OWNER’S MANUAL

Operating and Servicing

Instructions

10/01

●Please read these

instructions carefully

before using your

Platinum Force™

Hand Vac.

●Let us help you

put your vacuum

together or answer

any questions, call

1-800-321-1134

(USA & Canada)

www.dirtdevil.com

For quick reference, please record your

vacuum information below.

Model #:

Mfg. Code:

(Mfg. code

located on the lower backside of cleaner)

WARNING:

Cleaner assembly may

include small parts.

Small parts can present

a choking hazard.

CONSUMER INFORMATION

• THIS VACUUM IS INTENDED FOR HOUSEHOLD USE ONLY.

IMPORTANT SAFETY INSTRUCTIONS

When you use an appliance, basic precautions should always be followed, including

the following:

•READ ALL INSTRUCTIONS BEFORE USING THIS APPLIANCE

•ALWAYS FOLLOW THESE SAFETY INSTRUCTIONS

•DO NOT LEAVE CLEANER UNATTENDED

•WARNING - FULLY ASSEMBLE CLEANER BEFORE OPERATING

•WARNING - THE CORDS, WIRES AND/OR CABLES SUPPLIED WITH THIS PROD-

UCT CONTAINS CHEMICALS, INCLUDING LEAD OR LEAD COMPOUNDS, KNOWN

TO THE STATE OF CALIFORNIA TO CAUSE CANCER AND BIRTH DEFECTS OR

OTHER REPRODUCTIVE HARM. WASH HANDS AFTER USING.

WARNING: TO REDUCE THE RISK OF

FIRE, ELECTRIC SHOCK OR INJURY:

•Do not leave appliance when plugged in. Unplug from outlet when not in use and

before servicing.

•Do not use outdoors or on wet surfaces.

•Do not allow to be used as a toy. Close attention is necessary when used by or

near children.

•Use only as described in this manual. Use only manufacturer’s recommended

attachments.

•Do not use with damaged cord or plug. If appliance is not working as it should,

has been dropped, damaged, left outdoors, or dropped into water, return it to a

service center for inspection. Call 1-800-321-1134 for the nearest service center.

•Do not pull or carry by cord, use cord as a handle, close a door on cord, or pull

cord around sharp edges or corners. Do not run appliance over cord. Keep cord

away from heated surfaces.

•Do not unplug by pulling on cord. To unplug, grasp the plug, not the cord.

•Do not handle plug or appliance with wet hands.

•Do not put any object into openings. Do not use with any opening blocked; keep

free of dust, lint, hair and anything that may reduce air flow.

•Keep hair, loose clothing, fingers, and all parts of body away from openings and

moving parts.

•Turn off all controls before unplugging.

•Use extra care when cleaning on stairs.

•Do not use to pick up flammable or combustible liquids, such as gasoline, or use

in areas where they may be present.

•Look on your vacuum cleaner and follow all label and marking instructions.

•

Do not use an extension cord with this cleaner.

•Keep end of hose, wands and other openings away from your face and body. Keep

your hands, feet, hair and clothing away from moving parts; especially the revolving

brush.

•Do not use the vacuum cleaner without dirt container and/or filters in place.

•Do not pick up anything that is burning or smoking, such as cigarettes, matches, or

hot ashes.

•The hose contains electrical wires. Do not use when damaged, cut, or punctured.

Avoid picking up sharp objects.

•Always turn off this appliance before connecting or disconnecting motorized nozzle.

Approved by the Vacuum Cleaner Manufacturer’s Association Executive Committee,

April 29, 1987.

SAVE THESE INSTRUCTIONS

WARNING:To reduce the risk of electric shock, this appliance has a polar-

ized plug (one blade is wider than the other). This plug will fit in a polarized outlet

only one way. If the plug does not fit fully in the outlet, reverse the plug. If it still

does not fit, contact a qualified electrician to install the proper outlet. Do not change

the plug in any way.

This cleaner contains a protective device which will automatically shut off

the brush motor current flow at abnormally high brush motor currents. If the pro-

tective device is activated - turn main switch off and inspect the motorized nozzle.

After approximately one (1) minute the device will have reset and the vacuum will be

ready to use. NOTE: The cleaner must remain off during the one (1) minute cooling

period.

NOTE: RETURN WARRANTY CARD TO REGISTER YOUR CLEANER

CONGRATULATIONS

You are now the proud owner of the Dirt Devil®Platinum

Force™Hand Vac, with Power You Can See®! You’ll never

buy another bag again with the unique bagless design that

includes a see-through dirt container for retrieving lost

items. And now you’ll never buy another belt again with a

new permanent belt system that never needs to be changed.

You’ll also enjoy superior cleaning performance with 6 amps

of power. We trust your new purchase will bring you many

years of satisfaction.

We are very proud of our products and hope that you are

equally satisfied with their quality and performance.

Thank you for your support of Dirt Devil®products.

