For receiver wiring, follow the steps below and See Figure # 4 :
Step 1 ) Locate the “ STOP “ wire currently connecng the door operator to the 3 buon
staon’s “ STOP ” buon which is located in the door operator control panel. Make note of
its locaon and remove it from the operator terminal.
Step 2 ) Take one of the Orange wires from the DC-5135 receiver and wire-nut it together
with the “ STOP “ wire you just removed from the operators stop terminal.
Step 3 ) Connect the following two wires from the DC-5135 to the door operators 3 buon
“Common “ terminal ( As shown in Figure # 4 )
One Blue ( Open ), One Yellow ( Close )
Step 4 ) Connect the other Yellow wire from the DC-5135 to the “ Close “ pushbuon
terminal on the door operators control panel.
Step 5 ) Connect the other Blue wire from the DC-5135 to the “ Open “ pushbuon
terminal on the door operators control panel.
Step 6 ) Connect the other Orange wire from the DC-5135 to the “ STOP “ pushbuon
terminal on the door operators control panel.
Step 7 ) Complete the wiring by connecng 24 VAC/VDC to the Red and Black wires of
the DC-5135
Step 1 ) Press and HOLD the “Learn\Erase” buon. The Red LED will come on.
Step 2 ) Once the Red LED turns o ( Approximately 3 Seconds ) release the “ Learn\Erase
“ buon.
To check operaon, move back about 50 feet and press the transmier buon. Operaon
should be reliable at this distance but environment and locaon of both the transmier
and receiver will eect the range. Try dierent mounng locaons and posions. If
operaon is sll undesirable, the problem may be isolated by:
1. Checking the door operator. If the door will not open\close or stop when the
DC-5035 buons are pressed, the problem is likely to be the wire connecons
to the operator. If the door will open by pressing the 3 buon wall staon
buons, but not when the radio control buons are pressed, the problem is
probably in the radios. Make sure the operator and the receiver have power.
2. Replacing the transmier baery.
If, aer performing the above operaonal checks, the controls sll do not funcon, they
should be returned to your dealer for repair or replacement.
WARRANTY
All Digi-Code door related products carry an eighteen (18) month warranty against
defects in workmanship or material. This warranty begins at the date of manufacture, for
eighteen months. Digi-Code warrantees our product only to our authorized dealers and
distributors, and not to the end customer. If you have any quesons about our warranty,
please ask your dealer to determine the nature and scope of their warranty. Digi-Code
does not assume, and is not responsible for, any real or consequenal damages from
claims against the performance of our product, nor is it liable for any costs related to
the loss of life, property, or revenue. Further, Digi-Code is in no way responsible for
installaon of our product, and will assume no cost related to reinstallaon or removal.
Digi-Code’s warranty is in lieu of all other warrantees, expressed, or implied.
CAUTION:
Any changes or modicaons in intenonal or unintenonal radiators which are not
expressly approved by Digi-Code Inc. could void the users authority to operate this
equipment. This applies to intenonal and unintenonal radiators cered per part 15 of
the FCC rules and regulaons.
CHECK ALL CONNECTIONS AND INSTALL THE ANTENNA BEFORE REAPPLYING POWER TO
THE OPERATOR
SECTION # 3
RECEIVER PROGRAMMING INSTRUCTIONS
SECTION # 4
ERASING THE RECEIVERS MEMORY
SECTION # 5
OPERATIONAL CHECK
Locate your transmier with your programmed switch sengs
( See Secon # 1 ) which we will now use to program to the
receiver.
Press and “ Release ” the “ Learn\Erase “ buon on the receiver.
(See Figure # 5 ) The Red LED will turn on solid. Now take your
programmed transmier, press and “Hold” any one of the
three buons ( Open, Close or Stop ). The receivers Red LED will
ash quickly and turn o. ( Now release the transmier buon ).
The receiver has now learned ALL three buons.
RED
PROGRAMMING
LED
LEARN/ERASE
BUTTON
Part # 72-5135DIGI-CODE, INC.
Close
Open
Stop
Digi-Code
STOP COM OPEN CLOSE
BLUE
YELLOW
ORANGE
YELLOW
ORANGE
BLUE
RED
BLACK
COMMERCIAL
OPERATOR
WALL PUSH
BUTTON
STATION
COMMON
STEP 3
STEP 5
STEP 4
REMOVED WIRE
(SEE STEP 1)
STEP 2
Figure 4
STEP 7
STEP 6
