Detecto D150 Manual de usuario

8 IN 1 WIDE BODY PLATFORM

GLASS BODY FAT SCALE

With Body Water and Muscle Mass, Bone Mass

Calorie Predictor, BMI & Athlete Mode

MODEL D150

USER MANUAL

O V E R 100 Y E A R S

OF MEDIC A L A C C U R A C Y

Table of Contents

PREPARATION BEFORE USE ........................................................................................... 3-4

NOTES ON SAFETY ............................................................................................................ 4

INTENDED USE................................................................................................................... 4

PRECAUTION NOTICE ...................................................................................................... 5

IMPORTANT NOTICE TOUSERS ........................................................................................ 5

PRODUCT DESCRIPTION .................................................................................................. 5

FRONT VIEW ................................................................................................................ 5

BACK VIEW ................................................................................................................. 6

LCDREADOUT ............................................................................................................ 6

OPERATION....................................................................................................................7-8

BODY FAT ANDTOTAL BODY WATER ESTIMATING OPERATION WITH USER

MEMORY........................................................................................................................ 7-8

A. TORECALL SETTINGS FROM MEMORY FOR BODY FAT

ANDTOTAL BODY WATER ESTIMATION ................................................................. 9

B. TOTURN OFF THE SCALE ........................................................................................ 9

PROBLEM-SOLVING AND QUESTIONS........................................................................... 10

CAREANDMAINTENANCE ........................................................................................... 11

PRODUCT SPECIFICATION ........................................................................................11-12

EDUCATION INFORMATION ......................................................................................12-15

LIMITED LIFETIME WARRANTY ......................................................................................... 16

Congratulations! You have purchased a precision health monitoring

product that should provide you with years of accurate use. To assure

you obtain the best performance please read the following set-up and

use instructions carefully before using the scale.

PREPARATION BEFORE USE

1. Insert the Battery

This scale operateson 2 AAA batteries (included).

Open the batterycover on the back of the scale unit. Remove

any plastic wrap on the batteries before inserting. Be sure the

polarity of the battery is set correctly for the scale to function

properly. If you do not intendto use this unit for a prolonged

period of time, it is advisable to remove the battery before storing.

Open the battery door Direction on installing 2 AAA batteries

2. To set weight unit

When scale is off at standby mode, step on scale to switch it on and step

off until LCD shows zero. Press SET button to convert units to Lbs or Kgs.

TIPS

Replace

batteries

when “Lo”

is displayed

PRECAUTION !

The scale must be

startedup after

battery insertion/

replacement of

batteryor each time it

is moved or bumped.

INTENDED USE

This scale is intended to measure body fat, impedance and estimate percentage

of body fat, body water, and muscle mass using BIA (Bioelectrical Impedance

Analysis). It is intended for use by healthy children 10-17 years old and healthy

adults with active, moderately active, to inactive lifestyles for body composition

assessment in the home environment.

3. Some models have a static cling label on the LCD

lens to prevent scratching. Remove before use.

4. Set the Right Position

surface. Do not use on carpets.

PRECAUTION !

Do Not stepon scale

unevenly (X)

To avoid injury, do not

step with wet feet or on

the edge of the platform.

NOTES ON SAFETY

Please read this section carefullytofamiliarize yourself

with features and operations before using the unit.

• The warning signs and the sample icons shown here

are listed in order for you to use this product safely

and correctly as well as to prevent product damage,

risk and injury to you and others.

• The icons and meanings are as follows:

PRECAUTION NOTICE

Indicates the right conditions to use the

product and to prevent damage, risk

and injury.

IMPORTANT NOTICETO USERSIndicates important notices users should

read before using the product.

CARE ANDMAINTENANCE

Indicatesmatters in which the possibility

of damage may happen as a result

of incorrect handling and improper

maintenance.

LCDReadout

POWER Button

SET Button

& Up/Down Buttons

Platform with

Electrodes

PRECAUTION NOTICE

•

Do not use the scale on people who have body implants such as a pacemaker,

artificial limbs, contraceptive devices, or metal plates or screws. It may cause the

device to malfunction or produce an inaccurate result. When in doubt, consult

your physician.

•

Do not disassemble the scale as incorrect handling may cause injury.

PRODUCT DESCRIPTION

FRONT VIEW

SET

• This product is intended for adults and children (ages 10 to 85).

