DMP Electronics SCS-105 Manual de usuario

SCS-105 SDLC SINGLE LINE

SERVICE RECEIVER

Installation Guide

Figure 1: SCS-105 SDLC

Single Line Service Receiver

DESCRIPTION

CABLE CONNECTIONS

1. Connect the 4-wire phone cable from the appropriate phone

jack into the TELCO port on the rear of the SCS-105.

2. Connect the 4-wire

data cable to the

rear HOST port on

the SCS-105 receiver.

3. Connect the 25-pin

male connector to

the convertor cable

using the 25-pin

female connector.

4. Connect the 9-pin

male connector on

the convertor cable

to the serial port

on the back of the

computer. Refer to

Figure 2 for cable

connectors.

Note: If you do not wish for the SCS-105 to pickup incoming calls,

call DMP Technical Support

The serial port selected must be free from any other devices

such as modems, mouse, or printers. You cannot use COM 1 if

you are using COM 3 for another device. Also, you cannot use

COM 2 if you are using COM 4 for another device. These COM

ports have the same interrupt and cannot be used together.

TELCO TELEPHONE

Incoming

Phoneline To Optional

Telephone

12 VDC

HOST

AC/DC

Power Converter

RS-232 to Remote Link,

System Link, or Host Computer

Figure 3: Rear Connections

The SCS-105 Single Line Service

Receiver provides a control interface

between a host computer and one

or more DMP panels. The SCS-105

allows users with DMP Remote

Link™ or System Link™ software

to remotely program and perform

control functions on control panels

without using a DMP SCS-1R Security

Control Receiver. The SCS-105 comes

preset for standard 2-wire digital

dialer operation and can easily be

conﬁgured to work with 2-wire or

4-wire multiplex systems.

Compatibility

• All DMP panels

What’s Included

• Converter Cable

• 4-Wire Connector

• 376 Power Supply

Questions?

Contact DMP tech Support by phone

(between 7 AM and 7 PM Central Time)

or by email:

• 1-888-4DMPTEC (1-888-436-7832)

• 417-831-9362

• techsupport@dmp.com

4-Wire Connector to

HOST Port on SCS-105

25-Pin

Female

Connector

Convertor

Cable

9-Pin

Female

Connector

25-Pin

Male

Connector

Figure 2: Cable Connectors

INSTALLATION

The best place to install the SCS-105 is near your Remote Link™

or System Link™ computer. This allows you to monitor the

communication status LEDs while receiving or sending transmissions,

and provides easy access to the line monitor volume control.

If you are using the SCS-105 with DMP Remote Link or System Link

software, you must make a few conﬁguration adjustments before you

contact any subscriber accounts. See section 3 for more information

about conﬁguring.

Note: For additional information, see the Remote Link User’s

Guide (LT-0565) or System Link User’s Guide (LT-0570).

MODEL SCS-105

Single Line

Service Receiver RESET VOLUME

LT OL CD RD TD ST

MULTIPLEX MODE

To use the SCS-105 in multiplex mode with multiplex subscriber accounts, you must make some jumper

adjustments on the inside of the receiver.

Figure 4: Jumper Locations

To conﬁgure the SCS-105 for multiplex mode:

1. Remove the two front panel screws

2. Slide the circuit board assembly out of the case and

place on a non-static surface.

3. Set the jumpers J2 and J5 to MPX.

4. If installing the SCS-105 in a 4-wire multiplex system,

set the jumpers J3 and J6 to 4W.

5. Once the jumpers have been set, slide the SCS-105

circuit board assembly into the case and install the

two front panel screws.

Digital dialer mode must be set for 2-wire only: When

changing the SCS-105 from multiplex to digital dialer, make sure jumpers J3 and J6 are set to 2W.

During the conﬁguration of the SCS-105, the ST (Status) LED ﬂashes at a faster rate to indicate

programming of the receiver’s EEPROM memory. Do not remove the receiver’s power supply or reset the

receiver during the programming.

POWER UP

Once you have conﬁgured the SCS-105 and connected the cables, you can apply power.

1. Insert the AC adaptor cord plug into the rear 12 VDC jack.

2. Plug the AC adaptor into a nearby unswitched 120 VAC outlet.

At power up, the SCS-105 conducts an initialization routine for about ﬁve seconds, after which the green

status LED begins ﬂashing at a rate of once each second. This indicates the receiver is operating normally.

INITIALIZATION

During initialization, the SCS-105 tests its outputs, speaker, and internal circuits.

• After initialization, the ﬂashing green LED indicates normal operation.

• If the green LED does not ﬂash, remove all the data cables connected to the SCS-105 except the AC

cable and repeat the reset procedure.

• If the SCS-105 still does not function correctly, contact DMP Technical Support.

Status LEDs

The SCS-105 provides six status LEDs that allow you to monitor communication between the receiver and

the subscriber’s panel.

