InstallatIon GuIde

9800 Series

Wireless Graphic Touchscreen Keypads

TODAY

WEDNESDAY

98 77

HI LO

CURRENT

98 77

HI LO

Information furnished by DMP is believed to be accurate and reliable.

This information is subject to change without notice.

9800 Series Keypad Installation Guide 1

DMP Keypad Features

DMP Wireless Graphic Touchscreen Keypads offer exible features and functionality in

a stylish design.

Each keypad provides:

• AC Power/Armed LED

• Full color touchscreen display

• Internal speaker

• Wireless communication

• 12 Vdc plug-in power supply

• Internal rechargeable 3.7V lithium battery

• Micro SD for customized logo

• Icon-driven operation

• Wall tamper protection

• Optional backboxes for conduit or wall-mount applications

The Model 9862 keypad a built-in proximity card reader designed to read DMP/HID

proximity credentials.

The Model 9863 keypad provides a built-in proximity card reader designed to read

DMP/HID proximity credentials. The Model 9863 keypad also provides a door strike

relay and allows Wiegand input from external card readers.

Touchscreen Display

The 9800 Series Wireless Graphic Touchscreen Keypads have an integrated LCD

touchscreen user interface. The display can be set up to display a custom logo image

on the main screen. See the Custom Dealer Logo section. The display can also be

programmed to turn off (blank screen) during periods when the keypad is not in use.

See Backlighting Brightness under End-User Options.

Warning: DO NOT use any sharp objects to operate the touchscreen such as a pen

or pencil.

Figure 1: Keypad Main Screen

ARMED

TODAY

WEDNESDAY

Panic

Chime

Check-in

Reset

MON 5:35 AM

CURRENT

HI LO

98 77

HI LO

98 77

2 9800 Series Keypad Installation Guide

Select Areas

There are four Select Areas in the display as

seen in Figure 2. These Select Areas are one of

the features that make the system so easy to

operate. They allow you to make selections by

pressing the area over each key, icon, or other

selection to operate the keypad.

Warning: DO NOT use any sharp objects

to operate the touchscreen such as a pen

or pencil.

Panic Icons

Optional Panic functions allow users to send

Police, Emergency, or Fire reports to the central station as seen in Figure 3. You must

enable the Panic function in Installer Options in order to use the Panic Icons. See

Programming Keypad Options later in this document.

Press the panic icon in the carousel menu to bring up the Panic Options menu. This

icon can be seen in Figure 4. Press the panic menu icon for 2 seconds until a beep

is heard. At the beep, the panel sends the following zone alarm reports to the

central station:

Panic - Zone 19 + Device Address

Emergency - non-medical - Zone 29 + Device Address

Fire - Zone 39 + Device Address

Keypad Backlighting

The touchscreen illuminates at the maximum brightness any time the display is

pressed. During an alarm condition, the touchscreen turns Red. When all alarm

conditions are cleared from the display, the keyboard, logo, and the user-selected

brightness is restored.

Cleaning the Touchscreen Display

To minimize unintended key presses, select the keypad option from the main carousel

menu and clean the touchscreen using a water dampened soft, lint-free cloth. Apply

the water onto the cloth, do NOT apply directly onto the touchscreen. After cleaning,

wipe the touchscreen dry with a soft, lint-free cloth. Touch the blue mini shield that

displays in the upper left corner to return to the Main Screen.

Figure 2: Touchscreen Select Areas

1ABC

5MNO

9YZ

2DEF

6PQR

3GHI

7STU

4JKL

8VWX

CMD

Select Area 1 Select Area 2 Select Area 3 Select Area 4

Figure 3 and Figure 4: Graphic Keypad Panic Icons

DISARMED

NOW

TUE

Panic

Chime

Check-in

Reset

MONITOR ON

PANIC OPTIONS

PRESS AND HOLD BUTTON TO SEND

FIRE

POLICE EMERGENCY

9800 Series Keypad Installation Guide 3

Internal Speaker Operation

All keypads emit standard tones for screen presses, entry delay, and system alerts.

The speaker also provides distinct burglary, re, zone monitor, and prewarn cadences.

The keypads provide an alternate prewarn with alarm cadence that occurs when the

status list displays a zone alarm.