Visit our website at www.dirtdevil.com

TABLE OF CONTENTS

Saftey Instructions............................................Page 2,3

Feature Descriptions........................................Page 5

How to Operate................................................Page 6

Attachment Usage............................................Page 6,7

Dirt Container & Filter: Removal

& Replacement.................................................Page 8

Belt and Brushroll: Removal & Replacement...Page 9

Troubleshooting Guide......................................Page 9

LIMITED WARRANTY

To the consumer, Royal Appliance Mfg. Co. warrants this vacuum cleaner to be free of defects in materi-

al or workmanship commencing upon the date of the original purchase. Refer to your vacuum cleaner

carton for the length of warranty and save your original sales receipt to validate start of warranty period.

If the vacuum cleaner should become defective within the warranty period, we will repair or replace any

defective parts free of charge. The complete machine must be delivered prepaid to any ROYAL®

Authorized Sales & Warranty Service Station. Please include complete description of the problem, day

of purchase, copy of original sales receipt and your name, address and telephone number. If you are

not near a Warranty Station, call the factory for assistance at USA & Canada:

1-800-321-1134. Use only genuine Royal®replacement parts.

The warranty does not include unusual wear, damage resulting from accident or unreasonable use of

the vacuum cleaner. This warranty does not cover brushes, flat belts, filters and bulbs. This warranty

does not cover unauthorized repairs. This warranty gives you specific legal rights and you may also

have other rights (Other rights may vary from state to state in the USA).

FEATURES

234

567

1. Detachable Power Head

2. Revolving Brushroll

3. Power Nozzle Release Button

4. On/Off Switch

5. Crevice Tool

6. See Thru Dirt Cup

7. Filter

8. Power Cord

9. Dirt Cup Latch Release

10. Crevice Tool Storage

11. Electrified Hose

12. Carry Strap

13. Hose Locking Ring

HOW TO OPERATE

Plug cord into electrical

outlet. Turn power on.

1. 2.

Press the power nozzle

release button. Remove by sliding power

nozzle to the right.

Line up tabs with grooves

and slide until the power

nozzle locks into place.

REMOVE DETACHABLE

POWER NOZZLE

REATTACH POWER

NOZZLE

WARNING: ALWAYS TURN OFF APPLIANCE BEFORE CONNECTING OR DISCONNECT-

ING MOTORIZED NOZZLE.

Power reach nozzle with

revolving brushroll allows

you to clean in hard to

reach places.

ATTACHMENT USAGE

1. 2. 3.

Turn hose locking ring to the

unlock position (clockwise). Pull hose out of power nozzle

away from unit. Use hose for hard to reach

areas.

*Also see crevice tool usage.

ATTACHMENT USAGE CONTINUED

1. 2. 3.

HOSE USAGE

Reattach hose by lining up

tabs on power nozzle with

grooves on hose and push

into place.

Secure into place by turning

locking hose ring to the lock

position (counter clockwise).

REATTACH HOSE

Insert crevice tool into the end

of hose. Use crevice tool to clean tight

corners. Replace crevice tool by lin-

ing up tab in crevice tool with

slot in crevice tool storage.

2. 3. 4.

CREVICE TOOL

USAGE

Remove crevice tool from the

back of unit.

REPLACE

CREVICE TOOL

INSERT

CREVICE TOOL

Press dirt cup release latch.

Rock dirt cup down and

away from unit.

Grasp filter from the center. Pull filter out of dirt cup.

DIRT CONTAINER: REMOVAL & REPLACEMENT

1. 2. 3.

EMPTYING DIRT CUP

Empty contents into waste-

basket. For best results,

lightly tap filter against

wastebasket to remove

remaining dirt.

Return filter to dirt cup.

DIRT CUP

REPLACEMENT

Reattach by aligning slot on

dirt cup with base of unit.

Tilt dirt cup up until it locks

into place.

TROUBLESHOOTING GUIDE

PROBLEM POSSIBLE REASON POSSIBLE SOLUTION

Cleaner won’t

run

Motorized

nozzle won’t run

Cleaner won’t

pick-up or low

suction

Dust escaping

from cleaner

Cleaner tools

won’t pick up

1. Power cord not firmly

plugged into outlet.

2. Blown fuse or tripped breaker.

3. Needs service.

1. Hose not installed into

nozzle correctly.

2. The protective device is

tripped.

1. Dirt container not installed

correctly.

2. Dirt container full.

3. Clogged filter.

4. Nozzle/dirt passage hose

clogged.

5. Brushroll worn.

6. Broken or worn belt.

1. Dirt container full.

2. Dirt container not installed

correctly.

3. Hose not installed into

power nozzle correctly.

4. Filter not installed correctly.

1. Hose clogged.

2. Dirt container full.

3. Filter clogged.

1. Plug unit in firmly.

2. Check fuse or breaker. Replace

fuse/reset breaker.

3. Take to service center or call

1-800-321-1134.

1. Review hose installation - Pg. 6.

2. Turn until off and check for clogs.

Wait 1 minute, then turn back on.

