Denon DN-200WS Manual de usuario

DN-200WS

User Guide English ( 2 – 13 )

Guía del usuario Español ( 14 – 25 )

Guide d’utilisation Français ( 26 – 37 )

Guida per l’uso Italiano ( 38 – 49 )

Benutzerhandbuch Deutsch ( 50 – 61 )

ppendix English ( 62 – 63 )

User Guide (English)

Introduction

DN-200WSis a Wi-Fi audio receiver with professional-grade audio outputs. It

lets you add wireless stereo audio reception to any professional audio system

and supports high-resolution audio files using DLNA and AirPlay streaming.

Once your wireless device is connected to DN-200WS’s Wi-Fi network, you

can send your device’s audio signal out of the balanced XLR or unbalanced

1/4” (6.35 mm) outputs to your mixer, loudspeakers, or amplification system.

Please see this guide’s Setup chapter to learn how to integrate DN-200WS

with your audio system, and then refer to the Operation chapter to start using

DN-200WS. For a complete list of supported files, transmission specifications,

and other information, please see the Technical Specifications.

Box Contents

DN-200WS User Guide

Power Adapter Safety & Warranty Manual

Support

For the latest information about this product (system requirements,

compatibility information, etc.) and product registration, visit denonpro.com.

Features

OUTPUT

UNBAL.UNBAL.

BAL.

WI-FI AUDIO STREAMER

MODE

LEVEL

0dB

STA.

MODE POWER

RESET

DN-200WS

A.P.

5V 3ADC

10 10

1. Power Input: Use the included power adapter to connect this input to

a power outlet. See Setup for more information.

2. Power Light: This LED lights up when the unit is powered on

(connected to a power outlet).

3. Wireless Antenna: This antenna transmits and receives the wireless

signal. DN-200WS has a transmission range up to 65.6 feet (20

meters) in AP Mode and up to 164 feet (50 meters) in STA Mode,

depending on the strength of the original wireless signal.

4. Mode Button: Press and hold this button for 3 seconds to switch DN-

200WS from STA Mode (station) to AP Mode (access point). See

Operation for more information.

5.8”

(149mm)

3.4”

(88mm)

1.8”

(45mm)

5. AP Mode Light: This LED flashes while DN-200WS is entering AP

Mode and lights solidly when it is in AP Mode. In this mode, DN-

200WS and your wireless device are connected directly over DN-

200WS’s own wireless network. See Operation to learn more.

6. STA Mode Light: This LED flashes while DN-200WS is entering STA

Mode and lights solidly when it is in STA Mode. In this mode, DN-

200WS and your wireless device are connected in an existing wireless

network. See Operation to learn more.

7. Level Knob: Turn this knob to adjust the volume level of the audio

signal sent to the outputs.

8. Reset Button: Press this button to reset DN-200WS to its default

status. It will automatically enter AP Mode.

9. Outputs (Balanced XLR):These outputs send the audio signal from

your wireless device. Use XLR cables to connect these outputs to your

loudspeakers, mixer, etc. See Setup for more information.

10. Outputs (Unbalanced 1/4” /6.35 mm):These outputs send the audio

signal from your wireless device. Use standard 1/4” (6.35 mm) cables

to connect these outputs to loudspeakers, mixer, etc. See Setup for

more information.

Setup

Items not listed under Introduction > Box Contents are sold separately.

For examples of how you could set up DN-200WS, please see the

Example diagram later in this section.

1. Use either XLR cables or 1/4” (6.35 mm) cables to connect the DN-

200WS’s outputs (balanced or unbalanced) to your loudspeakers,

mixer, amplifier, or other device that accepts line-level inputs (this

device must be powered off).

Important: For stereo operation, make sure left (L) and right (R)

outputs are connected to left and right inputs, respectively.

2. Use the included power adapter to connect DN-200WS’s power input

to a power outlet.

Important: Do not use DN-200WS near a microwave oven, cordless

phone, Bluetooth®device, or other wireless device operating on the

2.4 GHz frequency, which can interfere with the reception.

3. If you are using a mixer, make sure all of its connections are secure,

and power it on.

4. Power on your loudspeakers last.

Example

OUTPUT

UNBAL.UNBAL.

BAL.

WI-FI AUDIO STREAMER

MODE

LEVEL

0dB

STA.

MODE POWER

RESET

DN-200WS

A.P.

5V 3ADC

PA loudspeakers Loudspeakers

Power

Mixer

DN-200WS

Front Panel

DN-200WS

Rear Panel

Operation

When powered on, DN-200WS is always operating in one of three modes:

•AP Mode: AP stands for access point. This is the most basic way to set up

DN-200WS, which will act as a wireless access point (like a standard wireless

router) for your wireless device. See the following AP Mode to learn how to

set this up.