• Make sure to use only the type of battery stated (see Section “PREPARATION

BEFORE USE”).

• The “Athlete” mode is applicable only to people 15-85 years of age.

• Body fat percentage estimates will vary with the amount of water in the

body, and can be affected by dehydration or over-hydration due to such

factorsasalcohol consumption, menstruation, illness, intense exercise, etc.

• Do not use on pregnant women. The result is inaccurate and effects on the

fetus are unknown.

• For body fatand body water estimates, always estimate in bare feet.

IMPORTANT NOTICE TO USERS

1. F = Body Fat %

2. W = Body Water %

3. M = Muscle Mass %

4. B = Bone Density

5. BMI

6. Ideal Calorie intake

7. Weight Readout in Pounds (LB)

8. User Code

10. (N) Normal / (A) Athlete mode

9. Male Icon

11. Age

12. Down Button - To decrease

numeric value and to toggle

the user selection

13. Confirm Selection

14. Power - on/off

15. Up Button - To increase

numeric value and to toggle

the user selection

16. Weight Readout in kilogram (Kg)

17. Female Icon

18. Height Displayed in Feet/Inches

19. Height Displayed in CM

Know Your Readout

FUNCTION KEYS

ON/OFF

• Turn the scale on or off

• Enter body fat and total body water estimation mode

SET

[ ] or [ ]

• Changes value of height and age, toggle between Male and Female, toggle

between Normal and Athlete mode in Body Fat function

• Select memory 1 - 12 in Memory mode & Recall mode

• Recall settings of memory locations

4 5 6

18 19

12 13 14 15

SET

BACK VIEW

Battery Compartment

SET SET

The accuracy of the results depends on how you stand on the scale. Position your feet with

maximum contact on the metal electrodes on the platform. This ensures the best contact

between your feet and the metal contacts. Stay on the scale until the body fat estimation is

completed and the result is displayed. Clean, slightly moist feet will provide the best results.

OPERATION

Fig. 1

Fig. 2

1. Press the POWER button to turn the scale on.

2. Press the SET button to enter memory mode.

3. Set Memory

Press the [ ] or [ ]key to select a memory location (1-12 users). Press [SET] to conﬁrm.

WEIGHING-ONLY OPERATION

1. Step onto the scale and stand still while the

weight is being measured (Fig.1).

2. The screen displays the weight which will flash,

stabilize and lock in (Fig. 2).

3. The scale turns off automatically after use.

Feet centered on platform (Correct) Feet not centered on platform (Incorrect)

® ®

8. After step 7 has been done, all personal information will be displayed again one screen at a time

(except AGE). Your personal information is now saved in memory.

9. Repeat steps 1-7 to set other pre-programmed user numbers.

6. Set Height

Press the [ ] or [ ] key to adjust the height. Press [SET] to conﬁrm.

7. Set Age

Press the [ ] or [ ] key to adjust the age. Press [SET] to conﬁrm.

5. Select Normal or Athlete Mode

Press the [ ] or [ ] key to toggle between normal [N] or athlete [A]. Press [SET] to conﬁrm.

NOTE: Athlete mode is only available for those 15 - 85 years of age. For those aged 14 or under,

this step is automatically by-passed. (See section: “Why is the Athlete Mode necessary in a

Body Fat Analyzer?”)

4. Select Gender

Press the [ ] or [ ]key to toggle between the male ( ) and female ( ) icons.

Press [SET] to conﬁrm.

SET

The scale features 12 personal memory settings. This allows users to store and recall their own

height, age, gender and normal/athlete mode selection. Follow steps in the previous section

“Program Personal Data” to input your personal information into a memory location.

A. To Recall Settings from Memory for Body Fat and Total Body Water Estimation

You must have bare feet for estimation results. Remove your shoes and socks before proceed-

ing. Clean, slightly moist feet will provide the best results. Position your feet for maximum

contact with the metal electrodes on the platform.

1. Press the POWER button to turn the scale on.

2. Press the SET button to enter memory mode.

3. Press the or key to toggle between memory locations (1-12). Wait until the memory

code numbers stop flashing. Press either [ ] or [ ] once to enter review mode.

LCD will show last/previous measured records by sequence: F/W/M/B/BMI/KCAL/ in 3 cycles

then shut down. Note: The previous reading for that user number will appear after ﬁrst use.)

