INSTALLATION GUIDE
DB3
2012 Toyota Avalon (G Key). 403.TL5 4.00
© 2021 Directed, Vista CA
This product is intended for installation by a professional installer only! Attempts to install this
product by a person other than a trained professional may result in severe damage to a vehicle’s
electrical system and components.
Introduction 3
Vehicle function compatibilities 3
Pre-installation and application warnings 4
Key type 4
Wiring diagram 5
Locating components in the vehicle 6
Vehicle connections 7
Connecting the module 9
Module programming 10
Important! A master key is required to program the module to the vehicle. 10
LED diagnostics and troubleshooting 11
Soft reset 13
Hard reset 13
Feature programming 14
Feature and option list 15
Limited one year consumer warranty 16
Quick reference guide 17
Contents
3403.TL5 4.00 2012 Toyota Avalon (G Key)
©2021 VOXX•DEI LLC. All rights reserved.
Introduction
DB3 is an all-in-one door lock and override module.
Warning!
This module can only be flashed and configured using DirectLink at www.directechs.com or using the Directechs
Mobile application for smartphones. Refer to “Connecting the module” for more information.
Vehicle function compatibilities
This section lists all the functions compatible with this vehicle for the installation illustrated in this guide.
Arm Factory Security
Disarm Factory Security
Door Lock Control
Door Unlock
Driver Priority Unlock
Trunk / Hatch Release
Immobilizer Bypass-Data No Key Req'd
Remote Start Takeover
SmartStart
Tach / RPM Output
Entry Monitoring ALL Door Pins
Entry Monitoring Driver Door Pin
Entry Monitoring Hood Pin
Entry Monitoring Trunk/Hatch Pin
Brake Status (foot brake)
E-Brake Status
Ignition Status
4403.TL5 4.00 2012 Toyota Avalon (G Key)
©2021 VOXX•DEI LLC. All rights reserved.
Pre-installation and application warnings
Firmware notes: This section highlights important information for this specic rmware and will assist in
pricing accordingly, as well as bringing awareness to any operational or vehicle limitations.
T-Harness
compatible
Keys required for
programming 1Keys required for
operation 0
Unless specied otherwise, all connectors are displayed from the wire side, with the exception of the OBDII diagnostic
connector.
Refer to the "Vehicle connections" following the installation diagram.
Connect the hood switch if factory equipped. If NOT, a hood switch must be installed and connected to the remote starter.
Autolights Interrupt ONLY required if vehicles are equipped with Autolights.
OR
AUX1 and AUX2 are only available to control sliding doors on the Sienna using rmware 3.00 +.
General notes: This section highlights important information for this specic rmware.
[1] Tach wire is an optional connection required on some remote starters, which do not support a tach signal in D2D
[2] The installation of an aftermarket hood pin is ONLY required on vehicles that are NOT equipped with a factory hood pin or
NOT supported in data.
[3] Autolights Interrupt ONLY required if vehicles are equipped with Autolights.
Key type
Some Toyota 2010+ models have different encryption types. Please look at your key blade and identify the markings.
G-stamped keys Standard Key
H-stamped keys
H
For vehicles with H-stamped keys, see
the TL10 firmware.
For vehicles with G-stamped keys, see
the TL5 & TL7 firmware.
For vehicles with dot-stamped keys,
see the TL11 firmware.
Note: Some replacement keys
may not have any markings on
the key.
5403.TL5 4.00 2012 Toyota Avalon (G Key)
©2021 VOXX•DEI LLC. All rights reserved.
Refer to "Pre-installation and application warnings" for important information, such as the description of each special note referenced in the diagram ( ).
Wiring diagramWiring diagram
D2D Port
(-) Ground (-) Ground
(+) Accessory
(+) 12V Input
HS CAN High: Tan/Black: 3
TX DATA Violet/Yellow: 2
HS CAN Low: Tan: 4
SIL DATA: Brown: 7
DATA Input: Yellow: 8
RDA: Orange/Yellow: 9
Autolights Interrupt (veh. side): Orange/Red: 10
Autolights Interrupt (conn. side): Yellow/Red: 11
DATA Output: Yellow/Black: 10
(-) Keysense Output: Green/Black: 2
RX DATA: Orange/Black: 11
1412
10 42
6: White/Black: (-) Keysense Input
Ignition, Accessory, Starter
& (+) 12V wires at ignition
switch, 8-pin connector
Refer to Vehicle
connections.
(-) Parking Lights Output
(+) Ignition 2 Output
(+) Ignition 1 Output
(+) Starter 2 Output
(+) Starter 1 Output
XKD2D65
456
161718 131415
10
1112
123
789
1920
(-) Parking Lights: Blue, pin 18
124567 3
Black 7-pin conn.
(transponder key amplifier
at ignition switch)
White 20-pin conn.
(headlight switch)
White 4-pin conn.