•STA Mode: STA stands for station. This lets you use DN-200WS in an

existing wireless network, extending the signal of the original wireless

access point. Connecting your wireless device to DN-200WS connects it to

the existing wireless network. See the following STA Mode to learn how to

set this up.

•WPS Mode: WPS stands for Wi-Fi Protected Setup. This lets you connect

DN-200WS to your wireless router, allowing you to send audio to DN-

200WS over your Wi-Fi network. (Your router must support WPS. Please

see your router’s documentation for more information.) See the following

WPS Mode to learn how to set this up.

Important:

When you switch modes, DN-200WS will play a voice confirmation through its

outputs.

DN-200WS will not receive audio from a phone call. While using it, we

recommend disabling your cellular connection, if possible.

Do not use DN-200WS near a microwave oven, cordless phone, Bluetooth

device, or other wireless device operating on the 2.4 GHz frequency. Devices

like these can interfere with the reception.

AP Mode

To set up DN-200WSin AP Mode:

1. If the AP Mode Light is off, press and hold the Mode Button for 3

seconds.

2. On your wireless device, enter the page or control panel used to select

a wireless network.

3. From the list of wireless networks, select DN-200WS. By default, this

is the one with DN-200WSin the name followed by a unique code for

your particular unit.

If you already entered a new network name in the AP SSID field in the

Settings page, select that name instead. The unit’s code appended to

the new name.

4. Enter the password for the wireless network. The default is pr215denn.

If you already entered a new password in the AP Password field in the

Settings page, enter that password instead.

If you left the AP Password field empty, no password is required.

Your wireless device is now connected to DN-200WS. Play audio on

your wireless device to send it from DN-200WS’s outputs to your

loudspeakers or mixer.

Note: To learn how to enter the settings for each mode (SSID,

password, etc.), see the following Settings Page section.

STA Mode

To set up DN-200WSin STA Mode:

1. Make sure DN-200WS is in AP Mode (as described earlier in AP Mode).

2. On your wireless device, open your web browser and go to http://192.168.0.1.

The Settings page will appear.

3. Click the STA Network Select field to select the desired wireless network.

4. Click the STA Security Mode field to select the desired wireless network’s

security mode.

Note: If you select WPA, WPA2, WPA-Personal, or WPS, you will need to

enter a password.

5. Click the STA Network Password field and enter the password for the

desired wireless network. (Check the Display Password checkbox to

reveal the password, or uncheck it to hide it again.)

6. Click Submit (under the Device Name field). You will see a webpage

confirming the new settings were sent to DN-200WS.

7. Disconnect DN-200WS from its power source, and then reconnect it. It will

automatically enter STA Mode using the new wireless network information.

The STA Mode Light will turn on.

Your wireless device is now connected to DN-200WS. Play audio on your

wireless device to send it from DN-200WS’s outputs to your loudspeakers

or mixer.

Important: After you have gone through Steps 3–6once, DN-200WS will

remember that information whenever you enter STA Mode. When you want

to use STA Mode with a different wireless network, repeat Steps 1–9.

Note: To learn how to enter the settings for each mode (wireless network,

password, etc.), see the following Settings Page section.

WPS Mode

To set up DN-200WS in WPS Mode:

1. Make sure DN-200WS is in STA Mode (as described earlier in STA Mode).

2. Press the Mode Button once. The AP Mode Light and STA Mode Light will flash.

3. On your wireless router, press its WPS, QSS, or Reset button. (Your router must

support WPS. Please see your router’s documentation for more information.)

4. Wait for 5–10 seconds. DN-200WS will automatically enter WPS Mode, and the

STA Mode Light will turn on.

To exit WPS Mode, do one of the following:

•Disconnect DN-200WS from its power outlet, and then reconnect it.

•Press the Reset button on DN-200WS.

Settings Page

To enter DN-200WS’s settings:

1. Connect your wireless device to DN-200WS.

2. On your wireless device, open your web browser and go to http://192.168.0.1.

The Settings page will appear and show several fields, described below.

Device Information:

•AP SSID (for AP Mode):Use this field to set the SSID (service set identifier). If

this field is empty, the default SSID will have DN-200WS in the name followed

by a unique code for your particular unit. If you rename the SSID, the unit’s code

will be appended to the new name.

•AP Password (for AP Mode):Use this field to set the password. The default

password is pr215denn. If this field is empty, there will be no password.
