Dimplex TFA36E Manual de usuario
Owner’s Manual
Model
TFA36E
CFA36BS
www.dimplex.com 7209730100rev04
IMPORTANT SAFETY INFORMATION: Always read this manual rst
before attempting to install or use this replace. For your safety, always
comply with all warnings and safety instructions contained in this manual
to prevent personal injury or property damage.
2 www.dimplex.com
Welcome & Congratulations ........................3
Important Safety Instructions ........................4
Battery Safety Instructions ..........................4
Quick Reference Guide ............................5
Fireplace Installation ..............................6
Operation .......................................9
Maintenance ....................................9
Warranty ......................................12
Table of Contents
Always use a qualied technician
or service agency to repair
this replace.
!NOTE: Procedures and
techniques that are
considered important
enough to emphasize.
CAUTION: Procedures and
techniques which, if not
carefully followed, will result
in damage to the equipment.
WARNING: Procedures
and techniques which, if not
carefully followed, will expose
the user to the risk of re,
serious injury, or death.
3
Welcome & Congratulations
Thank you and congratulations for
choosing to purchase an electric
replace from Dimplex, the world
leader in electric replaces.
Please carefully read and save
these instructions.
CAUTION: Read all
instructions and warnings
carefully before starting
installation. Failure to follow
these instructions may result
in a possible electric shock,
re hazard and will void
the warranty.
Please record your model and
serial numbers below for future
reference: model and serial
numbers can be found on the
Model and Serial Number Label
of your replace.
NO NEED TO RETURN
TO THE STORE
Questions With the Assembly?
Require Parts Information?
Product Under Manufacturer’s
Warranty?
Call Toll-Free
1-888-346-7539
Monday to Friday
8:00 a.m. to 4:30 p.m. EST
Please have your model
number and product serial
number ready. (See below)
Model and Serial
Number Label
Model Number
Serial Number
4 www.dimplex.com
① Read all instructions before
using this appliance.
②Any repairs to this appliance
should be carried out by a
qualied service person.
③Under no circumstances
should this appliance be modied.
Parts having to be removed for
servicing must be replaced prior
to operating this replace again.
④ Do not use outdoors.
⑤ Use this appliance only as
described in this manual. Any
other use not recommended by
IMPORTANT SAFETY INSTRUCTIONS
SAVE THESE INSTRUCTIONS
the manufacturer may cause re,
electric shock or injury to persons.
⑥ To prevent damage to the
electric fireplace and to prevent
bodily harm, only use Dimplex
replacement rechargeable
batteries.
⑦Always use caution when
handling, installing or replacing
the rechargeable battery. Do not
dispose of in or place near fire
or extreme heat. Consult your
local recycling facility for proper
disposal.
Battery Safety Instructions
WARNING: To avoid severe
bodily injury, read and follow
the battery safety guidelines
below:
Contains a sealed, non-
spillable lead acid battery.
WARNING: Improper handling
of battery may result in
possible explosion hazard,
electric shock and severe
bodily injury.
- Do not dispose of battery in a
re, the battery may explode
5
Quick Reference Guide
①The information regarding the
model of your electric replace
can be found on the label located
on the bottom of the unit.
② If you have any technical
questions or concerns regarding
- Do not open or mutilate battery.
The battery contains chemicals
that are toxic to the eyes and
skin
- To decrease risk of electric
shock, remove wrist watches
and jewelry such as rings and
bracelets when replacing
battery.
- To decrease risk of electric
shock, only use tools with
insulated handles.
- To prevent damage to the
electric replace and to prevent
bodily harm, only replace
battery with Dimplex
replacement rechargeable
batteries.
- To prevent damage to the
electric replace and to prevent
bodily harm, only use Dimplex
approved DC power supply to
power and recharge battery.
- To dispose of spent battery,
return it to place of replace
purchase, deliver it to a local
recycling facility or ship it to
Dimplex North America Limited
in the replacement battery
packaging material.
Battery Safety Instructions
the operation of your electric
replace, or require service
contact customer service.
③For dimensions of your
replace, refer to Figure 1.
6 www.dimplex.com
Fireplace Installation
Site Selection
This battery operated replace
can be mounted and used on any
interior wall.
The rechargeable battery
supplied with this unit can only be
recharged while installed in
the replace. Dimplex
recommends selecting a location
that would place the replace
near an electrical outlet and within
the six (6) foot (1.8 m) reach of
the power cord supplied.
If installing a new outlet for this
electric replace:
①Construction and electrical
outlet wiring must comply with
local building codes and other
applicable regulations to reduce
the risk of re, electric shock and
injury to persons.
②Do not attempt to wire your
own new outlets or circuits. To
reduce the risk of re, electric
shock or injury to persons, always
use a licensed electrician.
Quick Reference Guide
Figure 1
36" (914 mm)
22¼"
(565 mm)
6½"
(165 mm)
CFA36BS
36" (914 mm)
22¼"
(565 mm)
6¾"
(171 mm)
TFA36E
7
Figure 2
Installation
① Make sure the unit's Main
ON/OFF switch is switched OFF.
(Refer to operating instruction
section)
②Choose your desired height
and location for the electric
replace.
③Locate a minimum of two (2)
wall studs to install the wall mount
bracket on.
