Denver BTT-501 Manual de usuario
Warnings
This product was designed and manufactured to meet strict quality and safety
standards. There are, however, some operation precautions that you should
be aware of:
● Read all warnings. Follow all instructions.
● Check the mains voltage stated on the mains adaptor rating plate
corresponds to the local electricity supply, if it doesn’t, return the product to
the store where you bought it.
● Unwind and straighten the adaptor cord before use.
● Place the product on a firm and level surface. Allow space around the
product to ensure enough ventilation.
● Clean only with a dry cloth, unplug the outlet before cleaning. Do not
use aggressive cleaners as these will damage the surface.
● To completely disconnect this product from the mains, disconnect the plug
from the wall socket outlet. The mains plug is used to completely interrupt
the power supply to the unit and must be easily operable by the user.
● Remove the adaptor from the outlet, when the product is unused for a
long period of time and during thunder storms.
● Only use attachments/accessories specified by the manufacturers.
● Do not locate the appliance or the batteries in the vicinity of a heat
source or in direct sunlight. Do not place a naked flame source on or
near this product.
1
Warnings
● Do not attempt to open the cabinet or remove any covers. If the power
adapter or its lead becomes damaged, it must be replaced with an adapter
of the same type and rating.
● Repairs must only be performed by the manufacturer or its service
agent or similarly qualified person.
● Do not immerse the main unit, the power adapter or any accessories
in water or any other liquid.
● Do not expose this product to dripping or splashing or stand any vessel
containing liquid on or near this product.
● Replace batteries with the same or equivalent type.
● Do not cover the product or this will impede ventilation.
2
LOCATION OF CONTROLS
1. STANDBY button: Press to turn the speaker bar off or on.
2. SOURCE button: Press repeatedly to select the input sound to BT
(Bluetooth receiver), AUX, LINE in or FM.
3. VOLUME +: Press to increase volume.
4. VOLUME -: Press to decrease volume
5. MUTE: Press to mute the sound, press again to resume.
6. FM antenna.
7. AUX L/R IN jacks.
8. 3.5mm LINE IN jack.
9. DC jack in.
3
TOP VIEW: REAR PANEL:
VOL+SOURCE VOL
1 2 34 5
6
7
8
9
REMOTE CONTROL – LOCATION OF
CONTROLS
1. STANDBY button: Press to turn the unit on or off.
2. BLUETOOTH button: Press to switch to Bluetooth mode.
3. SCAN button: Press to scan for available radio stations in FM Radio
mode,then store in the memory list automatically. Total 30 stations can
be stored.
4. MUSIC button: Press to switch to the EQ optimized for music.
5. TREBLE buttons: Press to adjust the treble up or down.
6. AUX button: Press to switch to AUX mode.
7. MUTE button: Press to mute the sound, press again to resume.
8. LINE button: Press to switch to LINE In mode.
9. FM button: Press to switch to FM Radio mode.
10. CH + button: Press to skip to next stored channel.
11. CH - button: Press to skip to previous stored channel.
12. MOVIE button: Press to switch to the EQ optimized for movie sound.
13. VOICE button: Press to switch to the EQ optimized for dialogue.
14. BASS buttons: Press to adjust the bass up or down.
15. VOLUME buttons: Press to adjust the volume.
4
POWER SOURCE
Insert the small plug from the supplied AC/DC adapter to the DC in jack on
the unit. Insert the AC/DC adapter to DC in jack on the unit.
BATTERIES INSTALLATION (REMOTE
CONTROL)
To replace the button cell:
1. Push the tab, then slide out the battery tray as the figure on the right.
2. Replace the old button cell by a new CR 2025 button cell as the polarity
markings on the remote control.
3. Close the battery tray.
5
PUSH
OPEN
CR2025
PUSH
OPEN
Lithium Cell
CR2025
3V
SC UL
Lithium Cell
CR2025
3V
SC UL
4M
BATTERY PRECAUTIONS:
Follow these the size and type of battery specified.
1. Use only the size and type of battery specified.
2. Be sure the follow the correct polarity when installing the battery as
indicated in the battery compartment. A reversed battery may cause
damage to the device.
3. If the battery in the device is consumed or the device is not to be used for
a long period of time, remove the batteries to prevent damage or injury
from possible battery leakage.
4. Do not try to recharge the battery not intended to be recharged; it can
overheat and rupture.
