Digicom MTL01 Manual de usuario
http://www.digicom.it
MTL01
User's Guide
rev. 1.0 09/2002
I
MTL01 Index
INDEX
PREFACE II
DECLARATION CE OF CONFORMITY II
1. GENERALITY 1.1
1.1. CHARACTERISTICS 1.1
1.2. PACKAGE CONTENT 1.1
2. INSTALLATION 2.1
2.1. INSTALLATION - WINDOWS® 2.1
2.2. HARDWARE SETTING 2.2
3. MODEM AT COMMAND SET 3.1
3.1. AT COMMAND SET DESCRIPTION 3.1
3.1.1. MNP10 COMMAND 3.6
3.2. S REGISTERS 3.7
3.2.1. SPECIAL S REGISTER DESCRIPTION 3.7
3.3. CONNECTION MESSAGES 3.8
II
MTL01 Preface
PREFACE
All rights reserved; no part of this publication may be reproduced, stored in a retrieval system, or trasmitted in any form or by
any means, electronic, otherwise, without the prior written permission of Digicom S.p.A.
Thefollowinginstallationrulesshouldberespectedinordertohavethebestworkingorderoftheequipment
and for the user’s safety
ENVIROMENTAL CONDITIONS
Enviromental temperature Relative humidity
from -20 a +50°Cfrom 20 to 80% n.c.
Rapid changes of temperature or humidity should be avoided.
This equipment, including cables, should be installed in an area free from:
Dust, humidity, heat from direct sun light.
Objects which irradiate heat. These could cause damage to the container or other problems.
Objects which produce a strong electtromagnetic field (loudspeakers, etc.)
Liquids or chemical corrosive substances.
CLEANING THE TERMINAL
Use a clean and soft cloth. Wet the cloth with water or natural detergent if it is necessary to remove any
stains. Never use chemical products such as petrol or solvents.
VIBRATIONS OR DROPPING
Caution against vibrations and dropping.
WARNING: This is a class A product.
Inadomesticenvironmentthisproductmaycauseradiointerferenceinwhichcasethe user may be required
to take adequate measures.
DECLARATION OF CONFORMITY
We, Digicom S.p.A. with registered office at: via Volta 39 - 21010 Cardano al Campo (Varese - Italy) declare
under our sole responsability that the product:
Name: MTL01
satisfies the basic requirements of the below indicated Directive:
1999/5/CE of March 9 1999, R&TTE.
As having been designed in conformity with the requirements of following Reference Standards:
EN 55022, EN 61000-3-2, EN 55024, EN 60950, ETSI TBR 21
1.1
MTL01 Generality
1. GENERALITY
Congratulations for choosing Digicom MTL01.
MTL01 is an analog modem projected to be integrated into
professional equipments and to be used for data transfer with
remote devices.
It is possible to configure MTL01 using a completeAT commands
set.
To guarantee the maximum compatibility with the industrial
systems, MTL01 has been carried out with an ISA-Bus interface,
which is very popular in these environments.
ISA-Busslots are supported bythe most Operating Systems,even
by the less recent ones (eg. MSDOS).
1.1. CHARACTERISTICS
Standard: V90, K56flex, V34, V32bis, V32, V22, V22bis, V21
Connections up to 33600bit/s with another analog device
Internet Connections up to 56000bit/s
DTE speed up to 115200bit/s
Asynchronous functionality
MNP5 and V.42bis data compression
10 bit Asynchronous support
AT commands support
CTR21 International Line Interface
Autoanswer
Flash upgradable
Size: 125x90x15mm
Power supply: +5Vdc (from the Terminal ISA-Bus socket)
Power consumption: 1.5W
Data interface: comb connector for XT/AT bus
1.2. PACKAGE CONTENT
MTL01
Phone cord
Quick Guide
2.1
MTL01 Installation
2. INSTALLATION
Before inserting an ISA-Bus modem into the terminal, a COM serial port and an interrupt must be set
through the dip-switches and/or jumpers on the card. The Terminal will be able to interface the modem
using the COM and IRQ resources.
The same concept is used also for Terminals with Operating System: in this case MTL01 is detected as a
serial port; this means that, during the installation it is important to detect the new COM port.
After the installation, you can configure the modem using AT commands or a Windows“ driver (Standard
Modem).
For the hardware installation, please follow this procedure:
Remove the modem from its package, and check it is OK.
Set the dip-switch with COM port and IRQ (see table below).
Switch-OFF the Terminal, then insert the modem in a free ISA-Bus slot.
Fix the card modem and close the Terminal.
Insert the phone line cable using the one supplied in the package.
Oncethe installation oftheserial port isover,youcan start with themodem configuration usingATcommands.
2.1. INSTALLATION - WINDOWS®
Windows® sees MTL01 as a serial port, so you must look for a free COM and IRQ in the Operating System,
then set a COM and IRQ in MTL01.