④ Mark an approximate location
for one (1) of the supplied #8
screws to be used on each of the
wall studs.
⑤ Referring to Figure 2 for
placement possibilities of the wall
mount bracket, use the supplied
bubble level and mark the
appropriate positions for wall stud
and/or wall anchors as needed.
CAUTION: A minimum of
two (2) wall studs (marked
by S in Figure 2), and either
a third wall stud or two
(2) wall anchors (marked by
A in Figure 2) must be used
to securely support the
electric replace.
Fireplace Installation
⑥ Remove the wall mount
bracket and install any wall
anchors where marked (none
required if installing the wall
mount bracket using three (3) wall
studs as shown in Figure 2).
⑦ Following the example shown
in Figure 3, install the wall mount
bracket using the supplied #8 x 1½
inch screws.
Wall Stud
#8 x 1 1/2"
Screws
Bubble Level
Wall
Anchor
Figure 3
8 www.dimplex.com
Figure 5
Power Input
Fireplace Installation
⑧ Hang your electric replace
onto the wall mount bracket as
shown in Figure 4. The metal
lip on the back of the replace
should rest on the wall mount
bracket.
Figure 4 Wall
Segment
Front of Fireplace
⑨ Carefully spread supplied
rocks on front tray of the fireplace.
⑩ Using the supplied power cord,
plug in your electric fireplace
to charge the factory installed
battery. The power input on the
fireplace is located on the bottom
of the fireplace, under the right
hand corner (Figure 5).
!NOTE: Dimplex recommends
leaving your electric fireplace
plugged in to charge over night
for first time use.
9
Operation
This electric replace is operated
by a momentary switch located on
the bottom of the replace, under
the right hand corner (Figure 6-A).
Press the momentary switch to
toggle the replace's ame effect
on or off.
The battery charge LEDs (Figure
6-B) will indicate the charge level
of the battery. The LEDs read
green, yellow and red from right
to left. Once the red battery
charge LED is lit, the electric
replace should be plugged in
to recharge. The replace can
operate while charging.
Figure 6
A
B
!NOTE: The replace will shut
off automatically if it is
unplugged during operation.
The momentary On/Off Switch
will need to be activated to
turn the replace on again.
WARNING: Disconnect
power before attempting any
maintenance or cleaning to
reduce the risk of re, electric
shock or damage to persons.
!NOTE: Even if the replace is
not used regularly, the battery
should be fully recharged at
minimum every three (3)
months to prolong battery life.
Maintenance
Battery Replacement
The ame effect is generated by
a series of LED lights and will
provide long life. If the ame
effect should cease to appear
or areas of the ame effect not
work, call customer service for
assistance.
Should the replace not operate
at all when charged adequately,
10 www.dimplex.com
Figure 8
Battery Access Panel
Battery
Wire
Leads
or operate for a minimal period
of time while not plugged in, the
battery may need to be replaced.
To Replace The Battery
WARNING: Read battery
safety instructions prior to
attempting to replace battery.
①Unplug the unit from power
outlet.
② Remove the electric fireplace
from the wall mount bracket and
place on a flat surface.
③ On the back of the replace,
remove the eight (8) screws from
the battery access cover located
Figure 7
Battery Access Panel
Screws
to
Remove
Screws
to
Remove
Maintenance
in the bottom, right corner
(Figure 7).
④ Remove the battery access
cover.
⑤There are wire leads
connecting the battery to the
replace. Remove the battery
from the replace.
⑥Remove the two (2) wire
connectors from the battery being
careful not to damage the battery
connections (Figure 8).
⑦Replace the battery and re-
connect the wire leads with black
leading to black and red leading
to red to ensure correct polarity.
⑧ Insert the replacement
battery into the replace, carefully
Otros manuales para TFA36E
1
Este manual sirve para los siguientes modelos
1
Tabla de contenidos
Otros manuales de Chimenea de interior de Dimplex
Dimplex
Dimplex BLF50 Manual de usuario
Dimplex
Dimplex MINICUBE Manual de usuario
Dimplex
Dimplex Revillusion Osbourne Manual de usuario
Dimplex
Dimplex SIL48 Manual de usuario
Dimplex
Dimplex EWMC-CC-SS Manual de usuario
Dimplex
Dimplex WBK20 Manual de usuario
Dimplex
Dimplex Revillusion RBF30C-AU Manual de usuario
Dimplex
Dimplex DF2624L Manual de usuario
Dimplex
Dimplex PRISM BLF5051-AU Manual de usuario
Dimplex
Dimplex SAHARA FIREPLACE 6903950000 Manual de usuario
Dimplex
Dimplex Evolve 50 Manual de usuario
Dimplex
Dimplex CAS1000M Manual de usuario
Dimplex
Dimplex BLF5051-AU/PRISM 50" Manual de usuario
Dimplex
Dimplex CASSETTE M Manual de usuario
Dimplex
Dimplex Ignite 50 Manual de usuario
Dimplex
Dimplex OPTIFLAME BF Series Guía de inicio rápido
Dimplex
Dimplex ELECTRALOG DF203A Manual de usuario
Dimplex
Dimplex DF2024L Manual de usuario
Dimplex
Dimplex Rectory REC20R Manual de usuario
Dimplex
Dimplex MULTIFIRE DF3015 Manual de usuario
