Directional Drilling Locating System

Operator’s Manual

DIGITAL CONTROL INCORPORATED

2 DigiTrak®LT™

Operator’s Manual

403-1000-00-C1, Aug 2013

Trademarks

The DCI logo, CableLink®, DataLog®, DigiTrak®, Eclipse®, F2®, F5®, iGPS®, MFD®,SST®, target-in-the-

box®, Target Steering®, and TensiTrak®are U.S. registered trademarks and DucTrak™, FBC™, FBP™,

F Series™, FSD™, FasTrak™, LWD™, SBP™, SE™, SED™, SuperCell™, and TeleLock™ are

trademarks of Digital Control Incorporated.

Limited Warranty

All products manufactured and sold by Digital Control Incorporated (DCI) are subject to the terms of a

Limited Warranty. A copy of the Limited Warranty is included at the end of this manual; it can also be

obtained by contacting DCI Customer Service, 425-251-0559 or 800-288-3610, or at DCI's website,

www.digitrak.com.

Important Notice

All statements, technical information, and recommendations related to the products of DCI are based on

information believed to be reliable, but the accuracy or completeness thereof is not warranted. Before

utilizing any DCI product, the user should determine the suitability of the product for its intended use. All

statements herein refer to DCI products as delivered by DCI and do not apply to any user customizations

not authorized by DCI nor to any third-party products. Nothing herein shall constitute any warranty by DCI

nor will anything herein be deemed to modify the terms of DCI’s existing Limited Warranty applicable to all

DCI products. The most recent version of this manual is available on DCI's website.

Compliance Statement

This equipment complies with Part 15 of the Rules of the FCC and with Industry Canada license-exempt

RSS standards and with Australia Class License 2000 for LIPD (low interference potential devices).

Operation is subject to the following two conditions: (1) this equipment may not cause harmful

interference, and (2) this equipment must accept any interference received, including interference that

may cause undesired operation. DCI is responsible for FCC compliance in the United States: Digital

Control Incorporated, 19625 62nd Ave S, Suite B103, Kent WA 98032; phone 425-251-0559 or 800-288-

3610.

Changes or modifications to any DCI equipment not expressly approved and carried out by DCI will void

the user’s Limited Warranty and the FCC’s authorization to operate the equipment.

CE Requirements

DigiTrak receivers are classified as Class 2 radio equipment per the R&TTE Directive and

may not be legal to operate or require a user license to operate in some countries. The list of restrictions

and the required declarations of conformity are available on DCI’s website, www.digitrak.com, under the

Service & Support tab. Click on DOWNLOADS and select from the CE Documents pull-down menu to

download, view, or print the documents.

DIGITAL CONTROL INCORPORATED

DigiTrak®LT™

Operator’s Manual 3

United States

DCI Headquarters

19625 62nd Ave S, Suite B103

Kent, Washington 98032, USA

+1.425.251.0559 / 1.800.288.3610

+1.425.251.0702 fax

[email protected]

Australia

2/9 Frinton Street

Southport QLD 4215

+61.7.5531.4283

+61.7.5531.2617 fax

[email protected]

China

368 Xingle Road

Huacao Town

Minhang District

Shanghai 201107, P.R.C.

+86.21.6432.5186

+86.21.6432.5187 fax

[email protected]

Europe

Brueckenstraße 2

97828 Marktheidenfeld

Germany

+49.9391.810.6100

+49.9391.810.6109 fax

[email protected]

India

DTJ 1023, 10th Floor

DLF Tower A, DA District Center

Jasola, New Delhi 110044

+91.11.4507.0444

+91.11.4507.0440 fax

[email protected]

Russia

Molodogvardeyskaya Street, 4

Building 1, Office 5

Moscow, Russia 121467

+7.499.281.8177

+7.499.281.8166 fax

[email protected]

DIGITAL CONTROL INCORPORATED

4 DigiTrak®LT™

Operator’s Manual

Dear Customer,

Thank you for choosing a DigiTrak locating system. We are extremely proud of the equipment we have

been designing and building in Washington State since 1990. We believe in providing a unique, high-

quality product and standing behind it with superior customer service and training.

Please take the time to read this entire manual, especially the section on safety. Also, please fill in the

product registration card provided with this equipment and either mail it to DCI headquarters, fax it to us

at 253-395-2800, or complete and submit the form online at our website, www.digitrak.com. We will put

you on the Digital Control mailing list and send you product upgrade information and our FasTrak

newsletter.

Feel free to contact us if you have any problems or questions. Our Customer Service department is

available 24 hours a day, 7 days a week. International contact information is available on our website.

As the horizontal directional drilling industry grows, we’re keeping our eye on the future to develop

equipment that will make your job faster and easier. Visit us online any time to see what we’re up to.

We welcome your questions, comments, and ideas.

Digital Control Incorporated

Kent, Washington

2013

See our DigiTrak Training Videos on YouTube at www.youtube.com/dcikent.