LED Description

Display Deﬁnition

LT Line Trouble

Indicates improper phone line voltage or faulty connections. If this LED

is lit and you are experiencing trouble with a panel connection, check the

phone line voltages.

OL On Line Indicates the SCS-105 is in an o-hook condition.

CD Carrier Detect Indicates the receiver detects the carrier tone from the panel.

RD Receive Data Indicates the receiver is receiving data from the panel.

TD Transmit Data Indicates the receiver is transmitting data to the panel.

ST Status Flashes when the receiver is operating normally. See Reset Button on page

950-0020

ADDITIONAL INFORMATION

Reset Button

During normal operation, the green status (ST) LED ﬂashes about once every second. If the status LED either comes

on steady or goes out completely the SCS-105 needs to be reset. Follow the steps below to reset the SCS-105

receiver:

1. Place the head of a small slotted screwdriver against the reset button.

2. Lightly press the reset button and hold for about two seconds before releasing.

3. Wait about ﬁve seconds for the SCS-105 initialization routine to end.

Baud Rate Setting

When using the SCS-105 with Remote Link or System Link, the Baud Rate in the software must be set to 9600 baud.

You can set the Baud rate in Remote Link and System Link.

1. Select System > Conﬁgure > Remote Link (or System Link) > Receiver tab.

2. In the Baud Rate ﬁeld, select 9600 from the drop-down menu.

Receiver Key Programming

The SCS-105 comes with a blank default receiver key. This allows you to perform remote operations as the service

receiver. Make the default key unique to this SCS-105 to restrict unauthorized remote programming.

Note: For additional information, see the Remote Link User’s Guide (LT-0565) or System Link User’s Guide (LT-0570).

Answering Machine Bypass Function

If you are contacting a panel that has answering machine bypass capability, the SCS-105 turns on a carrier tone ﬁve

seconds after it ﬁnishes dialing the account phone number. The carrier tone is on for approximately 90 seconds while

the subscriber’s panel will pick up the phone line and communicate with the Remote Link or System Link computer.

Note: This requires SCS-105 ﬁrmware version 207 or higher.

Volume Control

You can adjust the volume control to listen to data transmissions between the SCS-105 and DMP panels.

• Set the volume control at about one sixth of a turn clockwise for normal listening levels,

• Turn the volume controler fully counterclockwise to mute the SCS-105.

Adding a Telephone

You can connect a standard telephone to the rear TELEPHONE port of the SCS-105 to call and talk to a subscriber at

the premises prior to any remote operations.

Digital Dialer Mode

The SCS-105 receiver comes conﬁgured for 2-wire digital dialer operation and no hardware adjustments are necessary.

800-641-4282

INTRUSION • FIRE • ACCESS • NETWORKS

www.dmp.com 2500 North Partnership Boulevard

Designed, Engineered and

Assembled in U.S.A. Springeld, Missouri 65803-8877

Designed, engineered, and

manufactured in Springﬁeld, MO

using U. S. and global components.

LT‑015319475

INTRUSION • FIRE • ACCESS • NETWORKS

2500North Partnership Boulevard

Springﬁeld, Missouri65803‑8877

800.641.4282 | DMP.com

Speciﬁcations

Operating Voltage 12 VDC supplied by AC adaptor

Operating Current 200 mA maximum

RS-232 Output 9600 Baud

Case Construction Extruded aluminum with plastic ends

Dimensions 10.4” L x 5.5” W x 1.6” H

Weight 2 lbs.

Accessories

Remote Link™ Panel Programming Software

System Link™ End-User Panel Management Software

Command Center Visual Command and Control Software

Alarm Monitoring Alarm Monitoring Software

395 SCS-105 Data Cable

SCS-105 SDLC SINGLE

LINE SERVICE RECEIVER MODEL SCS-105

Single Line

Service Receiver RESET VOLUME

LT OL CD RD TD ST

Troubleshooting

Symptom Cause Solution

Receiver does not operate

when connected to Remote

Link™ or System Link™

computer.

COM port conﬂict on

computer

Make sure the other devices are not on the same

interrupts or IRQs.

Baud rate is not properly set Conﬁgure the Baud rate in Remote Link™

or System Link™ to 9600 Baud.

Bad cable connection Check connections and the continuity of the

conductors.

Bad data switcher Bypass the data switch.

AC adaptor damaged Always unplug AC adapter from AC outlet before

removing the plug from the end of the receiver.

Incorrect Windows COM

driver

Install correct COM driver from your Windows install

disk.

Cannot connect with panel.

Jumper settings not correctly

set Open receiver case and check jumper settings.

Incorrect Account number Double-check that the account number is correct.

Panel not programmed

properly

In the panel Remote Options programming, be sure

that the Alarm Receiver or Service Receiver is set to

YES.

Telephone attached to

TELEPHONE port does not

work.

Receiver is on-line with a

panel Wait until the panel is ﬁnished communicating.

Receiver is unplugged Be sure that all connections are good. Check the

telco line connections and the AC connection.
