Devolo DLAN pro 1200+ Manual de usuario

dLAN®pro 1200+

pro 1200+

devolo dLAN®pro 1200+

While the information in this manual has been compiled with great care, it may not be deemed an assurance of product characteristics. devolo shall be liable only

to the degree specified in the terms of sale and delivery.

The reproduction and distribution of the documentation and software supplied with this product and the use of its contents is subject to written authorization from

devolo. We reserve the right to make any alterations that arise as the result of technical development.

Trademarks

HomePlug®is a registered trademark of HomePlug Powerline Alliance.

Linux®is a registered trademark of Linus Torvalds.

Windows®and Microsoft®are registered trademarks of Microsoft, Corp.

devolo, dLAN®, Vianect®and the devolo logo are registered trademarks of devolo AG.

All other names mentioned may be trademarks or registered trademarks of their respective owners. Subject to change without notice. No liability for technical errors

or omissions.

devolo AG

Charlottenburger Allee 60

52068 Aachen

Germany

www.devolo.com

Aachen, March 2015

Contents

devolo dLAN pro 1200+

Contents

1 Preface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

1.1 About this manual . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

1.1.1 Intended use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

1.1.2 CE conformity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

1.1.3 Safety notes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

1.2 devolo on the Internet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7

2 Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

2.1 What exactly is dLAN? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

2.2 devolo—Up to speed on green IT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

2.3 The dLAN pro 1200+ . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

2.4 All about the network . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

2.4.1 Internet standalone solution . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

2.4.2 dLAN Peer-to-Peer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

2.4.3 dLAN MDU . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

3 Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

3.1 Package contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15

3.2 System requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

3.3 Functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

3.3.1 Monitoring light . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

3.3.2 Network connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

3.3.3 Encryption button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

3.3.4 Integrated electrical socket . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

3.3.5 Standby mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

3.4 Connecting the dLAN pro 1200+ . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

3.5 Software installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18

3.5.1 Software for Windows . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

Contents

devolo dLAN pro 1200+

4 dLAN pro network . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

4.1 Security in the dLAN . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19

4.2 dLAN pro network encryption at the touch of a button . . . . . . . . . . . . . . . . . . . . . . . . . . 19

4.3 dLAN AVpro manager for Windows . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

5 Appendix . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25

5.1 Bandwidth optimization . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25

5.2 Disposal of old devices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .25

5.3 Warranty conditions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .26

Preface 5

devolo dLAN pro 1200+

1Preface

Thank you for placing your trust in this product.

devolo dLAN business solutions are a favourably

priced option for using the power grid infrastructure

in a building to establish a broadband IP network.

The advantage this brings is obvious: no new cables

have to be laid – expenditure and costs remain low.

dLAN can be used as an easily scalable, primary net-

work as well as to supplement an existing infrastruc-

ture.

The dLAN pro 1200+ allows you to set up your own

home network with almost no effort. Because the

clever dLAN technology transmits the data over the

electrical wiring, you do not have to lay any new cab-

les.

1.1 About this manual

Carefully read all instructions before setting up the de-

vice and store the manual and/or installation guide for

later reference.

After a brief introduction to "dLAN" and "Green IT"

basics and a presentation of the dLAN pro 1200+ in

Chapter 2, Chapter 3 will cover successfully setting

up your dLAN pro 1200+. Chapter 4 explains how to

configure your dLAN pro network. Tips for bandwidth

optimization, information of environmental compatibi-

lity of the device and our warranty conditions can be

found in Chapter 5 and conclude the manual.

You can find the technical data for the

dLAN pro 1200+ in the product information sheet on

the enclosed product CD.

Description of the symbols

Here we briefly describe the meaning of the symbols

used in this manual.

Very important note. Failure to ob-

serve this note may result in damage.

Important note that should be obser-

ved.

Additional information, background mate-

rial and configuration tips for your device.

6 Preface

devolo dLAN pro 1200+

1.1.1 Intended use

Use the adapter as described in these instructions to

prevent damage and injuries.

1.1.2 CE conformity

This product complies with the technical requirements

of the EMC directive 2004/108/EC and the other rele-

vant provisions of the FTEG.

This product is designed for use in

the EU, Switzerland and Norway.

The product is class B equipment.

You can find the CE declaration of this product on the

enclosed product CD and/or under www.devolo.com.

1.1.3 Safety notes

It is essential to have read and understood all safety

and operating instructions before the devolo device is

used for the first time; keep them safe for future refe-

rence.

DANGER due to electricity

Users should never open devolo devices. Opening

the device poses a risk of electric shock!

Users do not need to carry out any maintenance on de-

volo devices. In the event of damage, disconnect the

devolo device from the mains supply by pulling it or its

plug out of the power outlet. Then contact qualified

specialist personnel (after-sales service) exclusively.

Damage is deemed to have occurred, for example,

쎲if the power cable or plug is damaged

쎲if the devolo device has been showered with

liquid (e.g. rain or water).

쎲if the devolo device is inoperable.

쎲if the housing of the devolo device is damaged.

devolo devices may only be operated using a mains

power supply, as described on the nameplate.

To disconnect devolo devices from the mains supply,

pull the device itself or its mains plug from the power

outlet. The power outlet and all connected net-

work devices should be easily accessible so that

you can pull the mains plug quickly if needed.

devolo devices are designed for indoor use only.

Only use devolo devices at a dry location.

Disconnect devolo devices from the mains sup-

ply to clean! Avoid solvent cleaning agents since they

can cause damage to the housing. Only use a dry towel

for cleaning.

Preface 7

devolo dLAN pro 1200+

DANGER due to overheating

Batteries should never be exposed to large amounts

of heat, such as direct sunlight, fire or other heat sour-

ces.

Multiple devolo devices must not be interlocked.

devolo devices should only be installed at locations

that guarantee adequate ventilation. Slots and ope-

nings on the housing are used for ventilation:

쎲Do not cover devolo devices when operating.

쎲Do not place any objects on devolo devices.

쎲Do not insert any objects into the openings of

devolo devices.

쎲devolo devices must not be placed directly next

to an open flame (such as fire or candles).

쎲devolo devices must not be exposed to direct

heat radiation (e.g. radiator, direct sunlight).

1.2 devolo on the Internet

For detailed information on our products or "dLAN", vi-

sit www.devolo.com. The Service Centre area con-

tains downloadable product descriptions and

documentation, as well as updates to devolo software

and device firmware.

If you have any further ideas or suggestions related to

our products, we would be delighted to hear from you

at [email protected]!

8 Preface

devolo dLAN pro 1200+

Introduction 9

devolo dLAN pro 1200+

2 Introduction

dLAN is an intelligent, secure technology that lets you

set up a home network easily, quickly and economical-

ly via your household electrical wiring, without the

need for complex and expensive dedicated cabling.

The available performance and effort required for the

installation also compares favourably to traditional

methods.

Fig. 1
