Functions compatible with the 2018 Volkswagen Passat (Smart Key)

*Telematics features: The telematics features listed below (with an asterisk) ONLY apply when using SmartStart Pro.

* Odometer

3x LOCK START (Start control using OEM Remote)

3x LOCK STOP (Stop control using OEM Remote)

Accessory Activation

Arm Factory Security

Brake Status (foot brake)

Control of aftermarket alarm with OEM remote

Disarm Factory Security

Door Lock Control

Door Unlock

Driver Priority Unlock

E-Brake Status

Entry Monitoring ALL Door Pins

Entry Monitoring Hood Pin

Entry Monitoring Trunk/Hatch Pin

Fuel level/EV battery level

Ignition Activation

Remote Start Takeover

SmartStart

Start (Crank) Activation

Tach / RPM Output

Trunk / Hatch Release

933.VW09

v2.00.198.12

2018 Volkswagen Passat (Smart Key)

THVWN1 Compatible

(Sold Separately)

Introduction 3

Pre-installation and application warnings 4

Installation 5

Wiring diagram with T-Harness (THVWN1) 5

Wiring diagram 6

Key wrap options for THVWN1 7

Immobilizer Interface 8

Locating component in the vehicle 10

Vehicle connections 11

Module programming 14

(For security-only programming, see next section.) 14

Module programming for security-only installations 15

Pairing remotes 16

Connecting the module 16

8556T Temperature Sensor 16

8504D Combo Sensor 16

RF Systems 17

When used in conjunction with SmartStart 17

D2D port configuration 17

Manual transmission 18

LED diagnostics and troubleshooting 19

Soft reset 21

Hard reset 21

Tach learning procedure (not needed with Virtual Tach) 22

Initializing Virtual Tach (not needed with hardwired or data tach applications) 22

Limited lifetime consumer warranty 23

Quick reference guide 24

Contents

3933.VW09 2.00.198.12 2018 Volkswagen Passat (Smart Key)

Introduction

This guide provides information on the installation of the DS3/DS3+ and DS4/DS4+ modules as a digital solution. Using these modules in a

digital conﬁguration requires the module to be ﬂashed with vehicle-speciﬁc ﬁrmware. Refer to our website (www.directechs.com) and click

on the DIRECTLINK text in the header for additional information.

DS3/DS3+ and DS4/DS4+ modules provide an all-in-one solution for most modern vehicles, and include remote start, keyless entry, security,

and immobilizer bypass capabilities. T-harnesses may also be used in many applications for easy installation.

The following methods are available to conﬁgure modules:

• Web: www.directechs.com (DS3/DS3+ and DS4/DS4+)

• Desktop application: Directlink DT (DS3/DS3+ and DS4/DS4+)

• Mobile device: Directlink App (DS4/DS4+ only)

When ﬂashing via Directlink DT (desktop app) or via the Web, an XKloader2 will be required.

To conﬁgure via Web or DirectLink DT (desktop app):

1. Disconnect the main module from any (+) 12V power source.

2. Connect the module to your computer using the XKLoader2.

3. Follow the steps in the pop-up window that will be displayed when the module is detected.

Notes:

•Flashing via web is only possible using Internet Explorer on Windows 8, 8.1, and 10.

•This method is not compatible with any other browser (Edge, Chrome, Firefox, etc.).

•When using Windows 11 or newer, Directlink DT is mandatory.

The DS4/DS4+ module is designed to be conﬁgured using the DirectLink application through mobile devices.

To download the DirectLink mobile application, visit the Google Play or Apple store. They can also be

conﬁgured via Web and DirectLink DT. The DS4/DS4+ features are built in Bluetooth® 4.0, allowing you to

conﬁgure and control your system. The DS3/DS3+ module is not equipped with Bluetooth®, therefore is not

compatible with the DirectLink app for mobile devices.

To conﬁgure via DirectLink mobile app (Android/iOS):

1. Follow and complete the wiring diagram(s) related to your installation through the app.

2. When installation is complete, select Conﬁgure DS4/DS4+.

3. Follow the on-screen instructions.

FLASH REQUIRED!

4 White

4933.VW09 2.00.198.12 2018 Volkswagen Passat (Smart Key)

Pre-installation and application warnings

Firmware notes: This section highlights important information for this speciﬁc ﬁrmware and will assist in

pricing accordingly, as well as bringing awareness to any operational or vehicle limitations.

T-Harness

compatible THVWN1 Keys required for

programming 1Keys required for

operation 1

Important: Version 2.00 and higher use different input/output conﬁgurations and are NOT compatible with the wiring

instructions of previous versions. Updating an older version to version 2.00 or higher will require wiring modiﬁcations.

