Directed Passive Keyless Entry System (PKE)

Model 2102T

Owner’s Guide

G2102T

Contents

Government regulations .....................................................................................4

Warning! Safety first .........................................................................................6

Important information ........................................................................................6

System maintenance..................................................................................6

Maximize the performance of your system ...................................................6

Using the system ...............................................................................................7

Automatic unlocking and locking of the vehicle.............................................7

Manual unlocking and locking of the vehicle................................................7

Enabling/Disabling valet mode ..................................................................8

Sleep mode..............................................................................................9

SmartLock Feature...................................................................................10

Glossary of terms............................................................................................13

Limited lifetime consumer warranty ....................................................................14

Government regulations

This device complies with Part 15 of FCC rules. Operation is subject to the fol-

lowing two conditions: (1) This device may not cause harmful interference, and

(2) This device must accept any interference received, including interference

that may cause undesirable operation.

This equipment has been tested and found to comply with the limits for a

class B digital device, pursuant to Part 15 of the FCC Rules. These limits are

designed to provide reasonable protection against harmful interference in a

residential installation. This equipment generates and can radiate radio fre-

quency energy and, if not installed and used in accordance with the instruction

manual, may cause harmful interference to radio communications. However,

there is no guarantee that interference will not occur in a particular installa-

tion. If this equipment does cause harmful interference to radio or television,

which can be determined by turning the equipment Off and ON, the user is

encouraged to try to correct the interference by one or more of the following

measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit different from that to

which the receiver is connected.

• Consult the dealer or an experienced radio / TV technician for help.

To satisfy FCC RF exposure compliance requirements, this device should be used

in hand-held, hand operated conﬁgurations only. This device is designed to be

used in a person’s hands and its operating conﬁgurations do not support normal

transmissions while it is carried in pockets or holsters next to a persons’ body.

This device complies with the Industry Canada Radio Standards Speciﬁcation

RSS 210. Its use is authorized only on a no-interference, no-protection basis;

in other words, this device must not be used if it is determined that it causes

harmful interference to services authorized by IC. In addition, the user of this

device must accept any radio interference that may be received, even if this

interference could affect the operation of the device.

Warning:

The installation of this product must only be performed by technicians who

are trained or certiﬁed by Directed dealers. Changes or modiﬁcations not

expressly approved by the party responsible for compliance could void the

user’s authority to operate this device.

Warning! Safety ﬁrst

The following safety warning must be observed at all times:

Due to the complexity of this system, installation of this product must only be

performed by an authorized Directed dealer.

Important information

Congratulations on the purchase of your state-of-the-art Passive Keyless Entry

System (PKE). Due to the complexity of this system, it must be installed by an

authorized dealer only. Installation of this product by anyone other than an au-

thorized dealer voids the warranty. All dealers are provided with a preprinted

dealer certiﬁcate to verify authorization.

By carefully reading this Owner’s Guide prior to using your system, you will

maximize the use of this system and its features. You can print additional or

replacement copies of this manual by accessing our web site at

www.xpresskit.com.

System maintenance

The system requires no speciﬁc maintenance. Your remote is powered by a

small coin cell lightweight 3-volt lithium battery (CR2032) that lasts approxi-

mately 3 years under normal use. When the battery begins to weaken, the

operating range is reduced.

Maximize the performance of your system

Never put the key fob together with a cellphone as this may affect the range

and its performance.

A third antenna can be installed to extend the range of the active zone. The in-

stallation must be done by technicians who are trained or certiﬁed by Directed

dealers (optional parts and extra labor required). Refer to your authorized

dealer for more information.

Using the system

Automatic unlocking and locking of the vehicle

Passive door unlocking

The key fob LED will start ﬂashing green once you have entered the active

zone. The doors will be automatically unlocked and the starter kill (optional)

will be disarmed.

Note: The unlock operation may be delayed when approaching the vehicle

immediately after a remote start command has been sent.

Passive door locking

The key fob LED will start ﬂashing red once you have left the active zone. The

doors will be automatically locked and the starter kill (optional) will be armed.

The key fob LED will turn ON solid red for 1 second to conﬁrm when the doors

have been locked.

