DIG 400A Series Manual de usuario

INSTRUCTION MANUAL

400A Series

Single Station Irrigation

Battery Operated Controller

400A-000 | 400A-XXX

TABLE OF CONTENTS

1. Introduction ………………………………………………………… 1

2. About the 400A Series battery operated controller …………………… 1

3. Component identiﬁcation …………………………………………… 2

4. LCD display and controls …………………………………………… 3

5. Installing the batteries ……………………………………………… 4

6. Valve adapter installation …………………………………………… 5

7. In-line valve installation ……………………………………………… 7

8. Programming………………………………………………………… 8

9. Setting current time and date ………………………………………… 8

10. Setting watering day schedules ………………………………………10

11. Setting watering start times …………………………………………13

12. Setting watering run times (program(s) duration) ………………………15

13. Setting rain delay – optional feature …………………………………16

14. Manual watering ……………………………………………………18

15. Connecting a rain sensor ……………………………………………19

16. Changing the batteries ………………………………………………20

17. Maintenance, troubleshooting and repairs ……………………………20

18. Warranty ……………………………………………………………23

19. Technical assistance …………………………………………………24

20. To order replacement or spare parts …………………………………25

1. INTRODUCTION

Thank you for purchasing DIG’s 400A Series Single Station Battery Powered

Controller. This manual describes how to get the 400A Series controller up and

running quickly. After reading this manual and becoming familiar with the basic

functionality of the controller, use the manual as a reference for less common

tasks in the future.

2. ABOUT THE 400A SERIES BATTERY OPERATED

CONTROLLERS

The 400A Series watering controller employs the latest irrigation programming

features to allow for complete control of any irrigation system and comes

assembled on an in-line valve or the controller only with adapters to ﬁt most

manufacturers valves. The 400A Series is available in single station with a rain

sensor connection, and is powered by two AA batteries that can last up to 3 years

[using name brand alkaline batteries]. The controller is enclosed in a compact,

waterproof housing to protect it from the elements.

3. COMPONENT IDENTIFICATION

1. Controller cover

2. Quick reference label

3. LCD Display displays the icon-based

applications/ programs

4. 7 button programming keypad: Use for

programming, system on/off, manual run

and reviewing program

5. Battery compartment cap for

two AA alkaline batteries (not included)

6. Rain sensor yellow wire connection

7. Collapsible 36 in. solenoid wire

8. DC solenoid

9. Solenoid adapters

10. Manual ﬂow control

11. 3/4 in. professional grade

in-line valve

3 adapters

(included

with model

400A-000)

in-line valve

(included

with model

400A-XXX)

4. LCD DISPLAY AND CONTROLS

LCD Display

1. Time and Date Icon – Indicates current time and day is displayed

2. Sensor Icon – Appears when a rain sensor is active or when yellow wire loop

has been cut and watering is halted

3. Watering Icon – Appears when valve is open

4. Set Watering Days Icon – Choose either speciﬁc days, odd/even days, every X

hours, or up to once every 30 days

5. Start Time Icon – Up to 4 start times per day available

6. Run Time Icon – Watering duration from 1 minute to 5 hours and 59 minutes

7. Rain Delay Icon – Delay irrigation setting from 1 to 99 days with automatic restart

8. Manual Run Icon – Appears when manual button is pushed

9. Battery Level Indicator – Flashes when batteries are low and need to be replaced

10. Day of the Week Underscore –Shows which day of the week the controller

will operate

11. Represents Month

12. Represents Year

ry u i

Control Buttons

Select programming mode

Turn program(s) ON/OFF

Start/stop a manual cycle

Move left/right to select a value

Raise/lower the selected value

5. INSTALLING THE BATTERIES

1. Open the battery compartment cap by

turning it counter-clockwise.

2. Install two, fresh, brand name, AA

alkaline batteries (not included)

and note the proper direction of the

positive and negative orientation on the

underside of the controller.

3. Insert and screw the battery cap

clockwise. Make sure to securely

tighten the cover ﬁrmly by hand only.

The controller display appears with a

day, PM, and the hour digit ﬂashing. The controller

is ready to be installed and programmed.