(key switch)
1
34
2
Autolights Interrupt:
Orange, pin 19
16
8
9
1
Diagnostic
Connector OBDII
(connector side view)
HS CAN High: Pink, pin 6
SIL: Violet, pin 7
CUT
(AC) Tach Input
(AC) Tach Output: Violet/White: 5
67
1234
8 5
RDA: Lt.Green, pin 12
Body ECU Connector
(back of dash fuse box)
41
23
8910 7 56
141516 13 11
12
Keysense:
Black or Tan, pin 2
TX:
Brown
or Gray,
pin 5
RX:
Lt.Green,
pin 4
HS CAN Low:
White or Tan, pin 14
(-) Hood Pin Input
Hood Pin
7403.TL5 4.00 2012 Toyota Avalon (G Key)
©2021 VOXX•DEI LLC. All rights reserved.
Vehicle connections
The connection information listed below is specific to the 2012 Toyota Avalon (G Key). Refer to “Pre-installation and application warnings” for a list of important notes.
Data 14-pin blue connector (H1)
Module Connects To
Conn./Pin Color Description Wire Location (+/-) Wire Color
H1/1 Light Green No Connection No Connection
H1/2 Violet/Yellow (DATA) TXCT Transponder Key Amplifier on ignition switch, black 7 pin plug, pin
5
data gray
H1/3 Tan/Black (DATA) HS CAN High data link connector, white 16 pin plug, pin 6 data pink
H1/4 Tan (DATA) HS CAN Low data link connector, white 16 pin plug, pin 14 data beige
H1/5 Orange/Green No Connection No Connection
H1/6 Orange/Brown No Connection No Connection
H1/7 Brown Relay N.O. SIL data link connector, white 16 pin plug, pin 7 data violet
H1/8 Yellow Relay COM. Keyless Data Input Output 12-pin red connector - Pin 10
H1/9 Orange/Yellow Relay N.C. RDA Body ECU on back of dash fuse box, white 16 pin plug, pin 12 data lt. green
H1/10 Orange/Red Relay N.C. Auto Light Interrupt (Veh. side) [3] headlight switch, white 20 pin plug, pin 19 cut orange
H1/11 Yellow/Red Relay COM. Auto Light Interrupt (conn. side) [3] headlight switch, white 20 pin plug, pin 19 cut orange
H1/12 Brown/Red Relay N.O. No Connection No Connection
H1/13 Red (+) W2W Only - (+) 12 Volt Input ignition switch, white 8 pin plug, pin 7 + black (30A)
H1/14 Black (-) W2W Only - (-) Ground (chassis ground)
Output 12-pin red connector (H2)
Module Connects To
Conn./Pin Color Description Wire Location (+/-) Wire Color
H2/1 Black/White (-) W2W Only - E-Brake Output Remote Starter
H2/2 Green/Black (-) Keysense Output key switch, white 4 pin plug, pin 2 - beige
H2/3 Green/White (-) W2W Only - Door Output Remote Starter
H2/4 Red/Black (-) W2W Only - Trunk Output Remote Starter
H2/5 Violet/White (AC) W2W Only - Tach Output [1] Remote Starter
H2/6 Gray (+) W2W Only - Brake Output Remote Starter
H2/7 Gray/Black No Connection No Connection
H2/8 Violet/Green No Connection No Connection
H2/9 Violet/Brown No Connection No Connection
H2/10 Yellow/Black (Data) Keyless Data Data 14-pin blue connector - Pin 8
H2/11 Orange/Black (Data) RX Transponder Key Amplifier on ignition switch, black 7 pin plug, pin
4
data lt. green
H2/12 Blue/Red (-) W2W Only - Hood Output Remote Starter
8403.TL5 4.00 2012 Toyota Avalon (G Key)
©2021 VOXX•DEI LLC. All rights reserved.
Input 10-pin black connector (H3)
Module Connects To
Conn./Pin Color Description Wire Location (+/-) Wire Color
H3/1 Green (-) W2W Only - Lock Input Remote Starter
H3/2 Blue (-) W2W Only - Unlock Input Remote Starter
H3/3 Red/White (-) W2W Only - Trunk Input [2] Remote Starter
H3/4 White/Violet (-) Right Sliding Door Remote Starter
H3/5 Violet/Black (-) Left Sliding Door Remote Starter
H3/6 White/Black (-) Keysense Input key switch, white 4 pin plug, pin 2 - beige
H3/7 Pink/White No Connection No Connection
H3/8 Violet No Connection No Connection
H3/9 Pink No Connection No Connection
H3/10 Blue/White (-) W2W Only - Ground When Running (Status) Input Remote Starter
D2D 4-pin white connector (H4)
Module
Conn./Pin Color Description
H4/1 Blue (Data) TX
H4/2 Black (-) Ground
H4/3 Green (Data) RX
H4/4 Red (+) 12 Volt
RF 2-pin white connector (H5)
Module
Conn./Pin Color Description
H5/1 N/A No Connection
H5/2 N/A No Connection
Additional remote start connections
(Not all of these connections may be required for your installation. Refer to the wiring diagram for vehicle-specific connections.)