Starter kill output (optional)

When the optional starter kill feature is installed and active, it will interrupt the

starter wire of the vehicle when doors are locked; thus preventing vehicle theft

by not allowing the vehicle to be started.

Note

: This feature is optional and must be conﬁgured by the installer (optional

parts and extra labor required).

The optional starter kill is disabled as soon as the doors are unlocked by the

PKE system. It can also be disabled with a toggle switch installed somewhere

in the vehicle. Refer to your authorized dealer for the location.

Manual unlocking and locking of the vehicle

Although the PKE system allows for automatic locking and unlocking of the ve-

hicle when you approach and leave the active zone, it also offers the ﬂexibility

of manually locking and unlocking doors with the remote.

Manual unlocking

Press and hold the button until the LED on the remote ﬂashes red. The park-

ing lights will ﬂash twice to conﬁrm the doors have been unlocked.

Manual locking

Press and release the button for 1 second. The LED on the remote will ﬂash

red indicating that the command is being sent, and the parking lights will ﬂash

once to conﬁrm the doors have been locked.

Note: When installed with certain remote starter models, the doors might not

locks when the vehicle is running by the key.

Enabling/Disabling valet mode

Valet mode can be enabled and disabled using the following procedure.

When the feature is enabled, the automatic locking/unlocking operation upon

entering the active zone will be disabled. However, manual locking/unlocking

of the vehicle is possible in valet mode, as long as the ignition is off.

Enable valet mode

Within the active zone, quickly press and release the key fob button twice,

then press and hold until the remote LED ﬂashes red to conﬁrm the system has

entered valet mode. The key fob LED will no longer ﬂash to indicate whether

you are in the active zone or not.

Disable valet mode

Within the active zone, quickly press and release the key fob button twice,

then press and hold until the remote LED ﬂashes red to conﬁrm the system has

exited valet mode. The key fob LED will ﬂash to indicate whether you are in the

active zone or not.

Sleep mode

For security reasons, your PKE system is in sleep mode while the vehicle is in

motion.

Turning the sleep mode ON

In order to prolong the key fob battery life, the PKE system will enter sleep

mode once the user is in the vehicle, all the doors are closed and the brake

pedal is depressed (a valid key fob must be inside the vehicle).

Warning: Failure to execute these steps, while the key fob is present in the

vehicle, may cause its battery to be drained prematurely, and consequently

your keys may become locked inside the vehicle.

Turning the sleep mode OFF

The PKE system will exit sleep mode and will return to normal operation when

a door is opened.

Note

: This feature is automatically enabled/disabled every time vehicle is in

use. It does not affect the user's experience.

SmartLock Feature

The purpose of the SmartLock feature is to prevent the doors from unwanted

unlocking/locking when entering/exiting the active zone multiple times for a

pre-programmed delay (No delay*,1, 3 or 5 minutes). This is practical in situ-

ations such as loading/unloading packages.

*SmartLock feature is disabled when it is set to no delay, which is only con-

ﬁgurable by your authorized dealer.

Note: If the Door Open Interlock feature is enabled, the SmartLock feature will

not be able to lock a door when it is left opened.

To use the SmartLock feature, the following sequence must be performed:

1. Exit the active zone with the valid key fob in hand. This action will lock

the doors and initiate the pre-programmed timer.

2. Re-enter the zone within the pre-programmed delay (1, 3 or 5 minutes)

to activate the SmartLock feature. As long as you are still within the pre-

programmed delay and have the valid key fob in hand, the doors will

unlock.

3. At this point, the SmartLock timer is reset and frozen. If you exit the zone

with the valid key fob, the doors will not lock and a fresh timer will start.

4. Again, if you re-enter the zone within the pre-programmed delay, the

doors will not unlock since the door is already unlocked from step 2.

5. If step 3 and 4 are repeated many times, the lock/unlock operation will

never occur thus making it convenient during loading/unloading, as long

as the doors are not opened or closed during the whole sequence.

6. Once the valid key fob remains out of the active zone longer than the

pre-programmed delay, the doors will automatically lock. At this point,

the Smartlock feature will be disabled. It is important to note that the user

can always lock the doors immediately at any moment by quickly press-

ing and releasing the key fob button (See "Manual unlocking and locking

of the vehicle" on page 7).
