PDN LITES2 Field Manual
7. Once you have established eective Internet access, log o the network and push
the unit’s Standby Button, the LED light will turn o, indicating gateway services
have been turned o. Avoid leaving the gateway on when not in use, as it will
continue to draw power from the batteries if left on.
8. Locate AC charging cord, lift the weather cover on the recessed AC receptacle,
and plug in the unit. At this time observe the current charge level shown on the
Battery Gauge LEDs. If 30 days have passed since the last charge, it will likely
show low charge. Allow the battery to charge until Battery Gauge indicates
full-charge status.
9. Return to storage, leaving Main Power Switch in the “ON” position while
plugged into available live AC power source.
Record your maintenance data in the Maintenance Log on pages 16-19.
Note: All pass-through ports, caps, seals and gaskets should be inspected periodically to
ensure a tight fit. Contact DHWS for information regarding PDN remote updates or other
maintenance needs. If you are experiencing ongoing issues with your PDN or would like to
order parts, contact DHWS at 877.524.0430, option 3. For online support ticketing or incident
reporting, visit www.portablessupport.com.
TROUBLESHOOTING
1. If unit fails to power up, check to ensure Main Power Switch is in the on position.
Then check the Battery Gauge to ensure batteries are suciently charged. Unit
can run at the same time it is being charged by AC power source.
2. If batteries need to be charged, connect supplied AC Power Cord to unit’s AC
Charging Port and then plug into a live 110-120V AC power source. Main Power
Switch must be “ON” and Battery Gauge will scale to indicate PDN is charging.
3. If WiFi does not appear on your device, ensure cellular gateway is active by
checking status lights.
4. Should a power related issue persist, or to learn more about your on-board
SmartSource (S2), visit www.portablessupport.com.