Battery replacement

6. VALVE ADAPTER INSTALLATION 400A-000

The 400A-000 controller includes 3 adapters to retroﬁt Rainbird, Hunter and Toro

valves. Follow the instructions below to install.

1. Shut off the main water supply

2. Remove the existing solenoid if applicable.

NOTE: If adapting to an IRRITROL valve, remove the solenoid but leave the

existing solenoid adapter installed.

3. Select the appropriate solenoid adapter associated with the valve. (see chart A)

4. Screw the solenoid adapter into the valve bonnet by hand, tighten with pliers if

necessary – but do not over tighten.

5. Thread the 400A Series solenoid into the valve adapter. Hand tighten only.

6. Turn the main water supply on and pressurize the valve; the valve may discharge

water momentarily but should then shut off.

7. Test the controller and the installation by pressing the button or see

section 14 to perform a manual run. To turn the valve on via the solenoid,

lift the 400A Series controller from the solenoid and turn the solenoid counter

clockwise 1/2 to 3/4 of a turn, or until you hear or see water ﬂowing through the

valve. To turn the water off, turn the solenoid clockwise 1/2 to 3/4 of a turn and

wait for the a few seconds for the valve to close.

8. Program the 400A Series controller (see section 8).

Solenoid

adapter

CHART A

Model Compatible Valves

30-920* BERMAD series 200, HIT series 500,DOROT series 80,

GRISWOLD series2000, DW and BUCKNER series VB valves

30-921

INCLUDED

RAIN BIRD DV,DVF,PGA,PEB (1” only),GB,EFB-C P,

BPE, PESB (1” only)and ASVF valves

30-922

INCLUDED

HUNTER series ASV, HPV, ICV,PGV, SRV, IBV and

ASVF valves

30-923* WEATHERMATIC series 12000, 21000, 8200CR valves

30-924

INCLUDED

IRRITROL series 100, 200B, 205, 217B,

700, 2400, 2500, 2600 and TORO series 220, P220 valves

30-925* SUPERIOR series 950, HUNTER HBV and TORO series

252 valves (1.5” and larger)

30-926* RAIN BIRD SERIES PEB

AND PESB VALVES

*AVAILABLE THROUGH YOUR DISTRIBUTOR

+ 400A-000 ONLY

Below ground installation

7. IN-LINE VALVE INSTALLATION 400A-XXX

Rated operating pressure: 10-125 PSI

Recommended Operating Pressure: 10-80 PSI

Warning: Wrap all ﬁttings with Teﬂon tape! Do not

use pipe cement on valve as this will damage the

valve and void the warranty!

1. Shut off main water supply.

2. Install a 3/4 in. ball or gate valve onto the PVC pipe

or to the valve manifold before installing the controller

(Figure 1a and 1b).

3. Turn water supply on to ﬂush the line and then shut the

water off using the ball or gate valve.

4. Wrap the male threads of the PVC adapters with 4-6

layers of Teﬂon tape, then tighten into the valve

with a wrench.

5. Glue ﬁttings to PVC main line and allow

to dry.

6. Turn water supply on to

pressurize the system.

The controller will open

momentarily and then will

shut off.

Figure 1a

Figure 1b

Above ground installation

Water

ﬂow

8. PROGRAMMING

The 400A Series controller can be programmed to operate on any day of the week,

odd days or even days. In cyclical mode the 400A Series can also operate from every

1 hour up to every 12 hours or from once a day up to every 30 days. The

400A Series has four start times per day and durations from 1 minute up to 5 hours

and 59 minutes.

This section explains the programming features, and the steps necessary to assign

irrigation schedules. To program the controller use the to select the desired

programming mode, the to make the entry ﬂash and the buttons to

change the value.

NOTE: Only a ﬂashing value can be changed.

NOTE: If the last data entered stops ﬂashing, press again to resume

programming and repeat the steps.

9. SETTING CURRENT TIME AND DATE

The controller can display the time in either a 12 or 24 hour format.

To change the time format, from the home screen:

1. Press the button for three seconds until the display switches format

(AM/PM disappears).

SETTING THE CURRENT TIME AND DATE

To enable the controller to operate properly, the current time and date must

be set.

1. Press the button, until the icon appears along with the time and the day

of the week.
