BRIGHTSKY DRONES

SYSTEMS MANUAL

BrightSky Drones

Volume 2: Systems

Aircraft Type: DJI Mavic Pro

Version 1.0: Dated 18 July 2018

BRIGHTSKY DRONES

VOLUME 2 (MP)

Amendment Record

Change

Number

Change

Date

Incorporated by

Date

Incorporated

Initial Issue V1.0

Josh Jackson

18/07/2018

BRIGHTSKY DRONES

VOLUME 2 (MP)

Acronyms & Abbreviations

General

It should be noted that the terminology related to RPAS operations continues to evolve and

therefore this Glossary is not exhaustive. The terms listed below are a combination of the

emerging ICAO definitions, other 'common use' terms which are considered to be acceptable

alternatives, and a number of ‘legacy’ terms. Whilst these legacy terms will continue to be

recognised, in the interests of commonality the use of the following terminology is advised.

The abbreviation ANO refers to the Air Navigation Order. CAP 393 Air Navigation: The Order

and the Regulations includes the ANO and the Rules of the Air Regulations.

NOTE

The terms ‘pilot’ and 'Remote Pilot' are being increasingly used worldwide (including ICAO) to

describe the person who directly controls an unmanned aircraft and that trend is reflected in

this document. It should be noted, however, that within the United Kingdom there are many

legal requirements in the Air Navigation Order applicable to ‘pilots’. These references,

however, apply only to pilots in the traditional sense i.e. persons on board and flying the

aircraft. There are at present no legal requirements setting out the qualifications needed to

control an unmanned aircraft; this work is still to be completed.

Abbreviations

AAIB

Air Accidents Investigation Branch

ACAS

Airborne Collision Avoidance System

AIAA

Area of Intense Air Activity

AIP

Aeronautical Information Publication

ALARP

As Low as Reasonably Practicable

ANO

Air Navigation Order

ASD

Air Safety Directive

ASMS

Air Safety Management System

ATA

Aerial Tactics Area

ATC

Air Traffic Control

BRIGHTSKY DRONES

VOLUME 2 (MP)

ATCU

Air Traffic Control Unit

ATM

Air Traffic Management

ATS

Air Traffic Service

ATSU

Air Traffic Service Unit

ATZ

Aerodrome Traffic Zone

BMFA

British Model Flying Association

BNUC

Basic National UAS Certificate

BNUC-S

Basic National UAS Certificate-Small

BVLOS

Beyond Visual Line of Sight

FISO

Flight Information Service Officer

FMC

Flight Management Computer

FRC

Flight Reference Card(s)

FRTOL

Flight Radio Telephony Operators’ License

GCS

Ground Control Station

GPS

Global Positioning System

GUI

Graphical User Interface

HALE

High Altitude Long Endurance

Human Factors

HIRTA

High Intensity Radio Transmission Area

HMI

Human-Machine Interface

ICAO

International Civil Aviation Organization

IFR

Instrument Flight Rules

BRIGHTSKY DRONES

VOLUME 2 (MP)

MALE

Medium Altitude Long Endurance

MATZ

Military Aerodrome Traffic Area

MEMS

Micro-Electro Mechanical Systems

MOR

Mandatory Occurrence Reporting

MTOM

Maximum Take-off Mass

NAA

National Aviation Authority

NOTAM

Notice to Airman

NPPL

National Private Pilot’s License

NQE (SUA)

National Qualified Entity (Small Unmanned Aircraft)

OEM

Original Equipment Manufacturer

PCM

Post-Crash Management

RA(T)

Restricted Area (Temporary)

RG UAS

Resource Group Unmanned Aviation Services

Drone

Remotely Piloted Aircraft

RPAS

Remotely Piloted Aircraft System / Remotely Piloted Air System

RPAS Cdr

Remotely Piloted Air System Commander

RPQ-S

Remote Pilot Qualification-Small

RPS

Remote Pilot Station

RTF

Radiotelephony

RTS

Release to Service

QTI

Qualified Training Instructor

SRG

Safety Regulation Group

BRIGHTSKY DRONES

VOLUME 2 (MP)

