DEVA DB910 Manual de usuario

MAINTENANCE AND OPERATION

INSTRUCTION MANUAL

Publish Date: 25-Nov-2022

DB910

Full Duplex Compact IP Audio Codec

Contents

Introduction........................................................................................................................................ 5

Typographic conventions .................................................................................................................. 6

General Information.......................................................................................................................... 7

Product Features ................................................................................................................................ 8

Technical Specications..................................................................................................................... 9

Panel Indicators and Appointments............................................................................................... 11

Front Panel.................................................................................................................................... 11

Rear Panel..................................................................................................................................... 12

Rear Panel General Purpose Ports............................................................................................... 13

Connector Pinouts.................................................................................................................... 13

Block Diagram.................................................................................................................................. 14

Before you start ................................................................................................................................ 15

Safety Warning .............................................................................................................................. 15

Operating recommendations ......................................................................................................... 15

Unpacking and inspection............................................................................................................. 15

Mounting........................................................................................................................................... 16

Heat Dissipation............................................................................................................................ 16

Radio Frequency Interference....................................................................................................... 16

Basic Setup........................................................................................................................................ 17

Analog Audio Inputs...................................................................................................................... 17

Digital Audio Input........................................................................................................................ 17

Analog Audio Outputs ................................................................................................................... 17

Digital Audio Output..................................................................................................................... 17

LAN port........................................................................................................................................ 17

WEB Interface.................................................................................................................................. 18

Network Discovery ........................................................................................................................ 18

Access............................................................................................................................................ 18

WEB Interface Menu pages ............................................................................................................ 19

Status ............................................................................................................................................. 19

Settings .......................................................................................................................................... 21

Full-Duplex ................................................................................................................................... 22

Full-Duplex Connection ...................................................................................................... 22

Full-Duplex TX .................................................................................................................... 22

Full-Duplex RX.................................................................................................................... 22

Digital Input......................................................................................................................... 23

Analog input......................................................................................................................... 23

IP Audio......................................................................................................................................... 24

Backup........................................................................................................................................... 26

Dayparts........................................................................................................................................ 28

Output............................................................................................................................................ 29

General.......................................................................................................................................... 30

Network ......................................................................................................................................... 31

Network ............................................................................................................................... 31

E-mail ................................................................................................................................. 32

HTTP Server ....................................................................................................................... 32

FTP Server .......................................................................................................................... 32

SNMP Agent ........................................................................................................................ 32

GPIO ............................................................................................................................................. 33

RS-232 Port ......................................................................................................................... 33

GPI Function ....................................................................................................................... 33

GPO Function...................................................................................................................... 33

Other ............................................................................................................................................. 34

Firmware Update................................................................................................................. 34

Storage................................................................................................................................. 34

Factory Defaults .................................................................................................................. 34

Reboot Device...................................................................................................................... 34

System Log ................................................................................................................................... 35

Hardware Reset ............................................................................................................................. 36

Network Default Settings ......................................................................................................... 36

WEB Server Default Settings ................................................................................................... 36

APPENDIX A ................................................................................................................................... 37

How to Set a pair of DB910 to work in Full-Duplex Mode .......................................................... 37

Full-Duplex audio transmission ................................................................................................... 37

DB910 Set-up ................................................................................................................................ 37

Server DB910 set-up ..................................................................................................................... 38

Client DB910 set-up...................................................................................................................... 39

APPENDIX B ................................................................................................................................... 40

How should I congure the connection between my DEVA Device and an FTP Client? 40

1. FTP Server Settings ......................................................................................................... 40

2. IP Router and Port Translation Settings.......................................................................... 40

3. Example of FTP Client (FileZilla) Settings .................................................................... 41

WARRANTY TERMS AND CONDITIONS................................................................................. 42

Product Registration Card.............................................................................................................. 43

THIS PAGE

IS INTENTIONALLY

LEFT BLANK

65 Aleksandar Stamboliyski Str., 8000 Bourgas, Bulgaria

Tel: +359 56 820027, Fax: +359 56 836700

E-mail: o󰀩[email protected] ,Web: www.devabroadcast.com

- 5 -

Introduction

DEVA Broadcast Ltd. is an international communications and high-technology manufacturing

organization, its corporate headquarters and facility located in Burgas, Bulgaria. The company

serves the broadcast and corporate markets worldwide – from consumers and small businesses to

the largest global organizations. It is dedicated to the research, design, development and provision

of advanced products, systems and services. DEVA Broadcast launched its own brand back in

1997 and has nowadays evolved to become known as a market leader and internationally reputed

manufacturer of user-friendly, cost-eective and innovative broadcast products.

Creativity and innovation are deeply woven into DEVA Broadcast corporate culture. Through

successful engineering, marketing and management our team of dedicated professionals creates

future-oriented solutions to improve customers’ performance. You may rely that all issues

communicated to our crew would be addressed accordingly. We pride ourselves on our pre and

post-sales support and purchase services, which along with the outstanding quality of our radio

gear have won us due respect and the market authority position.

