Directed Electronics 4103 Series Manual de usuario

Model 4103

Remote Start

Owner’s Guide

G4103L 2008-07

Contents

Government Regulations ....................................................................................5

Warning! Safety first .........................................................................................7

What is Included ............................................................................................9

Important Information ........................................................................................9

System Maintenance .................................................................................9

Your Warranty..........................................................................................9

Transmitter Functions........................................................................................10

Standard Configuration ...........................................................................10

Using Your System .........................................................................................11

Locking..................................................................................................11

Unlocking ..............................................................................................11

Disabling the Starter Kill without a transmitter. ............................................11

Remote Start...........................................................................................12

Rear Defogger........................................................................................13

Valet Take-Over ......................................................................................14

Car finder..............................................................................................15

Timer Mode ...........................................................................................15

Starter Anti-Grind Circuitry.......................................................................16

Disabling the Remote Start system .............................................................16

Rapid Resume Logic ........................................................................................17

Programming options.......................................................................................18

Glossary of Terms............................................................................................19

Convenience Expansions .................................................................................20

Quick Reference Guide....................................................................................23

Limited lifetime consumer warranty ....................................................................25

Government Regulations

This device complies with Part 15 of FCC rules. Operation is subject to the fol-

lowing two conditions: (1) This device may not cause harmful interference, and

(2) This device must accept any interference received, including interference that

may cause undesirable operation.

This equipment has been tested and found to comply with the limits for a class B

digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to

provide reasonable protection against harmful interference in a residential instal-

lation. This equipment generates and can radiate radio frequency energy and,

if not installed and used in accordance with the instruction manual, may cause

harmful interference to radio communications. However, there is no guarantee

that interference will not occur in a particular installation. If this equipment does

cause harmful interference to radio or television, which can be determined by

turning the equipment OFF and ON, the user is encouraged to try to correct the

interference by one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit different from that to which

the receiver is connected.

• Consult the dealer or an experienced radio / TV technician for help.

This device complies with the Industry Canada Radio Standards Speciﬁcation

RSS 210. Its use is authorized only on a no-interference, no-protection basis; in

other words, this device must not be used if it is determined that it causes harm-

ful interference to services authorized by IC. In addition, the user of this device

must accept any radio interference that may be received, even if this interference

could affect the operation of the device.

Warning:

Changes or modications not expressly approved by the party responsible for

compliance could void the user’s authority to operate this device.

Warning! Safety ﬁrst

The following safety warnings must be observed at all times:

Due to the complexity of this system, installation of this product must only be

performed by an authorized Directed dealer.

When properly installed, this system can start the vehicle via a command signal

from the remote control transmitter. Therefore, never operate the system in an

enclosed area or partially enclosed area without ventilation (such as a garage).

When parking in an enclosed or partially enclosed area or when having the

vehicle serviced, the remote start system must be disabled using the installed

toggle switch. It is the user’s sole responsibility to properly handle and keep out

of reach from children all remote control transmitters to assure that the system

does not unintentionally remote start the vehicle. THE USER MUST INSTALL A

CARBON MONOXIDE DETECTOR IN OR ABOUT THE LIVING AREA ADJA-

CENT TO THE VEHICLE. ALL DOORS LEADING FROM ADJACENT LIVING

AREAS TO THE ENCLOSED OR PARTIALLY ENCLOSED VEHICLE STORAGE

AREA MUST AT ALL TIMES REMAIN CLOSED. These precautions are the sole

responsibility of the user.

Use of this product in a manner contrary to its intended mode of operation may

result in property damage, personal injury, or death. (1) Never remotely start the

vehicle with the vehicle in gear, and (2) Never remotely start the vehicle with

the keys in the ignition. The user must also have the neutral safety feature of the

vehicle periodically checked, wherein the vehicle must not remotely start while

the car is in gear. This testing should be performed by an authorized Directed

dealer in accordance with the Safety Check outlined in the product installation

guide. If the vehicle starts in gear, cease remote start operation immediately and

consult with the authorized Directed dealer to x the problem.

After the remote start module has been installed, contact your authorized dealer

to have him or her test the remote start module by performing the Safety Check

outlined in the product installation guide. If the vehicle starts when performing

the Neutral Safety Shutdown Circuit test, the remote start unit has not been

properly installed. The remote start module must be removed or the installer must

properly reinstall the remote start system so that the vehicle does not start in gear.

All installations must be performed by an authorized Directed dealer.

OPERATION OF THE REMOTE START MODULE IF THE VEHICLE STARTS IN

GEAR IS CONTRARY TO ITS INTENDED MODE OF OPERATION. OPERAT-

ING THE REMOTE START SYSTEM UNDER THESE CONDITIONS MAY RESULT

IN PROPERTY DAMAGE OR PERSONAL INJURY. YOU MUST IMMEDIATELY

CEASE THE USE OF THE UNIT AND SEEK THE ASSISTANCE OF AN AU-

THORIZED Directed DEALER TO REPAIR OR DISCONNECT THE INSTALLED

REMOTE START MODULE. DIRECTED WILL NOT BE HELD RESPONSIBLE OR

PAY FOR INSTALLATION OR REINSTALLATION COSTS.

This product is designed for fuel injected, automatic transmission ve-

hicles only. Use of this product in a standard transmission vehicle is

dangerous and contrary the product's intended use.

What is Included

The control module•

An HX receiver/antenna•

Two 4-button transmitters (P/N 474L)•

A push-button Valet switch•

Your warranty card•

A shut-down toggle switch•

Important Information

Congratulations on the purchase of your remote start keyless entry sys-

tem. This system has been designed to provide years of trouble-free

operation. By carefully reading this owner’s guide prior to using your

system, you will maximize the use of this system and its features. Addi-

tional or replacement copies of this guide can be printed by accessing

the Directed Electronics internet website at

www.directed.com

➢System Maintenance

The system requires no speciﬁc maintenance. Your remote is powered

by a miniature 3V lithium battery that lasts approximately one year

under normal use. When the battery weakens, the LED on the remote

will dim and operating range will be reduced.

➢Your Warranty

Your warranty card must be completely ﬁlled out and returned within

10 days of purchase. Your product warranty will not be honored if your

warranty card is not returned. Make sure that you receive the warranty

card from your dealer.

Transmitter Functions

The receiver uses a computer-based learn routine to learn the transmitter

buttons. The transmitter buttons indicated in all of the instructions in this

manual correspond to a Standard Conﬁguration transmitter.

➢Standard Conﬁguration



Button

The locking and panic functions are controlled by pressing



on the

transmitter for one second.



Button

The unlocking function is controlled by pressing on the transmitter

for one second.

Button

Silent Mode™ and an optional auxiliary function are controlled by

pressing . Silent Mode works by pressing for less than one

second. The optional trunk release output is controlled by pressing and

holding for 1.5 seconds.

Button

The remote start function of your system is controlled by pressing this

button for one second.

Buttons

+ +

When simultaneously pressed these buttons control the rear window

defogger during remote starting.