Note: Damage to the vehicle may occur if the appropriate wiring modiﬁcations are not done.

During remote start sequence, the car console will indicate "no key located". This is normal due to the key wrapped in the

installation. At vehicle takeover, the message will disappear.

This ﬁrmware does not support transponder override. One (1) programmed OEM key must be wired into the vehicle to

complete installation of a remote starter.

The optional Plug & Play THVWN1 T-Harness is sold separately.

The OBDII Diagnostic Connector features will remain the same even when the T-Harness is installed.

Important! All T-Harness wires NOT listed in the diagram are NOT required for the installation. Loose wires such as Siren

Output and Hood Input may need to be pulled from the tapped section of the T-Harness. Refer to the “Wiring diagram with

T-Harness” for more information on connections and installation instructions..

Unless speciﬁed otherwise, all connectors are displayed from the wire side, with the exception of the OBDII diagnostic

connector.

It is important to check that the fuses are positioned correctly in the module. Proper fuse positioning is displayed on each

wiring diagram.

Refer to the "Vehicle connections" following the installation diagram.

General notes: This section highlights important information for this speciﬁc ﬁrmware.

[1] The installation of an aftermarket hood pin is ONLY required on vehicles that are NOT equipped with a factory hood pin.

[2] The siren is ONLY required when enabling the security features during module ﬂashing.

[3] For Key Wrap instructions refer to the "Immobilizer interface" section.

[4] For security-only installations, refer to the "Locating components in the vehicle" section for Optional starter disable connection.

5933.VW09 2.00.198.12 2018 Volkswagen Passat (Smart Key)

Refer to "Pre-installation and application warnings" for important information, such as the description of each special note referenced in the diagram ( ).

(-) GWA Output:

Dk.Blue/Black

Cut the Dk.Blue/Black loop

labeled GWA and extend

the wires coming from the

module side.

Extend wire.

Refer to the Optional starter

disable connection section for relay

and connection details.

PKL 3 Key 2 Key 3

42 25 1

52 41 24 11

(+) Brake:

Black/Red,

pin 17

VESCM

(brown connector) (+) Brake Activation

Output: White

ESCLCM

(black connector under steering column)

Security Only

Mandatory Connections

Remote Start Only

Legend:

Remote Start + Security

22 812

4 2442

Slide to open

A module can also be used for

this installation.

IMPORTANT:

Position the

fuses correctly!

MAIN (5A) (+)

(-) RLY3 PK LIGHT (15A) (+)

(-) ACC & START (30A) (+)

(-) FLEX RLY (20A) (+)

IGN (20A) (+)

MAIN (5A) (+)

(-) RLY3/PK LIGHT (15A) (+)

PKL 1 PKL 2

NOT USED

Headlight Switch

(black connector)

NOT USED

Key 1

Ignition 2

PTS

NOT USED

Key Wrap

Hood Pin

22-pin White Connector

12-pin Black Connector

8-pin White Connector

OBDll Diagnostic

Connector

(-) Hood Input: Gray

Siren

(+) Siren Output:

Brown/Red

Optional THVWN1 (connector side view)

Starter

Kill

Relay

Parking Lights

Wiring diagram with T-Harness (THVWN1)

VESCM

(under driver’s side dash)

6933.VW09 2.00.198.12 2018 Volkswagen Passat (Smart Key)

Refer to "Pre-installation and application warnings" for important information, such as the description of each special note referenced in the diagram ( ).

HS CAN Low:

Orange/Brown, pin 14

910111213141516

12345678

Wiring diagram

FT CAN High: Orange/Green, pin 16

FT CAN Low: Orange/Brown, pin 15

(-) PTS 1: Pin 13

(-) PTS 2: Pin 4

OBDII Diagnostic

(connector side view)

HS CAN High:

Orange/Black, pin 6

CUT

42 25 1

52 41 24 11

(+) Brake:

Black/Red,

pin 17

VESCM

(brown connector)

(+) 12V:

Pin 42

(-) PTS 2 Output: Lt. Blue/Black: 10

(-) PTS 1 Output: Lt. Green/Black: 1

FT CAN High: Orange/Green: 4

FT CAN Low: Orange/Brown: 3

HS CAN High: Tan/Black: 2

HS CAN Low: Tan: 1

Parking Lights Interrupt (connector side): Blue/White: 1

(+) Parking Lights Output: Blue/Red: 2

Parking Lights Interrupt (vehicle side): Blue: 3

(+) 12 Volt Input: Red: 6 & 12

Key Wrap: Lt. Green/Red: 7

Key Wrap: Lt. Green: 8

Key Wrap: Lt. Green/White: 9

(-) Ground: Black: 10

Hood Pin

(-) Hood Input: Gray: 21

Siren

(+) Siren Output: Brown/Red: 11

(+) Brake Activation Output: White: 7

ESCLCM

(black connector under

steering column)

(-) GWA Output: Dk. Blue/Black: 9

Refer to the Optional starter

disable connection section for

relay and connection details.