Wire Connects To
Wire Location (+/-) Wire Color
12 Volts ignition switch, white 8 pin plug, pin 7 + black (30A)
Accessory ignition switch, white 8 pin plug, pin 3 + gray
Hood Pin hood switch, black 2 pin plug, pin 1 - blue
Ignition ignition switch, white 8 pin plug, pin 6 + yellow
Parking Lights - headlight switch, white 20 pin plug, pin 18 - blue
Second Ignition ignition switch, white 8 pin plug, pin 4 + green
Second Starter ignition switch, white 8 pin plug, pin 1 + red
Starter ignition switch, white 8 pin plug, pin 8 + blue
Tachometer left of steering column, white 18 pin plug, pin 17 ac black
9403.TL5 4.00 2012 Toyota Avalon (G Key)
©2021 VOXX•DEI LLC. All rights reserved.
Connecting the module
Important!
Make all the required connections to the vehicle, as described in this guide, and double check to ensure everything is correct prior
to moving onto programming.
Warning! To take advantage of advanced features, you must use DirectLink 4.5 (and higher) or the Directechs Mobile application.
Flashing a module using your computer:
1. Connect the interface module to your computer using the XKLoader2.
2. Go to www.directechs.com using Internet Explorer, and select the Flash Module button.
3. Follow the instructions to select your vehicle, installation type, and configure your options.
4. Once you have configured the firmware options, click on the FLASH button.
Flashing a module using your smartphone or tablet:
1. Connect the interface module to your XKLoader3.
2. Launch the Directechs Mobile app on your smartphone or tablet.
3. Select FLASH YOUR MODULE and follow the on screen instructions.
When the flashing operation is successful, you can proceed with the instructions below.
D2D installation
Recommended: Connect the 10-pin, 12-pin and 14-pin harnesses to the module, then
connect the 4-pin D2D harness. 3rd
(14-pin)
1st
(10-pin)
4th
(D2D)
2nd
(12-pin)
OR
W2W installation
If required: Connect the 10-pin and 12-pin harnesses to the module, then connect the 14-pin
harness to the module. 3rd
(14-pin)
1st
(10-pin)
2nd
(12-pin)
10 403.TL5 4.00 2012 Toyota Avalon (G Key)
©2021 VOXX•DEI LLC. All rights reserved.
Module programming
Refer to “LED diagnostics and troubleshooting” for more information and for troubleshooting purposes.
Important! A master key is required to program the module to the vehicle.
1Wait until the LED turns ON solid red.
2Enable the CAN bus by pressing the Unlock button on the OEM remote, the Unlock
button on the inside of the door, or by pressing and releasing the door pin switch. The
LED starts flashing orange quickly.
3
Note: To skip bypass, wait until the LED turns ON solid orange, then press the
programming button 5 times, before proceeding with the next step to continue
programming. This will only program convenience features then proceed to step 6.
Insert the key in the ignition barrel. The LED turns OFF. Wait until the LED turns back
ON solid orange to indicate the key is in learning mode (this may take up to 20
seconds).
Note: If the LED turns ON solid green, then shuts OFF, a module has already been
programmed into the vehicle.
4Turn the key to the ON position. The LED starts flashing green quickly after a few
seconds (this may take up to 5 seconds).
5Turn the key to OFF, and removethe keyfrom the ignition barrel. The LED keeps
flashing green quickly. Wait for the LED to start flashing orange slowly (this may take
up to 20 seconds).
6Insert and turn the key to ON, then OFF, before removing the key. The LED starts
flashing green slowly.
7
Wait for LED to turn ON solid green or orange for 3 seconds, before shutting OFF (this
may
take up to 90 seconds).
Green: The bypass was successfully programmed.-
Orange: The bypass programming was skipped in favor of only programming the
convenience features.
-
You have successfully completed the module programming sequence.
Otros manuales para Directechs DB3
82
Tabla de contenidos
Otros manuales de Accesorios para automóviles de Directed
Directed
Directed Directechs HYUNDAI1 Manual de usuario
Directed
Directed Directechs DB3 Manual de usuario
Directed
Directed VOXX DEI 933.VW14 v2.11.198.12 Manual de usuario
Directed
Directed DIRECTECHS CHRYSLER8 Manual de usuario
Directed
Directed Directechs DB3 Manual de usuario
Directed
Directed Directechs DB3 Manual de usuario
Directed
Directed VW09 Manual de usuario
Directed
Directed Directechs DB3 Manual de usuario
Directed
Directed 403.SUBARU1 Manual de usuario
Directed
Directed XpressKit DBALL Manual de usuario
Directed
Directed 403.SUBARU2 Manual de usuario
Directed
Directed Directechs MIT2 Manual de usuario
Directed
Directed DS3+ Manual de usuario
Directed
Directed 403.CHRYSLER6 v2.17 Manual de usuario
Directed
Directed Directechs DB3 Manual de usuario
Directed
Directed 403.NISS4HT 2.39 RSR Manual de usuario
Directed
Directed Directechs HYUNDAI2 Manual de usuario
Directed
Directed Xpresskit DBALL2 Manual de usuario
Directed
Directed Directechs HYUNDAI8 Manual de usuario
Directed
Directed 403.SUBARU11 Manual de usuario
