DGTEC DG-HDPVR320 Manual de usuario

THE FUTURE OF HOME ENTERTAINMENT

HIGH DEFINITION PERSONAL VIDEO RECORDER

INSTRUCTION MANUAL MODEL NUMBER:DG-HDPVR320

BC79752

After Sales Support

TEL : 1800 189 941

HELP PROVIDED

NEED HELP?

If you are experiencing difficulty operating this product or require set up

assistance please contact the DGTEC Service Centre. The call is free from

anywhere in Australia. Our operators will assist you in plain English without the

technical jargon:

(Australia)

8:00am - 6:00pm Australian EST

* Subject to change without notice.

INDEX

INDEX.........................................................................................................................2

SAFETY AND INSTRUCTIONS ..................................................................................3

ASSEMBLY AND PARTS LIST ...................................................................................4

1.1 PARTS LIST..........................................................................................................4

1.2 FEATURES ...........................................................................................................4

1.3 FRONT PANEL......................................................................................................5

1.4 REAR PANEL........................................................................................................6

1.5 REMOTE CONTROL UNIT....................................................................................7

1.6 INSTALLING THE BATTERIES IN THE REMOTE CONTROL...............................8

1.7 CONNECTING TO EQUIPMENT...........................................................................9

GETTING STARTED.................................................................................................11

2.1 INSTRUCTIONS .................................................................................................14

2.2 TIMER SETTING.................................................................................................14

2.3 SYSTEM SETTINGS...........................................................................................15

2.4 CHANNEL MANAGER ........................................................................................17

2.5 PARENTAL CONTROL........................................................................................18

2.6 FILE MANAGER..................................................................................................19

2.7 INSTALLATION ...................................................................................................19

2.8 EPG ....................................................................................................................21

2.9 TELETEXT..........................................................................................................22

3. PVR FUNCTION ...................................................................................................22

3.1 PVR SETTINGS..................................................................................................23

3.2 RECORD LIST....................................................................................................24

PS1 TROUBLE SHOOTING .....................................................................................27

PS2 SPECIFICATION ...............................................................................................28

SAFETY AND INSTRUCTIONS

CAUTION: TO PREVENT ELECTRICAL SHOCK, DO NOT REMOVE THE COVER.

THERE ARE NO USER SERVICEABLE PARTS INSIDE. REFER

SERVICING TO QUALIFIED SERVICE PERSONNEL.

SAFETY

．Never place the unit in hot, humid or excessively dusty places.

．Do not install the unit where it may be exposed to mechanical vibrations.

．This product should be operated only from the type of power source indicated on the

rear of the unit.

．Do not touch the power cord with a wet hand or continue to use a damaged power

cord. It may cause an electric shock.

．Never open the cover. High voltage in the unit may result in electrocution.

．Disconnect the power cord to the unit before connecting any cables.

CAUTION

．To prevent fire or electrical shock do not expose the appliance to water.

．Ensure that objects filled with liquids, such as vases, are not placed on the

apparatus.

．If an object or liquid gets into the unit, disconnect the plug and ask an approved

technician to check the unit.

．Never place the unit in a confined space such as a bookcase or built-in cabinet

unless proper ventilation is provided. Leave a 10cm gap around the unit.

．The recommended operating temperature is from 0 ~ 40

℃℃and humidity should be

under 95%.

．For your own safety, do not touch any part of the unit, power lead or aerial

lead during a lightning storm.

．Use a damp cloth to clean the unit.

．Do not use liquid cleaners, solvent or abrasive products, etc.

This symbol indicates that high voltage is present inside. It is dangerous to

make contact with any part inside the case.

This symbol alerts you of important information concerning operation and

maintenance of this product.

ASSEMBLY AND PARTS LIST

1.1 Parts List

Please make sure the following accessories are supplied with the PVR.

① High-Definition Personal Video Recorder (PVR )

② Remote Control

③ RCA Video/Audio Cable

④ Batteries (AAA Size)

⑤User Manual

⑦RF Loop Cable

1.2 Features

zTwin Tuner High Definition Personal Video Recorder.

zRecord two channels at the same time and watch a third channel from the same

bandwidth. For example record channels 7 and 9 and watch either channel 72 or

channel 99.

zRecord two channels at the same time and watch a recorded file in playback.

zChase play a file that is recording.

zTimeshift, press the PAUSE key on the remote to pause Live TV.

zSet your recordings a week ahead using the EPG.

zView JPEG files and play MP3s from a USB drive.

zRecords programs from standby mode.

ASSEMBLY AND PARTS LIST

1.3 Front Panel

1. POWER Button

Turns the PVR’s power on or off.

2. Front Panel Display

Front panel window displays information concerning current operation such as TIME,

CH number. The green LED lights up when the channel is locked in.

A hidden sensor senses infrared signal from the remote control.

3. CH Up/Down Button (▲/▼)

Moves the cursor up/down when in the menu or changes the current program to the

previous/next channel in operational mode.

4. Volume Left/Right Button (◄/►)

Press to switch between operation and standby modes. The blue LED illuminates

when in the standby mode.

