KU968

COM Express Compact Module

User’s Manual

A45600815

www.dﬁ.comChapter 1 Introduction

This publication contains information that is protected by copyright. No part of it may be re-

produced in any form or by any means or used to make any transformation/adaptation without

the prior written permission from the copyright holders.

This publication is provided for informational purposes only. The manufacturer makes no

representations or warranties with respect to the contents or use of this manual and specifi-

cally disclaims any express or implied warranties of merchantability or fitness for any particular

purpose. The user will assume the entire risk of the use or the results of the use of this docu-

ment. Further, the manufacturer reserves the right to revise this publication and make changes

to its contents at any time, without obligation to notify any person or entity of such revisions

or changes.

Changes after the publication’s first release will be based on the product’s revision. The website

will always provide the most updated information.

Trademarks

Product names or trademarks appearing in this manual are for identification purpose only and

are the properties of the respective owners.

COM Express Specification Reference

PICMG®COM Express ModuleTM Base Specification.

http://www.picmg.org/

FCC and DOC Statement on Class B

This equipment has been tested and found to comply with the limits for a Class B digital

device, pursuant to Part 15 of the FCC rules. These limits are designed to provide reason-

able protection against harmful interference when the equipment is operated in a residential

installation. This equipment generates, uses and can radiate radio frequency energy and, if not

installed and used in accordance with the instruction manual, may cause harmful interference

to radio communications. However, there is no guarantee that interference will not occur in a

particular installation. If this equipment does cause harmful interference to radio or television

reception, which can be determined by turning the equipment off and on, the user is encour-

aged to try to correct the interference by one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and the receiver.

• Connect the equipment into an outlet on a circuit different from that to which the receiver

is connected.

• Consult the dealer or an experienced radio TV technician for help.

Notice:

1. The changes or modifications not expressly approved by the party responsible for compli-

ance could void the user’s authority to operate the equipment.

2. Shielded interface cables must be used in order to comply with the emission limits.

www.dﬁ.comChapter 1 Introduction

Table of Contents

Trademarks........................................................................................................2

COM Express Specification Reference...................................................2

FCC and DOC Statement on Class B.....................................................2

Warranty ............................................................................................................4

Static Electricity Precautions......................................................................4

Safety Measures..............................................................................................4

About the Package.........................................................................................5

Optional Items..................................................................................................5

Before Using the System Board...............................................................5

Chapter 1 - Introduction.............................................................................6

Specifications ................................................................................................6

Features..........................................................................................................7

Chapter 2 - Concept.......................................................................8

COM Express Module Standards..............................................................8

Specification Comparison Table ...............................................................9

Chapter 3 - Hardware Installation.............................................. 10

Board Layout...............................................................................................10

Block Diagram.............................................................................................10

System Memory..........................................................................................11

Connectors...................................................................................................12

CPU Fan Connector.....................................................................................12

COM Express Connectors ............................................................................13

COM Express connectors Signal Discription ..................................................14

Standby Power LED...................................................................................21

Cooling Option............................................................................................21

Installing KU968 onto a Carrier Board................................................22

Installing the COM Express Debug Card.............................................24

www.dﬁ.comChapter 1 Introduction

Warranty

1. Warranty does not cover damages or failures that arised from misuse of the product,

inability to use the product, unauthorized replacement or alteration of components and

product specifications.

2. The warranty is void if the product has been subjected to physical abuse, improper instal-

lation, modification, accidents or unauthorized repair of the product.

3. Unless otherwise instructed in this user’s manual, the user may not, under any circum-

stances, attempt to perform service, adjustments or repairs on the product, whether in or

out of warranty. It must be returned to the purchase point, factory or authorized service

agency for all such work.

4. We will not be liable for any indirect, special, incidental or consequencial damages to the

product that has been modified or altered.

Static Electricity Precautions

It is quite easy to inadvertently damage your PC, system board, components or devices even

before installing them in your system unit. Static electrical discharge can damage computer

components without causing any signs of physical damage. You must take extra care in han-

dling them to ensure against electrostatic build-up.

1. To prevent electrostatic build-up, leave the system board in its anti-static bag until you are

ready to install it.

2. Wear an antistatic wrist strap.

3. Do all preparation work on a static-free surface.

4. Hold the device only by its edges. Be careful not to touch any of the components, contacts

or connections.

5. Avoid touching the pins or contacts on all modules and connectors. Hold modules or con-

nectors by their ends.

Safety Measures

To avoid damage to the system:

• Use the correct AC input voltage range.