5. The batteries shall not be exposed to excessive heat such as sunshine,
fire or the like.
6. Clean the battery contacts and also those of the device prior the battery
installation.
7. Do not mix different types of batteries together (e.g. Alkaline and
Carbon-zine) or old batteries with fresh ones.
EFFECTIVE DISTANCE OF REMOTE TRANSMITTER
6
NOTES:
1. When there is an obstacle
between the unit and the
transmitter, the transmitter may
not operate.
2. When direct sunlight, an
incandescent lamp, fluorescent
lamp or any other strong light
shines on the REMOTE
SENSOR of the unit, the remote
operation may be unstable.
OPERATION:
Listening from AUX IN jacks:
1. Connect the Aux out jacks from the external
audio player (such like DVD player, TV,
VCR …etc.) to the AUX IN jacks on the rear of
Sound Bar by the supplied RCA connection
cable as the figure below:
2. Connect the Sound Bar to the power as
previous procedures. The Standby indicator
will turn on.
3. Press the Standby ( ) button on the Sound
Bar or Remote Control to power on the Sound
Bar.
4. Press the SOURCE button on the unit repeatedly or press the AUX
button on the Remote Control to turn to AUX mode. The AUX indicator
will turn on.
5. Power on the connected external player and start playback as usual.
6. Press the volume buttons to adjust volume level.
7. Press the TREBLE buttons on the Remote Control to adjust treble as
desired.
8. Press the BASS buttons on the Remote Control to adjust BASS as
desired.
9. Press the EQ preset mode buttons MUSIC; MOVIE or VOICE to turn on
the preset EQ effect as desired.
10. Press the MUTE button to turn off the sound, press again to resume.
11. When finished listening, press Standby ( ) button on the Speaker or
Remote Control to power Off (Standby mode) the Speaker.
7
LISTENING FROM LINE IN JACKS:
1. Connect the Headphone/Earphone; Line out
jacks from the external audio player such like
MP3 player; Discman … etc) to the LINE IN
jacks on the rear of Sound Bar by the supplied
Line In connection cable as the figure below:
2. Connect the Sound Bar to the power as
previous procedures. The Standby indicator will
turn on.
3. Press the Standby ( ) button on the Sound
Bar or Remote Control to power on the Sound
Bar.
4. Press the SOURCE button on the unit repeatedly or press the LINE
button on the Remote Control to turn to LINE mode. The LINE indicator
will turn on.
5. Power on the connected external player and start playback as usual.
6. Other operations are same as AUX IN mode.
LISTEN TO RADIO :
1. Power on the Sound Bar as previous procedures.
2. Press the SOURCE button on the unit repeatedly or press the FM button
on the Remote Control to turn to Radio (FM) mode. The FM indicator will
turn on.
3. In first time: Press the SCAN button on the Remote Control to start auto
searching (It may take a few minutes). The available FM stations will be
stored into internal memory list. After scanning : Press the CH (Channel)
+ button to skip to next stored channel, press the CH (Channel) – button
to skip to previous stored channel. Repeat the same procedures until the
desired station are found and play.
4. Other operations are same as AUX IN mode.
8
BT PAIRING AND PLAYBACK:
1. Power on the Sound Bar as previous procedures.
2. Press the SOURCE button on the Sound Bar repeatedly or press the BT
(Bluetooth) button on the Remote Control to turn to BT mode. The BT
indicator will turn on.
3. Turn on the BT function in the external BT player and wait a few seconds
until the external BT player and the speaker were paired. Play the music
in the external BT Player as usual.
4. Other operations are same as AUX IN mode.
NOTES:
In first time use, connect the external BT Player as below:
1. Turn the Sound Bar to BT mode as previous procedures, the BT
indicator will turn on and blink.
2. Power on the external BT player and enter to BT searching mode. Start
pairing as the on screen instructions on the external BT Player (For
details pairing procedures, please refer to the user’s manual of your BT
player.).
3. When the external BT player searched the Sound Bar, our model
number “BTT-501” will appear on the display of external BT player.
4. Pairing code “0000” may need to enter.
Maintenance
1. Do not use harsh or abrasive cleaning agents or solvents.
2. Do not attempt to disassemble your product.
3. Do not paint your product.
4. Do not drop, throw or try to bend your product.
5. Do not expose your product to open flames.
9
