DigitalGuardDawg

WatchDawg‐X2



FunctionsandOperatingInstructions.



Armingthealarm

Stopthevehicle,removethekeyandpresstheLOCK(pictureoflocksymbol)buttononthetransmitter.

Thehornwillbeepandtheturnsignalswillflashindicatingthesystemhasbeenarmed.Thetransmitter

willreturnabeep,whilethelock(lockpicture)andhorn(hornpicture)iconsonthedisplayofthe

remoteareilluminatedtoconfirmthesystemhasbeenarmed.After5seconds,themotionsensorwill

becomeactiveandanymotionwilltriggerthealarm(Thesensitivityofthemotionsensorcanbe

adjustedonthesideoftheunit).Whenthealarmistriggertheremotewillvibrateandlightup

indicatingthealarmhasbeentrigged.WhentheAlarmistriggeredthebikewillflashtheturnsignals

andcausethehorntosoundfor30seconds.



ArmingtheAlarminMuteMode

Stopthevehicle,removethekeyandpresstheLOCKbutton(pictureoflock)twicewithin5seconds,The

turnsignalswillflash,thehornwillnotsoundandthesystemwillarminmutemode.Thetransmitter

willreturnabeep,whilethelockicon(lockicon)andthehorniconwillhaveasmalllinethroughit(horn

withanX)onthedisplayofthetransmitterareilluminated.Inthemutealarmmode,thebikeshornwill

notsoundifthealarmistriggered



DisarmingtheAlarm

WhenthesystemisarmedpresstheUnlock(pictureofunlock)buttononcethiswilldisarmthealarm.

Theturnsignalswillflashtwiceandhornwillmaketwobeepsindicatingthealarmhasbeendisarmed.

TheremotewillreturntwobeepswhiletheUnlockicon(unlockicon)onthedisplayoftheremoteis

illuminated.



RemoteStartingyourBike

WiththeEngineoffpressthestartbutton(lightningbolticon)onthetransmittertwicewithin3

seconds,thebikewillstartautomaticallywithin1second.Aftersuccessfullystartingthetransmitterwill

illuminatetheexhausticonandwillbeep3times.TheenginecannotbeshutoffuntiltheUNLOCK

(unlockicon)buttonispressed.



PrompttosetAlarm

Afterstoppingthebikeifthealarmisnotsetwithin8secondsthebikewillmake3beepsandflashthe

turnsignals3times,toremindtheridertoarmthebike.



RemotelykillingtheBike

WhentheBikeisdriving,holddowntheLOCK(lockicon)buttonfor2sorlonger,theturnsignalswill

flashrapidlyasthebikestartstoenteranti‐theftmode.Thehornofthebikewillmakealoudsound,the

turnsignalswillflash,andthevehiclesenginewilldie20secondslater.Thisstatecanonlybestoppedby

pressingtheUNLOCK(unlockicon)button.



ToShutofftheRemoteStart

Whilethebikeisrunning(duetoaremotestart),presstheunlock(unlockicon)buttontoremotelystop

yourbike.



AutomaticRe‐arm

WhilethebikeisarmediftheUNLOCK(unlockicon)buttonispressedthealarmwilldisarm,lfthebikeis

notstartedwithin25secondsthealarmwillautomaticallyre‐armitself.Thetransmitterwillbeepupon

armingindicatingithasre‐armed.Thebikewillalsobeepindicatingithasre‐armed.



KeySwitchReminder

Ifthealarmisdisarmedandnotstartedwithin25secondsthetransmitterwillbeepandvibrate

remindingyoutotakethekeyoutoftheignitionswitch.



LEDwarning

WhentheSystemhasbeenarmedtheLEDwillflashtwiceevery2seconds.Whilethesystemisarmed,if

themotionsensoristriggered(stage1)theLEDwithflash4timesevery2seconds.Whenthealarmis

fullytriggeredtheLEDwillflashtheentiredurationofthealarm.



MotionSensor

Themotionsensor,isanadjustable2stagesensor.Thesensitivitycanbeadjustedbyrotatingthedial

onthesideofthealarmunit.Ifthemotionsensoristriggered,thefirsttimeitwilltriggerafewshort

beepsfromthesirenandafewflashesfromtheturnsignals.Ifthemotionsensoristriggeredagain

within15secondsitwilltriggerthesystemtofullyalarm.



OutofRangeWarning

Whenthealarmhasbeensetandtheremotehasnothadcontactwiththealarmfor3minutesthe

rangeindicatorontheremotewillnolongerbelitup.



TransmitterBatteryIndicator

Whenthebatteryinyourtransmittergetslow,itwillmakeadistincttoneafterpressinganyofthe

buttonstoremindyoutoreplacethebatteriessoon.



SettingtheTimeonyourremote

PresstheLOCK(lockicon)andUNLOCK(unlockicon)buttonssimultaneouslyfor1s,thetransmitterwill

beep,andtheword"hour"willflash.ThenpresstheLOCK(lockIcon)buttontoswitchbetween"Hour"

and"Minute".PresstheUNLOCK(unlockicon)buttontoselectthetime.Aftersettingiscompletepress

theLOCK(lockicon)andUNLOCK(unlockicon)buttonssimultaneouslytosavethetimeentered.



LearningNewTransmitters

TurnthekeyfromOFFtoONeighttimesandleavethekeyinserted.TheLEDwillbeilluminated,press

anykeyofthefirsttransmitterwithin8seconds,thehornwillmaketwobeepsindicatingthe

transmitterhasbeenlearned,iflearninganadditionaltransmitterpressabuttonontheadditional

transmitterwithin8secondsofthetwobeepsofthehornfromthefirsttransmitter.After30seconds

thealarmwillexitremotelearningmode.

Eachalarmcanonlylearn2transmitters



WarrantyStatement

TheDGD‐WD‐X2motorcyclealarmfromDigitalGuardDawg,Incisguaranteedtobefreefromdefects

inmaterialand/orworkmanshipandtoperformasadvertisedforaperiodof1yearfromthedateofthe

purchasewhenproperlyinstalled,usedandmaintainedinaccordancewiththeinstallationinstructions.

Failuretoadheretoand/orcomplywiththeinstallationinstructionswillvoidallassociatedwarranty

obligations.Shouldanypart(s)provedefectivewithin1yearfromthedateofpurchase,it(they)willbe

replacedF.O.Bourfactorywithoutchargeprovidedthedefectivepart(s)isreturnedtoourfactory.



DigitalGuardDawg,Incisnotresponsibleforlaborcharges,lossorconsequentialdamageofanykindin

charactercausedbydefectedpartsorchargesincurredinthereplacementorrepairofdefectiveparts

bythepurchaser.Carelesshandling,includingthatbyfreightcompanies,andimproperinstallationor

usemayvoidallwarranties.



Questionorcommentsregardingthisproductoritswarrantycanbesentto:

DigitalGuardDawg,Inc.

705E.BidwellSt.

Suite2325

Folsom,CA95630

877‐246‐5395

www.DigitalGuardDawg.com