To reduce the risk of electric shock:

• Unplug the power cord before removing the system chassis cover for installation or servic-

ing. After installation or servicing, cover the system chassis before plugging the power

cord.

Important:

Electrostatic discharge (ESD) can damage your processor, disk drive and other com-

ponents. Perform the upgrade instruction procedures described at an ESD worksta-

tion only. If such a station is not available, you can provide some ESD protection by

wearing an antistatic wrist strap and attaching it to a metal part of the system chas-

sis. If a wrist strap is unavailable, establish and maintain contact with the system

chassis throughout any procedures requiring ESD protection.

www.dﬁ.comChapter 1 Introduction

About the Package

The package contains the following items. If any of these items are missing or damaged,

please contact your dealer or sales representative for assistance.

• One KU968 board

• One heat sink (Height: 23.8mm)

Optional Items

• COM332-B carrier board kit

• Heat spreader (Height: 11mm)

The board and accessories in the package may not come similar to the information listed

above. This may differ in accordance with the sales region or models in which it was sold. For

more information about the standard package in your region, please contact your dealer or

sales representative.

Before Using the System Board

Before using the system board, prepare basic system components.

If you are installing the system board in a new system, you will need at least the following

internal components.

• Storage devices such as hard disk drive, etc.

You will also need external system peripherals you intend to use which will normally include at

least a keyboard, a mouse and a video display monitor.

www.dﬁ.comChapter 1 Introduction

Chapter 1 - Introduction

Specifications

Chapter 1

SYSTEM Processor 7th Generation Intel®CoreTM Processors, BGA 1356

Intel®CoreTM i7-7600U Processor, Dual Core, 4M Cache, 2.8GHz (3.9GHz), 15W

Intel®CoreTM i5-7300U Processor, Dual Core, 3M Cache, 2.6GHz (3.5GHz), 15W

Intel®CoreTM i3-7100U Processor, Dual Core, 3M Cache, 2.4GHz, 15W

Intel®Celeron®Processor 3965, Dual Core, 2M Cache, 2.2GHz, 15W

Memory 4GB/8GB DDR4 Memory Down

Dual Channel DDR4 2133MHz

BIOS Insyde SPI 128Mbit

GRAPHICS Controller Intel®HD Graphics

Feature OpenGL 5.0, DirectX 12, OpenCL 2.1

HW Decode: AVC/H.264, MPEG2, VC1/WMV9, JPEG/MJPEG, HEVC/H265, VP8, VP9

HW Encode: AVC/H.264, MPEG2, JPEG, HEVC/H265, VP8, VP9

Display 1 x VGA/DDI (DDI available upon request)

1 x LVDS/eDP (eDP available upon request)

1 x DDI

VGA: resolution up to 1920x1200 @ 60Hz

LVDS: dual channel 24-bit, resolution up to 1920x1200 @ 60Hz

eDP: resolution up to 4096x2304 @ 60Hz

HDMI: resolution up to 4096x2160 @ 30/24Hz

DP++: resolution up to 4096x2304 @ 60Hz

Triple Displays VGA + LVDS + DDI

DDI + eDP + DDI

EXPANSION Interface 5 PCIe x1 or 4 PCIe x1 + 1 PCIe x4 or 3 PCIe x1 + 2 PCIe x2 (support up to 5

devices and 8 lanes)

1 x LPC

1 x I2C

1 x SMBus

2 x UART (TX/RX)

AUDIO Interface HD Audio

ETHERNET Controller 1 x Intel®I219LM with iAMT11.0 PCIe (10/100/1000Mbps)

I/O USB 4 x USB 3.0

8 x USB 2.0

SATA 3 x SATA 3.0 (up to 6Gb/s)

RAID 0/1/5/10

DIO 1 x 8-bit DIO

WATCHDOG

TIMER Output &

Interval System Reset, Programmable via Software from 1 to 255 Seconds

SECURITY TPM Available Upon Request

POWER Type 12V, 5VSB, VCC_RTC (ATX mode)

12V, VCC_RTC (AT mode)

Consumption TBD

OS SUPPORT Windows: Windows 10 IoT Enterprise 64-bit

LINUX: Yocto Project v2.2

ENVIRONMENT Temperature Operating

: 0 to 60°C

: -45 to 85°C (with heat spreader)

Storage: -40 to 85°C

Humidity Operating: 5 to 90% RH

Storage: 5 to 90% RH

MTBF TBD

MECHANICAL Dimensions COM Express®Compact

95mm (3.74") x 95mm (3.74")

Compliance PICMG COM Express®R2.1, Type 6

www.dﬁ.comChapter 1 Introduction

Chapter 1

Features

• Watchdog Timer

The Watchdog Timer function allows your application to regularly “clear” the system at the set

time interval. If the system hangs or fails to function, it will reset at the set time interval so

that your system will continue to operate.

