Dirt Devil DD2503 Manual de usuario
CYCLONE
VACUUM CLEANER 800W
220-240V~50/60HZ
ITEM: 871125247530
A.I.&E. Adriaan Mulderweg 9-11
5657 EM Eindhoven, The Netherlands
DD2503
2
YEAR
GUARANTEE
7,5M
2,2L
4,3KG
78dB
Points de collecte sur www.quefairedemesdechets.fr
Cet appareil,
ses accessoires,
piles et cordons
se recyclent
À DÉPOSER
EN MAGASIN À DÉPOSER
EN DÉCHÈTERIE
OU
FRFR
INSTRUCTION MANUAL
2.2 LITER
aINSTRUCTION MANUAL
BAGLESS SINGLE CYCLONE
VACUUM CLEANER
ITEM NO: 871125247530
MODEL: V8221
IMPORTANT SAFETY INSTRUCTIONS
This appliance should only be used for domestic cleaning and not for
commercial or industrial use. Please ensure that this guide is fully
understood before
operating the appliance.
WARNING: DANGER TO THE PERSON!
IMPORTANT: Damage to the appliance! In addition we offer the
following safety advice.
LOCATION
• Do not use or keep this product outside when it is raining.
• Do not store the appliance near hot ovens or heating appliances.
• Store your vacuum cleaner in a cool, dry area. If lters have been
cleaned as per user guide instructions ensure they are thoroughly dry
before storing away.
MAINS LEAD
• Do not allow the mains lead to become strained or run this
appliance over it.
• If the electrical cable becomes damaged, the complete cable
assembly must be replaced. Do not attempt this task yourself.
Contact the local retailers.
• Agency service: To ensure the continued safe and efcient
operation of this appliance we recommend that any servicing
or repairs are
only carried out by an authorized Agency service
engineer.
CHILDREN
• This appliance can be used by children aged from 8 years and
above and persons with reduced physical, sensory or mental
capabilities or lack of experience and knowledge if they have been
given supervision or instruction concerning use of the appliance in
a safe way and understand the hazards involved.
• Children shall not play with the appliance
• This appliance can be used by children aged from 8 years and above.
Scan QR-Code for
extended manual
PERSONAL SAFETY
• The plug must be removed from the wall socket before cleaning or
maintaining the appliance.
• Never modify the cleaner in any way.
• Never use in the presence of explosive liquids or vapors.
• Never pick up inammable or poisonous liquids such as petrol,
copier toner or other volatile substances. Never pick up acids,
asbestos or asbestos dust.
• Repairs to electrical appliances are only to be undertaken by
trained personnel.
• Unprofessional repairs can be dangerous for users.
• The appliance must never be left running when unsupervised.
PRODUCT SAFETY
• Never use the appliance without the lters being installed.
• Never use the appliance to vacuum hot ashes, broken glass, sharp
objects or liquids.
• To protect against re, electric shock and personal injury do not
immerse cord, plug or cleaner in water or other liquid.
• This appliance is not intended for use by persons (including
children) with reduced physical, sensory or mental capabilities, or
lack of experience and knowledge, unless they have been given
supervision or instruction concerning use of the appliance by a
person responsible for their safety.
• Cleaning and user maintenance shall not be made by children
without supervision
• If the supply cord is damaged, it must be replaced by the
manufacturer, its service agent or similarly qualied persons in
order to avoid a hazard.
• Always switch off the vacuum cleaner before
disconnecting or connecting the hose and accessories.
• Keep all openings clear and free from debris as this may
affect the airow/suction.
• Do not use the appliance to clean animals or people.
ELECTRICAL REQUIREMENTS
• Check that the voltage on the rating plate corresponds with your
house electricity supply which must be A.C (alternating current).
PRODUCT DESCRIPTION
FEATURES
1. Dirt container lid 7. Dirt container release button
2. Dirt container 8. Carry handle
3. Separator and shroud 9. Parking slot
4. Post-motor lter cover 10. Cord rewind button
5. Hose entry point 11. On/Off button
6. Post-motor lter (hidden)
HOW TO INSTALL / OPERATE THE MACHINE
Before you start
• Always switch off and unplug the vacuum cleaner before
connecting or disconnecting the hose/attachments, or removing
and emptying the dirt container.
• The vacuum cleaner is equipped with a thermal cut-out. If for
any reason the vacuum cleaner does overheat the thermostat
will automatically turn the vacuum cleaner off. If this happens,
switch the vacuum cleaner off and unplug from electrical
socket. Remove and empty the dirt container and also check
the vacuum cleaner for blockages. Allow the vacuum cleaner
to cool for approximately 1 hour (if you have cleaned the lters
please wait 24 hours for the lters to fully dry before putting
back into the machine).