[ ] [ ]

BODY FAT AND TOTAL BODY WATER ESTIMATING

OPERATION WITH USER MEMORY

4. When “0.0” appears on screen, step on the

scale with bare feet, positioning your feet evenly

on the scale platform with maximum contact

with the metal electrodes.

5. Stand still while the scale measures your

body weight first. Once your weight is

locked in the body impedance measurement

will start.

6. After the body impedance is measured, the scale will display the information as below.

This will repeat 3 times and then the scale will turn off.

B. TO TURN OFF THE SCALE

To turn the scale off, press the ON/OFF key.

Or, if no key has been pressed for a few seconds, the scale turns off automatically.

% % %

%%%

1. No weight is displayed?

Check if the scale is powered up and started up. If not, please refer to the

Section “Preparation Before use”.

2. Why does the display read “Lo”?

Battery is running low. Replace the battery.

3. The message displays “C”….

Initialization error occurs when LCD show ‘C’ after ﬁrst weighing. Step off the scale and wait

until the scale automatically switches off. Start the scale again by pressing lightly on the scale

platform to re-initialize the scale. The display shows “0.0” and the scale is ready for use again.

4. The message displays “Err” when measuring…

Low Fat % Indication

High Fat % Indication

Re-test

Overload warning. Remove the weight immediately; otherwise, permanent damage to the scale

will occur.

5. I have tried all corrective actions, but still can’t solve the problem …

Please contact the Detecto Customer Service at 1-800-336-5282.

6. Why do I get a different body fat reading when I use a different brand of body fat scale?

Different body fat scales take estimations around different parts of the body and use different

mathematic algorithum to estimate the percentage of body fat. The best advice is not to make

comparisons from one device to another, but to use the same device each time to monitor any

change.

PROBLEM SOLVING AND QUESTIONS

Tabla de contenidos

Otros manuales de Escala de Detecto

Detecto

Detecto 6880 Manual de usuario

Detecto

Detecto D401 Manual de usuario

Detecto

Detecto 8435 Manual de usuario

Detecto

Detecto WPB Series Manual de usuario

Detecto

Detecto 6875 Manual de usuario

Detecto

Detecto VET330WH Manual de usuario

Detecto

Detecto 6855KGEU Manual de usuario

Detecto

Detecto DL Series Manual de usuario

Detecto

Detecto 6550 Manual de usuario

Detecto

Detecto 6439 Manual de usuario

Detecto

Detecto CS Series CS-30 Manual de usuario

Detecto

Detecto 6856 Manual de usuario

Detecto

Detecto WeighRite W200 Series Manual de usuario

Detecto

Detecto d219 Manual de usuario

Detecto

Detecto CR-500D Manual de usuario

Detecto

Detecto 6550 Manual de usuario

Detecto

Detecto APEX Series Manual de usuario

Detecto

Detecto ProDoc PD100 Manual de usuario

Detecto

Detecto 6880 Manual de usuario

Detecto

Detecto 6745KG Manual de usuario

Detecto

Detecto Detecto 8432-CH Manual de usuario

Detecto

Detecto D228 Manual de usuario

Detecto

Detecto D118 Manual de usuario

Detecto

Detecto 6475 Manual de usuario

Manuales populares de Escala de otras marcas

AWS

AWS ZEO-50 Manual de usuario

Gima

Gima Glass Body Fat Analyzer Manual de lista de piezas

Seca

Seca 374 Manual de usuario

TEC

TEC TEC SL59 SERIES Manual de usuario

Axis

Axis B/E Series Manual de usuario

Alecto

Alecto ACW-40 Manual de usuario

Rice Lake

Rice Lake MSI-4260 IS Manual de usuario

IKA

IKA RCT basic safety control Manual de usuario

ADE

ADE M20011 Manual de usuario

Duronic

Duronic KS3000 Manual de usuario

Digi

Digi SM-720 Manual de usuario

Cardinal

Cardinal CS Series Manual de usuario

Korona

Korona Kastella Manual de usuario

A&D

A&D FC-50Ki Manual de usuario

BDA

BDA CAMARGUE Manual de usuario

Tanita

Tanita HD-357 Manual de usuario

Leifheit

Leifheit 03173 Manual de usuario

Lumme

Lumme LU-1340 Manual de usuario
