SDI 16-Screen Multiview
Model: MVP9116
VER 15
Users’ Manual
Website: www.devicewell.com Email: [email protected]
I
Precautions
To ensure the reliability, use and safety of the equipment, please observe the following
when installing, using and maintaining:
Before the device is powered on, it is necessary to check to ensure that the chassis is well
grounded to prevent electrostatic discharge from the chassis and endanger the equipment and
personal safety, and to provide good shielding effect.
◆Do not place system equipment in a location that is too cold or too hot.
◆The power supply of the device will generate heat during operation, so keep the working
environment well ventilated to avoid damage to the device due to excessive temperature.
◆Turn off the main power switch when it is rainy or wet or when it is not used for a long
time.
◆Non-professionals, please do not try to open the equipment case without permission, and do
not repair it yourself to avoid accidents or damage to the equipment.
◆Do not spill any chemicals or liquids on or near the equipment.
Website: www.devicewell.com Email: [email protected]
II
Contents
1. Product Introduction ............................................................................................................ 1
1.1. Product Overview ..................................................................................................... 1
1.2. Main Functions ......................................................................................................... 1
1.3. Product Parameters ................................................................................................... 2
1.4. Standard List ............................................................................................................. 3
2. Operation and Function Description ................................................................................... 3
2.1. Equipment operation ................................................................................................. 3
2.2. Multi-screen Mode Description ................................................................................ 4
2.2.1. 1-screen mode ................................................................................................ 4
2.2.2. 4-screen mode ................................................................................................ 5
2.2.3. 6-screen mode ................................................................................................ 5
2.2.4. 8-screen mode ................................................................................................ 6
2.2.5. 9-screen mode ................................................................................................ 6
2.2.6. 10-screen mode .............................................................................................. 7
2.2.7. 16-screen mode .............................................................................................. 7
2.3. Keypad Operation Instructions ................................................................................. 8
2.3.1. Channel switching operation .......................................................................... 8
2.3.2. Full Panel ........................................................................................................ 8
2.3.3. Mode ............................................................................................................... 8
2.3.4. Reso ................................................................................................................ 8
2.3.5. Audio .............................................................................................................. 8
2.3.6. Char ................................................................................................................ 8
2.3.7. Knob ............................................................................................................... 9
2.4. 16-Screen character setting control software description ......................................... 9
2.4.1. CONTROL module ........................................................................................ 9
2.4.2. UMD Module ................................................................................................. 9
2.4.3. COLOR Module ........................................................................................... 10
2.4.4. SETTING Module ........................................................................................ 11
2.5. USB Interface ......................................................................................................... 12
2.6. Menu usage and LCD display instructions ............................................................. 12
2.6.1. Boot LCD status ........................................................................................... 12
2.6.2. Menu ............................................................................................................. 12
2.7. Tally Function ......................................................................................................... 16
2.8. Dual power supply .................................................................................................. 16
3. Failure and Maintenance ................................................................................................... 17
3.1. Common Faults and Solutions ................................................................................ 17
3.2. Maintenance ............................................................................................................ 17
3.3. Warranty information .............................................................................................. 17
Website: www.devicewell.com Email: [email protected]
1
1. Product Introduction
1.1. Product Overview
This is a professional-grade SDI multiview that supports 16-channel SDI signal input
and 16-channel SDI output and 1-channel HDMI output. You can use the front panel keyboard
to change the display resolution to 1080i50 / 60, 1080p25 / 30 or more. The device is a
multi-screen splitter with 16 matrix switching functions. The device can connect 16 SDI
signals and has 16 loop-out functions. When performing multi-picture synthesis, there are 2
identical SDI outputs (the two left SDI interfaces) and 1 HDMI output. The display mode of
the screen can pass through the network port. Flexible configuration using PC-side software
allows configuration options for 1 to 16 screens. And the device supports SDI audio column
display and character overlay function. The device integrates SDI input/output interface and
control interface, which can conveniently process SDI signals for picture segmentation, signal
delay, frequency conversion processing, and frame synchronization. The device supports
network, RS422 and button control, and supports network interface to update internal
software, which can realize more functions and simple operation.
1.2. Main Functions
◆ Art design style
◆ Up to 16 signal inputs, up to 16 signal outputs
◆ Support single screen enlargement, 4 screens, 6 screens, 9 screens, 10 screens, 16 screen
modes
◆ Support input screen switching
◆ Audio column display and character overlay enabled or disabled
◆ Input port: SDI×16
◆ Output port: SDI × 16; SDI × 2; HDMI × 1
◆ SDI HD/SD Adaptive
◆ Support network, RS422, menu and button control
◆ Support network upgrade system function
◆ Support REF input expansion
◆ Support Tally extension
◇ Special features can be customized
Website: www.devicewell.com Email: [email protected]
2
1.3. Product Parameters
Name SDI HD 16-Screen Multiview
SDI Input
Input Signal SDI HD serial digital video signal
Rate 143Mbps~2.97Gbps
Connector BNC complies with IEC169-8
Reflection loss >15dB 5MHz~3GHz
Signal amplitude 800mV±10%
Impedance 75Ω
Balance 100m Belden 1694A HD
200m Belden 8281A HD
SDI Output
Output Signal SDI HD serial digital video signal
Connector BNC complies with IEC169-8
Reflection loss >15dB 5MHz~3GHz
Signal amplitude 800mV±10%
Impedance 75Ω
Up/Down time 0.6ns±100ps
DC offset 0V±0.5V
Clock recovery Auto output optional
Overshoot <5%
Jitter <0.2Ul
HDMI Output
Output Signal Standard HDMI signal
Rate 270Mbps~2.97Gbps
Signal amplitude 800mV±10%(100R)
Impedance 100Ω
Control
Parameter
Local control button (front panel)
Serial control RS422
Connection port RJ45 standard network interface (UDP/HTTP)
Control software WINDOWS (customizable IOS/Android)
Optional components Central control keyboard
General
Parameters
Power supply 100-240V/AC 50/60Hz
Power Rating 25W-150W, According to host type
Size 1U(standard power supply )
Control Panel YES
Weight 2.1KG
Operating
Temperature 0 ~50 without condensation℃ ℃
Storage Temperature -20 ~75℃ ℃
Working Humidity 20%~70%RH
Storage Humidity 0%~90%RH, No condensation
Website: www.devicewell.com Email: [email protected]
3
1.4. Standard List
Multiview main part
AC power cord x 1
Control software x1
User Manual x1
2. Operation and Function Description
2.1. Equipment operation
Note: Please use the following installation sequence. If the installation sequence is
not followed correctly, the device may not work or work abnormally.
(1) Connect the signal output of the signal source to the input of the unit.
(2) Configure the corresponding I/O card according to the input and output of the
site.
(3) Connect the signal output of this unit to the signal input of the display unit.
(4) Turn on the power of the device and turn on the power button switch.
(5) Use the manual button to select the input and output ports.
(6) Rear panel interface description:
① SDI×2(Multi-screen output) HDMI②（Multi-screen output） SDI×16③ input
SDI×16④ Loop ⑤Power Light ⑥Network and RS422 interface
⑦USB interface ⑧AC 100 – 240V ⑨RS232 serial port
1
2
3
4
5
6
7
8
9