• DDR4

DDR4 delivers increased system bandwidth and improves performance. The advantages of

DDR4 provide an extended battery life and improve the performance at a lower power than

DDR3/DDR2.

• Graphics

The integrated Intel®HD graphics engine delivers an excellent blend of graphics performance

and features to meet business needs. It delivers enhanced media conversion rates and higher

frame rates on 4K Ultra HD videos. These enhancements deliver the performance and compat-

ibility to meet the demand for business and home entertainment applications. Supports 1 x

VGA/DDI (DDI available upon request), 1 x LVDS/eDP ( eDP available upon request) and 1 x

DDI display interfaces.

• Serial ATA

Serial ATA is a storage interface that is compliant with SATA 1.0a specification. With speed of

up to 6Gb/s (SATA 3.0), it improves hard drive performance faster than the standard parallel

ATA whose data transfer rate is 100MB/s. The bandwidth of the SATA 3.0 will be limited by

carrier board design.

• Gigabit LAN

The Intel®I219LM Gigabit LAN PHY controller supports up to 1Gbps data transmission.

• USB

The system board supports the new USB 3.0. It is capable of running at a maximum transmis-

sion speed of up to 5 Gbit/s (625 MB/s) and is faster than USB 2.0 (480 Mbit/s, or 60 MB/s)

and USB 1.1 (12Mb/s). USB 3.0 reduces the time required for data transmission, reduces

power consumption, and is backward compatible with USB 2.0. It is a marked improvement in

device transfer speeds between your computer and a wide range of simultaneously accessible

external Plug and Play peripherals.

www.dﬁ.comChapter 2 Concept

Chapter 2

Chapter 2 - Concept

106.00

91.00

70.00

51.00

4.00

18.00

6.00

0.00

16.50

4.00

0.00

Extended

BasicCompact

Mini

74.20

80.00

91.00

121.00

151.00

Common for all Form Factors

Extended only

Basic only

Compact only

Compact and Basic only

Mini only

COM Express Module Standards

The figure below shows the dimensions of the different types of COM Express modules.

KU968 is a COM Express Compact module. The dimension is 95mm x 95mm.

www.dﬁ.comChapter 2 Concept

Chapter 2

Specification Comparison Table

Module Pin-out - Required and Optional Features C-D Connector. PICMG®COM.0 Revision 2.1

The table below shows the COM Express standard specifications and the corresponding specifications supported on the KU968 module.

• 5 Indicates 12V-tolerant features on former VCC_12V signals.

• 6 Cells in the connected columns spanning rows provide a rough approximation of features

sharing connector pins.

Connector Feature

COM Express Module Base

Specification Type 6

(No IDE or PCI, add DDI+ USB3)

Min

DFI KU968

Type 6

A-B

A-B PCI Express Lanes 0 - 5 1 / 6 6

A-B LVDS Channel A 0 / 1 1

A-B LVDS Channel B 0 / 1 1

A-B eDP on LVDS CH A pins 0 / 1 1

A-B VGA Port 0 / 1 0/1 (Option : DDI2 or VGA)

A-B TV-Out NA NA

A-B DDI 0 NA NA

A-B5Serial Ports 1 - 2 0 / 2 2

A-B CAN interface on SER1 0 / 1 0

A-B SATA / SAS Ports 1 / 4 3

A-B AC’97 / HDA Digital Interface 0 / 1 1

A-B USB 2.0 Ports 4 / 8 8

A-B USB Client 0 / 1 0

A-B USB 3.0 Ports NA NA

A-B LAN Port 0 1 / 1 1

A-B Express Card Support 1 / 2 2

A-B LPC Bus 1 / 1 1

A-B SPI 1 / 2 1

A-B SDIO (muxed on GPIO) 0 / 1 0

General Purpose I/O 8 / 8 8

A-B SMBus 1 / 1 1

A-B I2C 1 / 1 1

A-B Watchdog Timer 0 / 1 1

A-B Speaker Out 1 / 1 1

A-B External BIOS ROM Support 0 / 2 1

A-B Reset Functions 1 / 1 1

A-B6

System I/O

System Management

Connector Feature

COM Express Module Base

Specification Type 6

(No IDE or PCI, add DDI+ USB3)

