0 or higher) and Virtual Keypad (Version 6.35.0or higher)

▶Compatible with Mobile Credentials and 125 kHz proximity credentials

A technician on site must associate each reader with a system before mobile credentials can be purchased in Dealer

Admin by an Administrator.

Note: For XR Series panels with 734 Series Access Control Modules, ensure Program 734 Options is turned on and

Card Options is set to Custom in Device Setup before proceeding.

1. Stand at the reader and ensure your device has Bluetooth turned on.

2. Open Tech APP, then ﬁnd and open the appropriate system.

3. Tap the Bluetooth Readers tile.

4. Tap Add. Name the reader, then tap Create.

5. When prompted, touch your device to the reader. When paired successfully, the reader beeps.

6. In Tech APP, open the reader you added. Use the slider to adjust the Reader Range closer or farther as needed.

Range is 3in to 30ft (7.62 cm to 9.14 m).

7. To update the reader’s ﬁrmware, go to Firmware and tap Update. If no new ﬁrmware is available, this button is not

displayed.

8. Tap Save.

After being enrolled and associated, the reader’s LED changes from steady yellow to steady white.

Enroll & Associate the Reader in Tech APP