Micro SD Card

The 9800 Series Wireless Graphic Touchscreen Keypads provide a spring-loaded Micro

SD card slot on the right edge of the keypad housing. This is used to load a custom

logo onto the main screen. Insert the Micro SD card straight in, with the contacts

facing the wall, pressing in until a click occurs from the spring mechanism. To remove

the Micro SD card, gently press in to allow the spring to eject the card. Grasp the

edges of the card with two ngers and remove. See Figure 5.

Custom Dealer Logo

To display a custom dealer logo on the main screen, contact DMP Marketing at

1-800-641-4282 or [email protected] for information. To add a custom dealer

logo, see the Dealer Logo option under Installer Options menu.

AC Power/Armed LED Operation

The LED indicates the Power and Armed status of the panel. Depending on the

operation, the LED displays in Red or Blue as listed in the table.

Internal Card Reader

When a proximity credential is presented to an internal or external reader, a beep

tone is heard and the Power/Armed LED blinks. This provides both an audible and

visual acknowledgement of the credential read. See Figure 6.

Figure 5: Micro SD Card Slot

Micro SD

Card Slot

ARMED

TODAY

WEDNESDAY

Panic

Chime

Check-in

Reset

MON 5:35 AM

CURRENT

HI LO

98 77

Color and Activity Operation

Blue Steady Panel Disarmed, AC Power OK, Battery OK

Blue Blinking Panel Disarmed, AC Power OK, Battery Fault

No Light Panel Disarmed, AC Power Fault, Battery OK

Red Steady Panel Armed, AC Power OK, Battery OK

Red/Blue Alternate Panel Armed, AC Power OK, Battery Fault

Red Blinking Panel Armed, AC Power Fault, Battery OK

Figure 6: Internal Card Reader Area

Internal Card Reader Area

ARMED

TODAY

WEDNESDAY

Panic

Chime

Check-in

Reset

MON 5:35 AM

CURRENT

HI LO

98 77

4 9800 Series Keypad Installation Guide

End-User Options

All keypads provide three keypad adjustments the end-user can make through a User

Options Menu. The user can also view the keypad model number and address.

Scroll through the carousel menu and press the Options icon until it glows. The screen

displays the available options shown below. See Figure 7 for example.

Backlighting Brightness

Set the backlight illumination and AC Power/Armed LED brightness level. In the

touchscreen display below SET BRIGHTNESS, press the left < to lower and the right

> to raise the backlight brightness. If the brightness level is lowered, it reverts to

maximum intensity whenever the screen is pressed during normal operation. If the

screen is not pressed, and the speaker has not sounded for 30 seconds, the user-

selected standby brightness level restores.

Internal Speaker Tone

Set the keypad speaker tone for screen presses. At the SET TONE display, use the left

< to lower the tone and the right > to raise the tone.

Internal Volume Level

Set the keypad speaker volume level for screen presses, entry delay, and zone

monitor conditions. During alarm, entry delay, and trouble tone conditions, the

volume is always at maximum level. Use the left < to decrease the keypad volume

and the right > to increase the volume.

Model Number

The LCD displays the keypad model number and rmware version and date in the top

right corner of the screen. The user cannot change this information.

Figure 7: Options Screen

BRIGHTNESS

TONE

VOLUME

MODEL NUMBER 9800 V105 111912

INSTALLER

OPTIONS

9800 Series Keypad Installation Guide 5

Keypad Serial Number

For your convenience, an additional pre-printed serial number label is included. Prior to

installing the device, record the serial number or place the pre-printed serial number

label on the panel programming sheet. This number is required during programming.

The keypads can be programmed into the control panel by entering the serial number

in Device Setup panel programming, or alternatively using the wireless keypad

association operation. A maximum of 4 keypads may be used with the panel.

Installing the Keypad

All DMP keypad housings are designed to easily install on any single-gang switch box

or at surface. Figure 9 shows the keypad housing base mounting hole locations.

Selecting the Proper Location

The 9800 Series Wireless Graphic Touchscreen Keypads provide a built-in survey

capability in the Installer Options menu to allow one person to conrm keypad

communication with the panel. See Accessing Keypad Wireless Survey later in this

document.