Min

DFI KU968

Type 6

A-B

A-B Thermal Protection 0 / 1 1

A-B Battery Low Alarm 0 / 1 1

A-B Suspend/Wake Signals 0 / 3 1

A-B Power Button Support 1 / 1 1

A-B Power Good 1 / 1 1

A-B VCC_5V_SBY Contacts 4 / 4 4

A-B5Sleep Input 0 / 1 1

A-B5Lid Input 0 / 1 1

A-B5Fan Control Signals 0 / 2 2

A-B Trusted Platform Modules 0 / 1 1

A-B

A-B VCC_12V Contacts 12 / 12 12

Power Management

Power

Connector Feature

COM Express Module Base

Specification Type 6

(No IDE or PCI, add DDI+ USB3)

Min

DFI KU968

Type 6

C-D PCI Express Lanes 16 - 31 0 / 16 0

PCI Express Graphics (PEG) 0 / 1 0

Muxed SDVO Channels 1 - 2 NA NA

PCI Express Lanes 6 - 15 0 / 2 2

PCI Bus - 32 Bit NA NA

PATA Port NA NA

LAN Ports 1 - 2 NA NA

DDIs 1 - 3 0 / 3 1/2

(

tion : DDI2 or VGA

)

USB 3.0 Ports 0 / 4 4

C-D

C-D VCC_12V Contacts 12 / 12 12

System I/O

Power

C-D6

Module Pin-out - Required and Optional Features A-B Connector. PICMG®COM.0 Revision 2.1

www.dﬁ.comChapter 3 Hardware Installation

Chapter 3

Chapter 3 - Hardware Installation

Board Layout

Top View

Bottom View

Block Diagram

iTE

IT8528VG

TPM (optional)

DDR4 DDR4 DDR4 DDR4

SPI Flash BIOS

Intel

BGA 1356

Intel

I219LM NXP

PTN3460

Chrontel

CH7517

CPU Fan

Standby

Power LED

COM Express Connector

C110

D110

B1B110

A1A110

COM Express Connector

DDR4 DDR4

DDR4

EEPROM

SATA 3.0 3x

USB 3.0 4x

A / B

SATA

SMBus

7th Generation

Intel®Core™i7/i5/i3

Intel®Celeron™

USB

3.0

Intel®GLAN

I219LM

MDI

SPI Flash

SPI Bus

C / D

2GB/4GB DDR4

Memory Down

Channel A

PCIe x1

PCIe x1 (4x1/2x2/1x4)

LPC Bus

PCIe

(4x1/2x2/1x4)

LPC

Bus

8-bit DIO

WDT

I2C Bus

TPM

1.2/2.0

(optional)

Serial Port 0,1

Fan PWM/

TACH_IN

SLP/LID

WDT

SLP/LID

TCA6408A

(

Embedded

Controller

IT8528E

DDI Port 1

DDI

Port

HDA

USB 2.0 8x

USB

eDP/DDI

(optional)

(p )

PTN3460

LVDS

DDI

(optional)

CH7517

VGA

DDI Port 2

/DDI

PCIe x1 (2 x1/1 x2)

PCIe

x1/1

x2)

PCIe x1 (2 x1)

PCIe

x1)

2GB/4GB DDR4

Memory Down

Channel B

SLP/LID

EEPROM

SMBus

-bit DIO

SMBus

TCA6408A

C608

Otros manuales para KU968

Tabla de contenidos

Manuales populares de Unidad de control de otras marcas

Festo

Festo Compact Performance CP-FB6-E Manual de lista de piezas

Elo TouchSystems

Elo TouchSystems DMS-SA19P-EXTME Manual de usuario

JS Automation

JS Automation MPC3034A Manual de usuario

JAUDT

JAUDT SW GII 6406 Series Guía rápida

Spektrum

Spektrum Air Module System Manual de usuario

BOC Edwards

BOC Edwards Q Series Manual de usuario

KHADAS

KHADAS BT Magic Manual de usuario

Etherma

Etherma eNEXHO-IL Manual de usuario

PMFoundations

PMFoundations Attenuverter Manual de usuario

GEA

GEA VARIVENT Manual de usuario

Walther Systemtechnik

Walther Systemtechnik VMS-05 Manual de usuario

Altronix

Altronix LINQ8PD Instrucciones de montaje

Eaton

Eaton Powerware Series Manual de usuario

WAGO

WAGO 750-407/040-000 Manual de usuario

Sony

Sony CCU-590 Manual de usuario

Graco

Graco 25D614 Manual de usuario

Task Force Tips

Task Force Tips YE-RF-900 Manual de programación

Shini

Shini SPV-U Series Manual de usuario