DIGITAL CONTROL INCORPORATED

DigiTrak®LT™

Operator’s Manual 5

Table of Contents

Safety Precautions and Warnings.................................................................................................................7

General ....................................................................................................................................................7

Equipment and Battery Disposal .............................................................................................................8

Pre-Drilling Testing ..................................................................................................................................8

Interference..............................................................................................................................................8

Equipment Maintenance..........................................................................................................................9

Introduction..................................................................................................................................................10

Power Requirements .............................................................................................................................11

Environmental Requirements ................................................................................................................11

Receiver......................................................................................................................................................12

Main Display Screen..............................................................................................................................13

Standard Display Screen Symbols ........................................................................................................14

Power On/Off .........................................................................................................................................15

Proper Handling of Receiver..................................................................................................................15

Accessing and Changing Menu Settings...............................................................................................16

Receiver Display Menus........................................................................................................................16

Transmitter..................................................................................................................................................26

Types of LT Transmitters.......................................................................................................................26

Transmitter Housing Requirements.......................................................................................................27

Transmitter Battery Power.....................................................................................................................28

Transmitter Temperature.......................................................................................................................28

Sleep Mode (Automatic Shutoff)............................................................................................................29

General Transmitter Care Instructions...................................................................................................29

Remote Display...........................................................................................................................................30

Main Display Screen..............................................................................................................................30

Remote Display Menus..........................................................................................................................32

Power On/Off....................................................................................................................................32

Telemetry Channel Settings .............................................................................................................32

Backlight On/Off................................................................................................................................32

Depth Units.......................................................................................................................................33

Pitch Units.........................................................................................................................................33

Battery Charger...........................................................................................................................................34

General Description ...............................................................................................................................34

AC/DC Power Setup ..............................................................................................................................35

Charging a Battery.................................................................................................................................35

Locating Instructions ...................................................................................................................................38

Depth or Slant Distance.........................................................................................................................38

Locate Points (FLP & RLP) and Locate Line (LL) .................................................................................38

Effects of Depth, Pitch, and Topography on Distance Between FLP and RLP....................................39

Marking Locate Points ...........................................................................................................................40

Locating the Transmitter –Standard Method ........................................................................................41

Finding the FLP ................................................................................................................................42

Finding the Transmitter and the LL...................................................................................................43

Confirmation of Exact Heading and Transmitter Position.................................................................44

Finding the RLP................................................................................................................................45

Plus/Minus ("+/–") Locating Method.......................................................................................................46

Finding the FLP ................................................................................................................................46

Finding the Transmitter and the LL...................................................................................................47

DIGITAL CONTROL INCORPORATED

6 DigiTrak®LT™

Operator’s Manual

Confirmation of Exact Heading and Transmitter Position.................................................................48

Finding the RLP................................................................................................................................48

Limited Warranty

DIGITAL CONTROL INCORPORATED

DigiTrak®LT™

Operator’s Manual 7

Safety Precautions and Warnings

Carefully review this manual and be sure you always operate your DigiTrak locating system properly to

obtain accurate depth, pitch, roll, and locate points. If you have any questions about the operation of the

system, please contact DCI Customer Service for assistance.

General

Warning All operators must read and understand the following safety

precautions and warnings and must review this operator’s manual

before using the DigiTrak F5 Locating System.

Serious injury and death can result if underground drilling equipment makes

contact with an underground utility such as a high-voltage electrical cable or a

natural gas line.

Substantial property damage and liability can result if underground drilling

equipment makes contact with an underground utility such as a telephone, cable

TV, fiber-optic, water, or sewer line.

Work slowdowns and cost overruns can occur if drilling operators do not use the

drilling or locating equipment correctly to obtain proper performance.

DCI equipment is not explosion-proof and should never be used near flammable

or explosive substances.

In the event of electrostatic shock, the display screen may go blank. No data loss

will occur. Click the trigger to reset the receiver, or toggle down to reset the

remote display.

Hot surfaces can occur on cable transmitters if housing requirements are not met.

Always ensure the transmitter is installed properly in the housing during use.

Directional drilling operators MUST at all times:

Understand the safe and proper operation of drilling and locating equipment, including the use of

ground mats and proper grounding procedures.

Ensure that all underground utilities have been located, exposed, and accurately marked prior to

drilling.

Wear protective safety clothing such as dielectric boots, gloves, hard hats, high-visibility vests, and

safety glasses.

Locate and track the transmitter in the drill head accurately and correctly during drilling.

Maintain a minimum distance of 8 in. (20 cm) from the front of the receiver to the user’s torso to

ensure compliance with FCC requirements.

Comply with federal, state, and local governmental regulations (such as OSHA).

Follow all other safety procedures.

DIGITAL CONTROL INCORPORATED

8 DigiTrak®LT™

Operator’s Manual

DigiTrak locating systems cannot be used to locate utilities.

Continued exposure of the transmitter to heat due to frictional heating of the drill head can cause

inaccurate information to be displayed and may permanently damage the transmitter.

Remove the batteries from all system components during shipping and prolonged storage; damage

caused by leakage may occur.

