INSTRUCTION MANUAL

For domestic household use only.

Willowbrook 2kW Opti-myst

Portable Electric Stove

Model: WLL20-AU

08/53726/1 Issue 7

OCN 11905

IMPORTANT

THESE INSTRUCTIONS SHOULD BE READ CAREFULLY AND

RETAINED FOR FUTURE REFERENCE.

CAUTION: FAILURE TO FOLLOW THESE INSTRUCTIONS MAY CAUSE INJURY AND/

OR DAMAGE AND MAY INVALIDATE YOUR WARRANTY

Please read the operating instructions carefully before using your product for

the first time and keep them in a safe place.

• When using electrical appliances, basic precautions should always be

followed to reduce the risk of fire, electrical shock and injury to persons,

including the following:

• If the appliance is damaged, check with the supplier before installation and

operation.

- Do not use outdoors.

- Do not use in the immediate surroundings of a bath, shower or a

swimming pool.

- Do not use this heater if it has been dropped.

- Do not use if there are visible signs of damage to the heater.

- Use this heater on a horizontal and stable surface, or fix it to the

wall, as applicable.

• Do not locate the appliance immediately below a fixed socket outlet or

connection box.

• This appliance is not intended for use by persons (including children) with

reduced physical, sensory or mental capabilities, or lack of experience

and knowledge, unless they have been given supervision or instruction

concerning use of the appliance by a person responsible for their safety.

• Children should be supervised to ensure that they do not play with the

appliance.

• Do not use this appliance in series with a thermal control, a program

controller, a timer or any other device that switches on the heat

automatically, since a fire risk exists when the appliance is accidentally

covered or dis-placed.

• In the event of a fault, unplug the appliance.

• Unplug the appliance when not required for long periods.

• This product is only intended for INDOOR RESIDENTIAL applications only.

• DO NOT cover cord with carpeting, throw rugs, runners, or similar coverings.

• DO NOT route cord under furniture or appliances. Take care to position the

cord away from traffic areas and where it will not be a tripping hazard.

• This appliance must not be used in a bathroom.

• Although this appliance complies with safety standards, we do not

recommend its use on deep pile carpets or on long hair type of rugs

• The appliance must be positioned so that the plug is accessible.

• If the supply cord is damaged it must be replaced by the manufacturer or

service agent or a similarly qualified person in order to avoid a hazard.

• Keep the supply cord away from the front of the appliance.

• Do not use this heater in small rooms when they are occupied by persons

not capable of leaving the room on their own, unless constant supervision is

provided.

• To reduce the risk of fire, keep textiles, curtains and or flammable material a

minimum distance of 1m from the air outlet.

• In order to avoid overheating, DO NOT COVER the appliance. Do not place

material or garments on the appliance, or obstruct the air circulation around

the appliance, for instance by curtains or furniture, as this could cause

overheating and a fire risk.

• This Heater carries the warning symbol indicating that it must not

be covered.

• In order to avoid a hazard due to inadvertent resetting of the thermal cut-

out, this appliance must not be supplied through an external switching

device, such as a timer, or connected to a circuit that is regularly switched

on and off by the utility.

• CAUTION Some parts of this product can become very hot and cause

burns. Particular attention has to be given where children and vulnerable

people are present.

• Children shall not turn on/off the appliance.

• Ensure that furniture, curtains or other combustible material are positioned

no closer than 1 metre from the appliance.

• Unplug the appliance when not required for long periods.

• Keep the supply cord away from the front of the appliance.

• This product is only suitable for well insulated rooms or occasional use.

WARNING: KEEP BATTERIES OUT OF REACH OF CHILDREN

• Swallowing may lead to serious injury in as little as 2 hours or death, due to

chemical burns and potential perforation of the oesophagus.

• If you suspect your child has swallowed or inserted a button battery

immediately call the 24-hour Poisons Information Centre on 13 11 26 (in

Australia) or 0800 764 766 (in New Zealand) for fast, expert advice.

• Examine devices and make sure the battery compartment is correctly secured,

e.g. that the screw or other mechanical fastener is tightened. Do not use if the

compartment is not secure.

• Dispose of used button batteries immediately and safely. Flat batteries can

still be dangerous.

CAUTION: No obvious symptoms

Unfortunately, it is not obvious when a button or coin battery is stuck in a

child's oesophagus (food pipe).