5. OK Button (OK)

Press to select an item in the menu or to activate the Channel List in operational

mode.

6. Menu Button (MENU)

Press to display the Main Menu or to exit from the menu.

ASSEMBLY AND PARTS LIST

1.4 Rear Panel

1. ANT IN

Used to connect an antenna.

2. ANT OUT (LOOP OUT)

Used to connect an extra analogue or digital STB.

Please connect ANT OUT1 with ANT IN2 correctly.

3. DIGITAL AUDIO (S/PDIF / Optical)

Connects to an External Audio Amplifier with S/PDIF / Optical Digital Audio

(optional).

4. USB

USB port is used to view JPEG files, play MP3 files and for possible software

upgrades. (To be advised by DGTEC technician)

5. HDMI Connector

Connect High-Definition Multimedia output to HD Monitors (HDMI Type).

6. VIDEO (Yellow RCA)

Connect to a TV with video input.

7. AUDIO L/R (White / Red RCA)

Connect to a TV audio input, HD Monitors audio input or an External Audio Amplifier.

8. YPbPr

Connect component video to HD Monitors (YPbPr Type).

ASSEMBLY AND PARTS LIST

1.5 Remote Control Unit

All PVR features can be operated with the remote control.

1. POWER: Press to switch between

operation and standby mode.

2. MTS: Press to select an item in the sound

mode.

3. AUDIO: Select an item in the audio mode.

4. NUMERIC KEYS: Select channels and input

numbers for codes

5. EXIT: Press to return to the previous menu

or to escape from the current mode.

6. Up▲/ Down▼: Change the channel or

move the cursor in the menu.

7. Left◄/ Right►: Adjust volume or move

cursor in the menu.

8. PAGE +/ PAGE–: Press to navigate to top

and bottom of pages in the channel list and

EPG.

9. 30- (Red) / 30+ (Green): 30sec jump

backwards / forward.

10. P.STD: Selects the display resolution mode

(1080i/720p/576p).

11. TV/RADIO: Press to switch between TV

and RADIO mode.

12. MUTE: Press to mute the sound.

13. TEXT: Display the Teletext information (not

always available).

14. SUBT: Displays Closed Captions (CC).

15. FAV: Press to display Favorite Channel

Mode.

16. ASPECT: Press to select 4:3 or 16:9 aspect

ratio mode.

17. SCAN: Press to automatically scan for digital channels.

18. TIMER: Enters Timer environment.

19. MENU: Displays or exits the Main Menu.

20. OK: Select a highlighted item in the menu or displays the channel list.

21. i: Displays current program information.

22. RECALL: Return the previous channel.

23. FREEZE (Yellow): Freeze the video output of the PVR (this is not Timeshift,

press Pause to activate Timeshift).

24. EPG (Blue): Displays the 8 day Electronic Program Guide.

25. P.STD: Selects the display resolution mode (1080i/720p/576p).

ASSEMBLY AND PARTS LIST

1.6 Installing the batteries in the remote control

1. Press down on the retaining catch on the lid of the battery recess on the remote

control and slide downward to remove the lid.

2. Insert two AAA batteries into the recess.

3. Replace the lid over the recess and gently push down on the lid and slide upward

until it snaps firmly into place.

Caution

1. Keep batteries out of the reach of children.

2. Do not attempt to recharge, short-circuit, disassemble, heat or throw the batteries

into the fire.

3. Always replace both batteries at the same time. Never mix new and old batteries

or batteries of a different type.

4. If you don’t intend to use the remote control for an extended period, remove the

batteries to prevent possible leakage and corrosion.

5. Do not drop, apply shock or step on the remote control.

6. Do not spill water on the remote control.

Note: If the PVR does not respond when operating the remote control from a

close range, you will need to replace the batteries.

Using the Remote Control

1. To use the remote control, point it towards the front of the PVR.

2. The remote control has a range of up to 7 metres from the PVR at an angle of up

to 60 degrees.

3. The remote control will not operate if its path to the sensor on the front panel of the

PVR is blocked.

Note: Sunlight or very bright light will decrease the sensitivity of the remote

control.

ASSEMBLY AND PARTS LIST

1.7 Connecting to Equipment

1. Connect your TV antenna cable to the “ANT IN” jack on the back of the PVR using

coaxial RF cable. Make sure the loop cable is connected correctly to activate the

second tuner (see the diagram below)

YPbPr connection

2. Connect the YPbPr output connectors (three RCA connectors - green, red and

blue) for video from the rear panel of the PVR to the COMPONENT IN on your

television matching colour for colour and AUDIO L/R output connectors (two RCA

connectors – red and white) for audio from rear panel of the PVR to the

corresponding audio input of your television.

HDMI

High Definition Multimedia Interface (HDMI) provides both high quality digital video

and audio connection in one cable.

3. Connect the HDMI cable from the HDMI output on the rear panel of the PVR to

the corresponding HDMI input of HDTV or Amplifier using HDMI cable for both

Video and Audio connections.