DEVA Broadcast best-of-breed solutions have become the best sellers for our partners. The

strategic partnerships which have been formed with industry leaders during all these years that

we have been operating on the broadcasting market, have proved us a reliable business partner

and a valuable asset, as our dealers worldwide would conrm. In constant pursuit of precision and

long-term satisfaction, DEVA Broadcast enhances the reputation of our partners and clients alike.

Furthermore, we have already a proven merit as a credible partner provider.

Our portfolio oers complete line of high quality and competitive products for FM and Digital

Radio, Radio Networks, Telecommunication Operators and regulation authorities. For almost

two decades of intensive software and hardware development, we have achieved a unique price-

performance and endurance of our product lines. Our company’s multitude of equipment and

services is in line with the latest technologies and key trends. The most recognizable characteristics

attributed to DEVA Broadcast products are their clear-cut, streamlined design, easiness of use and

cost-eectiveness: simplicity of forms but multiplicity of functions.

For us there is no stage when we deem that we have reached the most satisfactory level in

our work. Our engineers are in constant pursuit of new ideas and technologies to be captured in

DEVA Broadcast solutions. Simultaneously, a strict control is being exercised at each step of any

new development. Experience and hard work are our fundament but the continuous improving

process is what we never leave aside. DEVA Broadcast participates on a regular basis in all

landmark broadcasting events, not only to promote its products, but to exchange valuable know-

how and experience. We are also engaged in international large-scale projects involving radio and

audio solutions which makes us even more competitive on the global market.

All DEVA Broadcast products are developed and produced in accordance with the latest ISO

9001 quality control standards.

65 Aleksandar Stamboliyski Str., 8000 Bourgas, Bulgaria

Tel: +359 56 820027, Fax: +359 56 836700

E-mail: o󰀩[email protected] ,Web: www.devabroadcast.com

- 6 -

Typographic conventions

The following table describes important conventions used in the manual.

Convention and Style Description Examples

Menu > Sub Menu >

Menu Command

A menu item(s) and menu

command that you need to click

in sequence

Click Settings > General

[Button] Interface Interactive buttons Press [OK] to save the changes

NOTE Important notes and

recommendations

NOTE: The notication will appear

only once

“Reference Name” on

Page XXX

References and links refer to “New Connection”

(see “Monitoring” on page 56)

Example Used when example text is cited Example for E-mail Notication:

Date: 04 Nov 2013, 07:31:11

65 Aleksandar Stamboliyski Str., 8000 Bourgas, Bulgaria

Tel: +359 56 820027, Fax: +359 56 836700

E-mail: o󰀩[email protected] ,Web: www.devabroadcast.com

- 7 -

General Information

Inspired by DEVA continuous strive for excellence, and based on our long-term formative

experience in the eld of IP audio broadcasting tools, DEVA product portfolio is extended with yet

another strategic solution - the DB910 Full Duplex IP Audio Codec.

A full duplex solution when two tools are in use, the DB910 allows you to send and receive

audio at the same time, while guaranteeing fast and easy monitoring of the signal fed to the

transmitter. Where two-way transmission is not required, DB910 may be used as a decoder, being

fully compatible with DEVA’s already widely-known hallmark IP audio codecs.

The real time audio encoding/decoding into a high quality congurable format process is

uncompromisingly guaranteed by the powerful DSP processor. Supporting all the mandatory

compressed audio streams and lossless, uncompressed PCM stream, the DB910 can be used for

a wide range of professional audio applications: Broadcast, Internet Radio, Studio to Transmitter

Link and VoIP.

Apart from its main audio source, DB910 supports several IP audio sources and a built-in MP3

Backup Audio Player in addition. With several backup audio sources incorporated, the DB910 will

immediately switch between the sources when the audio is lost, and return to the main one when

the audio is restored, with no user intervention. The audio content for the MP3 player is recorded

on the internal SD card. The backup les can be managed remotely through the built-in FTP

Server, via standard FTP client.

Combining the super compact form of the DB90 and some of the most impressive features of

the renowned DB9000 line in a single product, the DB910 will meet the requirements of the most

demanding broadcasters. This advanced radio gear is equipped with two-way GPIOs and RS-232

serial communication that could be used for telemetry and automation. The front panel audio level

bar graphs and LED indicators of the unit allow reading the current state of the device at a glance.

Controlled through a simple and intuitive HTML5 interface and any kind of web browser, be it

your PC, smart phone or tablet, the DB910 could be managed remotely or locally.

DB910 is the ultimate all-in-one solution to maintain your competitiveness, combining essential

professional applications and key trends.