SUA

Small Unmanned Aircraft

SUSA

Small Unmanned Surveillance Aircraft

TDA

Temporary Danger Area

TQC2

Trained, Qualified, Competent and Current

Unmanned Aircraft

UAS

Unmanned Aircraft System(s)

UAS-c

UAS Commander

UAS-p

UAS Pilot (legacy term)

UAV

Unmanned Aerial Vehicle(s) (legacy term)

UAV-p

UAV Pilot (legacy term)

VFR

Visual Flight Rules

VLOS

Visual Line of Sight

BRIGHTSKY DRONES

VOLUME 2 (MP)

Table of Contents

Amendment Record

Acronyms & Abbreviations

Contents

Systems Chapter 1

Design & Manufacturing Organisation 1.1

Design Flight Envelope 1.2

Air Vehicle Characteristics 1.3

Design Features 1.4

Construction 1.5

Electrical Power Provision and Distribution 1.6

Propulsion System 1.7

Fuel System 1.8

Flight Management System (FMS) 1.9

Navigation Guidance 1.10

Other Avionics 1.11

Landing Aids 1.12

Payloads 1.13

Emergency Recovery or Safety Systems 1.14

Modifications to the System 1.15

Command & Control C2 1.16

Whole System Points of Failure 1.17

Ground Control Station 1.18

Service Life, Maintenance Schedules & Inspections 1.19

Spares 1.20

Repair 1.21

Known Failure Modes 1.22

Failsafe Features 1.23

Transportation Requirements 1.24

BRIGHTSKY DRONES

VOLUME 2 (MP)

1 Systems

1.1 Design & Manufacturing Organisation

Item

Detail

Designer & Manufacturer:

DJI Innovations

DJI Headquarters

14th Floor, West Wing,

Skyworth Semiconductor Design Building,

No.18 Gaoxin South 4th Ave,

Nanshan District,

Shenzhen,

China, 518057.

Aircraft Name:

DJI Mavic Pro

Type:

Multi-Rotor (Quadcopter)

Distributor:

DJI

BRIGHTSKY DRONES

VOLUME 2 (MP)

1.2 Design Flight Envelope

Item

Detail

Ceiling Height:

<400ft As per VLOS rules

Operating Radius*:

<500m VLOS rules

Maximum Operating Altitude:

16,404ft AMSL

Maximum Operating Range

4,000m

Maximum Endurance (with payload):

Approximately 27 Minutes

MTOW

734g

Maximum Surface Wind for Take-off*:

10m/s (19.5Kts)

Maximum Operating Temperature:

40°c

Maximum Operating Speed:

18m/s (35kts)

Minimum Operating Temperature*:

0°c

Can operate in:

Dry weather, within wind tolerances.

*Flight in known icing conditions should be avoided.

BRIGHTSKY DRONES

VOLUME 2 (MP)

1.3 Air Vehicle Characteristics

Item

Detail

Dimensions: Airframe

Width: 83mm

Length: Width: 198mm

Height: 83mm

Weight with battery & props

734g

Power Source:

Lithium Polymer (Li-Po) Battery - 3830 mAh

Motor Type:

4 x Electric Brushless Motor

Battery Weight:

240g

Internal Components:

DJI Flight Controller including:

Solid State MEMS (Micro - Electro-

Mechanical- Systems) Gyros

Solid State MEMS Accelerometers

Magnetometers (Magneto resistive sensors)

1 x Barometric pressure sensor

1 x GPS unit

1 x Compass module

1 x Vision positioning module

Control Data Link

2.400 – 2.483 GHz @ 10mW

Transmitter Power (EIRP):

FCC:23dBm;CE:17dbm

Video data down link:

2.4GHz ISM

Antennas:

4 x Omni-Directional, Vertically Polarised.

Control Data Link:

7cm (2.7in) Antenna.

Video Data Downlink:

4 x Omni-Directional, Circularly Polarised, 70mm

Antenna.

Video / Control Link notes:

The Mavic Pro is controlled by DJI’s proprietary

quad-antennae design. Each of the four legs of the

Mavic Pro contains a high-powered antenna, all

constantly broadcasting the live video feed and

receiving control commands from any direction.