The ESCLCM

connector is

located at the

Electronic Steering

Column Lock

Module

behind the

steering column

trim.

Security Only

Mandatory Connections

Remote Start Only

Legend:

Remote Start + Security

22 812

4 2442

Slide to open

A module can also be used for

this installation.

IMPORTANT:

Position the

fuses correctly!

MAIN (5A) (+)

(-) RLY3 PK LIGHT (15A) (+)

(-) ACC & START (30A) (+)

(-) FLEX RLY (20A) (+)

IGN (20A) (+)

MAIN (5A) (+)

(-) RLY3/PK LIGHT (15A) (+)

678910

12345

Parking Lights: Pin 8

(+) Parking Lights: Pin 3

Headlight Switch

(black connector)

VESCM

(under driver’s side dash)

7933.VW09 2.00.198.12 2018 Volkswagen Passat (Smart Key)

THVWN1 (main section of T-Harness, connector side view)

Key Wrap (Option 2)

OEM

Immobilizer

Receiver

Use the T-harness component labeled Key Wrap - Option 2 for PTS and Key type vehicles.

Wrap the loops around the OEM Remote and the OEM Immobilizer Receiver as shown below.

Key Wrap Option 2 with T-Harness (THVWN1)

loop

Remove

the battery

from the OEM

Remote Control.

4 2442

The loop must

be positioned

between the

Lock button

and the

Flip Key button.

Key Wrap

Key Wrap (Option 1)

THVWN1 (main section of T-Harness, connector side view)

4 2442

OEM

Immobilizer

Receiver

Remove

the battery

from the OEM

Remote Control.

loop Connect

the 2-pin

connector from

the T-Harness

into the

OEM Immobilizer

Receiver Switch.

Key Wrap Option 1 with T-Harness (THVWN1)

Use the T-harness component labeled Key Wrap - Option 1 for Key type vehicles.

Wrap the loop around the OEM Immobilizer Remote and connect to the OEM Immobilizer Receiver Switch as shown below.

Test and secure the loop before

reassembling the vehicle.

Test and secure the loops before

reassembling the vehicle.

The loop must be

positioned

between the

Lock button and

the Flip Key

button.

8933.VW09 2.00.198.12 2018 Volkswagen Passat (Smart Key)

Immobilizer interface

For vehicles with Keyless Entry you must remove battery from OEM key (the OEM remote may differ from the models shown in

the illustrations).

OEM

Immobilizer

Receiver

N/A: Green, pin 6

Black/White - NOT USED

Black/Red

Black

N/A: Violet, pin 5

N/A: Pink, pin 3

(-) GWR: Blue, pin 2

(+)12V : Red, pin 1 (+)12V

(-) Ground: Black, pin 4

556UXL is sold SEPARATELY.

Method 1: Immobilizer interface using 556UXL

IMPORTANT!: Not all OEM remotes can be inserted in 556UXL because of their size.

Make sure the key will fit, otherwise it is recommended to use a different method.

COM Relay 2: Lt. Green: 8

N.O. Relay 2: Lt. Green/Red: 7

4 2442

22 810 12

Note: The discontinued 556U or 556UW can

still be used for the installation.

Move 556UXL loop as close to the

front of ignition cylinder (OEM

Immobilizer Receiver) as possible.

Test and secure mounted loop

before reassembling the vehicle.

For vehicles with Keyless

Entry, you MUST remove the

battery from the OEM key.

(Your OEM remote

may differ from the models

shown in the illustrations.)

Method 2: Key Wrap

- Make 4-6 loops and place them as close to the front of key port (OEM Immobilizer Receiver) as possible.

- Test and secure mounted loops before reassembling the vehicle.

- Make 4-6 loops and place them around the front of the plastic body of the vehicle’s coded key as shown above.

- When possible use valet key for key wrap, if blade key is used, battery must be removed.

