INSTALLATION GUIDE
DB3
2021 Kia K5 2.5L Turbo (Smart Key). 403.HKRS03 1.02
© 2021 Directed, Vista CA
This product is intended for installation by a professional installer only! Attempts to install this
product by a person other than a trained professional may result in severe damage to a vehicle’s
electrical system and components.
Introduction 3
Vehicle function compatibilities 4
Pre-installation and application warnings 5
Wiring diagram 6
Locating components in the vehicle 7
Vehicle connections 8
Module programming 10
Connecting the module 11
LED diagnostics and troubleshooting 12
Soft reset 14
Hard reset 14
Feature programming 15
Feature and option list 16
Limited one year consumer warranty 17
Quick Reference Guide (customer copy) 18
Contents
3403.HKRS03 1.02 2021 Kia K5 2.5L Turbo (Smart Key)
©2021 VOXX•DEI LLC. All rights reserved.
Introduction
DB3 is an all-in-one door lock and override module.
Warning!
This module can only be flashed and configured using DirectLink at www.directechs.com or using the Directechs
Mobile application for smartphones. Refer to “Connecting the module” for more information.
4403.HKRS03 1.02 2021 Kia K5 2.5L Turbo (Smart Key)
©2021 VOXX•DEI LLC. All rights reserved.
Vehicle function compatibilities
This section lists all the functions compatible with this vehicle for the installation illustrated in this guide.
Parking Lights Control
Arm Factory Security
Disarm Factory Security
Door Lock Control
Door Unlock
Driver Priority Unlock
Trunk / Hatch Release
Control of aftermarket alarm with OEM remote
Immobilizer Bypass-Data No Key Req'd
RAP Shut Down (Retained ACC Power)
Remote Start Ready
Remote Start Takeover
SmartStart
Tach / RPM Output
Entry Monitoring ALL Door Pins
Entry Monitoring Hood Pin
Entry Monitoring Trunk/Hatch Pin
Factory Alarm Trigger Monitoring
Brake Status (foot brake)
Door Locks Status
E-Brake Status
Ignition Status
5403.HKRS03 1.02 2021 Kia K5 2.5L Turbo (Smart Key)
©2021 VOXX•DEI LLC. All rights reserved.
Pre-installation and application warnings
START HERE This section highlights important information for this specific firmware and will assist in pricing accordingly, as
well as bringing awareness to any operational or vehicle limitations.
Compatibilities and Requirements
T-Harness
compatible T-Harness is not compatible.
AUX
Keys
required for
programming 1Keys required
for operation 0
Vehicle Takeover Refer to the Quick Reference Guide section for more details.
Firmware notes
Runtime:
•This firmware has a 10 minutes runtime and cannot be modified.
•The parking lights will flash every two seconds during runtime, by default. If this does not occur, you can select a different option in
the Data Feature Configuration when flashing your module.
SmartStart Compatible:SmartStart is equipped with D2D, which means it can be connected to an interface module.
Unless specified otherwise, all connectors are displayed from the wire side, with the exception of the OBDII diagnostic connector.
Refer to the "Vehicle connections" following the installation diagram.
Conditions and Limitations
Vehicle must be locked and armed for at least 45 seconds before remote starting.
The remote start system will not work in the following conditions:
The vehicles ignition has not been cycled for 4 days or more.
The ignition is on.
The alarm system is triggered.
The doors/hood are open.
The transmission is not in Park (P).
The vehicle battery voltage is too low.
The service engine light is on.
Footnotes
[1] Hood pin: The installation of an aftermarket hood pin is only required on vehicles that are not equipped with a factory hood pin, or if
not supported in data.
6403.HKRS03 1.02 2021 Kia K5 2.5L Turbo (Smart Key)
©2021 VOXX•DEI LLC. All rights reserved.
Refer to "Pre-installation and application warnings" for important information, such as the description of each special note referenced in the diagram ( ).
Wiring diagram
D2D Port
1412
10 42
XKD2D65
(+) 12V Input
(-) Ground
Hood Pin
(-) Hood Pin Input
(+) Ignition Input/Output
(+) Ignition Status Output: Gray/Black: 7
(+) 12V: Red, pin 1
IGPM Plug (A)
(black connector
in dash fuse box)
12 3 4
HS CAN 2 High: Tan/Black: 3
HS CAN 2 Low: Tan : 4
HS CAN 4 High: Orange/Green: 5
HS CAN 4 Low: Orange/Brown: 6
B-CAN High:
Green, pin 14
B-CAN Low:
Orange, pin 13
169
81
1314
IGPM Plug (G)
(white 16-pin conn.
rear dash fuse box) 16
15
M-CAN High:
Yellow, pin 16
M-CAN Low:
Black, pin 15
8403.HKRS03 1.02 2021 Kia K5 2.5L Turbo (Smart Key)
©2021 VOXX•DEI LLC. All rights reserved.