Remove the Cover

The keypad housing is made up of two parts: the cover,

which contains the circuit board and components, and the

base. Use the following steps to separate the keypad cover

and base:

1. Insert a at screwdriver into one of the slots on the

bottom of the keypad and gently lift the screwdriver

handle toward you while pulling the halves apart.

Repeat with the other slot. See Figure 8.

2. Using your hands, gently separate the front from the

base and set the cover and components aside.

9800

Series

Graphic

Keypad

Building Wall

Insert small

screwdriver and

lift to remove

cover.

Do not twist.

Figure 8: Removing the

Keypad Cover

6 9800 Series Keypad Installation Guide

Mounting the Keypad

Secure the keypad base to the wall ensuring that the wall tamper switch makes

proper contact with the wall. Use the supplied screws in the mounting hole locations

as shown in Figure 9.

Primary DC Power Supply

Figure 10 shows the Model 373-500 plug-in DC power supply connector. The plug-in

power supply provides a six foot cord. The cord may be lengthened, but should be

located within 100 feet of the keypad using 22 AWG wire. For ease of connection,

locate the keypad near a wall outlet.

In addition to powering the keypad, the power supply also charges the internal back-

up battery. OBSERVE POLARITY WHEN EXTENDING THE POWER SUPPLY CORD.

Firmly grasp the wires near the base of the connector and

hold the outside edges of the keypad housing. Connect the

power supply to the J5 header on the 9800 Series Wireless

Graphic Touchscreen Keypads.

Note: Do not remove the PCB from the keypad housing to

install the power supply connector.

When the power supply connector is plugged into the keypad,

the internal battery is automatically connected. The keypad

can operate from battery only as long as the power supply

connector is plugged into the keypad.

Figure 9: 12 Vdc Wiring

White –Connect Reader Data 1

Orange –Door Strike Normally Open

Gray –Door Strike Common

Violet –Door Strike Normally Closed

Black – Ground

Red – Keypad Power

External Card

Reader

Green/White – Connect Reader Data 0

Black/White

Black

Surface and Backbox

Mounting Holes

Keypad Back

To A/C

Power

Supply

Tamper

Keypad Back

Black/White

Stripe (+)

Black (-)

Figure 10: Installing

the Wiring Harness

9800 Series Keypad Installation Guide 7

Standby Battery

The keypad rechargeable battery provides 24 hours of backup battery power when

primary DC power is not available. It is shipped already installed inside the keypad.

The battery is intended for backup power only and not to operate the keypad on

a daily basis. If the battery is low, or not plugged into the internal J3 battery

connector, a low battery condition is indicated by the panel when the battery falls

below 3.62 volts. To restore the keypad from a low battery state, the voltage must

be above 3.62.

Use the following steps to replace the battery. DMP recommends replacing the

battery every 3 years under normal use.

Note: If removing the keypad from service, disconnect the power supply connector

from the back of the keypad to avoid discharging the battery.

Battery Replacement

1. Disconnect the battery lead connector from the keypad J3 battery header.

2. Squeeze the battery straps to remove the standby battery.

3. Observe polarity and connect the battery lead connector to the keypad J3

battery header. See Figure 11.

4. Place the new battery (DMP Model 9800BAT) on the keypad PCB and replace

the battery straps.

5. Properly dispose of the used battery.

Caution: Risk of re, explosion, and burns. Do not disassemble, heat above

212°F (100°C), or incinerate.

Figure 11: Battery Connection

Battery Strap

Battery

J3 Battery

Connection

8 9800 Series Keypad Installation Guide

Programming the Keypad in the Panel

The keypads can be programmed into the control panel by entering the serial number

in Device Setup panel programming, or alternatively using the wireless keypad

association operation. A maximum of 4 keypads may be used with the panel.

Device Setup Programming

Program the keypad as a device in Device Setup during panel programming. At the

serial number prompt, enter the eight-digit serial number. Continue to program the

device as directed in the panel programming guide.

Note: If the keypad serial number is entered manually, the Wireless Keypad

Association operation is not required.

Wireless Keypad Association

To enable association operation in the XTL Series panel, press the XTL Series RESET

button 3 times within 12 seconds allowing 3 seconds between each press of the reset

button. When in keypad association, the XTL Series Red and Green logo LEDs turn on

steady.