65 Aleksandar Stamboliyski Str., 8000 Bourgas, Bulgaria

Tel: +359 56 820027, Fax: +359 56 836700

E-mail: o󰀩[email protected] ,Web: www.devabroadcast.com

- 8 -

Product Features

• Full duplex IP audio transmission

• Analog Audio Output and Input (4 x ¼” phone jack connectors)

• Digital Audio Output and Input (2 x ¼” phone jack connectors)

• High Quality HE-AAC (v.1 and v.2), MPEG-1 and MPEG-3 Decoding

• 32 kHz, 44.1 and 48 kHz sample rates support

• Decoding of all standard bitrates and VBR as well

• Auto backup switching in the event of an audio loss

• Build-in MP3 Player

• 6 x General Purpose Inputs

• 6 x General Purpose Outputs

• 2 x 6 LED front panel audio level bar graphs

• 2 x 6 GPIO and 4 x Status LEDs, and Phones output for quick diagnostics

• Full Control and easy setup via a standard web browser

• DHCP Client automatically assigning Network Settings

• IP address pronunciation at startup (through the headphones)

• UPnP for easy discovery in Local Networks

65 Aleksandar Stamboliyski Str., 8000 Bourgas, Bulgaria

Tel: +359 56 820027, Fax: +359 56 836700

E-mail: o󰀩[email protected] ,Web: www.devabroadcast.com

- 9 -

Technical Specications

OPERATING MODES

Two-way Full-duplex RTP

Receiver IP Audio Client, RTP

File Player SD Card based player

AUDIO CODECS

Channels 1 or 2

Sample Rates 32 kHz, 44.1 kHz, 48 kHz

Codec MPEG-1 Layer 3; HE-AAC (v.1 and v.2); 16-bit PCM

Bitrates (Encoding) Up to 320 kbps (MPEG-1); Up to 88 kbps (HE-AAC);

Up to 1536 kbps (PCM);

Bitrates (Decoding) All standard bit rates, including VBR

AUDIO BACKUP

Source Any of the available sources; Up to 3 congurable backups

Trigger Audio Silence Detector

Threshold Adjustable, -90dBFs to 0dBFs

Trigger time Adjustable, 1s to 240s

FILE PLAYER

Storage microSD Card

Supported codecs MPEG-1 Layer 3, HE-AAC (v.1 and v.2)

Supported le types *.MP3, *.AAC, *.M4A, *.M3U

Playback modes Alphabetical ascending and descending, Shue, Playlist and

Shued playlist

Remote le management Build-in FTP server

ANALOG AUDIO INPUT

Connector 2 x 1/4” (6,3mm) phone jack;

Shared with Digital input, software selectable

Type Balanced

Impedance 600Ω or High Impedance, software selectable

Level (0 dBFS) -12dBu to +18dBu, software selectable

Frequency response ±0.5dB, 10Hz-20kHz

Distortion <0.01% THD+N

Dynamic range >100 dB

ANALOG AUDIO OUTPUT

Connector 2 x 1/4” (6,3mm) phone jack;

Shared with Digital output, Soft. select

Type Balanced

Impedance 600Ω or High Impedance, software selectable

Level (0 dBFS) -12dBu to +18dBu, Software selectable

Frequency Response ±0.5dB, 10Hz-20kHz

Distortion <0.01% THD+N

Dynamic range >100 dB

65 Aleksandar Stamboliyski Str., 8000 Bourgas, Bulgaria

Tel: +359 56 820027, Fax: +359 56 836700

E-mail: o󰀩[email protected] ,Web: www.devabroadcast.com

- 10 -

DIGITAL AUDIO INPUT

Connector 1/4” (6,3mm) phone jack;

Shared with Left Analog input, software selectable

Type AES/EBU (IEC 60958)

Sample rate 32kHz, 44.1kHz and 48kHz

DIGITAL AUDIO OUTPUT

Connectors 1/4” (6,3mm) phone jack;

Shared with Left Analog output, software selectable

Type AES/EBU (IEC 60958)

Sample rate 48kHz

GPIO

Type 6 x GPI; 3.3V TTL logic with internal pull-up

6 x GPO; Open-collector; 20V/100mA

1 x RS-232

Connector DB-15

GPI Operating Modes Transparent two-way channel or Force Audio source trigger

GPO Operating Modes Transparent two-way channel or Source Audio loss indicator

RS-232 Operating Modes Transparent two-way channel or TCP/IP to RS-232 Redirector

RS-232 baud rate 9600 to 115200 bps

FRONT PANEL

Level Indicators 2 x 6 LED bar graphs

GPIO Indicators 2 x 6 LEDs

Status Indicators 4 LEDs

Headphones 1/8” (3.5mm) phones jack

SD Card microSD card slot up to 16GB

REMOTE CONTROL

Web interface Built-in web server with HTML5 interface

SNMP SNMP 2c

NETWORK

Connector RJ-45

Type 10/100Mbps Ethernet

Device Discovery UPnP Support

OPERATING CONDITIONS

Temperature 10°C - 45°C

Humidity < 75%, non-condensing

POWER

Voltage 12V DC, 1A

Power Consumption 10VA

Connector Power Jack 5.5mm

SIZE AND WEIGHT

Dimensions (W;H;D) 170 x 35 x 167 mm

Shipping Weight 270 x 54 x 230 mm / 0.9kg

HS Code 8517620000