There are no specific symptoms associated with this. The child might:

• cough, gag or drool a lot

• appear to have a stomach upset or virus

• be sick

• point to their throat or stomach

• have a pain in their abdomen, chest or throat

• be tired or lethargic

• be quieter or more clingy than usual or otherwise 'not themselves'

• lose their appetite or have a reduced appetite

• not want to eat solid food/be unable to eat solid food

These types of symptoms vary or fluctuate. with the pain increasing and then

subsiding.

A specific symptom to button and coin battery ingestion is vomiting fresh

(bright red) blood. If the child does this seek immediate help. The lack of clear

symptoms is why it is important to be vigilant with 'flat' or spare button or

coin batteries in the home and the products that contain them.

Exposed to the

weather outdoors

Near water If the power cable

wires are frayed or cut

Where small children

may be left unattended

No extension leads or

power boards

Where there is risk

of fire or close to

a naked flame

Where the power

cable may be

damaged

On a slope or

uneven surface

Where it may be

damaged by

chemicals

If there is a risk

of water falling on

the unit

Where there is a risk

of interference by

foreign objects

This product is not

made for DIY repair

Model no. WLL20-AU

Colour/Finish Black

Wattage

2000

Heat Settings

Thermostat Control Yes

Remote Control Yes

Warranty 2 Years

Dimensions (w x d x h) 440 x 305 x 582mm

Specifications

For greater precision, please always refer to the rating label placed on the product.

Product Dimensions

General Information

The fire incorporates a flame effect, which can be used with or without heat, so that

the comforting effect may be enjoyed at any time of the year.

To reduce heat loss and to prevent any chimney up draft affecting the operation of

your stove fire, we recommend that the chimney flue is sealed off. A fan heater can

provide heating in cold weather. A distance of 1 metre (3 feet) must be maintained

between the front of the heater and any surrounding furniture, overhanging curtains

or other obstructions.

Always ensure that the appliance is sitting on a level surface.

Before connecting the appliance, check that the supply voltage is the same as that

stated on the appliance.

Only used filtered water in this appliance.

Once installed, never move this appliance or lay it on its back, without draining the

water from the sump and water tank. The water tank, sump, sump lid, tank cap and air

filters must be cleaned once every week, particularly in hard water areas. If you intend

on not using the appliance for longer than 1 week, drain the water from the sump and

water tank and dry the sump.

Please note: Used in an environment where background noise is very low, it may be

possible to hear a sound which is related to the operation of the fan heater & flame

effect. This is normal and should not be a cause for concern.

The sump and water tank in this product are treated with a biocidal product, being

Silver Biocide, in order to control harmful or unwanted organisms. This conforms with

the latest relevant ISO standard, Do not drink water from the sump or from the tanks.

Electrical Connection

WARNING: THIS APPLIANCE MUST BE EARTHED

This heater must be used on an AC ~ supply only and the voltage marked on the

heater must correspond to the supply voltage. Before switching on, please read the

safety warnings at the start of the instruction manual and operating instructions to

follow. Please retain this user’s guide for future reference

If you settle this appliance in an existing chimney space, we recommend that;

1. You have your chimney cleaned by a competent chimney sweep.

2. You block off the chimney flue.

This procedure is important for the efficient operation of the heating unit and will also

reduce heat loss up the chimney.

Ensure that all packing items are removed (read any warning labels carefully). Retain

all packing for possible future use e.g. in the event of moving or returning the appliance

to your supplier.

Setup

WARNING: FALLING OR TIPPING APPLIANCES CAN CAUSE INJURY OR DEATH OF

YOUNG CHILDREN, PLEASE ENSURE CHILDREN DO NOT CLIMB, HANG OR STAND

ON THIS PRODUCT.

Thermal Safety Cut-out

A thermal safety cut-out is incorporated in the fan heater to prevent damage due

to overheating. This can happen if the heat outlet was restricted in any way. If the

cut-out operates, unplug the heater from the socket outlet and allow approximately

10 minutes before reconnecting. Before switching the heater back on remove any

obstruction that may be restricting the heat outlet, then continue normal operation.

WARNING: In order to avoid a hazard due to inadvertent resetting of the thermal cut-

out, this appliance must not be supplied through an external switching device, such

as a timer, or connected to a circuit that is regularly switched on and off by the utility.

Setup

Installation

Installing the Appliance

1. Clean the area where the fire will be installed e.g. remove ash residue from an

existing fireplace.

2. Hold the fire by the sides of the surround and gently manoeuvre into position.

3. Plug the fire into a 10amp/230 volt outlet. Ensure that the supply cable is not

trapped under the fire such that it might cause it to be damaged.

