INTRODUCTION
Thank you for purchasing DIG Model ST100AS Drip and Soaker Vegetable Watering Kit. Please take the
time to read through the enclosed instructions and to follow them step by step. If you have any questions,
please call our customer service line at 1.800.344.2281. To automate the system, use DIG’s B09D or
EVO 100 Hose End Timer. Use this
Vegetable Watering Kit to efciently use water while maximizing the
amount of water at the root zone, resulting in a healthy abundant crop
.
INSTALLATION
The Drip and Soaker Vegetable Watering Kit can be
installed easily either above or below the ground. It is
designed mainly for use in vegetable gardens, but can
easily be used for any row plantings.
Begin your installation at the water source by
attaching the backow preventer to the faucet. Next,
insert the ow control and then the screen into the
swivel adapter, and thread the swivel adapter into the backow preventer. If the backow preventer is not
included, connect the swivel adapter directly to the faucet, and connect the compression side to the 1/2″poly
tubing by pushing and wiggling the 1/2″poly tubing into the adapter end.
CONNECTING DRIP AND SOAKER TAPE TO 1/2″POLY TUBING
Option 1- single row: Use #77 Connector to have one line of Drip and Soaker
Tape. Connect the poly tubing to the compression side of the #77
Connector by pushing and wiggling the 1/2″poly tubing into the adapter
end. Connect the Drip and Soaker Tape to the other end by turning the ring
counter clockwise to expose the barb. Push the Drip and Soaker Tape over
the barb, and thread the ring clockwise to lock in place.
Option 2- multiple rows: Additional 1/2″poly tubing may be added to the
enclosed 5′section and used as the main line running perpendicular to the
vegetable garden rows. Near each row, punch a hole in the 1/2″poly tubing and
insert the barbed end of the #29 Reducer into the 1/2″poly tubing. Connect the
Drip and Soaker Tape to the other end of the #29 Reducer by turning the ring
counter clockwise to expose the barb. Then, push the Drip and Soaker Tape over
the barb, and thread the ring clockwise to lock in place.
CONNECTING OR ENDING DRIP AND SOAKER TAPE
After connecting the Drip and Soaker Tape to the 1/2″poly tubing, we recommend
ushing the system to make sure that all debris is ushed out before closing the end of
the line. Flush the system by turning the water on for a minute or so, then close the ends
of the poly tubing and the ends of the Drip and Soaker Tape by inserting the #28 Hose
End into the Drip and Soaker Tape and pulling the ring forward to secure.
To connect two pieces of Drip and Soaker Tape together, use a #27
Connector by inserting the #27 Connector into the Drip and Soaker
Tape and pulling the ring forward to secure.
CONNECTING AND ENDING THE 1/2″POLY TUBING
After ushing the system, connect the end cap to the 1/2″poly
tubing by pushing and wiggling the 1/2″poly tubing into the
compression end. Make sure that the threaded end cap is tightened rmly.
INSTALLATION INSTRUCTIONS
Drip and Soaker Vegetable
Watering Systems
Models ST100AS
1/2″Poly tubing
3/4″Adapter Flow Control
Screen Backow Preventer
DIG CORPORATION THREE-YEAR WARRANTY
DIG CORPORATION warrants this packaged product to be free from defects in material and workmanship
for a period of three years. Under this warranty DIG CORPORATION will repair or replace at no charge any
of DIG products that fails in normal use within the warranty stated below.
This warranty does not cover damage resulting from accident, misuse, neglect, modication, improper
installation or subjection to line pressure in excess of normal drip irrigation system operation. This
warranty shall extend only to the original purchaser of the product for use by the purchaser. This warranty
shall not cover any malfunction of the product if used with battery and due to battery failure. The
obligation examination is found to contain defects in material and workmanship.
DIG CORPORATION SHALL IN NO EVENT BE LIABLE FOR ANY INCIDENTAL OR CONSEQUENTIAL DAMAGES
OF ANY KIND; THE SOLE OBLIGATION OF DIG IS LIMITED TO REPAIR OR REPLACEMENT OF DEFECTIVE
PRODUCTS. SOME STATES DO NOT ALLOW THE EXCLUSION OR LIMITATION OF INCIDENTAL OR
CONSEQUENTIAL DAMAGES, SO THE ABOVE LIMITATION OR EXCLUSION MAY NOT APPLY TO YOU.
Unattended use for prolonged periods without inspection to verify proper operation is beyond the
intended use of this product, and any damage resulting from such use shall not be the responsibility of
DIG CORPORATION. There are no warranties, which extend beyond the description on the face hereof.
In the case of purchase of the product for use other than, for irrigation purposes, DIG CORPORATION
hereby disclaims any implied warranties including any warranties of merchantability and tness for a
particular purpose. In the case of the purchase of the product for personal, family or household purposes,
DIG CORPORATION disclaims any such warranties to the extent permitted by law. To the extent that any
such disclaimer or implied warranties shall be ineffectual, then any implied warranties shall be limited
in duration to a period of one year from the date of the original purchase for use by the purchaser. Some
states do not allow limitation on how long an implied warranty lasts, so the above limitation may not apply
to you. In order to obtain performance under this warranty, the responsibility of the user is to returned the
products to the factory, along with proof of purchase indicating original date of purchase, shipping prepaid,
addressed as follows:
DIG CORPORATION, 1210 Activity Drive, Vista, CA 92081. Repaired or replaced units will be shipped
prepaid to the name and address supplied with the unit returned under warranty. Allow four weeks
for repairs and shipping time. Repair of damaged units not otherwise within warranty may be
refused or done at a reasonable cost or charge at the option of DIG CORPORATION.
This warranty gives you specic legal rights, and you may also have other rights, which vary
from state to state.
1.800.322.9146 FAX: 760.727.0282
www.digcorp.com
1210 Activity Drive
Vista, CA 92081-8510
Printed in the USA. We at DIG strongly believe in conservation.
Please recycle whenever possible. 051818 REV B 26-005
