Digital Watchdog DW-716 DW-709 Manual de usuario

Digital Video Recorder

Operating Instructions

REV 1.0

Models DW-716 DW-709

DW716 Manual

This manual is published by KALTECH Enterprises. and contains information on DW716

for you to use this product comfortably.

If you require additional copies of this manual, please print and use the manual

contained in the CD provided.

3KALTECH DW716 Manual

KALTECH DW716 Manual



Thank you for purchasing KALTECH DW716.

This DVR is produced by the most advanced technology developed by KALTECH and its quality is

guaranteed by strict reliability and compatibility tests.

This DW716 manual provides necessary information I order to use this product to its maximum capacity

and also contains useful tip.

Please read this manual thoroughly before using DW716 in order to prevent any breakdown due to

mishandling.

Introduction

KALTECH DW716 Manual

KALTECH DW716 Manual 4

This manual applies to DW716 DVR only.

This manual describes external features of DW716 DVR, part names, correct connection methods for

Pan/Tilt control, Control devices, peripheral devices, and the system setting method.

• KALTECH is not held responsible if the DVR is damaged due to non-compatible devices being used with

the product.

• KALTECH is not held responsible if the DVR is damaged due to the product being disassembled or

modified by the user without permission.

• If you wish to open the system to modify, repair, or upgrade, it is recommended that you ask for

KALTECH engineer’s assistance by contacting your dealer or by contacting KALTECH head office.

• DW716 are registered trademarks of KALTECH .

• This product is qualified for both domestic and industrial use. This product has qualified the Radio

Equipment Requirements of Korea and acquired international certificates including CE (Europe) and FCC

(USA).



Notice

5KALTECH DW716 Manual

KALTECH DW716 Manual

All copyrights of this manual are reserved by KALTECH Enterprises.

It is prohibited to copy or republish this manual for commercial reasons.

It is prohibited to transfer this manual via online media such as, but not limited to, Internet. It is also

prohibited to post, distribute, or translate this manual without given permission.

KALTECH is not held responsible if the DVR is damaged either accidentally or intentionally due to the

system being handled inappropriately by a user who is not aware of how to operate this product, or by a

user who did not refer to this manual before operating the product.

KALTECH reserves the right to change the contents of this manual for specific groups or individuals without

notice.

KALTECH reserves all copyrights of registered trademark in this manual.



Copyrights

KALTECH DW716 Manual

KALTECH DW716 Manual 6



Caution

Please beware of the following precautions before installing the DVR.

• Avoid any place with moisture, dust, or soot.

• Avoid any place with direct sunlight or heating appliances.

• Keep the product away from electric shock or magnetic substances.

• Avoid high or low temperature (recommended operation temperature is between

0C and ~40 C).

• Do not place any conductive material through the ventilation.

• Turn off the system before installation.

• Ensure enough space for cable connections.

• Place the system on a solid surface with sufficient air ventilation. Avoid any

surface that vibrates.

• Placing the system near electronic devices such as radio or TV may cause

breakdown to the product.

• Do not disassemble the product without an assistance from KALTECH .

• Do not place any heavy object on the system.

7KALTECH DW716 Manual

KALTECH DW716 Manual

The following are warnings and cautions for the safety of the users and for the prevention of any

property damage. Please read below thoroughly.

Warning and Caution signs

If you are not aware of this

caution, you may be injured

or cause property loss.

If you are not aware of this

warning, you may be seriously

injured or be killed.

Warning Caution

 

Safety Warnings and Cautions

Turn off the system before installing the system. Do not plug in

several electric devices to the same outlet.

This may cause heating, fire, or electric shock.

Do not place any liquid container on the system, such as water,

coffee, or beverage.

• If liquid is poured onto the system, it can cause a system

breakdown or cause fire.

Prevent power cable from being severely bent or pressed by a

heavy object.

• This may cause fire.

Clean the dust around the system on regular basis. When

cleaning the system, always use dry cloth. Do not use wet cloth

or other organic solvents.

• This may damage the surface of the system and can cause

system breakdown or electric shock.

Avoid any place with moisture, dust, or soot.

• This can cause fire or electric shock.

When pulling the power cable from the plug, do so gently. Do

not touch the plug with wet hands and avoid using the plug if

the holes on the outlet are too loose.

• This may cause fire or electric shock.

Warning

KALTECH DW716 Manual

KALTECH DW716 Manual 8

Safety Warnings and Cautions

D not attempt to disassemble, repair, or modify the system on

your own. It is extremely dangerous due to high voltage running

through the system.

• This may cause fire, electric shock, or serious injuries.

Install the system in a cool place without direct sunlight and

always maintain room temperature. Avoid candle light and

heat-generating devices such as heater. Keep the system away

from places where many people pass.

• This may cause fire.

Check for any danger signs such as moist floor, loosened or

damaged power cable, or unstable surface. If you encounter any

problems, ask for assistance from your dealer.

• This may cause fire or electric shock.

Install the system on a plain surface with sufficient air ventilation.

Do not place the system on elevated surface.

• This may cause system breakdown or serious injuries.

Keep at least 15cm between the back of the system and a wall

for the cables connected into the system. Otherwise, cables

may be bent, damaged, or cut.

• This may cause fire, electric shock, or injuries.

The power outlet must be placed on a ground, and the voltage

range must be within 10% of the voltage rate. Do not use the

same outlet with a hair dryer, iron, refrigerator, or any heating

appliances.

• This may cause fire, heating, an electric shock.

Warning

9KALTECH DW716 Manual

KALTECH DW716 Manual

Safety Warnings and Cautions

When the system’s battery is deplete, you must change it with

the same or equivalent type of battery specified by the

manufacturer. Depleted batteries should be discarded according

to manufacturer’s instructions.

• This may cause an explosion.

If the system’s HDD exceeded its life span, you may not be able

to recover any data stored inside the HDD. If the video on the

system screen appears ‘damaged’ while playing a recording

stored inside the system’s HDD, it must be replaced with a new

one. Ask for an engineer’s assistance for HDD replacement

from your dealer.

• KALTECH is not responsible for deleted data caused by

user’s mishandling.

Warning

KALTECH DW716 Manual

KALTECH DW716 Manual 10

Safety Warnings and Cautions

Do not install the system in a place with high magnetic, electric

wave, or wireless devices such as radio or TV.

• Install the system in a place without magnetic objects, electric

frequencies, or vibration.

Install the system in a place with appropriate moisture and

temperature level.

• Avoid installing the system with high (over 40 ) or low (under

0 ) temperature.

Prevent any substances from being inserted into the system.

• This may cause system breakdown.

Do not place any heavy object on the system.

• This may cause system breakdown.

Install the system in a place with sufficient air ventilation.

• Keep at least 15cm distance between the back of the system

and a wall, and at least 5cm distance between the side of the

system and a wall.

Install the system on a stable and leveled surface..

• The system may not operate properly.

Caution