1. Review dirt container removal and

replacement - Pg. 7.

2. Empty dirt container - Pg. 7.

3. Remove filter and clean - Pg. 7.

4. Remove base nozzle cover; remove

obstruction OR Remove hose; remove

obstruction.

5. Replace brushroll - Take to a service

center or call 1-800-321-1134.

6. Replace belt - Take to a service

center or call 1-800-321-1134.

1. Empty dirt container - Pg. 7.

2. Review dirt container removal and

replacement - Pg. 7.

3. Review hose installation - Pg. 6.

4. Review filter installation - Pg. 7.

1. Remove hose and tools; remove

obstruction - Pg. 6.

2. Empty dirt container - Pg. 7.

3. Clean filter - Pg. 7.

ANY OTHER SERVICING SHOULD BE DONE BY AN

AUTHORIZED SERVICE REPRESENTATIVE

CUSTOMER SERVICE (1-800-321-1134)

In the event that further assistance is required, see your Yellow Pages for an authorized

Royal®Dealer. Costs of any transportation to and from any place of repair are to be paid by

the owner. The service parts used in this unit are easily replaced and readily available from an

authorized Royal®Dealer or retailer. Always identify your cleaner by the model number and

manufacturing code when requesting information or ordering replacement parts. (The model

number appears on the bottom of the cleaner.)

This vacuum contains a permanent belt. If you experience problems

with this unit, please call 1-800-321-1134 (USA & Canada) to locate

the nearest Service Center.

BELT/BRUSHROLL REMOVAL & REPLACEMENT

WARNING: TO REDUCE RISK OF PERSONAL INJURY - UNPLUG CLEANER BEFORE SERVICING

Otros manuales para Platinum Force

Tabla de contenidos

Otros manuales de Aspiradora de Dirt Devil

Dirt Devil

Dirt Devil Vacuum Cleaner Manual de usuario

Dirt Devil

Dirt Devil Scorpion BD10050RED Manual de usuario

Dirt Devil

Dirt Devil Bagline M7020 Manual de usuario

Dirt Devil

Dirt Devil Upright vacuum cleaner Manual de usuario

Dirt Devil

Dirt Devil CENTEC M2828-0 Manual de usuario

Dirt Devil

Dirt Devil paroly Manual de usuario

Dirt Devil

Dirt Devil Black Label CP -1 Manual de usuario

Dirt Devil

Dirt Devil M082600 Manual de usuario

Dirt Devil

Dirt Devil BLACK LABEL BG72 Manual de usuario

Dirt Devil

Dirt Devil Quick Flip; Express Lithium Cordless Hand... Manual de usuario

Dirt Devil

Dirt Devil M086020 Manual de usuario

Dirt Devil

Dirt Devil BLADE 2 MAX DD788 Manual de usuario

Dirt Devil

Dirt Devil Vacuum Cleaner Manual de usuario

Dirt Devil

Dirt Devil M084100 Manual de usuario

Dirt Devil

Dirt Devil KWIK BD10000 Manual de usuario

Dirt Devil

Dirt Devil Scorpion Manual de usuario

Dirt Devil

Dirt Devil Vacuum Cleaner Manual de usuario

Dirt Devil

Dirt Devil UD70200PC Manual de usuario

Dirt Devil

Dirt Devil M08230RED Manual de usuario

Dirt Devil

Dirt Devil Centrino Cleancontrol M2881-6 Manual de usuario

Dirt Devil

Dirt Devil SD40010 Manual de usuario

Dirt Devil

Dirt Devil Magnum PR Manual de usuario

Dirt Devil

Dirt Devil BD10040 Manual de usuario

Dirt Devil

Dirt Devil M085610 Manual de usuario

Manuales populares de Aspiradora de otras marcas

Bissell

Bissell LittleGreen Proheat 1425 Series Manual de usuario

Panasonic

Panasonic MC-YL637S147-AE Manual de usuario

NEFF

NEFF N17XH10 0 Series Manual de usuario

LG A9 Series Manual de usuario

Oreck

Oreck Cordless Captura BK51700 Series Manual de usuario

Kogan

Kogan KAVACROBVWA Manual de usuario

Kränzle

Kränzle VENTOS 50 ID Guía del usuario

EVVO

EVVO Ai35 Manual de usuario

DeWalt

DeWalt DWH200D Manual de usuario

Pontec

Pontec Pondomatic Vacuum Cleaner Manual de usuario

Cleanmaxx

Cleanmaxx PC-P007E Manual de usuario

Exido

Exido 240-114 Manual de usuario

RIDGID

RIDGID WD1685AU0 Manual de usuario

Ezviz

Ezviz RE4P Manual de usuario

STG global

STG global TANVAC HDV3000 Manual de usuario

Shark

Shark ROTATOR PRO COMPLETE NV550 Series Manual de usuario

Factory

Factory M3340 Manual de usuario

Shop-Vac

Shop-Vac VN92 SERIES Manual de usuario