• Clean the pre-motor lter every time the dirt container is
emptied and replace the lters every 12 months.
• If the vacuum cleaner is blocked, switch off and unplug before
removing the blockage.
• When using the accessories always make sure the brush bar is
switched to the off position.
ASSEMBLING YOUR MACHINE
1. Press both buttons at the end of hose and insert into hose entry
point.
2. Insert hose grip into telescopic extension tube.
3. Press button on telescopic extension tube and adjust to required
length.
4. Insert the other end of the telescopic tube into the oorhead.
USING YOUR ACCESSORIES
5. Push the accessory onto the telescopic
extension tube or hose end.
HOW TO USE
IMPORTANT: The base of the vacuum cleaner should always be
positioned at on the oor when starting and in use. The dirt
container should be locked into place before lifting the vacuum
cleaner by the carry handle.
IMPORTANT: The power cord must always be completely
unwound, do not pull further than the yellow marker.
Hard oors
Carpets
6. Unwind the power cord. Do not pull further than the yellow marker.
7. Plug into mains and press the On/Off button to switch the machine
on.
8. For use on carpets, click rocker switch forward. For use on hard
oors click rocker switch back.
9. Raise brushed for carpets.
10.Lower brushes for hard oors.
11. Slide vent cover on hose grip open to reduce suction if required.
Note: Brushes on the oorhead should be visible when using on
hard oors.
EMPTYING AND CLEANING THE DIRT CONTAINER
IMPORTANT: Unplug and switch off vacuum cleaner before
performing maintenance or troubleshooting checks.
12.Press dirt container release button. Lift to remove dirt
container from machine.
13.Hold dirt container over the bin. Press release clip at the
bottom of the container, the dirt release door will open allowing
dirt/debris to fallout.
Note: Don’t over ll the dirt container to avoid blocking
the air ow through the vacuum cleaner.
CLEANING THE PRE-MOTOR FILTER
Note: Clean the pre-motor lter every time the dirt container
is emptied and replace the lters every 12 months.
14.Turn the dirt container lid anti-clockwise to remove.
15.Lift to remove the pre-motor lter out of dirt container.
16.Tap the lter against a bin to remove excess debris.
17.Wash pre-motor lter under running water (4
0°C Max)
.
18.Leave to dry for 14 hours or until fully dry before placing back
in the machine.
CLEANING THE SEPARATOR
19.Turn the dirt container lid anti-clockwise to remove.
20.Lift to remove the pre-motor lter out of dirt container.
21.Using central grips lift to remove separator from dirt container.
22.Twist grips clockwise and remove cap from separator.
23.Tap the separator against a bin to remove any dirt of debris.
Note: For any stubborn dirt / debris remaining in the
separator, use a soft brush to remove.
REFITTING THE SEPARATOR
IMPORTANT: Incorrect tting of the separator will reduce
suction.
24.Replace the separator cap, twist clockwise to lock.
25.Replace separator into dirt container, make sure the rectangular
hole in the dirt container lines up with the rectangular hole on the
separator.
POST-MOTOR FILTER MAINTENANCE
IMPORTANT: The exhaust lter is designed to offer long life with
no maintenance. The lter should be checked periodically and
when heavily discolored it should be replaced. Please do not
wash, scrub or brush the lter as this will damage the delicate
lter media.
26.Turn the post-motor lter cover anti-clockwise to remove.
27.Pull to remove post-motor lter.
28.Check the post-motor lter for discoloration.
29.Push post-motor lter into wheel and re-t.
30.Line up the lter cover tabs with the wheel and turn clockwise. The
lter cover will be locked into place when the center trim is in the
horizontal position.
PET ODOR FILTER MAINTENANCE
IMPORTANT: Do not wash, scrub or brush the ped odor lter as
this will damage it. Replace lters at least every 6-9 months.
31.Turn the post-motor lter cover anti-clockwise to remove.
32.Pull to remove post-motor lter to gain access to the pet odor lter.
33.Tap the pet odor lter against a bin to remove any dirt or debris.
STORE YOUR VACUUM CLEANER
CAUTION: Make sure to hold the cord with your other hand to
prevent injury when re-winding.
34.Unplug from the mains and hold the rewind button into the vacuum
cleaner.
35.Place oorhead into parking slot located at the back of the vacuum
cleaner for storage and carrying.
REMOVING BLOCKAGES FROM THE HOSE
36.Remove the hose from the vacuum cleaner and telescopic
extension tube. Remove any blockage by inserting a wire
coat hanger into the hose.
NOTE: To test for a blockage in the hose, drop a small ball
of paper into the hose. The paper will drop through if the
hose is clear.