Vehicle connections
The connection information listed below is specific to the 2021 Kia K5 2.5L Turbo (Smart Key). Refer to “Pre-installation and application warnings” for a list of important
notes.
Data 14-pin blue connector (H1)
Module Connects To
Conn./Pin Color Description Wire Location (+/-) Wire Color
H1/1 Light Green No Connection No Connection
H1/2 Violet/Yellow No Connection No Connection
H1/3 Tan/Black (DATA) HS CAN 2 High ICU Junction Block-Dash Fuse Box, rear, white 16 pin plug (G), pin
14
Data Green (B-CAN)
H1/4 Tan (DATA) HS CAN 2 Low ICU Junction Block-Dash Fuse Box, rear, white 16 pin plug (G), pin
13
Data Orange (B-CAN)
H1/5 Orange/Green (DATA) HS CAN 4 High ICU Junction Block-Dash Fuse Box, rear, white 16 pin plug (G), pin
16
Data Yellow (M-CAN)
H1/6 Orange/Brown (DATA) HS CAN 4 Low ICU Junction Block-Dash Fuse Box, rear, white 16 pin plug (G), pin
15
Data Black (M-CAN)
H1/7 Brown Relay N.O. No Connection No Connection
H1/8 Yellow Relay COM. No Connection No Connection
H1/9 Orange/Yellow Relay N.C. No Connection No Connection
H1/10 Orange/Red Relay N.C. No Connection No Connection
H1/11 Yellow/Red Relay COM. No Connection No Connection
H1/12 Brown/Red Relay N.O. No Connection No Connection
H1/13 Red (+) W2W Only - 12 Volt Remote Starter
H1/14 Black (-) W2W Only - Ground Remote Starter
Output 12-pin red connector (H2)
Module Connects To
Conn./Pin Color Description Wire Location (+/-) Wire Color
H2/1 Black/White (-) W2W Only - E-Brake Output Remote Starter
H2/2 Green/Black No Connection No Connection
H2/3 Green/White (-) W2W Only - Door Output Remote Starter
H2/4 Red/Black (-) W2W Only - Trunk Output Remote Starter
H2/5 Violet/White (AC) W2W Only - Tach Output Remote Starter
H2/6 Gray (+) W2W Only - Brake Output Remote Starter
H2/7 Gray/Black (+) Ignition Status Output Remote Starter
H2/8 Violet/Green No Connection No Connection
H2/9 Violet/Brown No Connection No Connection
H2/10 Yellow/Black No Connection No Connection
H2/11 Orange/Black No Connection No Connection
H2/12 Blue/Red (-) W2W Only - Hood Output Remote Starter
9403.HKRS03 1.02 2021 Kia K5 2.5L Turbo (Smart Key)
©2021 VOXX•DEI LLC. All rights reserved.
Input 10-pin black connector (H3)
Module Connects To
Conn./Pin Color Description Wire Location (+/-) Wire Color
H3/1 Green (-) W2W Only - Lock Input Remote Starter
H3/2 Blue (-) W2W Only - Unlock Input Remote Starter
H3/3 Red/White (-) W2W Only - Trunk Input Remote Starter
H3/4 White/Violet No Connection No Connection
H3/5 Violet/Black No Connection No Connection
H3/6 White/Black No Connection No Connection
H3/7 Pink/White (+) W2W Only - Pk Light Input Remote Starter
H3/8 Violet (+) W2W Only - Starter Input Remote Starter
H3/9 Pink (+) W2W Only - Ignition Input Remote Starter
H3/10 Blue/White (-) W2W Only - Ground When Running (Status) Input Remote Starter
D2D 4-pin white connector (H4)
Module
Conn./Pin Color Description
H4/1 Blue (Data) TX
H4/2 Black (-) Ground
H4/3 Green (Data) RX
H4/4 Red (+) 12 Volt
RF 2-pin white connector (H5)
Module
Conn./Pin Color Description
H5/1 N/A No Connection
H5/2 N/A No Connection
Additional remote start connections
(Not all of these connections may be required for your installation. Refer to the wiring diagram for vehicle-specific connections.)
Wire Connects To
Wire Location (+/-) Wire Color
12 Volts ICU Junction Block-Dash Fuse Box, black 4 pin plug
(A), pin 1
+ Red (50A)
Ground (chassis ground)
Hood Pin ICU Junction Block-Dash Fuse Box, white 58 pin plug
(B), pin 25
- Green
10 403.HKRS03 1.02 2021 Kia K5 2.5L Turbo (Smart Key)
©2021 VOXX•DEI LLC. All rights reserved.
Module programming
Refer to “LED diagnostics and troubleshooting” for more information and for troubleshooting purposes.
1Connect the 10-pin, 12-pin, and 14-pin harnesses to DB3 and wait until the LED turns
ON solid red.
2Press the PTS button twice to turn the ignition ON.
The LED will flash green quickly.
3Wait for the LED will turn on solid green for 3 seconds and then turn off.
You have successfully completed the module programming sequence.