To enable association operation in the XR100/XR500, XR150/XR350/XR550 or XT30/

XT50 panel, reset the panel 3 times within 12 seconds. Allow the keypad bus

Transmit/Receive LEDs to turn back on between each reset.

To enable association operation in the keypad use the Keypad Wireless Survey

feature.

For 60 seconds the panel listens for wireless keypads that are in the Installer Options

Menu (3577 CMD) and have not been programmed, or associated into another panel.

Those keypads are assigned to the rst open device position automatically based upon

the order in which they are detected.

Accessing Keypad Wireless Survey

Access the Options menu through the carousel menu. While in the Option display,

press the Installer Options icon and enter the code 3577 (INST) at the keypad and

press CMD.

KPD KPD KPD

OPT DIAG RF STOP

Keypad Wireless Survey (KPD RF)

Press KPD RF to start the RF communication survey test.

The keypad Power/Armed LED turns Red, indicating

communication has not been established with the panel

receiver. When successful communication has been

established, the keypad Power/Armed LED turns Blue.

RF SuRvey

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Teclado de DMP Electronics

DMP Electronics

DMP Electronics 691 Manual de usuario

DMP Electronics

DMP Electronics Security Command 670-A Manual de usuario

DMP Electronics

DMP Electronics Security Command 670 Manual de usuario

DMP Electronics

DMP Electronics 791 Easy Entry Instrucciones de montaje

DMP Electronics

DMP Electronics 9000 Series Manual de usuario

DMP Electronics

DMP Electronics 699 Manual de usuario

DMP Electronics

DMP Electronics Thinline 7060 Manual de usuario

DMP Electronics

DMP Electronics XR5FC Manual de usuario

DMP Electronics

DMP Electronics Thinline 7160 Manual de usuario

DMP Electronics

DMP Electronics 9800 Series Manual de usuario

DMP Electronics

DMP Electronics 7800 Series Guía de instalación

DMP Electronics

DMP Electronics Easy Entry 693 Instrucciones de montaje

DMP Electronics

DMP Electronics Thinline Series Manual de usuario

DMP Electronics

DMP Electronics Thinline Series Guía de instalación

DMP Electronics

DMP Electronics 7000INT Series Guía de instalación

DMP Electronics

DMP Electronics Thinline 7060 Manual de usuario

DMP Electronics

DMP Electronics Thinline 7463 Guía de instalación

DMP Electronics

DMP Electronics 7760 Manual de usuario

DMP Electronics

DMP Electronics 9800 Series Guía de instalación

DMP Electronics

DMP Electronics 9800 Series Guía de instalación

DMP Electronics

DMP Electronics 7872 Manual de usuario

DMP Electronics

DMP Electronics 7800 International Series Guía de instalación

DMP Electronics

DMP Electronics 9000 Series Guía de instalación

DMP Electronics

DMP Electronics 9800 Series Manual de usuario

Manuales populares de Teclado de otras marcas

BFT

BFT SELETTO Manual de usuario

Micro Id

Micro Id MP7G3BL Manual de instrucciones

WindowMaster

WindowMaster WLI 130 Manual de usuario

ACT

ACT ACT PRO 1030 Manual de usuario

Cardin

Cardin SSB Series Manual de usuario

Harman Kardon

Harman Kardon KP 1 Manual de usuario

Chamberlain

Chamberlain KPR2000 Guía del usuario

CYP

CYP CR-KP1 Manual de usuario

Aeware

Aeware k-35 Series Guía de referencia

Aritech

Aritech CS-175 Series Manual de usuario

GE NetworX NX-1600E Series Manual de usuario

Lenze AC Tech

Lenze AC Tech MC SERIES Manual de usuario

Burg Wächter

Burg Wächter secuENTRY 7711 Manual de usuario

Aeware

Aeware in.k450 Manual de usuario

Lenze

Lenze EPM-H410 Manual de usuario

Toshiba

Toshiba RKP007Z Manual de usuario

Gemini

Gemini GEM-DXK1 KEYPAD Manual de usuario

Russound

Russound MDK-C5 Manual de funcionamiento