Equipment and Battery Disposal

This symbol on equipment indicates that the equipment must not be disposed of with your

other household waste. Instead, it is your responsibility to dispose of such equipment at a

designated collection point for the recycling of batteries or electrical and electronic

equipment. If the equipment contains a banned substance, the label will show the pollutant

(Cd = Cadmium; Hg = Mercury; Pb = Lead) near this symbol. Before recycling, ensure

batteries are discharged or the terminals are covered with adhesive tape to prevent

shorting. The separate collection and recycling of your waste equipment at the time of

disposal will help conserve natural resources and ensure it is recycled in a manner that

protects human health and the environment. For more information about where you can

drop off your waste equipment for recycling, please contact your local city office, your

household waste disposal service, or the shop where you purchased the equipment.

The battery charger provided with your DigiTrak locating system is designed with adequate safeguards to

protect you from shock and other hazards when used as specified within this document. If you use the

battery charger in a manner not specified by this document, the protection provided may be impaired. Do

not attempt to disassemble the battery charger, it contains no user-serviceable parts. The battery charger

shall not be installed into caravans, recreational vehicles, or similar vehicles.

Pre-Drilling Testing

Before each drilling run, test your DigiTrak locating system with the transmitter inside the drill head to

confirm it is operating properly and providing accurate drill head location and heading information.

During drilling, the depth will not be accurate unless:

The receiver has been properly calibrated and the calibration has been checked for accuracy so the

receiver shows the correct depth.

The transmitter has been located correctly and accurately and the receiver is directly above the

transmitter in the drill head underground or at the front locate point.

The receiver is placed on the ground or held at the correct height-above-ground distance, which has

been set correctly.

Always test calibration after you have stopped drilling for any length of time.

Interference

Interference can cause inaccuracies in the measurement of depth and loss of the transmitter’s pitch, roll,

or heading. Always perform a background noise check prior to drilling.

Sources of interference include, but are not limited to, traffic signal loops, invisible dog fences, cable

TV, power lines, fiber-trace lines, metal structures, cathodic protection, telephone lines, cell phones,

transmission towers, conductive earth, salt, salt water, rebar, and radio frequencies.

DIGITAL CONTROL INCORPORATED

DigiTrak®LT™

Operator’s Manual 9

Interference at the remote display may also occur from other sources operating nearby on the same

frequency, such as car rental agencies using their remote check-in modules or other directional

drilling locating equipment.

Background noise must be minimal and signal strength must be at least 150 points above the

background noise during all locating operations.

Because this equipment may generate, use, and radiate radio frequency energy, there is no

guarantee that interference will not occur at a particular location. If this equipment does interfere with

radio or television reception, which can be determined by powering the equipment off and on, try to

correct the interference using one or more of the following measures:

oReorient or relocate the receiving antenna.

oIncrease the separation between the receiver and affected equipment.

oConsult the dealer, DCI, or an experienced radio/TV technician for help.

oConnect the DCI equipment to an outlet on a different circuit.

Equipment Maintenance

Turn off all equipment when not in use.

Store the equipment in cases, away from heat, cold, and moisture. Test to confirm proper operation prior

to use.

Clean the screens on the receiver and remote display using a damp soft cloth without chemicals or

cleaning agents.

Clean the receiver, remote, and battery charger case using only a soft moist cloth and mild detergent.

Do not use chemicals to clean the transmitter.

Inspect the equipment daily and contact DCI if you see any damage or problems. Do not disassemble or

attempt to repair the equipment.

Do not store or ship this equipment with batteries inside. Always remove the batteries from the equipment

before shipping or periods of non-use.

DIGITAL CONTROL INCORPORATED

DigiTrak®LT™

Operator’s Manual 10

Introduction

DigiTrak LT Locating System

The DigiTrak LT Locating System is used to locate and track the drill head during horizontal directional

drilling (HDD) operations. The system consists of a handheld receiver, a transmitter, which is placed in

the drill head, and a remote display. The receiver and remote are powered by a rechargeable DCI battery

pack, and a battery charger is also included with the system.

Locating is streamlined using the LT receiver’s graphic display and menu system. The real-time graphic

display guides you in positioning a target (or a line) in a box on the display window to locate the trans-

mitter in the drill head. You can also locate using the plus/minus signs, as on earlier DigiTrak models

produced by Digital Control Incorporated (DCI).

This manual provides information on each LT system component—the receiver, transmitter, remote dis-

play, and battery charger—in separate sections following this introduction. These sections are followed by

the Locating Instructions section, which explains important locating terms and gives step-by-step locating

instructions.

The remainder of this section presents the LT system’s power requirements, environmental requirements,

and equipment maintenance requirements.

If you have any questions about the information in this manual or about the use of the LT system, please

call DCI’s Customer Service Department at 800-288-3610 or 425-251-0559.

Remote

Display

Battery

Charger

Receiver

Transmitter

Rechargeable

Battery Packs

Mini

Adapter

LS Transmitter