Selectthe System utilityin the Control panel,thenselect the Hardware folder and click the Device manager
button. In the most recent Operating Systems use the System Information utility present in Programs/
Accessories/System Utility.
Now set the dip-switch and the jumper on the modem card.
If there are not free COM or IRQ, you can disable COM1 or
COM2 (if it is not used) in BIOS.
For the hardware installation, please follow this procedure:
Remove the modem from its package, and check it is
OK.
Set COM and IRQ by the dip-switch (see table below).
Switch-OFFthe PC, then insert the modem in a free ISA-
Bus slot.
Fix the card modem, and close the PC.
Insert the phone line cord supplied in the modem
package.
Run Windows®: MTL01 could not automatically detect the
new serial port as it is not a Plug&Play (PnP) card. Run the
Add/Remove Hardware utility in the Control Panel and
select automatic search: Windows® will detect a new serial port.
Afterthe serial portinstallation is over, you canconfigure the modemusingATcommands,or with aWindows®
driver (Standard Modem).
2.2
MTL01 Installation
2.2. HARDWARE SETTING
MTL01 supports a dip-switch (see picture below) for COM and IRQ setting. You can see the configuration in
the following table.
Address DIP SWITCH DS1 Jumper
12345678 U1
COM1 3F8 OFF OFF
COM2 2F8 OFF ON
COM3 3E8 ON OFF
COM4 2E8 ON ON
IRQ3 ON OFF OFF OFF OFF OFF Pos. 1-2
IRQ4 OFF ON OFF OFF OFF OFF Pos. 1-2
IRQ5 OFF OFF ON OFF OFF OFF Pos. 1-2
IRQ7 OFF OFF OFF ON OFF OFF Pos. 1-2
IRQ10 OFF OFF OFF OFF ON OFF Pos. 1-2
IRQ11 OFF OFF OFF OFF OFF ON Pos. 1-2
IRQ14 OFF OFF OFF OFF OFF OFF Pos. 2-3
factory default
3.1
MTL01 Modem AT Command Set
3. MODEM AT COMMAND SET
The modem supports a completeAT commands set to define the configuration, initiate or terminate modem
communication, test the modem and the communication link. The modem will work in two basic operations:
command mode and data mode.
COMMAND mode is when the modem is not connected to another modem, therefore “Off Line” or in a idle
condition. In this mode the modem will accept commands beginning withAT prefix. DATA mode is when the
modem is connected to another modem, that is an “On Line” condition or functioning. In this mode all the
characters sent from computer are interpreted as data and they are sent to the remote modem. You may
switch from data to command mode by entering an escape sequence. The default escape sequence is +++.
To be valid, the sequence must be followed by an AT command, i.e. "+++AT<CR>".
Data Length
Digicom's modems can manage the following ASCII code formats:
CASE START BIT DATA BIT PARITY STOP BIT TOT
11 7 1 110
21 8 0 110
31 7 0 210
The modem will accept even, odd, mark, or space.
3.1. AT COMMAND SET DESCRIPTION
NOTE:
""
default factory commands
AT Attention
All the characters following the letters ‘AT’are commands. InAT command mode the modem automatically
detects the computer speed and parity format. The modem will response using the same speed and parity
format of AT command.
ATA Answer incoming data call
Cause the modem to go off hook and attempt a handshake in answer mode.
A/ Repeat last command
Cause the modem to repeat the lastAT command.This command must not be preceded byATand followed
by CR.
ATD Dial Command
0:9 Dial numbers
*DTMF digits
#DTMF digits
A..D DTMF digits
PPulse dial
TTone dial
S=n Select a number stored in the modem internal book (see AT&Z command)
!Flash
WWait for dial tone
@Wait for five seconds of silence
,Pause
LRecall the last number dialed
;Return to Command state. Added to the end of the dial string, this causes the modem to return
to the command state after it processes the portion of the dial string preceding the “;”. The
modem will enter call progress only after an additional dial command is issued without the “;”
terminator.
ATE Commands Echo
E0 Commands echo disabled.
E1 Commands echo enabled.
3.2
MTL01 Modem AT Command Set
ATH DISCONNECTION
H0 Modem disconnects
H1 Modem connects to the line and remain in command mode for the time defined in S7.
ATI IDENTIFICATION
I0 Maximum line speed
I1 Product type
I3 Product name
I4 Software release
I5 Active Country Code
ATO RETURN ON LINE
O0 On line state when during connection the modem is in command mode.
O1 Like previous plus equalizer retrain.
ATP SET PULSE DIAL DEFAULT
This command forces pulse dialling.
ATQ QUIET RESULT CODES
Q0 Answer codes enabled.
Q1 Answer codes disabled.
ATS READ/WRITE REGISTER
Sn=vvvWrite the vvv value in the n Register.
Sn? Display the value stored in the n Register.
ATT SET TONE DIAL DEFAULT
This command forces tone DTMF dialling.
ATV RESULT CODE FORMAT
V0 Result code display as digit (short form).
V1 Result code display as words (extened form).
