Denver MP-2021 Manual de usuario
DENVER MP-2021 PLL
Quick start guide
1. Installation instruction
1.1 Installing driver for Windows 98SE (not required for Windows ME or above)
a. Connect the MP3 Player to the USB port of a PC, "Find new hardware"
appears on the screen, then click "Search latest driver for this device" and
insert the driver CD into CD-ROM, and then click "Next".
b. Select "Look in" to direct the installation directory to the "Drivers" files in the
driver CD, and then click Yes.
c. PC will install the driver for Windows 98SE automatically.
1.2 Installing battery
Install one AAA 1. 5V alkaline battery properly upon indicator on the player.
Press and hold the button 2 seconds to power the player on and
enter the MP3 standby mode.
2. USB mode
2.1Connecting a PC as USB
Before operation, please verify the player is powered off with connecting the
PC port to the player USB port.
2.2 Removing the USB device
a. Double click the Safely Remove Hardware icon in taskbar.
b. From Safely Remove Hardware screen, highlight "USB Mass Storage
Device" item, and then click "Stop" button. "Stop to Hardware Device"
window appears on the screen.
1
e) From play mode, you can press the ʜor ʜbutton to fast backward or
forward in this music.
f) From play mode, press the V + or V-button to adjust volume.
g) From MP3 standby, play and pause mode, press and hold the
button 3 seconds, the player will save the data and enter the power off mode.
6. Playing voice
a) Push the ʜor ʜbutton to select Voice and press the Menu button to
enter. You can press the button to play, and press this button
again ot pause. To resume playing, please press this button a third time.
b) From voice standby or play mode, you can press the ʜor ʜbutton to
select last or next voice file.
c) From STOP status, you can push and hold the ʜor ʜbutton to find your
desired music quickly.
d) From Play mode, you can push and hold ʜor ʜbutton to fast backward
or forward in this music.
e) From voice standby mode, press the button 3seconds, the player will
enter the MP3 power off mode.
7. Function Setting
Any function mode is chosen according to the following steps: firstly keep
pressing menu, then push the ʜorʜbutton to find your desired function mode
quickly, thirdly press menu (menu is equal to “enter’ key) and enter the extended
3
function though pushing the ʜorʜbutton , at last press menu to save and
choose the extended function automatically. Besides, the specific function
settings can be referred as follows.
7.1 Setting EQ mode
Push the ʜor ʜbutton to select the EQ mode: normal, pop,rock, classical,
jazz and bass. Press the MENU button to save.
7.2 Setting Play mode
Push the ʜor ʜbutton to select the playing mode, including: Normal,
repeat one, repeat all and shuffle repeat. press the MENU button to save.
7.3 Setting Contrast
Push the ʜor ʜbutton to adjust the contrast of LCD. Press the MENU
button to save the selected setting.
7.4 Adjusting Backlight
Push the ʜor ʜbutton to select the backlight set, including:always off,
5sec,10sec,always on. Press the MENU button to save the selected setting.
7.5 Setting Power set
Push the ʜor ʜbutton to select the Power set, including: Disable, 2min,
10 min,30min. Press the MENU button to save the selected shutdown time.
7.6 Setting Recording
Push the ʜor ʜbutton to select the recording setting, including:8000Hz,
11000Hz, 16000Hz, 22000Hz. Press the MENU button to save.
4
7.7 Setting language
Push the ʜor ʜbutton to select language:German, English, French,
Spanish, Italian, Dutch,Portuguese.Press the MENU button to save.
8. Preview function
Push the ʜor ʜbutton to select preview,press the MENU button to enter,
During previewing, it will play the initial 10 seconds of each music file and then
skip to next. press the button to exit.
9. About
Push the ʜor ʜbutton to select about,press the MENU button to enter,You
can view the total memory and available memory.
10. Folder function
Push the ʜor ʜbutton to select folder, and then press the MENU button to
enter. You can push and hold the MENU button to browse the file, and push the
ʜor ʜto select the desired one.
In the folder mode,press MENU to enter the PLAY OR DELETE mode, press the
ʜorʜbutton to select.Press MENU to confirm .If you select the play,it will play
the current song.If you select the delete,it will come into the delete mode.Repress
the ʜorʜbutton to select the YES OR NO.Press MENU to confirm and
press to exit.
Note: You can not view the record folder and file under play music mode, which
will only be available in play voice mode.
5
7.8 Exit
Return to the previous setting.
11. Exit
Return to MP3 mode. Note: From setting mode, you can press the button to
exit the setting mode quickly.
12. Recording
From MP3 mode or voice standby mode, press the REC /A-B button 2 seconds,
the player will enter the recording mode, and press the REC /A-B button to stop.
You can press the button to play voice, and press this button again to
pause. To resume playing, please press this button a third time.
13. A-B Play Mode
From MP3 or voice mode:
1) Press the REC/A-B button to select starting point A.
2) Press the REC/A-B button to select end point B, it will repeat between A-B.
3) Press the REC/A-B button again to cancel setting and resume playing MP3 or
voice.
14. Lock function
From MP3 and voice standby/ play/ pause/ record mode, you can push the
HOLD switch opposite the arrow to lock all the other buttons with a Lock icon on
the LCD accordingly. If you want to use other buttons, please push the HOLD
switch to the opposite direction of arrow.
6
15. Lyric sync:
This player supports lyric sync function.
Notice: The lyric name shall be the same as music with suffix of *. LRC and
saved in the same directory, and only the lyrics with time indication can be
displayed properly.
16. FM Tuner
1. Press the MENU button to enter the main menu.
button to select FM tuner and press the MENU button toʜorʜUse the2.
confirm. The player automatically searches for all radio stations and saves
them in memory locations.
button to select another saved station.ʜorʜPress the3.
4. Press the V+ or V- to adjust the volume.
ʜorʜTo enter the FM Tuner submenu, press the MENU button. Use the5.
button to select a submenu from Play music, Play voice, Save station, Delete
station, Auto Scan, Exit and press the MENU button to confirm.
7
ENGLISH
Instructions on environment protection
Do not dispose of this product in the usual household garbage at the end
of its lifecycle; hand it over at a collection point for the recycling of
electrical and electronic appliances. The symbol on the product, the
instructions for use or the packing will inform about the methods for
disposal.
The materials are recyclable as mentioned in this marking. By recycling,
material recycling or other forms of re-utilization of old appliances, you
are making an important contribution to protect our environment.
Please inquire at the community administration for the authorized
disposal location.
8
