Denver LDS-3272 Manual de usuario
SMART TV with DVB-T2/S2/DVB-C
and H.265/HEVC Support
User’s Guide
NOTE:
Read all of the instructions before using this TV and keep the instruction
manual in a safe place for future reference.
Model: LDS-3272/LDS-4074
Contents
Customizing TV Settings 13-28
1
2
3
Due to the manufacturing process of components, televisions and other electronic products
can have parts that may produce a smell after the product is first turned on and warms up.
The smell will usually dissipate within a few days of use and does not return.
This is normal and occurs with many electronic products. Please ensure there is sufficient
ventilation around the TV and in the room and the odor will dissipate.
4
POWER/STANDBY:
Model:LDS-3272
Model:LDS-4074
5
HDMI: Connect DVD/Blu-ray player or other equipment.
PC AUDIO
USB: Connect to USB device for multimedia .
TV2(T2/C):
LAN(RJ45):
TV1(S2) HDMI3 OPTICALTV2(T2/C) Common Inter fa ce
Mini YPbPr Mini AV
USB
5V 500mA
OPTICAL:
VGA HDMI1 HDMI2 SCART
PC
AUDIO
LAN
(RJ45)
RJ45 plug for connecting to external modem or network access equipment.
6
The remote control is using Infra-Red(IR). Point it towards the front of the LED TV. The remote
control may not work correctly if it is operated out of range or out of angle.
:
mode.
:Mute and restore TV sound.
0~9:Select
a program.(ATV/DTV mode).
:Return to the previous viewing
Switch the TV between On and Standby
channel.
Display program list.CH.LIST:
APP:Press to select the desired
APP.
MENU:Display the main menu.
SOURCE:Select among the different input
signal sources:TV/AV/COMPONENT/HDMI1/
HDMI2/HDMI3/VGA/USB.
:Allows you to navigate the on
screen display menus and adjust the system
settings to your preference.
VOL+/-:Adjust the volume.
CH :Select the channel.
To show the Electronic Program GuideEPG:
during no- menu state only in DTV mode.
OK:
Confirm the selection.
RETURN:Return to previous menu.
EXIT:Exit the on screen display menu.
INFO: Display the present screen information
such as the current channel and input source.
7
CANCEL:Cancel the Teletext display.
Reverse playback rapidly.
:
TTX:Enter the Teletext.
:Skip to the beginning of the previous
chapter/track/photo.
:Start playback or pause.
TIMESHIFT:Press the button to pause current
DTV program and start record background
(Used for models with DTV function only).
HOLD: Hold or carry on the current subpage.
:Skip to the beginning of the next chapter/
track/photo.
:Advance playback rapidly.
REVEAL:Reveal any hidden text.
press again to see the bottom half of page double
size.Press again for normal siza.
SIZE: Press to see top half of page double size,
:Stop the playback.
FAV:Display the favorite channel list.
to cancel.
SUBPAGE:Press to enter subpages,pressagain
RECORD:Start to record.
INDEX:Go to index.
mode and DVD mode.
SUBTITLE:Turn on/off the subtitle dispaly in DTV
AUDIO:Switch the available sound-track.
Customizing TV Settings
Turning On/Off Your TV
• Connect the power cord to the power socket after you have completed all the
physical connections. At this stage, the TV will enter Standby Mode and the red
LED indicator will illuminate.
• In Standby Mode, press the button on the main unit or on the remote control to
turn the TV on. The red LED indicator will turn blue.
The POWER button on the main unit or on the remote control can only
switch the TV into standby. To completely turn off the TV, please disconnect
the power cord from the power socket.
Initial Setup
• The time you turn the TV on, it will go into
the Setup Wizard. Press the Arrow buttons
to highlight and select your desired mode and
press OK to
31
Country Germany
Environment Home Mode
OSD Language English