4-6 loops

COM Relay 2: Lt. Green: 8

N.O. Relay 2: Lt. Green/Red: 7

OEM

Immobilizer

Receiver

Remove battery from

OEM Remote Control

4-6 loops

4 2442

22 810 12

Note: OEM immobilizer receiver is located on the

underside of the steering column, where the ignition

switch would normally be.

9933.VW09 2.00.198.12 2018 Volkswagen Passat (Smart Key)

- Make 4-6 loops and place them as close to the front of key port (OEM Immobilizer Receiver) as possible.

- Test and secure mounted loops before reassembling the vehicle.

- Make 4-6 loops and place them around the front of the plastic body of the vehicle’s coded key as shown above.

Method 3: Key wrap - Alternative

Note:

4 2442

22 810 12

COM Relay 2: Lt. Green: 8

NO Relay 2: Lt. Green/Red: 7

NC Relay 2: Lt. Green/White: 9

Immobilizer ECU

Remove battery from

OEM Remote Control

4-6 loops

Note: OEM immobilizer receiver is located on the

underside of the steering column, where the ignition

switch would normally be.

Cut

10 933.VW09 2.00.198.12 2018 Volkswagen Passat (Smart Key)

Locating components in the vehicle

Important: When flashing your module for Security Only, the Ground When Armed (GWA)

function is pre-configured. When flashing your module for Remote Start & Security, you must

manually assign the designated output to Anti Grind (AG) Starter Kill.

(Applicable to CORE 194+.)

22 812

4 2442

86 85

87a

Refer to the

Vehicle connections

section for wire

and connector

details.

(-) Ground When Armed (GWA) Output: Dk.Blue/Black: 9

Starter (connector side)

Starter (vehicle side)

(+) Ignition

Cut

Security Only

Mandatory Connections

Remote Start Only

Legend:

Remote Start + Security

Optional starter disable connection

1A Diode (1N4002+)

When using an external relay, use a 1N4002 diode or larger.

Otros manuales para DS3+

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Accesorios para automóviles de Directed

Directed

Directed Directechs DB3 Manual de usuario

Directed

Directed Directechs DB3 Manual de usuario

Directed

Directed Xpresskit DBALL2 Manual de usuario

Directed

Directed DIRECTECHS HONDA4 Manual de usuario

Directed

Directed Directechs DB3 Manual de usuario

Directed

Directed Directechs DB3 Manual de usuario

Directed

Directed Directechs DB3 Manual de usuario

Directed

Directed DS3+ Manual de usuario

Directed

Directed Directechs DB3+ Manual de usuario

Directed

Directed DS3+ Manual de usuario

Directed

Directed DS3+ Manual de usuario

Directed

Directed Directechs DB3 Manual de usuario

Directed

Directed 403.CHRYSLER6 v2.17 Manual de usuario

Directed

Directed DIRECTWIRE DIRECTECHS 933.TL14 Manual de usuario

Directed

Directed VOXX DEI 403.VW14 v2.11 Manual de usuario

Directed

Directed Directechs VW08 Manual de usuario

Directed

Directed Directechs DB3 Manual de usuario

Directed

Directed VW02 Manual de uso y cuidado

Directed

Directed Directechs DB3 Manual de usuario

Directed

Directed DIRECTECHS HYUNDAI11 Manual de usuario

Directed

Directed DIRECTECHS CHRYSLER8 Manual de usuario

Directed

Directed 403.CHRYSLER6 v2.17 Manual de usuario

Directed

Directed Directechs DS3 Manual de usuario

Directed

Directed Directechs DB3 Manual de usuario

Manuales populares de Accesorios para automóviles de otras marcas

James Baroud

James Baroud Odyssey Manual de usuario

Motorola

Motorola i50sx Manual de usuario

Yakima

Yakima 9MM STANDARD BIKE MOUNT Manual de usuario

Feniex

Feniex T3 Manual de usuario

Renault

Renault 77 11 423 180 Manual de usuario

Kia

Kia E8300-4D000 Manual de usuario

Brink

Brink 756843 Manual de usuario

Whispbar

Whispbar K085W Manual de usuario

v.link

v.link CI-VL2-PC-HSD Manual de usuario

Viking

Viking Stack-Rack Guía de configuración rápida

Aries

Aries 203015 Manual de usuario

Choetech

Choetech AT0005 Manual de usuario

ZZ2

ZZ2 ZZAIR-PRO Manual de usuario

Holman

Holman 4A80L Manual de usuario

Thule

Thule 2075 Manual de usuario

Motorola

Motorola T325 Manual de usuario

TAUBENREUTHER

TAUBENREUTHER 16-3950 Guía de instalación

DV8

DV8 FBJL-02 Manual de usuario