Connecting the Transducer

1. Open the stove door.

2. Gently lift out the fuel bed and carefully set aside (Fig 4).

3. Remove the water tank by lifting upwards and outwards (Fig 5).

4. Remove the nozzle by unclipping and lifting upwards and outwards (Fig 6).

5. The transducer will be inside the sump. Remove from its bag.

6. Place the Transducer unit into the sump and make the connection.

7. Locate the tab on the Transducer unit into the moulded recess in the base of the

sump (Fig 7A).

8. Ensure that the cable does not obstruct the Transducer disc. To prevent the cable

becoming pinched between the nozzle and the sump, place the cable in the slot

in the wall of the sump (Fig 7B).

Installation

Filling the Water Tank

1. Gently lift out the fuel bed and carefully set aside.

2. Remove the water tank by lifting upwards and outwards.

3. Place the water tank in the sink and remove the cap. Turn anti-clockwise to open

(Fig 8).

4. Fill the tank with filtered tap water only. This is necessary to prolong the life of

the flame and smoke producing unit. The water should be filtered through a con-

ventional domestic water filter unit and the filter should be replaced regularly.

5. Screw the cap back on, ensuring to not over-tighten.

6. Return the tank to the sump, with the tank cap facing down.

7. Gently place the fuel bed back into position.

Note: When the water tank is empty, the flame and smoke effect shuts off. You will

hear 2 audible beeps and the digital display will display .

Tabla de contenidos

Otros manuales de Cocina de Dimplex

Dimplex

Dimplex EOSM-2007 Manual de usuario

Dimplex

Dimplex Westcott Manual de usuario

Dimplex

Dimplex Bellingham 5kW BLM5SE Manual de usuario

Dimplex

Dimplex SNG20 Manual de usuario

Dimplex

Dimplex CDS8515 Manual de usuario

Dimplex

Dimplex DS4411 Manual de usuario

Dimplex

Dimplex Opti-myst Cassington CSN20 Manual de usuario

Dimplex

Dimplex BAR20-AU Manual de usuario

Dimplex

Dimplex ELECTRALOG CS1205 Manual de usuario

Dimplex

Dimplex Club CLB20R Manual de usuario

Dimplex

Dimplex OMWFC20 Manual de usuario

Dimplex

Dimplex Purifire Electric Stove Manual de usuario

Dimplex

Dimplex COURCHEVEL CVL20E Manual de instrucciones

Dimplex

Dimplex Opti-myst Evandale Slate EVN20SL Manual de instrucciones

Dimplex

Dimplex Stockbridge SKG20BL Manual de instrucciones

Dimplex

Dimplex DS3311 Manual de usuario

Dimplex

Dimplex ELECTRIC STOVE Manual de usuario

Dimplex

Dimplex Willowbrook WLL20 Manual de instrucciones

Dimplex

Dimplex ELECTRALOG CS2307 Manual de usuario

Dimplex

Dimplex Optiflame Electric Fireplace Manual de instrucciones

Dimplex

Dimplex BFD20 Manual de usuario

Dimplex

Dimplex Lucia LUC20-EU Manual de usuario

Dimplex

Dimplex SKG20BL Manual de usuario

Dimplex

Dimplex Piermont PMN20 Manual de usuario

Manuales populares de Cocina de otras marcas

Arada

Arada Cassette Stove Manual de usuario

Parmco

Parmco FS 600 Manual de usuario

MCZ

MCZ SUITE AIR 10 M2 Manual de usuario

HearthStone

HearthStone Stowe DV 8321 Guía de solución de problemas

Cattara

Cattara FAMILY Manual de usuario

Stanley

Stanley Argon F500 OVAL Manual de usuario

Avalon

Avalon B-VENT Manual de usuario

Nordpeis

Nordpeis Vega Manual de usuario

Exquisit

Exquisit EKC601-5 Manual de operación

Stanley

Stanley Oisin Oil MK II Manual del propietario

Thermocet

Thermocet Brookfield S/CC Manual de usuario

HASE

HASE delhi Manual de usuario

Vermont Castings

Vermont Castings Intrepid 2 Manual de usuario

Italiana Camini

Italiana Camini CLASSICA Guía de inicio rápido

Avalon

Avalon Vashon Avanti DVS FS Manual de usuario

Spartherm

Spartherm ambiente a1 Manual de usuario

Warmlite

Warmlite WL46040 Manual de usuario

Regency

Regency Ultimate U39E Series Guía de inicio rápido
